2022 Husqvarna TE250i Guide

2022 Husqvarna TE250i

2022 Husqvarna TE250i 2022 Husqvarna TE250i 2022 Husqvarna TE250i 2022 Husqvarna TE250i

2022 Husqvarna TE250i: REVOLUTIONARY 2-STOKE.

Introducing the 2022 Husqvarna TE250i…

Rolling into 2022 all Enduro bikes feature premium Michelin Enduro tyres. To cope with the added traction the suspension settings on the fork and shock have been revised improving rider feedback. New Braktec hydraulics offer superior braking power and perfect modulation of the clutch under all conditions. Underlining the update, our Enduros wear new rugged grey colour and electric yellow accents.

Husqvarna Motorcycles is pleased to introduce the 2022 enduro range. The seven-strong line-up of 2-stroke and 4-stroke machines boasts a host of innovations, delivering light, manageable machines without rival in conquering all types of terrain. The new TE and FE range furthers the reputation of Husqvarna Motorcycles for its winning combination of dynamic performance and advanced ergonomics.

Riders of every level from amateur to professional can choose from a line-up unequalled in their sector for power, performance and agility.

Revisions to the damping and action of the WP XPLOR forks and XACT rear shock featured across the enduro range let riders make the most of the torque and power of their choice of TE or FE machine. The reworked suspension combines with the chromium-molybdenum steel frame designed to deliver precision flex, progressive bodywork and 2-piece carbon composite subframe to deliver consistent damping, exact handling and peerless rider comfort.

All models come with a new BRAKTEC hydraulic clutch system. Ensuring light action with perfect progression and reliable performance in all conditions, the hydraulic system is also self-adjusting and almost maintenance-free. Furthermore, new BRAKTEC brake systems front and rear offer superior stopping power with outstanding sensitivity and modulation in conjunction with high-performance GSK wave discs.

All models in the enduro range come with an electric starter as standard and feature the latest electronic fuel injection technology for efficiency and economy. The 4-stroke models continue to feature two switchable engine maps plus traction control, while the 2-strokes have two switchable ignition curves for rider-selectable control in all conditions. Additionally, the TE 250i has revised final drive gearing for improved low-end response.

As well as technical innovation for 2022, Husqvarna Motorcycles has also paid attention to aesthetics with new colours, trims and graphics bringing additional style to the Swedish-inspired design. A new seat cover blends in with the updated design without compromising on rider comfort or control. In addition, the 2022 enduro range passes the competition right from the dealer floor, thanks to superior traction of the new Michelin Enduro tyres.





2022 Husqvarna TE250i Totalmotorcycle.com Key Features
  • New colours, trims and graphics with rugged grey and electric yellow accents are a distinctive and stylish adornment for the Swedish-inspired design
  • New BRAKTEC hydraulic clutch system – perfect modulation and reliable performance in all conditions
  • New BRAKTEC brake system and high-performance GSK discs – superior stopping power with outstanding sensitivity and modulation
  • Revised suspension settings for improved performance and rider feedback
  • Oil bypass in the outer fork tubes reduces friction for smooth, consistent travel through the stroke and a revised cartridge joint offers added damping performance
  • Revised shock valve seals with reduced hardness (Model Year 21 = 90 Shore / Model Year 22 = 70 Shore) offer improved feedback and consistent damping performance
  • Inspired and tested by our Factory Racing Team all 2022 enduro machines run Michelin Enduro tyres for maximum traction on difficult terrain
  • New 13:52 gearing on TE 250i for improved low-end response



Ensuring all enduro riders can fully enjoy their next ride, Husqvarna Motorcycles offers the Functional Offroad Apparel Collection 2021 – a range of high-performance gear and protective equipment that takes into account the unique challenges of offroad riding. Furthermore, the Husqvarna Motorcycles Technical Accessories catalogue features a host of performance and suspension parts, machine protectors and workshop equipment to customise and maintain both TE and FE models.

The 2022 enduro range is now available at all authorised Husqvarna Motorcycles dealers. Availability may differ from country to country.



2022 Husqvarna TE250i Totalmotorcycle.com Features and Benefits

High performance

Engine

Arguably the best combination of power and weight, the TE 250i engine is a longstanding favourite with enduro riders. While technological advancements mean the TE 250i features a pioneering fuel injection system, it remains a low maintenance workhorse of an engine. Additionally, the TE 250i engine has an advanced construction featuring shaft arrangements precisely positioned for greater mass centralisation, a counter balancer shaft reducing vibration and a twin-valve controlled power valve for smoother power delivery.



Cylinder

The 66.4 mm bore cylinder in the TE 250i features a twin valve-controlled power valve system which delivers smooth and controlled power throughout the RPM range. Optimal exhaust port timing is achieved with the combination of an state-of-the-art, adjustable power valve drive. The cylinder also features two inlet positions at the rear of the cylinder where a pair of fuel injectors are mounted. This ensures efficient combustion resulting in reduced fuel consumption and emissions.



CRANKCASES

Designed for minimal weight, the die-cast crankcases on the TE 250i engine feature a thin-wall design. To centralise mass, the shaft arrangement has been precisely positioned to harness oscillating masses at the ideal centre of gravity. The counter balancer shaft is also specifically integrated, making for a compact design. Additionally, the water pump casing is designed to improve cooling by optimising the flow of coolant.



EXHAUST

Tailored specifically for each model using an innovative 3D design process, the header pipe on the TE 250i offers an advanced geometry and performance. This allows for improved ground clearance, while a corrugated surface makes the header pipe resistant to impact out on the trail. The muffler also features an aluminium mounting bracket and advanced internal construction for excellent noise damping and weight saving.

FRAME

he chromium molybdenum steel frame is expertly crafted using laser-cut, robot-welded, hydro-formed tubes, ensuring the highest level of precision and quality. The specifically crafted geometry utilises advanced longitudinal and torsional flex characteristics, for unparalleled rider feedback, energy absorption and exceptional straight-line stability. The cylinder head mountings are made of forged aluminium, improving handling and comfort. The premium blue powder coated frame features standard frame protectors, providing extra durability.



Composite carbon fibre subrame

The carbon composite subframe is unique to Husqvarna Motorcycles and showcases advanced production technology and innovation. Using 70% polyamide and 30% carbon fibre, the 2-piece subframe has a total weight of just over 1 kg. With the help of computational dynamics, specific rigidity was engineered into the light and robust subframe, delivering outstanding handling and rider comfort.



OIL TANK AND PUMP

An electronic oil pump feeds vital 2-stroke oil into the engine. It is located just below the oil tank and feeds the oil via the throttle body, meaning the oil is only mixed with air at this stage. The pump is controlled by the EMS and delivers the optimal amount of oil according to the current RPM and engine load. The oil tank is connected to a filler hose which runs through the upper tube of the frame to a filler cap conveniently located for easy refills. The tank capacity is 0.7 l and is connected to a low-level sensor which illuminates when the tank needs refilling.

INTEGRATED COOLING AND RADIATORS

The radiators are expertly crafted using high-strength aluminium with CFD (computational fluid dynamics) to channel air through the radiators more efficiently. The cooling system is intelligently integrated into the frame, eliminating the need for additional hoses. The large centre tube running through the frame reduces pressure at this point, allowing for a consistent coolant flow. Additionally, the radiators are mounted close to the centre of gravity for improved handling agility. An optional radiator fan can be fitted and is available in the Husqvarna accessories catalogue.

WP XPLOR FRONT FORK

The WP XPLOR 48 front fork is designed specifically for enduro riding. Its open cartridge layout has a spring in each leg with split damping functions. Compression damping in the left leg and rebound damping in the right. Adjustment is via easy-to-access clickers (30 clicks) on the top of each fork leg. The standard preload adjusters allow for easier adjustment without the use of tools. The fork’s mid-valve piston delivers consistent damping, while the setting allows the fork to operate higher in the stroke for exceptional rider feedback and bottoming resistance. A new oil bypass in the outer tube reduces friction for a smoother, consistent travel through the stroke and a revised cartridge joint offers added damping performance.



WP XACT REAR SHOCK

he WP XACT shock provides advanced damping characteristics to the range. New valve seals with reduced hardness offer improved shock feedback. The compact and lightweight shock features a pressure balance inside, ensuring consistent damping and superior rider comfort. Using the same linkage progression found in the Husqvarna Motocross range, the rear end sits low for improved control in extreme enduro conditions. The fully adjustable component delivers 300 mm rear wheel travel, as well as unrivalled traction, feeling and energy absorption.



Hydraulic Brakes

The highest level of quality is guaranteed with the new BRAKTEC braking system, offering the highest level of braking performance while being specifically tailored for enduro riding and delivering a sensitive and modulated feel. GSK wave disks (260 mm disc front and 220 mm rear) complete the high-quality braking package for complete confidence.



Hydraulic Clutch

The new high quality BRAKTEC clutch system guarantees even wear, reliable and near maintenance-free operation as well as perfect modulation in every condition. Meaning that play is constantly compensated so that the pressure point and function of the clutch remain identical in cold or hot conditions, as well as over time.



BODYWORK

The TE 250i features a bodywork which clearly showcases Husqvarna Motorcycles’ progressive approach to offroad motorcycles while rugged grey and electric yellow accents provide a distinctive look and stylishly adorn the Swedish inspired design….



PREMIUM TECHNOLOGY

MAP SWITCH

By using the MAP SELECT SWITCH, the engine characteristics can be tailored to modify the power delivery according to rider preference, conditions and terrain. It has two settings which can be toggled on the fly, namely, Map 1, for standard and full power and Map 2, for softer power and delayed ignition timing for terrain with less traction.



THROTTLE BODY

The TE 250i uses a 39 mm throttle body which regulates the amount of air entering the engine via a butterfly operated by dual throttle cables connected to the handlebar throttle assembly. 2-stroke oil is mixed with the air and enters the engine to lubricate the crankshaft, cylinder & piston. Additionally, a throttle position sensor (TPS) relays airflow data to the ECU which in turn calculates the amount of oil and fuel delivered to the engine while a bypass screw regulates the idling speed and a cold start device opens a bypass providing more air for cold starts.



ELECTRIC START AND WIRING HARNESS

All TE models come standard with an electric starter. The system uses a compact and lightweight Li-Ion battery which is 1 kg lighter than a conventional battery. With several years of experience of developing and perfecting electric starting, the proven reliability on the Husqvarna enduro range is second to none, ensuring a quick and seamless start in any condition. Additionally, the wiring harness concentrates all needed electrical components into a common area below the seat for easy accessibility.



ENGINE MANAGEMENT SYSTEM

The TE 250i features an electronic control unit (ECU) which is responsible for a number of functions. The unit determines the ignition timing, the amount of fuel & oil injected into the cylinder and additionally, translates the information received from various sensors to adapt values and make corrections for automatic temperature and altitude compensation. This means the engine always runs at the optimum fuel/air mixture at any altitude.









2022 Husqvarna TE250i – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $ USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)

ENGINE
TRANSMISSION 6-speed
STARTER Electric starter
STROKE 72 mm
BORE 66.4 mm
CLUTCH DDS wet multi-disc clutch, Braktec hydraulics
DISPLACEMENT 249 cm³
EMS Continental EMS
DESIGN 1-cylinder, 2-stroke engine
CHASSIS
WEIGHT (WITHOUT FUEL) 106.2 kg
TANK CAPACITY (APPROX.) 8.5 l
FRONT BRAKE DISC DIAMETER 260 mm
REAR BRAKE DISC DIAMETER 220 mm
FRONT BRAKE Disc brake
REAR BRAKE Disc brake
CHAIN X-Ring 5/8 x 1/4″
FRAME DESIGN Central double-cradle-type 25CrMo4 steel
FRONT SUSPENSION WP XACT-USD, Ø 48 mm
GROUND CLEARANCE 360 mm
REAR SUSPENSION WP XACT Monoshock with linkage
SEAT HEIGHT 950 mm
STEERING HEAD ANGLE 63.5 °
SUSPENSION TRAVEL (FRONT) 300 mm
SUSPENSION TRAVEL (REAR) 300 mm

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
