2023 Ducati Scrambler Desert Sled: SPARKING BLUE HORIZONS.
Introducing the new 2023 Ducati Scrambler Desert Sled…
Even more off-road. Even more Scrambler. Here is the new Desert Sled.
Making its way out of the roughest roads of California and New Mexico, the new Scrambler Desert Sled is designed for those who love the unconventional streets and the less traveled paths. This essential and yet grand version of Scrambler offers a unique mix of off-road spirit and lifestyle values.
2023 Ducati Scrambler Desert Sled Totalmotorcycle.com Key Features
Fly with your Scrambler motorbike in the Land of Joy with positivity, fun and a free-spirited attitude.
2023 Ducati Scrambler Desert Sled Totalmotorcycle.com Features and Benefits
New livery
New “Sparking Blue” livery enriched with red and white details on the tank and mudguards. This livery is a tribute to the Enduro bikes of the 80s and enhances the distinctly off-road character of the bike, along with the golden rims and the classic black frame.
Premium LED Lighting
Headlight with glass lens and DRL. LED turn indicators.
Offroad setting
High front mudguard. Extended rear fender. High plate holder. Variable cross-section handlebar. Adjustable Kayaba Suspensions with 46mm fork and 200mm excursion.
Pirelli SCORPION™ RALLY ST tyres
Front 120/70 R 19 M/C 60V M+S TL and rear 170/60 R 17 M/C 72V M+S TL tyres, for the right balance between off-road and enduro street performance.
Brand new seat
860mm, with dedicated riding position.
Optimize riding experience & safety
Ducati Multimedia System ready. Selected gear indicator and fuel level. Handlebar switch controls. Hydraulic clutch control with adjustable lever. Dual-channel Bosch Cornering ABS.
2023 Ducati Scrambler Desert Sled – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $12,595 USD
Canada MSRP Price: from $ See Dealer CDN
Europe/UK MSRP Price: from £ See Dealer GBP (On The Road inc 20% Vat)
Type
L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
Displacement
803 cc
Bore x stroke
88 x 66 mm
Compression ratio
11:1
Power*
73 hp (53,6 kW) 8250 rpm/min
Torque*
6,7 Kgm (66,2 Nm) @ 5750 rpm
Fuel injection
Electronic fuel injection, 50 mm throttle body
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Standard
Euro 5 (Only for countries where Euro 5 standard applies)
Consumption – Emissions
5,4 l/100 km – CO2 124 g/km
Gearbox
6 speed
Ratio
1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26
Primary drive
Straight cut gears, Ratio 1,85:1
Final drive
Chain, front spocket 15, rear sprocket 46
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch
Frame
Tubular steel Trellis frame
Front suspension
46mm fully adjustable usd forks
Front wheel travel
200 mm (7,9 in)
Front wheel
Spoked aluminium wheel 3,00″ x 19″
Front tyre
Pirelli SCORPION™ RALLY STR 120/70 R19
Rear suspension
Kayaba rear shock, pre-load and rebound adjustable. Aluminium double-sided swingarm
Rear wheel travel
200 mm (5,9 in)
Rear wheel
Spoked aluminium wheel 4,50″ x 17″
Rear tyre
Pirelli SCORPION™ RALLY STR 170/60 R17
Front brake
Ø330 mm disc, radial 4-piston calliper with Bosch Cornering ABS as standard equipment
Rear brake
Ø245 mm disc, 1-piston floating calliper with Bosch Cornering ABS as standard equipment
Dashboard
LCD
Wheelbase
1.505 mm (59,3 in)
Rake
24°
Trail
112 mm (4,4 in)
Total steering lock
35°
Fuel tank capacity
13,5 l – 3,57 gallon (US)
Dry weight
193 kg (425,5 lb)
Wet weight**
209 kg (460,8 lb)
Seat height
860 mm (33,9 in) – low seat 840 mm (33,0 in) available as accessory
Max height
1.213 mm (47,8 in) (brake reservoir)
Max width
940 mm (37,0 in) (mirrors)
Max length
2.200 mm (86,6 in)
Number of seats
Dual seat
Standard equipment
Steel tank with interchangeable aluminium side panels, headlight with DRL by LED light-guide and interchangeable aluminium cover, LED rear light with diffusion-light, LED turn indicator, LCD instruments with gear and fuel level indications and interchangeable aluminium cover, under-seat storage compartment with USB socket, ABS cornering, machine-finished aluminium belt covers, black engine with brushed fins.
DESERT SLED equipment
Aluminium handlebar with cross-strut, front stem protectors, seat with specific design, high front mudguard, long rear mudguard and high plate support
Details
24 months unlimited mileage
Servicing
12,000 km (7.500 mi) / 12 months
Checking valve clearance
12,000 km (7.500 mi)
*Power/Torque
The power/torque values indicated are measured using and engine dynamometer according to homologation regulation and they correspond to the homologated data, as quoted in the Bike Registration Document.
**Wet weight
The weights in running order are considered with all operating fluids, standard equipment and the fuel tank filled to 90% of its useful capacity (UE regulation no. 168/2013).
2023 Ducati Scrambler Desert Sled – Totalmotorcycle.com Canada Specifications/Technical Details
Type
L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
Displacement
803 cc
Bore x stroke
88 x 66 mm
Compression ratio
11:1
Power*
73 hp (53,6 kW) 8250 rpm/min
Torque*
6,7 Kgm (66,2 Nm) @ 5750 rpm
Fuel injection
Electronic fuel injection, 50 mm throttle body
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Standard
Euro 5 (Only for countries where Euro 5 standard applies)
Consumption – Emissions
5,4 l/100 km – CO2 124 g/km
Gearbox
6 speed
Ratio
1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26
Primary drive
Straight cut gears, Ratio 1,85:1
Final drive
Chain, front spocket 15, rear sprocket 46
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch
Frame
Tubular steel Trellis frame
Front suspension
46mm fully adjustable usd forks
Front wheel travel
200 mm (7,9 in)
Front wheel
Spoked aluminium wheel 3,00″ x 19″
Front tyre
Pirelli SCORPION™ RALLY STR 120/70 R19
Rear suspension
Kayaba rear shock, pre-load and rebound adjustable. Aluminium double-sided swingarm
Rear wheel travel
200 mm (5,9 in)
Rear wheel
Spoked aluminium wheel 4,50″ x 17″
Rear tyre
Pirelli SCORPION™ RALLY STR 170/60 R17
Front brake
Ø330 mm disc, radial 4-piston calliper with Bosch Cornering ABS as standard equipment
Rear brake
Ø245 mm disc, 1-piston floating calliper with Bosch Cornering ABS as standard equipment
Dashboard
LCD
Wheelbase
1.505 mm (59,3 in)
Rake
24°
Trail
112 mm (4,4 in)
Total steering lock
35°
Fuel tank capacity
13,5 l – 3,57 gallon (US)
Dry weight
193 kg (425,5 lb)
Wet weight**
209 kg (460,8 lb)
Seat height
860 mm (33,9 in) – low seat 840 mm (33,0 in) available as accessory
Max height
1.213 mm (47,8 in) (brake reservoir)
Max width
940 mm (37,0 in) (mirrors)
Max length
2.200 mm (86,6 in)
Number of seats
Dual seat
Standard equipment
Steel tank with interchangeable aluminium side panels, headlight with DRL by LED light-guide and interchangeable aluminium cover, LED rear light with diffusion-light, LED turn indicator, LCD instruments with gear and fuel level indications and interchangeable aluminium cover, under-seat storage compartment with USB socket, ABS cornering, machine-finished aluminium belt covers, black engine with brushed fins.
DESERT SLED equipment
Aluminium handlebar with cross-strut, front stem protectors, seat with specific design, high front mudguard, long rear mudguard and high plate support
Details
24 months unlimited mileage
Servicing
12,000 km (7.500 mi) / 12 months
Checking valve clearance
12,000 km (7.500 mi)
*Power/Torque
The power/torque values indicated are measured using and engine dynamometer according to homologation regulation and they correspond to the homologated data, as quoted in the Bike Registration Document.
**Wet weight
The weights in running order are considered with all operating fluids, standard equipment and the fuel tank filled to 90% of its useful capacity (UE regulation no. 168/2013).
2023 Ducati Scrambler Desert Sled – Totalmotorcycle.com European Specifications/Technical Details
Type
L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
Displacement
803 cc
Bore x stroke
88 x 66 mm
Compression ratio
11:1
Power*
73 hp (53,6 kW) 8250 rpm/min
Torque*
6,7 Kgm (66,2 Nm) @ 5750 rpm
Fuel injection
Electronic fuel injection, 50 mm throttle body
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Standard
Euro 5 (Only for countries where Euro 5 standard applies)
Consumption – Emissions
5,4 l/100 km – CO2 124 g/km
Gearbox
6 speed
Ratio
1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26
Primary drive
Straight cut gears, Ratio 1,85:1
Final drive
Chain, front spocket 15, rear sprocket 46
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch
Frame
Tubular steel Trellis frame
Front suspension
46mm fully adjustable usd forks
Front wheel travel
200 mm (7,9 in)
Front wheel
Spoked aluminium wheel 3,00″ x 19″
Front tyre
Pirelli SCORPION™ RALLY STR 120/70 R19
Rear suspension
Kayaba rear shock, pre-load and rebound adjustable. Aluminium double-sided swingarm
Rear wheel travel
200 mm (5,9 in)
Rear wheel
Spoked aluminium wheel 4,50″ x 17″
Rear tyre
Pirelli SCORPION™ RALLY STR 170/60 R17
Front brake
Ø330 mm disc, radial 4-piston calliper with Bosch Cornering ABS as standard equipment
Rear brake
Ø245 mm disc, 1-piston floating calliper with Bosch Cornering ABS as standard equipment
Dashboard
LCD
Wheelbase
1.505 mm (59,3 in)
Rake
24°
Trail
112 mm (4,4 in)
Total steering lock
35°
Fuel tank capacity
13,5 l – 3,57 gallon (US)
Dry weight
193 kg (425,5 lb)
Wet weight**
209 kg (460,8 lb)
Seat height
860 mm (33,9 in) – low seat 840 mm (33,0 in) available as accessory
Max height
1.213 mm (47,8 in) (brake reservoir)
Max width
940 mm (37,0 in) (mirrors)
Max length
2.200 mm (86,6 in)
Number of seats
Dual seat
Standard equipment
Steel tank with interchangeable aluminium side panels, headlight with DRL by LED light-guide and interchangeable aluminium cover, LED rear light with diffusion-light, LED turn indicator, LCD instruments with gear and fuel level indications and interchangeable aluminium cover, under-seat storage compartment with USB socket, ABS cornering, machine-finished aluminium belt covers, black engine with brushed fins.
DESERT SLED equipment
Aluminium handlebar with cross-strut, front stem protectors, seat with specific design, high front mudguard, long rear mudguard and high plate support
Details
24 months unlimited mileage
Servicing
12,000 km (7.500 mi) / 12 months
Checking valve clearance
12,000 km (7.500 mi)
*Power/Torque
The power/torque values indicated are measured using and engine dynamometer according to homologation regulation and they correspond to the homologated data, as quoted in the Bike Registration Document.
**Wet weight
The weights in running order are considered with all operating fluids, standard equipment and the fuel tank filled to 90% of its useful capacity (UE regulation no. 168/2013).
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
