2021 Zero FXS Guide

2021 Zero FXS

2021 Zero FXS 2021 Zero FXS 2021 Zero FXS 2021 Zero FXS 2021 Zero FXS

2021 Zero FXS : STEALTHY SUPERMOTO.

Introducing the 2021 Zero FXS…

Quick. Mean. Compact. With precise handling and blistering acceleration, the Zero FXS stealthily shreds any urban slalom or conquers your local track with tarmac carving fierceness. Combining off road ruggedness with on-road agility, the Zero FXS is the ultimate way to cut through the concrete jungle.







2021 Zero FXS Totalmotorcycle.com Key Features

PERFORMANCE PROFILE
Transform performance profiles with the press of a button to perfectly conquer city streets or your local supermoto track. The Zero FXS is pre-programmed with Eco or Sport modes. Connect using your mobile device to customize performance or get stats on your ride.

CHARGE. NO STATION NEEDED.
Standard outlet. Done. No special charging equipment required. Your household outlets just became “fueling” stations that deliver daily rides at a fraction of the cost of gasoline. Ride up to 100 miles a day in the city and plug in overnight to start the next day with a full “tank.”

Need a faster charging solution? Use accessory Quick Chargers to cut charge times by over 60%.

POWERFUL. MINIMALIST.
THE ZERO FXS DELIVERS UNFILTERED THRILL BY COMBINING OUR MOST COMPACT Z-FORCE® POWERTRAIN WITH PIRELLI DIABLO ROSSO II TIRES AND THE OFF-ROAD DNA OF THE ZERO FX. NO SHIFTING OR CLUNKINESS. DIRECTLY CONNECT YOUR DESIRE FOR SPEED WITH INSTANT, MASSIVE, SILENT, AND SEAMLESS ACCELERATION.
INSTANT “FULL TANK”
Ride. Swap batteries. Continue. The Zero FXS’s optional hot-swappable tech allows you to go from empty to full in seconds. Depleted additional batteries can be easily charged while you ride using off-board charging accessories.

PASS ON SERVICE.
Imagine savage performance delivered without tedious and greasy servicing regimes. Forget oil changes, spark plugs, clutches, filters, chain adjustments or expensive tune-ups. Instead, a carbon fiber belt cleanly connects the rear wheel to an air-cooled Z-Force® motor that uses a single moving part. Swap threadbare tires. Replace used-up brake pads. Ride.

Always advancing. Code for the Z-Force® powertrain is constantly refined to deliver improved performance. The Zero App easily delivers the upgrades using your mobile device.

GO THE DISTANCE.
The Zero FXS travels up to 100 mi when traversing city streets. At its core is Zero’s most compact and lightweight Z-Force® battery that, like rest of the lineup, boasts the highest power and energy density in the EV industry.

Don’t need the range and looking for Zero’s most economical model? Drop some weight. The Zero FXS ZF3.6 cuts the battery’s weight and size by roughly 50 percent. Add a second battery module at any time to match the range and performance of the ZF7.2.







2021 Zero FXS Totalmotorcycle.com Features and Benefits

SWAPPABLE BATTERY CAPABILITY
The Zero FXS is available in two battery configurations. The ZF3.6 features modular battery technology that allows riders to add a second battery to double range and makes it possible to fully “recharge” by quickly swapping batteries on the fly. The ZF7.2 is fully integrated into the motorcycle and is the more economical option for those looking to maximize the range of the Zero FXS.

Zero Motorcycles’ Z-Force® battery is the most power and energy dense in the EV industry. The ZF7.2 offers a maximum battery capacity of 7.2 kWh that delivers up to 100 miles of city riding.

The battery is designed to last and backed by a five-year, unlimited mileage warranty. The Zero FXS also features Long Term Storage Mode to optimize the battery’s state of charge and further improve long term battery health.

MOTOR
The Zero FXS powerplant produces up to 78 ft-lb of torque. The air-cooled Interior Permanent Magnet (IPM) motor delivers impressive performance and fierce acceleration, which works in conjunction with regenerative braking to channel energy back into the battery. No heavy, complicated or expensive liquid cooling. No routine maintenance. No fuss. This is the industry’s most efficient, powerful, and compact motor.

NOSE
Twin projector beam headlamps flood the road ahead with light, and an integrated fly screen adds an aggressive styling touch.

DASH
Minimalist. Cool blue LCD. The Zero FXS dash projects the specs you need: speed, state of charge, power output, selected riding profile, projected recharge time. Sync with your smartphone to turn it into a secondary customizable dash or view detailed ride stats.

SUSPENSION
The Zero FXS’s Showa suspension offers outstanding articulation and full adjustability. With nearly 9 inches of rear travel, the Zero FXS offers superior damping to smooth out the road’s imperfections.

WHEELS AND TIRES
The Zero FXS’s responsive handling matches its lean, mean looks. Pirelli Diablo Rosso II tires are mounted on stylish cast alloy wheels to form a system that delivers maximum grip. A hollow front axle shaves unsprung weight to improve handling.

BRAKES
The Bosch anti-lock brake system (ABS) delivers confident braking. Tested for just about any situation you can imagine, the system optimizes deceleration under hard braking. Braking is actuated via levers that can be adjusted for improved ergonomics. ABS can be switched on or off by the rider.

DIRECT DRIVE
Strip away clutches, gears, shifting, chains and all their weighty complexities. Seamlessly accelerate with pure efficiency as energy quietly transforms into propulsion. The Zero FXS is direct drive. Its state-of-the-art motor connects directly to the rear wheel using a carbon fiber belt.

ONBOARD CHARGER
The Zero FX’s discreetly accessible 650 W onboard charger can be plugged into any household outlet. Charge times can be slashed by using optional Quick Chargers.

FRAME
The Zero FXS’s precision-built aircraft-grade aluminum frame is an exercise in efficiency. When fully built the minimalist Zero FXS tips the scales at as little as 251 pounds.









2021 Zero FXS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9295 USD
Canada MSRP Price: $ 12363 CAD
Europe/UK MSRP Price: £11850 GBP (On The Road inc 20% Vat)

STANDARD / PREMIUM

Range / ZF3.6
ZF7.2
City
50 miles (80 km) / 100 miles (161 km)
Highway, 55 mph (89 km/h)
30 miles (48 km) / 60 miles (97 km)
Combined
37 miles (60 km) / 75 miles (121 km)
Highway, 70 mph (113 km/h)
20 miles (32 km) / 40 miles (64 km)
Combined
29 miles (47 km) / 57 miles (92 km)
Motor
ZF3.6 / ZF7.2
Peak torque
78 ft-lb (106 Nm) / 78 ft-lb (106 Nm)
Peak power
27 hp (20 kW) @ 4,300 rpm / 46 hp (34 kW) @ 4,300 rpm
Top speed (max)
85 mph (137 km/h) / 85 mph (137 km/h)
Top speed (sustained)
75 mph (121 km/h) / 75 mph (121 km/h)
Type
Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor / Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor
Controller
High efficiency, 550 amp, 3-phase brushless controller with regenerative deceleration
High efficiency, 550 amp, 3-phase brushless controller with regenerative deceleration
Power system
ZF3.6 / ZF7.2
Power pack
Z-Force® Li-Ion intelligent modular / Z-Force® Li-Ion intelligent integrated
Max capacity
3.6 kWh / 7.2kWh
Nominal capacity
3.2 kWh / 6.3 kWh
Charger type
650 W, integrated / 650 W, integrated
Charge time (standard)
5.1 hours (100% charged) / 4.6 hours (95% charged)
9.7 hours (100% charged) / 9.2 hours (95% charged)
With one accessory charger
2.3 hours (100% charged) / 1.8 hours (95% charged)
4.1 hours (100% charged) / 3.6 hours (95% charged)
With max accessory chargers
1.6 hours (100% charged) / 1.1 hours (95% charged)
1.8 hours (100% charged) / 1.3 hours (95% charged)
Input
Standard 110 V or 220 V / Standard 110 V or 220 V
Drivetrain
ZF3.6 / ZF7.2
Transmission
Clutchless direct drive / Clutchless direct drive
Final drive
90T / 18T, Poly Chain® HTD® Carbon™ belt
90T / 18T, Poly Chain® HTD® Carbon™ belt

Chassis / Suspension / Brakes
ZF3.6 / ZF7.2
Front suspension
Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping / Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension
Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping / Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel
7.00 in (178 mm) / 7.00 in (178 mm)
Rear suspension travel
8.94 in (227 mm) / 8.94 in (227 mm)
Front brakes
Bosch Gen 9 ABS, J-Juan asymmetric dual piston floating caliper, 320 x 5 mm disc / Bosch Gen 9 ABS, J-Juan asymmetric dual piston floating caliper, 320 x 5 mm disc
Rear brakes
Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc / Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire
Pirelli Diablo Rosso II 110/70-17
Pirelli Diablo Rosso II 110/70-17
Rear tire
Pirelli Diablo Rosso II 140/70-17
Pirelli Diablo Rosso II 140/70-17
Front wheel
3.00 x 17 / 3.00 x 17
Rear wheel
3.50 x 17 / 3.50 x 17
Dimensions
ZF3.6 / ZF7.2
Wheelbase
56.0 in (1,422 mm) / 56.0 in (1,422 mm)
Seat height
32.9 in (836 mm) / 32.9 in (836 mm)
Rake
24.4° / 24.4°
Trail
2.8 in (71 mm) / 2.8 in (71 mm)
Weight
ZF3.6 / ZF7.2
Curb weight
251 lb (114 kg) / 293 lb (133 kg)
Carrying capacity
379 lb (172 kg) / 337 lb (153 kg)
Economy
ZF3.6 / ZF7.2
Equivalent fuel economy (city)
533 MPGe (0.44 l/100 km) / 533 MPGe (0.44 l/100 km)
Equivalent fuel economy (highway)
213 MPGe (1.10 l/100 km) / 213 MPGe (1.10 l/100 km)
Typical cost to recharge
$0.40 / $0.81
Pricing
ZF3.6 / ZF7.2
MSRP
$9,295 / $11,295
Warranty
ZF3.6 / ZF7.2
Standard motorcycle warranty
2 years / 2 years
Power pack warranty
5 years/unlimited miles
5 years/unlimited miles





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
