2024 Yamaha YZ250F: LEGACY OF DOMINANCE.
Introducing the new 2024 Yamaha YZ250F…
THE LIGHTER, SHARPER, MORE ADVANCED NEW YZ250F
Lighter, sharper handling, with an all-new frame, more compact body and improved smartphone tuneability, the new generation YZ250F is ready to continue a legacy of dominance in the 250 class.
All-New Aluminum Bilateral Beam Frame
A completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lightweight feel and increased front wheel traction, allowing the rider to enter corners with greater confidence and more line choices.
SLIMMER BODY & IMPROVED ERGOS
The new 2024 YZ250F has a slimmer, flatter body design for improved control, including a more narrow fuel tank, lower airbox and more narrow radiator shrouds. The rider triangle is also improved with increased legroom between the seat and footpegs for greater rider comfort.
NEW YAMAHA POWER TUNER APP
Like having factory team support in your pocket, Yamaha’s groundbreaking Power Tuner App is revised to be even more user-friendly. New features include an intuitive “Simple Tuning” slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with helpful engine and suspension tuning guides.
2024 Yamaha YZ250F Totalmotorcycle.com Key Features
- New intake path and revised ECU settings results in more mid- to high-end power.
- Completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of straight-line stability and cornering performance
- Slimmer, flatter body design for improved control, including a more narrow fuel tank, lower airbox and more narrow radiator shroud
- Front fork now includes hand-adjustable knob for toolless compression adjustment
- All-new Traction Control System communicates wheel slip to the ECU, tuning the engine to maintain ideal rear wheel traction
A completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lightweight feel and increased front wheel traction, allowing the rider to enter corners with greater confidence and more line choices.
Optimized intake path draws air from under the side covers and seat allowing for a lighter, slimmer and more compact body. This redesign allows radiator shrouds to be slimmer and the airbox cover to be lower and more narrow. The more efficient intake path also boosts mid- to high-rpm engine performance.
50 years of winning. 50 years of innovation. 50 years of YZ.
Yamaha was born to race. Right from day one Yamaha put competition at the heart of its operations. And 50 years ago, Yamaha launched its first YZ production motocross models – the same year that the company won its first ever Motocross World Championship with Hakan Andersson on a factory YZM250. It was the beginning of a new era for the sport, and over the last half century Yamaha has established itself as one of the most innovative and competitive brands in the 4-stroke and 2-stroke classes.
Yamaha are marking this significant moment in the company’s history with an all new YZ250F that has been created with the immense knowledge gained during half a century of competition in every major GP category.
To commemorate 50 successful years since the first Yamaha YZ models made a lasting impact on the motocross racing world, the 2024 line-up will include exclusive YZ250F, YZ450F, YZ250 and YZ125 50th Anniversary Edition models. Featuring racing white bodywork, purple seats, black wheels and retro-styled purple/pink graphics, these 50th Anniversary Edition bikes offer every Yamaha rider the chance to be a part of this very special occasion.
The 50th Anniversary Edition colouring is inspired by the bold designs used on the YZ250 and YZ125 in the mid-1990s – a period of transition for Yamaha motocross machines which was soon to be followed by the arrival of the first YZ 4-stroke in 1998 and the beginning of a new era of ‘Yamaha Blue’ colours for the company’s Off Road Competition models.
The introduction of the new YZ250F reinforces the range to make the 2024 Yamaha Off Road Competition line-up stronger than ever – with a diverse choice of 4-strokes, 2-strokes, motocross, enduro, youth and kids’ bikes.
2024 Yamaha YZ250F Totalmotorcycle.com Features and Benefits
NEW FOR 2024
All-New Aluminum Bilateral Beam Frame
A completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lightweight feel and increased front wheel traction, allowing the rider to enter corners with greater confidence and more line choices.
Iconic Heritage YZ Styling
Class-leading four-stroke performance wrapped in iconic heritage YZ style, the YZ250F 50th Anniversary Edition draws its inspiration from 1990s-era Yamaha two-stroke motocrossers to honor 50 years of Yamaha off-road innovation.
New Air Intake
Optimized intake path draws air from under the side covers and seat allowing for a lighter, slimmer and more compact body. This redesign allows radiator shrouds to be slimmer and the airbox cover to be lower and more narrow. The more efficient intake path also boosts mid- to high-rpm engine performance.
New Traction Control & Launch Control
The all-new Traction Control System communicates wheel slip to the ECU, tuning the engine to maintain ideal rear wheel traction. Three levels can be selected: HIGH, LOW or OFF. The updated Launch Control System now features an rpm limiter which can be adjusted in 500 rpm increments between 6,000 rpm and 14,000 rpm for optimized launches when the gate drops. Both systems are controlled through the Yamaha Power Tuner App.
New Yamaha Power Tuner App
Like having factory team support in your pocket, Yamaha’s groundbreaking Power Tuner App is revised to be even more user-friendly. New features include an intuitive “Simple Tuning” slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with helpful engine and suspension tuning guides.
Revised Suspension Settings
Class leading, fully adjustable KYB® coil spring-type fork with speed-sensitive damping delivers exceptional balance between handling and bump absorption for championship-winning performance. New for 2024, the fork now includes hand-adjustable knob for toolless compression adjustment. Linkage-type rear suspension features a KYB® shock with revised settings to provide less pitch on corner entry/exit for improved stability.
Slimmer Body & Improved Ergos
The new 2024 YZ250F has a slimmer, flatter body design for improved control, including a more narrow fuel tank, lower airbox and more narrow radiator shrouds. The rider triangle is also improved with increased legroom between the seat and footpegs for greater rider comfort.
TOP FEATURES
Advanced 250cc Four-Stroke Engine
Featuring a high-spec piston, aggressive cam profiles and forward positioned intake cylinder head layout, the YZ250F’s advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque. New for 2024, a more efficient intake path and revised ECU settings results in even more mid- to high-end power.
All-New Aluminum Bilateral Beam Frame
A completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of straight-line stability and cornering performance. The result is a better handling machine with lighter feel, more agility and increased traction, allowing the rider to charge corners with greater confidence.
Class-Leading Suspension
Fully adjustable KYB® coil spring-type fork with speed-sensitive damping delivers exceptional balance between handling and bump absorption for championship-winning performance. New for 2024, the fork now includes hand-adjustable knob for toolless compression adjustment. Linkage-type rear suspension features a KYB® shock with revised settings to provide less pitch on corner entry/exit and improved stability.
High Performance Braking System
A large 270mm front brake disc and 240mm rear are coupled with a Nissin calipers to provide exceptional stopping power and control.
Innovative Yamaha Power Tuner App
Yamaha’s industry-leading Power Tuner App puts the flexibility and precision tunability of the GYTR® Power Tuner into your smartphone. Make fueling and ignition timing changes on the app, then instantly upload them to your bike for ultimate track-side tuning. Now even more user-friendly, new features include an intuitive “Simple Tuning” slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with helpful engine and suspension tuning guides. Best of all, it’s free-of-charge.
Slimmer Body & Improved Ergos
The new 2024 YZ250F has a slimmer, flatter body design for improved control, including a more narrow fuel tank, lower airbox and more narrow radiator shrouds. The rider triangle is also improved with increased legroom between the seat and footpegs for greater rider comfort.
ADDITIONAL FEATURES
Sharp, Durable 50th Anniversary Graphics
Iconic 1990s-era livery highlights the Yamaha YZ’s unmatched heritage and racing pedigree. Premium 50th Anniversary graphics are embedded to provide excellent durability and scratch resistance.
Simplified Servicing
Sleek air cleaner cover provides tool-free access to the air filter, positioned at the front of the bike to avoid roost from the rear wheel.
Top-Spec Details
The YZ250F boasts top-spec details including 1-1/8-inch aluminum tapered handlebars secured to four-position adjustable handlebar mounts, wide 55mm footpegs and a quick-adjust clutch perch.
CHASSIS/SUSPENSION
All-New Aluminum Bilateral Beam Frame
A completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lightweight feel and increased front wheel traction, allowing the rider to enter corners with greater confidence and more line choices.
Class-Leading Suspension
Fully adjustable KYB® coil spring-type fork with speed-sensitive damping delivers exceptional balance between handling and bump absorption for championship-winning performance. New for 2024, the fork now includes hand-adjustable knob for toolless compression adjustment. Linkage-type rear suspension features a KYB® shock with revised settings to provide less pitch on corner entry/exit and improved stability.
Compact Body & Seat Design
Adopting the aggressive body design of the flagship YZ450F, the new 2024 YZ250F is slimmer and flatter, easing rider movement for improved control. A more narrow fuel tank, lower airbox and more narrow radiator shrouds provide a compact rider cockpit. The rider triangle is also improved with increased legroom between the seat and footpegs for greater comfort.
Enhanced Mass-Centralization
The compact engine, wraparound exhaust and fuel tank are strategically positioned to enhance mass centralization for a lightweight handling feeling on the track. The wide 55mm footpegs provide added control and comfort.
High Performance Braking System
A large 270mm front brake disc and 240mm rear are coupled with a Nissin calipers to provide exceptional stopping power and control.
Strong, Lightweight Wheels
Careful computer-aided refinement of each wheel’s cross-sectional profile shaves valuable weight without sacrificing durability. Unique three-cross-spoke pattern on the rear wheel improves impact absorption and overall feel.
ENGINE
Adjustable Engine Maps
New handlebar-mounted switch allows on-the-fly selection between two preloaded engine maps with the push of a button, making it easy to make immediate adjustments to changing track or weather conditions. Maps are loaded and configured within the Power Tuner App.
Advanced 250cc Four-Stroke Engine
The YZ250F’s liquid-cooled, DOHC 4-valve, fuel-injected powerplant features a forward-positioned straight downdraft intake with symmetrical intake ports, high-spec piston and aggressive cam profiles. The advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque. New for 2024, a more efficient intake path and revised ECU settings results in even more mid- to high-end power.
Advanced Fuel Injection
The adjustable fuel injection system uses a 44mm throttle body, fed by a high-pressure electric fuel pump, to inject fuel through a 12-hole Denso® injector. This ensures optimum fuel atomization and air/fuel calibration for excellent rideability in a wide range of riding conditions.
Durable Clutch
The YZ250F features a large-diameter 15 plate clutch to withstand the high demands of motocross racing.
Innovative New Yamaha Power Tuner App
The free-of-charge Yamaha Power Tuner App brings the power of the GYTR® Power Tuner to your iOS® or Android® device. Using wireless connectivity to talk to the bike’s onboard electronics system, the app allows owners to adjust air/fuel mixture and ignition timing to tune engine character for track conditions, log track set-up information, and monitor a range of data such as maintenance and system diagnosis, engine run time and more. For the 2024 YZ250F, the app has been revised to be more user-friendly. New features include an intuitive “Simple Tuning” slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with helpful engine and suspension tuning guides.
New Air Intake
A new, optimized intake path draws air from under the side covers and seat more efficiently, resulting in a boost in mid- to high-rpm performance and improved over-rev characteristics. The redesign also allows radiator shrouds to be slimmer and the airbox cover to be lower and more narrow.
Piston, Rod & Crankshaft Balance
A forged piston features a bridge-box design for maximized strength with minimal weight. The piston, rings and DLC-coated piston pin, along with the offset cylinder configuration, all reduce friction loss. Intake ports, cam profiles, high-strength connecting rod, optimized crank and counter-balancer all work together to produce potent high-rpm power with user-friendly delivery and exceptional reliability. New for 2024, a redesigned cam chain improves durability.
Wraparound Rear-Positioned Exhaust Layout
An innovative exhaust pipe design improves mass centralization and power characteristics. This layout moves the rear end of the exhaust pipe farther forward and positions the muffler closer to the bike’s center of mass.
*Manufacturer’s Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
**Fuel Economy is estimated.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
New bilateral aluminium frame With a lower head pipe and new tank rails the YZ250F lightweight bilateral aluminium frame gives improved handling faster and smoother cornering. The lower centre of gravity and reduced weight make the YZ250F 50th Anniversary Edition more agile than ever – and the revised balance of rigidity and YZ250F-speci c engine mounts give plenty of feel and feedback.
Optimized rider ergonomics The revised rider triangle accommodates riders of varying sizes and physiques. The shrouds are 50mm narrower, the atter seat is 5mm higher and the footrests are 5mm lower, providing better ergonomics with enhanced controllability. The new side panels give a tighter and lighter look – and the new smaller front fender improves air ow to the radiators for consistent cooling.
Increased top-end power
The YZ250F is already regarded as one of the most competitive and responsive 250cc 4-stroke engines in the low to midrpm range. The YZ250F benefits from the new rear duct air-management system together with a reprogrammed ECU that boost top-end engine performance, making this Motocross Grand Prix race winning machine even more competitive for every rider.
Efficient air-management
The new rear duct air ow system channels fresh air through the spaces between the fuel tank, frame, seat and side panels – resulting in increased top-end engine performance and narrower body width. When air reaches the lightweight airbox it is pre-cleaned by a vortex that throws particles to the side, reducing air cleaner clogging and making routine maintenance easier.
Revised suspension settings
The YZ250F KYB front forks are widely regarded as being amongst the best in class, and the new generation bike features revised settings as well as a new hand-adjustable compression damping adjuster. The link-type Monocross rear suspension and KYB shock also runs revised settings for high levels of traction and control – and the renewed Power Tuner App contains useful suspension setting data for quick and accurate manual adjustments
2024 Yamaha YZ250F – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8,899 USD
Canada MSRP Price: $10,799 CDN
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)
ENGINE
| ENGINE | 4-stroke, liquid-cooled, DOHC, 4-valve (titanium), single |
| DISPLACEMENT | 250 cc |
| BORE AND STROKE | 77 x 53.6 mm |
| COMPRESSION RATIO | 13.8:1 |
| FUEL DELIVERY | 44 mm Mikuni throttle body F.I. |
| LUBRICATION | Wet sump |
| IGNITION / STARTING | TCI |
| TRANSMISSION | Constant-mesh 5-speed |
| FINAL DRIVE | Chain |
CHASSIS
| SUSPENSION (FRONT) | Fully adj. 48mm KYB SSS inverted fork / 310 mm (12.2 in) wheel travel |
| SUSPENSION (REAR) | Fully adj. KYB monoshock / 317 mm (12.5 in) wheel travel |
| BRAKES (FRONT) | 270 mm, floating hydraulic wave disc / twin-piston caliper |
| BRAKES (REAR) | 240 mm hydraulic wave disc / single piston caliper |
| TIRES (FRONT) | 80/100-21 Dunlop® Geomax MX33F |
| TIRES (REAR) | 110/90-19 Dunlop® Geomax MX33 |
CRITICAL DATA
| LENGTH | 2,179 mm (85.8 in) |
| WIDTH | 825 mm (32.5 in) |
| HEIGHT | 1,275 mm (50.2 in) |
| WHEELBASE | 1,475 mm (58.1 in) |
| GROUND CLEARANCE | 351 mm (13.8″) |
| SEAT HEIGHT | 970 mm (38.2″) |
| FUEL CAPACITY | 6 litres (1.3 imp. gal.) |
| WET WEIGHT | 104 kg (231 lb) |
| COLOUR(S) | Team Yamaha Blue, Anniversary White |
2024 Yamaha YZ250F – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
| ENGINE | 4-stroke, liquid-cooled, DOHC, 4-valve (titanium), single |
| DISPLACEMENT | 250 cc |
| BORE AND STROKE | 77 x 53.6 mm |
| COMPRESSION RATIO | 13.8:1 |
| FUEL DELIVERY | 44 mm Mikuni throttle body F.I. |
| LUBRICATION | Wet sump |
| IGNITION / STARTING | TCI |
| TRANSMISSION | Constant-mesh 5-speed |
| FINAL DRIVE | Chain |
CHASSIS
| SUSPENSION (FRONT) | Fully adj. 48mm KYB SSS inverted fork / 310 mm (12.2 in) wheel travel |
| SUSPENSION (REAR) | Fully adj. KYB monoshock / 317 mm (12.5 in) wheel travel |
| BRAKES (FRONT) | 270 mm, floating hydraulic wave disc / twin-piston caliper |
| BRAKES (REAR) | 240 mm hydraulic wave disc / single piston caliper |
| TIRES (FRONT) | 80/100-21 Dunlop® Geomax MX33F |
| TIRES (REAR) | 110/90-19 Dunlop® Geomax MX33 |
CRITICAL DATA
| LENGTH | 2,179 mm (85.8 in) |
| WIDTH | 825 mm (32.5 in) |
| HEIGHT | 1,275 mm (50.2 in) |
| WHEELBASE | 1,475 mm (58.1 in) |
| GROUND CLEARANCE | 351 mm (13.8″) |
| SEAT HEIGHT | 970 mm (38.2″) |
| FUEL CAPACITY | 6 litres (1.3 imp. gal.) |
| WET WEIGHT | 104 kg (231 lb) |
| COLOUR(S) | Team Yamaha Blue, Anniversary White |
2024 Yamaha YZ250F – Totalmotorcycle.com European Specifications/Technical Details
Engine
Engine type 4-stroke, Liquid-cooled, DOHC, 4-valves, Single cylinder
Displacement 250cc
Bore x stroke 77,0 x 53,6 mm
Compression ratio 13,8:1
Lubrication system Wet sump
Clutch type Wet, Multiple Disc
Ignition system TCI
Starter system Electric
Transmission system Constant Mesh, 5-speed
Final transmission Chain
Fuel system Fuel Injection
Chassis
Frame Semi double cradle
Caster angle 26°55
Trail 119 mm
Front suspension system Upside-down telescopic fork
Rear suspension system link suspension, Swingarm
Front travel 310 mm
Rear travel 313 mm
Front brake Hydraulic Single Disc, Ø270 mm
Rear brake Hydraulic Single Disc, Ø240 mm
Front tyre 80/100-21 51M Tube type
Rear tyre 110/90-19 62M Tube type
Dimensions
Overall length 2.180 mm
Overall width 825 mm
Overall height 1.275 mm
Seat height 970 mm
Wheel base 1.475 mm
Minimum ground clearance 350 mm
Wet weight (including full oil and fuel tank) 105 kg
Fuel tank capacity 6,2 L
Oil tank capacity 0,95 L
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
