2024 Ducati MIG-S: TRUE CARBON RELIEF.
Introducing the new 2024 Ducati MIG-S…
An All Mountain ebike with sporting features, for those looking for an agile, performing and fun e-mtb in all conditions.
The Ducati MIG-S with 150mm travel at the front and 140 rear, thanks to high-level components (Marzocchi Bomber Z2 fork, Fox Float TPS rear shock, 4-calipers Sram Guide T brakes, 29” Thok e-plus rims at the front and 27.5″ rear, 12 speeds Sram SX transmission 11-50) it is an e-mtb that will allow you to explore any trail with a unique ride-ability. Its geometries are designed to safely face both the most demanding climbs and the roughest descents. Equipped with Shimano Steps E8000 engine and 630Wh Shimano battery positioned below the down tube to improve handling.
The graphics realized by Aldo Drudi’s D-Perf enhance the lines of the hydroformed aluminum frame.
The Ducati MIG-S is ready to take you on all your off-road adventures.
2024 Ducati MIG-S Totalmotorcycle.com Key Features
An All Mountain with sporty characteristics, for those looking for an agile, performing and fun vehicle in all conditions.
2024 Ducati MIG-S Totalmotorcycle.com Features and Benefits
Shimano E8000
Shimano E8000. Specific for e-mtb. It has three levels of assistance (Eco, Trail, Boost) and a Power-Walk mode. With the Shimano E-Tube app you can customize the Trail and Boost assistance levels to three different positions. 630 Wh Shimano battery.
Improves handling
6061 aluminum frame, forged and CNC-machined parts with hydroformed tubes with variable thickness. The battery situated below the diagonal tube lowers the centre of gravity and improves handling.
Suspension
Marzocchi Bomber Z2 air, customized tuning fork with 150mm travel. FOX Float DPS customized tuning rear shock with 140mm travel, and Horst-link TPS (Thok Progressive System)
Battery cover
Easily removable, it allows you to recharge the battery even while it is mounted on the MIG-RR. Exclusive design and connection to the chassis derived from the systems used on the fairings of the MotoGP Desmosedici.
Tires and rims
Thok e-plus rims: 29″ front and 27,5” rear. MAXXIS Assegai tires: 29″x2.6 EXO+, TR, 3C front and 27.5″x2.6 EXO+, TR, 3C rear. They allow to easily overcome the most difficult obstacles and maintain maximum grip on any terrain.
2024 Ducati MIG-S – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $5,995 USD
Canada MSRP Price: $7,695 CDN
Europe/UK MSRP Price: from £5,390 GBP (On The Road inc 20% Vat)
FRAME
Aluminum, Forged and CNC machined, 29″/27,5″ geometry, semi-integrated down tube battery, internal cable, fully sealed cartridge bearing , 140 mm travel
ENGINE
Shimano Steps E8000 (250Watt – 51.6 lb-ft – 6.1 lb)
BATTERY
Shimano 630Wh
SUSPENSIONS
Front: Marzocchi Bomber Z2 – Air, 150mm customized tuning Rear: FOX Float DPS – 140mm customized tuning
REAR SUSPENSION LAYOUT
TPS Thok Progressive System (Horst Link)
BRAKES
Sram Guide T – 4 calipers – 203mm rotor disks
WHEELS
THOK Drift: 29″x30mm (27.5″x30mm Small size) front – 27,5″x 35 mm rear
TIRES
Front: PIRELLI Scorpion S – E-mtb 29″x2.6 TR, SmartGrip, HyperWall (27.5″x2.6 Small size) Rear: PIRELLI Scorpion S – E-mtb 27,5″x2.6 TR, SmartGrip, HyperWall
SEAT POST
KS – dropper post micro height adjustable, remote control
HANDLEBAR
Thok 780mm alloy oversize, 35mm section, 20mm rise
WEIGHT
48.5 lbs (size M without pedals)
TRANSMISSION
Sram SX, 12 speed (11-50)
2024 Ducati MIG-S – Totalmotorcycle.com Canada Specifications/Technical Details
FRAME
Aluminum, Forged and CNC machined, 29″/27,5″ geometry, semi-integrated down tube battery, internal cable, fully sealed cartridge bearing , 140 mm travel
ENGINE
Shimano Steps E8000 (250Watt – 51.6 lb-ft – 6.1 lb)
BATTERY
Shimano 630Wh
SUSPENSIONS
Front: Marzocchi Bomber Z2 – Air, 150mm customized tuning Rear: FOX Float DPS – 140mm customized tuning
REAR SUSPENSION LAYOUT
TPS Thok Progressive System (Horst Link)
BRAKES
Sram Guide T – 4 calipers – 203mm rotor disks
WHEELS
THOK Drift: 29″x30mm (27.5″x30mm Small size) front – 27,5″x 35 mm rear
TIRES
Front: PIRELLI Scorpion S – E-mtb 29″x2.6 TR, SmartGrip, HyperWall (27.5″x2.6 Small size) Rear: PIRELLI Scorpion S – E-mtb 27,5″x2.6 TR, SmartGrip, HyperWall
SEAT POST
KS – dropper post micro height adjustable, remote control
HANDLEBAR
Thok 780mm alloy oversize, 35mm section, 20mm rise
WEIGHT
48.5 lbs (size M without pedals)
TRANSMISSION
Sram SX, 12 speed (11-50)
2024 Ducati MIG-S – Totalmotorcycle.com European Specifications/Technical Details
Frame
Alloy frame 6061 forged and CNC parts, hydroformed tubes
Battery
Shimano – 630 Wh (semi-integrated)
Brakes
Sram Guide T – 4 calipers – 203 mm rotor
Handlebar
Thok 780 mm alloy oversize, 35 mm section, 20 mm rise
Wheels
Thok e-plus – 29” front (Small size 27.5″) – 27.5” rear
Tyres
Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 (Small size 27.5″ x 2.6) Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 (Small size 27.5″ x 2.6) Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6
Saddle
Ducati Fit – hollow Cr.Mo rail
Display
Shimano – SC-E7000 LCD display with remote control
Rear derailleur
SRAM NX 12 speed (11-50)
Shift lever
SRAM SX 12 speed
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
