2010 Victory Cory Ness Jackpot

Back to 2010 Victory Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2010 Victory Cory Ness Jackpot
2010 Victory Cory Ness Jackpot

2010 Victory Cory Ness Jackpot
2010 Victory Cory Ness Jackpot

2010 Victory Cory Ness Jackpot
2010 Victory Cory Ness Jackpot

2010 Victory Cory Ness Jackpot
2010 Victory Cory Ness Jackpot

– 2010 Victory Cory Ness Jackpot

2010 Victory Cory Ness Jackpot

Custom motorcycle builder Cory Ness, with the help of his father the legendary Arlen Ness, has done it again in designing the breathtaking 2010 Cory Ness Signature Victory Jackpot® Motorcycle. This limited-edition masterpiece comes complete with Ness custom-designed paint, a powerful 106-cubic-inch Freedom® V-Twin Engine with diamond-cut heads, Ness Signature chrome, hand-stitched leather seats, and so much more.

For smooth, powerful, eye-catching cruising on Main Street or cruising across state lines, the Cory Ness Signature Victory Jackpot® provides the ultimate experience. Find out more about its features, specifications, pricing, comparisons, reviews, videos, images, brochures, downloads, and locate your nearest dealer that has the Cory Ness Signature Victory Jackpot® Motorcycle.







Features/Benefits

Billet Engine Covers

The premium-quality billet engine covers complement hte bike’s overall custom treatment and feature distinctive Ness styling.


Diamond-Cut Cylinder Heads

The epitome of customizing, these precision dismond-cut cylinders help this Ness model stand out from the crowd. It’s a premium styling touch from a custom master, Cory Ness.


Numbered Badges

Each limited-edition bike has a metal plate with the bike’s number, the Arlen Ness logo and a facsimile of Arlen Ness’s autograph.


Custom-Stitched Seats

Arlen likes his bikes long and low, so he has developed a seat that is lower than the stock Victory Vision seat. It’s a custom, stitched seat that enhances the bike’s flowing lines.


Chrome Ness Grips

The custom treatment extends to the tips of the handlebars with Ness custom grips. They complement the bike’s overall custom treatment and feature Nexx styling.


Custom Ness Paint and Graphics

Arlen Ness designed the stunning custom paint for his Signature Series Victory Vision, and the paint is framed and highlighted by the many blacked-out components on the bike.

Ness Billet Wheels

The bike rolls on contract-cut Ness “Evil 7” billet wheels with machined highlights. The rear pulley features the “Evil 7” design as well.


Ness Footpegs

Even the lower controls get the Ness custom treatment. The bright finish of these pegs complements the bike’s rich chrome treatment.


Chrome Ness Mirrors

Ness custom chrome missors add style to the high-profile handlebar area and complement the bike’s rich chrome treatment








2010 Victory Cory Ness Jackpot – Specifications
MSRP: US See Dealer for Pricing and Availability
MSRP: US-CA See Dealer for Pricing and Availability
MSRP: CAN See Dealer for Pricing and Availability


Engine Type 4-stroke 50° V-Twin
Cooling Type Air / Oil
Displacement 106 ci / 1,731 cc
Bore x Stroke 101 x 108 mm
Compression Ratio 9.4:1
Valve Train Single overhead camshafts with 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Fuel Capacity 4.5 gal / 17.0 ltr
Exhaust Staggered slash-cut dual exhaust with crossover
Oil Capacity 5.0 qts / 4.75 ltr
Charging System 38 amps max output
Battery 12 volts / 18 amp hours
Primary Drive Gear drive with torque compensator
Clutch Wet, multi-plate
Transmission 6-speed overdrive constant mesh
Final Drive Carbon Fiber Reinforced Belt

Length 95.9 in / 2,435 mm
Wheelbase 66.3 in / 1,684 mm
Seat Height 25.7 in / 653 mm
Ground Clearance 5.3 in / 135 mm
Rake/Trail 32.9° / 4.9 in / 125 mm
Dry Weight 652 lbs (296 kg)
GVWR 1,171 lbs. / 532 kg

Front Suspension Conventional telescopic fork, 43 mm diameter, 5.1 in/130 mm travel
Rear Suspension Single, mono-tube gas, cast aluminum with rising-rate linkage, 3.0 in/76 mm travel, preload adjustable spring

Front Brake 300mm floating rotor with 4-piston caliper
Rear Brake 300mm floating rotor with 2-piston caliper

Front Wheel 21 x 2.15 in
Rear Wheel 18 x 8.5 in
Front Tire 90/90 21 Dunlop Elite 3
Rear Tire 250/40R18 Dunlop Elite 3

Solid Colors Ness Custom
Multiple Colors

MSRP: US See Dealer for Pricing and Availability
MSRP: US-CA See Dealer for Pricing and Availability
MSRP: CAN See Dealer for Pricing and Availability

* Price shown is the manufacturer’s suggested retail price (MSRP) and is subject to change. MSRP excludes applicable taxes, title, registration, license, and documentary, installation, setup and destination fees. See a Polaris dealer for specific pricing information.
