2023 Kawasaki Z125 Pro: REBELLIOUS SIDE OF FUN.
Introducing the 2023 Kawasaki Z125 Pro…
Compact and lightweight, Kawasaki’s Z125 PRO is the ideal way to have fun while navigating the urban landscape. Don’t let its size fool you, the Z125 PRO is designed to provide a high level of riding performance on par with its much larger Z siblings.
Small on size but big on fun, the Kawasaki Z125 PRO mini naked motorcycle is a nimble streetfighter that makes a statement wherever it goes. Featuring a 125cc engine, low seat height, upright riding position and responsive street tires, it’s your invitation to the rebellious side of fun. The 2023 Z125 PRO also features a four-speed manual transmission, smooth power delivery, lightweight chassis, offset laydown single-shock, digital LCD screen with analog tachometer and gear position indicator, 12-inch cast wheels, and aggressive Kawasaki Z styling.
Small in size but big on fun, the Kawasaki Z125 PRO motorcycle is a nimble streetfighter that makes a statement wherever it goes. With a 125cc engine, upright riding position and responsive street tires, it’s your invitation to the rebellious side of fun.
Displaying Kawasaki’s unique Sugomi design philosophy for all to see, the Z125 is here to be noticed and make a profound Naked bike statement. The exposed trellis type chassis blends with minimal and aggressive Z bodywork encouraging spirited riding from the A1 friendly 15PS (11kW) engine that is both new-rider friendly and as sporting as you would expect from Kawasaki. Welcome to the Z family. Z125-Ignite.
2023 Kawasaki Z125 Pro KRT Totalmotorcycle.com Key Features
- DISTINCTIVE STYLING EMULATES THE AGGRESSIVE DESIGN OF ITS LARGER Z SIBLINGS.
- COMPACT CHASSIS COMBINES WITH SPORTY SUSPENSION AND TIRES FOR LIGHT, NIMBLE HANDLING
- QUICK-REVVING, FUEL-INJECTED ENGINE PROVIDES AMPLE PERFORMANCE FOR NEGOTIATING CITY TRAFFIC
- CONFIDENCE-INSPIRING LOW SEAT HEIGHT
- PETAL DISC BRAKES
- HIGH-TECH INSTRUMENTATION INCLUDES GEAR POSITION INDICATOR AND FUEL GAUGE
2023 KAWASAKI Z FAMILY MOTORCYCLE LINEUP A TRUE SUPERNAKED EXPERIENCE
For 2023, Kawasaki welcomes the return of its iconic Z Family line of naked motorcycles, which includes several supernaked, retro sport, and mini naked models. Z models set to hit dealerships this fall include an updated Z650 and Z650 ABS with Kawasaki TRaction Control (KTRC) as well as the Z650RS, Z900 ABS, Z900 SE, and Z125 PRO
2023 Kawasaki Z125 Pro KRT Totalmotorcycle.com Features and Benefits
ENGINE
• Simple and reliable air-cooled, SOHC, 2-valve Single is tuned for strong acceleration throughout the rev range.
• Cam profiles and intake port design contribute to the smooth, quick-revving engine character.
• Fuel injection ensures stable fuel delivery regardless of outside air temperature or atmospheric pressure. It also ensures reliable engine starting, whether the engine is hot or cold.
• The airbox is positioned above and forward of the cylinder head, contributing to the sporty power feeling and helping to minimize intake noise.
• 24 mm throttle body adds to the quick-revving character with its long-nose type injector.
• Stainless steel exhaust pipe offers excellent durability, while the under-engine muffler design contributes to a compact package as well as mass
centralization for light handling and increased maneuverability.
• Smart regulator with built-in microprocessor reviews the battery charging level and engine rpm, cutting the generating current when the battery is
fully charged or during acceleration to minimize power loss. The system also helps to improve fuel efficiency.
• 4-Speed transmission with manual clutch
• Link-type shift lever, similar to that found on larger displacement models, reduces the input load required to shift gears for a light shift touch. The cylinder is tilted forward 20 degrees to help reduce overall engine height.
• Lightweight flywheel lets the engine rev quickly for sharp response and direct power feeling. Designed to have a sporty character, the quick-revving engine pulls smoothly from the bottom all the way to redline and provides superb passing performance for negotiating city traffic.
CHASSIS
• High-tensile steel backbone frame is robust and capable of handling two-up riding.
• Offset laydown rear suspension enables a compact package while contributing to sporty handling. The shock’s mounting angle is designed to provide superb shock action and excellent ride comfort.
• The rear shock is a 4-way preload adjustable, allowing riders to set the preload for their weight and to adjust for carrying a passenger.
• Highly rigid box-section swingarm enhances to the handling while providing the strength for carrying a passenger.
• 30mm inverted front fork with lightweight aluminum upper triple clamp offers excellent rigidity and low unsprung weight for sporty riding potential. The fork settings also contribute to the Z125 PRO’s nimble handling.
• Cast aluminium wheels reduce unsprung weight and are fitted with tubeless tires for great sporty street performance.
• Tire sizes and tread pattern were selected to deliver sporty, nimble handling.
• Rear rim is wide enough to accommodate a larger 130mm rear tire.
• Front and rear disc brakes provide stopping power to match the Z125 PRO’s sporty handling. The petal discs are just like those of its larger brothers in the Kawasaki line-up and add to the sporty look with optimized lateral rigidity benefits handling by adding to cornering performance.
• Radial tires offer light weight, excellent grip and contribute to both agile handling and riding comfort. The compact chassis combined with sporty suspension and tires provides light, nimble handling.
• Compact headlamp cowl is one of the key styling elements of the aggressive Z design.
• Sporty, single headlamp design helps provide a slim image. The multi-reflector headlamp throws a clear beam of light.
• Compact engine shrouds contribute to the bike’s hourglass figure as well as its overall aggressive design.
• The slim fuel tank is flared at the top edges and slants forward to add to the aggressive design.
• Ignition switch is located at the front of the tank, adding to the bike’s sporty image and a tidy cockpit design.
• Sharp, supernaked-style under-cowl with an aggressive chiseled design adds to the sporty image.
• Sporty front fender has integrated fork guards that help protect the fork tubes from road debris.
• Front and rear turn signals feature a sharp design and clear, transparent lenses, adding to the sporty image.
• Stepped seat design adds to the sporty look while accommodating both a rider and passenger.
• Slim tail section is complemented by a sharp LED tail light, where the LED bulbs form a “Z” pattern.
• Rear inner fender adds to the sharp design and helps to keep the under-tail and rear suspension clean.
• Machined footpegs for the rider and passenger further contribute to the sporty image while offering direct feedback to the rider.
• Stylish front sprocket cover adds to the sharp look.
Z STYLE
• Instrument console combines a race analog-style tachometer with a multi-function LCD screen.
• In addition to premium features like a gear position indicator and fuel gauge, there are the standard functions such as speedometer, clock, odometer and trip meter.
Convenient Features
• Large-volume fuel tank and superb fuel efficiency enable a long riding range.
• Locking fuel tank cap deters tampering.
• Low seat height makes it easy for riders to reach the ground with both feet.
• The Z125 PRO’s light weight and compact chassis make it easy to handle, whether maneuvering in tight quarters or walking beside the bike.
• Tight turning radius makes it easy to navigate urban traffic.
Powerful Engine
125 cm3 4-stroke Single
Smooth power delivery contributes to the Z125’s 125 cm3 engine’s feel-good performance. Like a typical Kawasaki engine, the engine delivers a good “punch” at high rpm, and continues to pull right up to the rev limiter. Reliability inherited from its robust 250cc base engine adds peace of mind.
Six-speed transmission
Smooth-shifting six-speed transmission complements the sporty street performance, offering a gear for every situation.
Electric start & fuel injection
Electric starter and fuel injection ensure hassle-free starting at the push of a button.
Transmission
Smooth-shifting six-speed transmission complements the sporty street performance, offering a gear for every situation. The clutch engages smoothly and disengages cleanly, making it easy to operate for new riders and optimising clutch feel for on-road performance.
All-digital Instrumentation
All-digital instrument panel gives the cockpit a modern, sporty look.
Brakes/wheels/tyres
Front and rear disc brakes offer impressive stopping performance. Dualpiston calipers grip a ø290 mm disc up front, and a ø220 mm disc at the rear. Petal disc design adds to the sporty Kawasaki looks.
ERGO-FIT Low Seat
ERGO-FIT seats enable riders to select seats that optimise their fit on the bike. For the Z125, an ERGO-FIT low seat (-25 mm) is available. (Patterns on the seat material are unique to each machine.)
Sharp Taillight Design
Sharp taillight design enhances the sporty look of the rear.
Independent Sport ABS
Standard equipment ABS contributes to rider reassurance. The highspec system was designed specially for motorcycles and features a very compact ABS unit. Independent activation maximises sporty control.
Full-size Chassis
The Z125 features a full-size chassis. With a slim, compact trellis frame, sporty suspension and lightweight 17” wheels, the light, nimble handling they offer is ideal for new riders to become familiar with operating a full-size motorcycle.
Slim, compact trellis frame
Trellis frame enables a slim, compact package that is easy to manage, and makes it easy to reach the ground with your feet.
Supernaked Ergonomics
The Z125 light, nimble handling character together with an upright riding position and wide handlebar put the rider in the ideal position for active control, facilitating dynamic, sporty riding that enables the Z125 rider to deftly navigate urban traffic.
Uni Trak Rear Suspension
Uni Trak rear suspension provides great road holding ability and bump absorption, contributing to the bike’s sporty handling. The shock linkage decreases leverage on the shock as the suspension is compressed: small bumps are damped very lightly while big bumps receive lots of damping. The shock has a 5 stroke of 60 mm, helping to ensure the balance of lightweight handling and a composed character. 5-way rear preload adjustability allows riders to adjust the rear ride height, as well as set up the bike to accommodate a passenger or luggage.
Sporty Suspension
ø37 mm telescopic fork contributes to both light, nimble handling as well as a generally composed riding character. Kawasaki’s original linkage-equipped Uni Trak rear suspension delivers a smooth ride over a wide range of road conditions.
Z Supernaked Styling
Like its larger brothers in the Z Series, the Z125’s aggressive styling hints at its sporty potential. A dynamic design created by its slim, hourglass figure is complemented by extremely lightweight looks care of sharp, close-fit bodywork and an original trellis frame.
2023 Kawasaki Z125 Pro KRT – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3,399 USD
Canada MSRP Price: $3,899 CDN
Europe/UK MSRP Price: £4,299 – 4,399 GBP (On The Road inc 20% Vat)
Engine Type 4-Stroke, Air-Cooled, SOHC, Single, 2-Valve Cylinder Head
Displacement 125 cc
Bore & Stroke 56.0 x 50.6 mm
Compression Ratio 9.8:1
Fuel System DFI® with 24 mm Throttle Body
Ignition TCBI w/Electronic Advance
Transmission 4-Speed
Rake/Trail 26° / 2.7 in.
Front Tire Size 100/90-12
Rear Tire Size 120/70-12
Front Suspension 30mm Inverted Fork
Front Suspension Travel 3.9 in.
Rear Suspension Offset Single Shock w/4-way preload adjustment
Rear Suspension Travel 4.1 in.
Wheelbase 46.3 in.
Front Brake Type 200mm Petal Disc
Rear Brake Type 184mm Petal Disc
Fuel Tank Capacity 2.0 gal.
Ground Clearance 6.1 in.
Seat Height 31.7 in.
Curb Weight= 225 lb.
Warranty 12 months
Kawasaki Protection Plus™ 12, 24, 36 or 48 months
(Specifications subject to change without notice.)
= Includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90% of capacity) and tool kit (if supplied).
When equipped, 50-state models with evaporative emissions equipment adds approximately 2.2 pounds.
(KP) = See Kaw-Pedia section for more details.
** = Also available as a 50-state model with the last character ending in “L”
2023 Kawasaki Z125 Pro KRT – Totalmotorcycle.com Canadian Specifications/Technical Details
POWER
Engine 125cc, air-cooled, 4-stroke, SOHC 2-valve single
Bore x Stroke 56.0 x 50.6 mm
Compression Ratio 9.8:1
Fuel System Fuel injection: ø24 mm x 1
Ignition Digital
Starting Electric
Lubrication Forced lubrication, wet sump
Transmission 4-speed, return
Clutch Wet multi-disc, manual
Final Drive Chain
PERFORMANCE
Frame Backbone, high-tensile steel
Front Suspension / Wheel Travel ø30 mm inverted fork / 100 mm (3.9 in)
Rear Suspension / Wheel Travel Offset laydown single-shock with adjustable preload / 104 mm (4.1 in)
Rake / Trail 26.0° / 69 mm
Steering Angle (L/R) 35° / 35°
Front Tire 100/90-12 49J
Rear Tire 120/70-12 51L
Front Brake ø200 mm petal disc with single-piston caliper
Rear Brake ø184 mm petal disc with single-piston caliper
DETAILS
Dimensions (L x W x H) 1,700 x 750 x 1,005 mm (66.9 x 29.5 x 39.6 in)
Wheelbase 1,175 mm (46.3 in)
Road Clearance 155 mm (6.1 in)
Seat Height 805 mm (31.7 in)
Curb Mass** 102 kg (225 lb)
Fuel Capacity 7.4 litres
Instrumentation Analogue-style tachometer + multi-function LCD screen with gear position indicator, fuel gauge, speedometer, clock, odometer and trip meter
Warranty 12 months
Kawasaki Protection Plus 12 / 24 / 36 / 48 months
2023 Kawasaki Z125 Pro KRT – Totalmotorcycle.com European Specifications/Technical Details
Engine
Engine typeLiquid-cooled, 4-stroke Single
Displacement125 cm³
Displacement125 cm³
Bore x stroke58 x 47.2 mm
Compression ratio11.7:1
Valve systemDOHC, 4 valves
Fuel systemFuel injection: Ø 28 mm x 1
Starting SystemElectric
LubricationForced lubrication, wet sump
Gear Performance & Transmission
Maximum power11 kW {15 PS} / 10,000 rpm
CO2 emission61 g/km
Maximum torque11.7 N•m {1.2 kgf•m} / 7,700 rpm
Transmission6-speed
Final driveChain
Primary Reduction Ratio2.966 (86/29)
Gear Ratios 1st2.833 (34/12)
Gear Ratios 2nd1.875 (30/16)
Gear Ratios 3rd1.444 (26/18)
Gear Ratios 4th1.208 (29/24)
Gear Ratios 5th1.056 (19/18)
Gear Ratios 6th0.962 (25/26)
Final reduction ratio3.500 (56/16)
ClutchWet multi-disc
Suspensions Brakes & Suspension
Brakes, frontSingle 290 mm petal disc. Caliper: Dual piston
Brakes, rearSingle 220 mm petal disc. Caliper: Dual piston
Suspension, front37 mm telescopic fork
Suspension, rearUni-Trak, gas-charged shock with adjustable preload
Dimensions Frame & Dimensions
Frame typeTubular diamond, steel
Trail90 mm
Wheel travel front110 mm
Wheel travel rear120 mm
Tyre, front100/80-17M/C 52S
Tyre, rear130/70-17M/C 62S
Tyre, rear130/70-17M/C 62S
L x W x H1,935 x 740 x 1,015 mm
Wheelbase1,330 mm
Ground clearance185 mm
Fuel capacity11 litres
Seat height815 mm
Curb mass147 kg
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
