2024 Honda Shadow Phantom ABS Guide

2024 Honda Shadow Phantom ABS
ReviewKey FeaturesFeatures & BenefitsSpecifications
2024 Honda Shadow Phantom ABS 2024 Honda Shadow Phantom ABS 2024 Honda Shadow Phantom ABS 2024 Honda Shadow Phantom ABS 2024 Honda Shadow Phantom ABS

2024 Honda Shadow Phantom ABS: COOLER THAN EVER.

Introducing the 2024 Honda Shadow Phantom ABS…

Our Honda Shadow Phantom may be a traditional-style cruiser, but it’s sporting some major updates and improvements for 2024. First of all, we’ve given the Phantom a powerful new rear disc brake this year for excellent, linear stopping power. Plus, the new rear disc means you can get a Phantom with optional anti-lock brakes (ABS) now.* Then there are all the styling updates: new paint and graphic patterns, a new headlight cover, bright, machined-edge cylinder-head fins, a new air cleaner cover, and new instruments. There’s even a cool new solo seat standard, with an optional passenger seat and footpegs available—you decide how you want to roll. New fork-leg covers, and front and rear LED turn signals complete the package.

Few V-twin cruisers can measure up to the clean, understated style and rock-solid reliability of the Shadow Phantom. For the 2024 model year, the cruiser icon takes it to the next level with updates to its quintessential bobber styling, along with improved performance. With a two-tone gas tank, new handlebar, handlebar clamps, headlight cover, air-cleaner cover, display instruments, turn signals and machine-cut cylinder-head fins, this cruiser’s appearance is only more timeless than that of its predecessor. In addition, an updated single seat provides comfort for long, relaxing rides, and an available passenger seat and footpegs are offered for those who want to bring a plus-one along for the ride. A new ABS version is available for the new model year, and both versions receive a rear disc brake. And to top it off, the Shadow Phantom is built with Honda’s unmatched durability, quality and reliability, giving owners the peace of mind to enjoy the sense of freedom that only a V-twin cruiser can provide.

Note: Non-ABS version not available in California.







2024 Honda Shadow Phantom ABS Totalmotorcycle.com Key Features

Special Features

  • Anti-lock brakes (ABS)



Base Features

  • 745cc liquid-cooled V-twin engine
  • Blacked-out engine components
  • Shaft final drive
  • Solo saddle
  • Low seat height
  • 2-into-2 exhaust system
  • Spoked wheels



STYLE

BOBBER-INSPIRED STYLING

The short fenders, clean seat, hidden wiring and de-chromed treatment all give the Phantom its unique look: like an old-school cruiser that’s ready for the way we roll today.

TANK-MOUNTED INSTRUMENTS

A key element of the Shadow Phantom’s look are the tank-mounted instruments. Set in a blacked-out pod to match the rest of the bike’s look, they combine a traditional feel with a thoroughly modern treatment.

BLACKED-OUT STYLING

The closer you look at a Shadow Phantom, the better it looks. That’s because the styling is so unified. Check out the way the blacked-out engine, rims, frame, fork, headlight and seat all hang together. It really makes the tank stand out on the Deep Pearl Gray or Orange Metallic model.

ALL LED LIGHTING

For 2024, the Shadow Phantom gets LED turn signals that give the bike a clean, updated look.

NEW CYLINDER-FIN HIGHLIGHTS

The Phantom embraces a blacked-out look, but we’ve added machined-edge cylinder-head fins this year that really stand out. It’s just the right amount highlighting to catch your eye and make this critical component sing.

NEW FRONT FENDERS

Just keeping things fresh here, but new front and rear fenders are a big part of the Phantom’s contemporary, muscular, athletic look.

SPOKED WHEELS

The Shadow Phantom’s spoked black wheels and hubs complete the overall custom look.



COMFORT

LOW SEAT HEIGHT

The Phantom’s low seat height makes flat-footing it at stoplights or in parking lots a breeze. And the Phantom’s narrow seat/tank junction makes it feel even lower.

SOLO SADDLE

Sleek, one-piece solo seat is comfortable and looks great too. If you’re bringing a passenger along, check out our accessory passenger seat and footpegs.

DRIVETRAIN

SHAFT FINAL DRIVE

Clean, efficient, proven, and low maintenance. Shaft final drive is the perfect choice for a machine like this, and for riders who pile on the miles. You never have to worry about lubrication or adjustment out on the road. And an added plus: it helps keep your bike cleaner, too.

FIVE-SPEED TRANSMISSION

The Shadow Phantom’s wide-ratio five-speed transmission lets you cruise the boulevard at a low, unhurried pace, yet allows you hop on the highway without revving the engine through the roof.







2024 Honda Shadow Phantom ABS Totalmotorcycle.com Features and Benefits

ENGINE / DRIVETRAIN

  • 745cc liquid-cooled V-twin engine produces impressive power over a broad rpm range.
  • Crankshaft features long-stroke design to produce strong V-twin feel and low-rpm torque peak.
  • Three-Valve Dual-Plug Combustion Chamber.
  • Wide-ratio five-speed transmission.
  • Shaft final-drive system provides smooth and reliable low-maintenance operation.
  • Programmed Fuel Injection (PGM-FI) for good throttle response and fuel efficiency.

CHASSIS / SUSPENSION

  • Bobber-inspired styling with extensive blacked-out and matte finishes.
  • Updates minimalist front and rear fenders.
  • Revised headlight cover.
  • New handlebar and handlebar clamps enhance style and comfort.
  • Updated fork boot covers
  • The cylinder head now features machine-cut fins to contrast the black engine components.
  • Sturdy and responsive 41mm fork features large-diameter matte-finished shrouds and large billet-aluminum triple clamp for a distinctive look, and delivers confident, neutral handling.
  • Dual-shock rear suspension features five-position spring preload adjustability for a smooth ride.
  • New single rear disc brake on standard and ABS versions
  • Single front disc brake with twin-piston caliper grips a 296mm drilled rotor between sintered metal pads.
  • Shaft final-drive system provides smooth and reliable low-maintenance operation.
  • Spoke black wheels and hubs feature a 120/90-17 front tire and 160/80-15 rear tire to complete the overall custom look.
  • Low 25.6-inch seat height.
  • Sleek, new single seat with an available passenger seat.
  • Updated Tank-mounted display instruments.
  • Stylish 3.7-gallon fuel tank.
  • New LED front and rear turn signals.

Transferable one-year, unlimited-mileage limited warranty; extended coverage available with a HondaCare® Protection Plan.

Honda ACCESSORIES
New Passenger Seat and Step, Boulevard Screen (smoke), Custom Rider Seat, Solo Rider Rear Carrier, Backrest (tall/low), Rear Carrier, Backrest/Rear Carrier Mounting Brackets, Tank Belt (plain/studded), Saddlebags, Saddlebag Supports, Saddlebag Liner Set, Touring Bag (plain/studded/fringed), Front Pouch (plain/studded), Cycle Cover.







2024 Honda Shadow Phantom ABS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8,699 USD
Canada MSRP Price: $ NA Dealer CDN
Europe/UK MSRP Price: £ NA GBP (On The Road inc 20% Vat)

Model Shadow Phantom ABS
(VT750CBS)
Shadow Phantom
(VT750C2B)
ENGINE
Type Transverse-mounted 745cc liquid-cooled 52º V-twin four-stroke
Valve Train SOHC; three valves per cylinder
Bore x Stroke 79.0mm x 76.0mm
Compression Ratio 9.6:1
Induction PGM-FI w/ automatic enrichment, one 34mm throttle body
Ignition Full transistorized
Starter Electric
Transmission 5-speed
Clutch Multiplate wet
Final Drive Shaft
SUSPENSION
Front 41mm telescopic fork; 5.5 in. travel
Rear Dual shocks w/ five-position spring preload adjustability; 3.6 in. travel
BRAKES
Front Single twin-piston hydraulic caliper w/ 296mm disc
Rear Single twin-piston hydraulic caliper w/ 276mm disc
TIRES
Front 120/90-17
Rear 160/80-15
MEASUREMENTS
Rake (Caster Angle) 34°
Trail  161mm (6.3 in.)
Length 93.0 in.
Width 32.6 in.
Height 42.1 in.
Seat Height 25.6 in.
Ground Clearance  5.0 in.
Wheelbase 64.5 in.
Fuel Capacity 3.9 gal.
Curb Weight* 553 lbs. 543 lbs.
OTHER
Color Deep Pearl Gray; Orange Metallic

*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Meets current EPA and CARB emissions standards









2024 Honda Shadow Phantom ABS – Totalmotorcycle.com Canada Specifications/Technical Details

NA





2024 Honda Shadow Phantom ABS – Totalmotorcycle.com Europe Specifications/Technical Details

NA





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
