2024 Triumph Tiger 900 Rally Aragón Edition: MAXIMUM ADVENTURE.
Introducing the 2024 Triumph Tiger 900 Rally Aragón Edition…
Class-leading specification with race-winning performance. The Tiger 900 Rally Aragón Edition exemplifies adventure.
The distinctive and exclusive triple colour scheme is complemented with striking Racing Yellow accents, prominent Tiger branding and unique Aragón Edition details.
Maximum adventure in every ride.
2024 Triumph Tiger 900 Rally Aragón Edition Totalmotorcycle.com Key Features
CLASS-DEFINING CAPABILITY
The Tiger 900 family represents a quantum leap forward in capability, with two ranges opening up a world of urban long-distance touring and extreme off-road riding adventures.
Triumph Tiger 900 Aragon Editions
A QUANTUM LEAP FORWARD IN CAPABILITY, FOR MAXIMUM ADVENTURE IN EVERY RIDE.
NEW TRIUMPH TIGER 900 ARAGÓN EDITIONS LAUNCHED
In July 2022, Iván Cervantes secured victory in the Baja Aragón, one of the most demanding races known to two wheels. One year on, Triumph celebrates this stand-out performance with the launch of the Tiger 900 Rally Aragón and the Tiger 900 GT Aragón. Available in 2023 only, these special editions each feature unique liveries and specification.
Piloting a Tiger 900 Rally Pro, Cervantes dominated the 450km race, crossing the line an impressive 1 hour and 6 minutes ahead of his rivals, demonstrating the Tiger’s ability to endure some of the harshest terrain at an elite level of competition.
Both Tiger 900 Aragón editions deliver all the specification, technology and capability that the market-leading Tiger 900 GT Pro and Rally Pro are known for. Their advanced performance, accompanied by two fresh new looks, preserves the ultimate feel of aggression and attitude, while also adding that race-ready edge.
The Tiger 900 Rally Aragón dons a triple colour of Matt Phantom Black, Matt Graphite and Crystal White, featuring distinct Racing Yellow accents paired seamlessly with Triumph Tiger and Aragón Edition detailing, as well as a new and unique twin colour seat design.
The GT Aragón follows suit with Triumph Tiger and Aragón Edition detailing, in addition to a refreshing twin colour seat design, but instead features a triple colour scheme of Diablo Red, Matt Phantom Black and Crystal White to echo a bold and elegant feel.
Both models continue to boast an impressive 87 Nm of peak torque at 7,250 rpm, as well as a slip and assist clutch, to deliver a rich triple performance. Maintaining a lightweight modular frame and high specification suspension, these new additions to the Tiger family are tailored to optimise both road and off-road potential with the ultimate agile and dynamic handling experience.
Further maximising handling, the GT Aragón Edition carries fully adjustable 45mm USD Marzocchi cartridge forks with electronically adjustable RSU, whereas the Rally Aragón Edition features Showa forks tuned for even greater off-road performance.
Engine protection bars are fitted as standard to both Aragón Editions, while the Rally Aragón Edition also has fuel tank protection bars as standard to top off the ultimate competitive aesthetic. A collection of over 65 dedicated accessory options is available for both models, allowing you to tailor your machine to suit your own adventure.
2024 Triumph Tiger 900 Rally Aragón Edition Totalmotorcycle.com Features and Benefits
In addition to engine protection bars, the Aragón Edition also features fuel tank protection bars to guard against damage and keep the adventure alive.
Tractable and packed with character, the torque-rich 900cc engine with its T-plane triple crank and unique 1,3,2 firing order deliver the ideal throttle response both on and off-road.
A lightweight chassis and class-leading Showa suspension designed exclusively for the Tiger 900 Rally provide assured road handling with incredible off-road capability.
Ride-enhancing technology such as switchable ABS and traction control with off-road- riding modes ensure pure rally bike performance and control with added road comfort and safety.
The distinctive Rally Aragón Edition paint scheme is finished to the very highest standard. Premium quality detailing such as the unique twin colour seat add exclusivity and style.
Over 65 genuine Triumph accessories are available to fully equip your Tiger 900 Rally Aragón Edition for the most challenging adventures or to simply add protection, comfort and style.
2024 Triumph Tiger 900 Rally Aragón Edition – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $16,995 USD
Canada MSRP Price: $17,795 CDN
Europe/UK MSRP Price: £13,995 TBA (On The Road inc 20% Vat)
ENGINE & TRANSMISSION
Feature Details
Type Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Capacity 888 cc
Bore 78
Stroke 61.9
Compression 11.27:1
Max Power EC 93.9 HP (70 kW) @ 8,750 rpm
Max Torque EC 64 LB-FT @ 7,250 rpm
System Multi-point sequential electronic fuel injection
Exhaust Stainless steel 3-into-1 header system, side mounted stainless steel silencer
Final Drive O-ring chain
Clutch Wet, multi-plate
Gearbox 6-speed
CHASSIS
Frame Tubular steel frame, bolt-on subframe
Swingarm Twin-sided, cast aluminum alloy
Front Wheel Spoked Tubeless, 21 x 2.15 in
Rear Wheel Spoked Tubeless, 17 x 4.25 in
Front Tire 90/90-21
Rear Tire 150/70R17
Front Suspension Showa 45 mm upside down forks, manual preload, rebound damping and compression damping adjustment, 9.44 in (240 mm) travel.
Rear Suspension Showa rear suspension unit, manual preload and rebound damping adjustment, 9.05 in (230 mm) wheel travel.
Front Brakes Twin 320 mm floating discs, Brembo Stylema 4-piston Monobloc calipers. Radial front master cylinder, Multi-mode ABS, Optimized Cornering ABS.
Rear Brakes Single 255 mm disc. Brembo single-piston sliding caliper, Multi-mode ABS, Optimized cornering ABS
Instrument Display and Functions 7″ TFT multifunctional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and Riding Modes.
DIMENSIONS & WEIGHTS
Width Handlebars 36.81 in (935 mm)
Height Without Mirror 57.16-59.13 in (1,452-1,502 mm)
Seat Height 33.86-34.65 in (860-880 mm)
Wheelbase 61.06 in (1,551 mm)
Rake 24.4 º
Trail 5.74 in (145.8 mm)
Dry Weight 443 Lbs (201 kg)
Tank Capacity 5.28 US gal (20 L)
FUEL CONSUMPTION
Fuel Consumption 55.4 mpg (5.2 L / 100km)
2024 Triumph Tiger 900 Rally Aragón Edition – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE & TRANSMISSION
Feature Details
Type Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Capacity 888 cc
Bore 78
Stroke 61.9
Compression 11.27:1
Max Power EC 93.9 HP (70 kW) @ 8,750 rpm
Max Torque EC 64 LB-FT @ 7,250 rpm
System Multi-point sequential electronic fuel injection
Exhaust Stainless steel 3-into-1 header system, side mounted stainless steel silencer
Final Drive O-ring chain
Clutch Wet, multi-plate
Gearbox 6-speed
CHASSIS
Frame Tubular steel frame, bolt-on subframe
Swingarm Twin-sided, cast aluminum alloy
Front Wheel Spoked Tubeless, 21 x 2.15 in
Rear Wheel Spoked Tubeless, 17 x 4.25 in
Front Tire 90/90-21
Rear Tire 150/70R17
Front Suspension Showa 45 mm upside down forks, manual preload, rebound damping and compression damping adjustment, 9.44 in (240 mm) travel.
Rear Suspension Showa rear suspension unit, manual preload and rebound damping adjustment, 9.05 in (230 mm) wheel travel.
Front Brakes Twin 320 mm floating discs, Brembo Stylema 4-piston Monobloc calipers. Radial front master cylinder, Multi-mode ABS, Optimized Cornering ABS.
Rear Brakes Single 255 mm disc. Brembo single-piston sliding caliper, Multi-mode ABS, Optimized cornering ABS
Instrument Display and Functions 7″ TFT multifunctional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and Riding Modes.
DIMENSIONS & WEIGHTS
Width Handlebars 36.81 in (935 mm)
Height Without Mirror 57.16-59.13 in (1,452-1,502 mm)
Seat Height 33.86-34.65 in (860-880 mm)
Wheelbase 61.06 in (1,551 mm)
Rake 24.4 º
Trail 5.74 in (145.8 mm)
Dry Weight 443 Lbs (201 kg)
Tank Capacity 5.28 US gal (20 L)
FUEL CONSUMPTION
Fuel Consumption 55.4 mpg (5.2 L / 100km)
SERVICE
Service Interval (10,000 kms)/12 months service interval, whichever comes first
2024 Triumph Tiger 900 Rally Aragón Edition – Totalmotorcycle.com European Specifications/Technical Details
ENGINE & TRANSMISSION
Type Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Capacity 888 cc
Bore 78 mm
Stroke 61.9 mm
Compression 11.27:1
Max Power EC 95.2 PS / 93.9 bhp (70 kW) @ 8,750 rpm
Max Torque EC 87 Nm @ 7,250 rpm
System Multipoint sequential electronic fuel injection
Exhaust Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Final Drive O-ring chain
Clutch Wet, multi-plate
Gearbox 6 speed
CHASSIS
Frame Tubular steel frame, bolt on sub frame
Swingarm Twin-sided, cast aluminium alloy
Front Wheel Spoked Tubeless, 21 x 2.15 in
Rear Wheel Spoked Tubeless, 17 x 4.25 in
Front Tyre 90/90-21
Rear Tyre 150/70R17
Front Suspension Showa 45mm upside down forks, manual preload, rebound damping and compression damping adjustment, 240mm travel
Rear Suspension Showa rear suspension unit, manual preload and rebound damping adjustment, 230mm wheel travel
Front Brakes Twin 320mm floating discs, Brembo Stylema 4 piston Monobloc calipers. Radial front master cylinder, Optimised Cornering ABS
Rear Brakes Brembo single piston sliding caliper.
DIMENSIONS & WEIGHTS
Width Handlebars 935 mm
Height Without Mirror 1452-1502 mm
Seat Height 860-880 mm
Wheelbase 1551 mm
Rake 24.4 º
Trail 145.8 mm
Dry Weight 201 kg
Tank Capacity 20 L
FUEL CONSUMPTION
Fuel Consumption 5.2l/100 km (55.4 MPG)
CO2 Figures EURO 5 Standard: 119 g/km CO2 and fuel consumption are measured according to regulation 168/2013/EC. Figures on fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
SERVICE
Service Interval 6,000 miles (10,000km) /12 months service interval, whichever comes first
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
