2023 Yamaha TT-R110E: SMALL PACKAGE. BIG FUN.
Introducing the new 2023 Yamaha TT-R110E…
The bike that produces big fun for both young and older riders and everyone in between. The versatile TT‑R110E is a bike for the whole family.
The TT-R110 is the middle bike in the Yamaha 4-stroke fun bike family, and is the perfect step up for riders moving up from a TT-R50 or PW50 – as well as being an ideal choice for first-time riders. Features like the electric starter, low seat and natural riding position make it perfect for young riders, and the dynamic Icon Blue bodywork is inspired by Yamaha’s bigger motocross race bikes.
Small package – big fun!
For easy steering and high levels of rider comfort this great-looking youth bike features long-travel front forks and monocross rear suspension – while the 14-inch front wheel and 12-inch rear wheel feature durable and wide knobbly tyres to handle off road terrain.
New and experienced off-road riders will love the smooth and strong performance of the quiet-running 110cc 4-stroke engine – and with its automatic clutch, the 4-speed gearbox is very easy to use. Key-type ignition gives added security, and low maintenance features make the TT-R110 so much fun to ride – and easy to own.
Whichever Yamaha fun bike you choose, you can be sure that it has been built to the same high quality and safety standards as all of the company’s 2-wheel products. And like every model in the kids’ bike line, the TT-R110 is designed to be simple to use, fun to ride and easy to maintain.
2023 Yamaha TT-R110E Totalmotorcycle.com Key Features
- Accessible Performance
Big fun for the whole family, the YZ-styled, four-stroke-powered TT-R110E begs to be ridden by everyone. - Low Seat Height
A seat height of only 26.4 inches makes the TT-R110E accessible to most riders, but the 7.1 inches of ground clearance and great suspension at both ends means it can go almost anywhere too. - Electric Starter
Convenient push-button electric start feature for effortless engine startup with a backup kick starter. - Auto-Clutch Convenience
Four-speed auto-clutch transmission has an easily accessible gear for nearly any terrain.
2023 Yamaha TT-R110E Totalmotorcycle.com Features and Benefits
ENGINE
- Torque-Rich Engine
Powerful 110cc air-cooled SOHC four-stroke engine is tuned for off-road performance in a wide range of trail conditions. - Compact Cylinder Design
Compact hemispherical combustion chamber with 9.3:1 compression produces max torque at 4,000 rpm and max horsepower at 7,500 rpm. - Auto-Clutch Convenience
Four-speed gearbox with automatic clutch has the right gear for wherever you ride. - Electric Starter
Convenient push-button electric start feature for effortless engine startup with a backup kick starter. - Digital Ignition
CDI ignition system is ultra-reliable and never needs maintenance. - Low Maintenance Engine
Automatic cam chain tensioner means minimal maintenance and longer engine life. - Easy Serviceability
Easy-access, tool-free air filter adds extra convenience during maintenance. - Forest-Friendly Exhaust
Lightweight exhaust system features quiet, USFS-approved spark arrestor.
CHASSIS/SUSPENSION
- Robust, Compact Frame
Steel backbone frame ties steering head and swingarm pivot together via a straight line, with the engine mounted at three places for optimum strength and high ground clearance. - Well-Damped Front Fork
The 31mm fork with high-tech internals including a damper valve with oil lock provide excellent damping, great bottoming resistance and 4.5 inches of smooth travel. - Advanced Rear Suspension
Monocross® rear suspension and gusseted steel swingarm provide excellent rear wheel control through 4.3 inches of travel. - Stylish Aluminum Top Clamp
Die-cast aluminum top triple clamp provides light, precise handling and looks great too. - Trail-Ready Dimensions
The 26.4-inch seat height and 7.1 inches of ground clearance inspire confident performance on rugged trails. - Enclosed Drum Brakes
Front and rear drum brakes deliver strong, dependable stopping power. - Nimble Wheels and Tires
The 14-inch front and 12-inch rear wheels inspire great rider confidence by keeping the seat low and the steering light. - Durable Knobby Tires
Knobby tires offer superb grip and exceptional wear.
ADDITIONAL FEATURES
- Low Seat Height
The long, YZ-style gripper seat is low and comfortable and allows for easy rider movement. - Racing Style
Team Yamaha-inspired colors and graphics with front and side number plates create competition motocross styling similar to its YZ siblings. - Grippy Foot Pegs
Large folding, cleated foot pegs provide excellent footing, even in wet or muddy conditions. - Standard Security
Key-type ignition switch deters unauthorized riding.
2023 Yamaha TT-R110E – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ 2299 USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 110cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 51.0mm x 54.0mm
Compression Ratio 9.3:1
Fuel Delivery Mikuni® VM16 carburetor
Ignition CDI
Transmission Constant-mesh 4-speed; multiple wet clutch
Final Drive Chain
Suspension / Front 31mm telescopic fork; 4.5-in travel
Suspension / Rear Monocross® shock; 4.3-in travel
Brakes / Front Drum, 95mm
Brakes / Rear Drum, 110mm
Tires / Front 2.50-14-4PR
Tires / Rear 3.00-12-4PR
L x W x H 61.6 in x 26.8 in x 36.2 in
Seat Height 26.4 in
Wheelbase 42.5 in
Rake (Caster Angle) 26.0°
Trail 2.4 in
Maximum Ground
Clearance
7.1 in
Fuel Capacity 1.0 gal
Fuel Economy n/a
Wet Weight 159 lb
Warranty 90 Day (Limited Factory Warranty)
Color Team Yamaha Blue
2023 Yamaha TT-R110E – Totalmotorcycle.com Canada Specifications/Technical Details
2023 Yamaha TT-R110E – Totalmotorcycle.com European Specifications/Technical Details
Engine
Engine type SOHC;Single cylinder;4-stroke;Air-cooled;2-valves
Lubrication system Wet sump
Clutch type Wet;Multiple Disc
Ignition system CDI
Starter system Electric and kick
Transmission system Constant Mesh;4-speed
Final transmission Chain
Fuel system Mikuni VM16/1
Chassis
Frame Steel tube backbone
Rear suspension system Swingarm
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
