2022 Harley-Davidson CVO Road Glide: RIDE OUT FRONT.
Introducing the 2022 Harley-Davidson CVO Road Glide…
Menacing style meets unrelenting performance in the 2022 CVO Road Glide. A distinctive sharknose fairing with the scorching power of the Milwaukee-Eight 117 powertrain and finished with custom paint makes for a bike that only the world’s most-desirable motorcycle brand could offer.
For the rider who runs out front and never looks back. The CVO Road Glide model offers menacing style behind its distinctive dual LED headlamps and frame-mounted sharknose fairing, and the unrelenting performance of the Milwaukee-Eight 117 powertrain. Powerhouse audio, an exclusive 21-inch front wheel, fabulous custom paint and extraordinary attention to detail complete this very desirable bike.
- NEW decorative insert finishes and scorched chrome powertrain covers (with Blue Steel paint option)
- Harley-Davidson Audio powered by Rockford Fosgate Stage II for super-premium sound
- Road Glide fairing features splitstream venting to limit head buffeting; Dual Daymaker LED headlamps push out an impressive punch with a bright-white beam that lights up the road; all other lighting is LED
- Exclusive Combo 21-inch front / 18-inch rear wheel
- Features a cast-aluminum rim and laced spokes for a look that is both rugged and very exclusive/custom
- Enables TPMS (tire pressure monitoring systems) on a laced wheel
- This is the only 21-inch front wheel offered on a H-D Touring model; suspension is re-tuned for no compromise in handling and braking performance; adds to custom-bagger look and CVO model exclusivity
- Low-profile console with CVO light
- Heated Kahuna Collection hand grips match Kahuna shifter pegs, brake pedal cover, muffler end caps, and rider and passenger pegs
- Fang Front Spoiler is dramatic lower bodywork and a custom styling feature
- Screamin’ Eagle Heavy Breather intake for improved air flow and bold hot-rod style
- NEW Paint Options
- Wicked Orange Pearl/Black Hole with Lightning Silver Two-Tone and Bright Chrome finishes
- Envious Green with Black Hole Fade with Flame Pattern and Gloss Black finishes
- Blue Steel Solid Color and Scorched Chrome finishes
2022 Harley-Davidson CVO Road Glide Totalmotorcycle.com Key Features
STANDARD FEATURES
- Upright riding position
- Floorboards
- Saddlebags
- Frame mounted fairing
- Infotainment
- Rider safety enhancements available
THIS IS THE RIGHT BIKE FOR
- Performance-hungry distance riders
- Enthusiasts seeking stand-out power and comfort
- Classic touring design with premium H-D features
Harley-Davidson Custom Vehicle Operations (CVO)
Premium limited-production factory custom models from Harley-Davidson Custom Vehicle Operations (CVO) offer the most-discerning rider a very special motorcycle designed to represent the pinnacle of style and design from the world’s most-desirable motorcycle brand. Exclusive and hand-crafted paint and designs are executed to a level of intricate quality that is unmatched in the motorcycle and automotive categories. Each is powered by a Milwaukee-Eight 117 powertrain. Other standard features include a premium Harley-Davidson Audio powered by Rockford Fosgate system, a Boom! Audio 30K Bluetooth Helmet Headset, and Cornering Rider Safety Enhancements by Harley-Davidson, technology designed to enhance rider confidence during unexpected situations or poor road conditions. Each CVO model offers all-new paint options for 2022.
(See 2022 CVO release for complete details.)
CVO Street Glide Model is a super-premium bagger for the rider who rolls loud and proud. The classic silhouette of the batwing fairing topped with jaw-dropping paint and finish details, premium audio and the pavement-peeling power of the Milwaukee-Eight 117 engine make this one outrageous bike.
CVO Road Glide Model is designed for the rider who wants to run out front behind its distinctive dual LED headlamps, frame-mounted shark nose fairing and the unrelenting performance of the Milwaukee-Eight 117 powertrain. Powerhouse audio, an exclusive 21-inch front wheel, fabulous custom paint and extraordinary attention to detail complete this very desirable bike.
CVO Road Glide Limited Model is loaded with luxury and long-haul comfort, head-turning style and power that always satisfies. Premium audio, heated seats and grips, and the aerodynamic Road Glide model shark nose fairing make this motorcycle the ultimate Harley-Davison Touring machine.
CVO Tri Glide Model is a super-premium trike offering distinctive style, powerful performance and long-haul touring capability plus the added confidence of a third wheel. The CVO Tri Glide is loaded with premium audio, luxurious comfort features and an astounding finish and attention to detail, on a chassis designed from the wheels up as a trike.
Cornering Rider Safety Enhancements by Harley-Davidson
Standard on CVO models and an option for all Grand American Touring models, including the Street Glide ST and Road Glide ST models, Cornering Rider Safety Enhancements by Harley-Davidson is a collection of technologies designed to assist the rider in maintaining the rider’s intended path through a curve. This technology package provides the following enhancements:
Cornering Electronically Linked Brakes
Cornering-ABS
Cornering-Traction Control with modes
Drag Torque Slip Control
Vehicle Hold Control
Tire Pressure Monitoring (TPMS)
HARLEY-DAVIDSON CVO MOTORCYCLES REPRESENT PINNACLE OF STYLE AND DESIGN
MILWAUKEE, WI (January 26, 2022) – Advanced technology, exclusive components and obsessive attention to detail distinguish four new 2022 motorcycle models from Harley-Davidson Custom Vehicle Operations (CVO). Limited-production, super-premium CVO motorcycles represent the pinnacle of forward-looking style, design and craftsmanship from Harley-Davidson, the world’s most-desirable motorcycle brand.
CVO models for 2022 include the CVO Road Glide Limited, the CVO Street Glide, the CVO Road Glide and the CVO Tri Glide. Each model offers exclusive paint colors and designs executed to a level of intricate quality and hand-crafted detail that is unmatched in the motorcycle and automotive categories.
“Gunslinger is our partner in custom paint that’s been that’s been adding incredible artisanal techniques to our CVO arsenal and family for a long time now, and they’re inspiring us to push the limits, so we try to do the same thing with them,” said Brad Richards, Harley-Davidson Vice President of Design. “When most manufacturers are at the limits of a robot, Gunslinger can go in there with an artist who has the ability to brush by hand and deliver the sharpest pinstripe possible. That hand applied technique allows for very intricate two-tones, three-tones, airbrush drop shadows, and really transcends the ‘expected’ by delivering a truly custom look.”
Each CVO model is also equipped with Milwaukee-Eight 117 engine, plus the complete technology suite of Cornering Rider Safety Enhancements and the advanced Boom! Box GTS infotainment system equipped with high-performance Harley-Davidson Audio powered by Rockford Fosgate.
2022 Harley-Davidson CVO Road Glide Totalmotorcycle.com Features and Benefits
POWER
Milwaukee-Eight 117 V-Twin
The new pinnacle of torque and displacement with a factory-installed powertrain. Precision oil/air cooling. 126 ft. lbs. of torque at 3750 RPM. Tuned heavy breather intake and high flow exhaust maximize engine performance, a boost you can feel with every twist of the throttle.
STYLE
Premium paints and finishes
Heated Kahuna Collection hand grips match Kahuna shifter pegs, brake pedal cover, muffler end caps, heated grips and rider and passenger boards
Fugitive custom wheels
THE RIDE
All the features you need for a ride that feels comfortable and rides secure.
H-D Touring Chassis
Daymaker Adaptive LED headlamp and bright LED lighting for enhanced visibility
Corner Safety Enhancements
Enhanced Experience
HARLEY-DAVIDSON AUDIO POWERED ROCKFORD FOSGATE
Step up to the ultimate motorcycle audio experience. Harley-Davidson Audio powered by Rockford Fosgate Stage II speakers deliver ultra-clear highs, super clean mids, and ground thumping bass. These amplified three-way speakers feature a durable injection molded woofer and a separate bridge-mounted Midrange and Tweeter speakers.
BOOM! BOX GTS INFOTAINMENT
Nothing standard about this state-of-the-art system with color touch screen, two fairing-mount speakers and hidden radio antenna. Every element is optimized to enhance the rider’s interaction with the bike and connectivity with the world.
WIRELESS HEADSET
The Boom! Audio 30K Bluetooth headset lets you call hands-free on your Bluetooth mobile phone, listen to stereo music or voice instructions of GPS navigation and have intercom conversations with your passenger or fellow riders.
2022 Harley-Davidson CVO Road Glide – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: from $41899 (Color), $44899 (Custom Color) USD
Canada MSRP Price: from $51899 (Colour), $54399 (Custom Colour) CDN
Europe/UK MSRP Price: from £36695 (Colour), £39395 (custom Colour) GBP (On The Road inc 20% Vat)
| Dimensions | FLTRXSE CVO™ Road Glide® | Notes |
| Length | 96.9 in. (2,460 mm) | |
| Overall Width | 38 in. (965 mm) | |
| Overall Height | 50.4 in. (1,280 mm) | |
| Seat Height, Laden | 25.9 in. (658 mm) | 2 |
| Seat Height, Laden (Low seat position) | ||
| Seat Height, Laden (High seat position) | ||
| Seat Height, Laden (Low seat position with optional ARH suspension) | ||
| Seat Height, Laden (High seat position with optional ARH suspension) | ||
| Seat Height, Unladen | 26.8 in. (680 mm) | |
| Seat Height, Unladen (Low seat position) | ||
| Seat Height, Unladen (High seat position) | ||
| Seat Height, Unladen (Low seat position with optional ARH suspension) | ||
| Seat Height, Unladen (High seat position with optional ARH suspension) | ||
| Static Ground Clearance | 4.9 in. (125 mm) | |
| Dynamic Ground Clearance (with optional suspension) | ||
| Rake (steering head) (deg) | 26 | |
| Fork Angle (deg) | 29.25 | |
| Trail | 6.8 in. (173 mm) | |
| Wheelbase | 64 in. (1,625 mm) | |
| Tires, Type | Dunlop® Harley-Davidson Series, bias blackwall front and rear | |
| Tires, Front Model | D408F | |
| Tires, Front Specification | BW 130/60B21 M/C63H | |
| Tires, Rear Model | D407 | |
| Tires, Rear Specification | BW 180/55B18 M/C80H | |
| Fuel Capacity | 6 gal. (22.7 l) | |
| Reserve Fuel Capacity, Fuel Injection (warning light) | 1 gal. (3.8 l) | |
| Oil Capacity (w/filter) | 5.2 qt. (4.9 l) | |
| Transmission Capacity | 1 qt. (.95 l) | |
| Primary Chain Case Capacity | 1.1 qts. (1 l) | |
| Coolant Capacity | N/A | |
| Weight, As Shipped | 860 lb. (390 kg) | |
| Weight, In Running Order | 893 lb. (405 kg) | |
| Gross Vehicle Weight Rating | 1,360 lb. (617 kg) | |
| Gross Axle Weight Rating, Front | 500 lb. (227 kg) | |
| Gross Axle Weight Rating, Rear | 927 lb. (420 kg) | |
| Luggage Capacity -Volume | 2.4 cu ft (0.068 m3) |
| Engine | FLTRXSE CVO™ Road Glide® | Notes |
| Engine | Milwaukee-Eight® 117 | |
| Valves | Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder | |
| Bore | 4.075 in. (103.5 mm) | |
| Stroke | 4.5 in. (114.3 mm) | |
| Displacement | 117 cu in (1,923 cc) | |
| Compression Ratio | 10.2:1 | |
| Fuel System | Electronic Sequential Port Fuel Injection (ESPFI) | 3 |
| Air Cleaner | Paper, washable | |
| Exhaust | Dual, with crossover | |
| Lubrication System | Pressurized, dry-sump with oil cooler |
| Drivetrain | FLTRXSE CVO™ Road Glide® | Notes |
| Primary Drive | Chain, 34/46 ratio | |
| Final Drive | Belt, 32/68 ratio | |
| Clutch | Mechanically actuated 10 plate, wet Assist & Slip | |
| Transmission | 6-Speed Cruise Drive® | |
| Gear Ratios (overall) 1st | 9.593 | |
| Gear Ratios (overall) 2nd | 6.65 | |
| Gear Ratios (overall) 3rd | 4.938 | |
| Gear Ratios (overall) 4th | 4 | |
| Gear Ratios (overall) 5th | 3.407 | |
| Gear Ratios (overall) 6th | 2.875 |
| Chassis | FLTRXSE CVO™ Road Glide® | Notes |
| Frame | Mild steel; tubular frame, two-piece stamped and welded backbone; cast and forged junctions; twin down tubes; bolt-on rear frame with forged fender supports; MIG welded | |
| Swingarm | Mild steel, two piece drawn and welded section; forged junctions; MIG welded | |
| Front Fork | 49mm Dual Bending Valve | |
| Front Fork, Optional | ||
| Rear Shocks | Premium Low Hand-Adjustable Rear Suspension | |
| Rear Shocks, Optional | ||
| Wheels, Optional Style Type | Denim Black with Contrast Gloss Black Combo; Gloss Black with Contrast Smoked Satin Combo | 4 |
| Wheels, Front Type | Gloss Black and Contrast Chrome Combo | 4 |
| Wheels, Front Width | 3.5 in. (89 mm) | |
| Wheels, Front Height | 21 in. (533 mm) | |
| Wheels, Rear Type | Gloss Black and Contrast Chrome Combo | 4 |
| Wheels, Rear Width | 5 in. (127 mm) | |
| Wheels, Rear Height | 18 in. (457 mm) | |
| Brakes, Caliper Type | 32 mm, 4-piston fixed front and rear | |
| Brakes, Rotor Type | Dual floating rotors (front), fixed rotor (rear) | |
| Brakes, Front Diameter | 11.8 in. (300 mm) | |
| Brakes, Front Thickness | 0.2 in. (5.1 mm) | |
| Brakes, Front is dual | Yes | |
| Brakes, Rear Diameter | 11.8 in. (300 mm) | |
| Brakes, Rear Thickness | 0.2 in. (5.1 mm) | |
| Front brake lever free travel | N/A | |
| Rear brake pedal free travel | N/A | |
| Brakes, Anti-Lock Braking System (ABS) | Standard | |
| Suspension Travel, Front | 3.6 in. (91 mm) | |
| Suspension Travel, Rear | 2.1 in. (54 mm) |
| Performance | FLTRXSE CVO™ Road Glide® | Notes |
| Engine Torque Testing Method | J1349 | |
| Engine Torque | 126 ft-lb (171 Nm) | 5 |
| Engine Torque (rpm) | 3,750 | |
| Power (Hp/kW) | 106 HP / 79 kW @ 4750 rpm | |
| Lean Angle Testing Method | J1168 | |
| Lean Angle, Right (deg.) | 34 | |
| Lean Angle, Left (deg.) | 34 | |
| Maximum hill-starting ability | N/A | |
| Fuel Economy Testing Method | Estimated City/Hwy | |
| Fuel Economy | 41 mpg (5.7 l/100 km) | 6 |
| CO₂ Emissions Testing Method | N/A | |
| CO₂ Emissions | N/A |
| Electric | FLTRXSE CVO™ Road Glide® | Notes |
| Battery | Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per Battery Council International Rating) | |
| Charging | Three-phase, 48-amp system (600W @13V, 2000 RPM, 625W max power @ 13V) | |
| Starting | 1.6 kW electric with solenoid shift starter motor engagement | |
| Lights (as per country regulation), Headlamp | LED 34-watt, 915 lumen low beam, 37-watt, 915 lumen high beam. | |
| Lights (as per country regulation), Tail/Stop | LED | |
| Lights (as per country regulation), Front Signal Lights | LED | |
| Lights, Rear Turn Signals | LED | |
| Gauges | – Custom gauges styled to complement each CVO vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators. | |
| Auxiliary Lamps | N/A | |
| Electric Power Outlet | Electric power accessory port in fairing | |
| GPS System | Boom!™ Box GTS audio system with GPS and touchscreen | |
| Reverse Gear | N/A |
| Warranty And Service | FLTRXSE CVO™ Road Glide® | Notes |
| Warranty | 24 months (unlimited mileage) | 7 |
| Service Interval | First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter | 8 |
Notes
- Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings and competitive comparisons) are based on available information at the time of publication. Although such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and may change or discontinue models, without notice and without incurring any obligation. Attention: Vehicles in the configurations shown and many of the accessories described in this catalog may not be available for sale or use in some locations. Please check with your dealer for complete product details and the latest information. All models feature 6-speed transmission (VRSC™ models and Sportster® models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
- Measurement reflects 180 lb. (81.7 kg) operator weight.
- Recommended 91 octane or higher fuel (R+M)/2.
- Standard and optional wheels may vary by country and region.
- Values shown are nominal. Performance may vary by country and region.
- The combined fuel economy numbers were derived using a combination of estimated city and highway values. Fuel economy estimates are derived from US EPA exhaust emission certification data on a sample motorcycle from the corresponding family under ideal laboratory conditions. Your actual fuel economy will vary depending on your personal riding habits, road and driving conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
- See motorcycle owner’s manual for complete details.
- Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals. See Owner’s Manual for full details.
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
