2009 Can-Am Youth 90
2009 Can-Am Youth 90
2009 Can-Am Youth 90
– 2009 Can-Am Youth 90
2009 Can-Am Youth 90
AS GOOD AS THEY ARE, THE SPECS AND STATS ARE JUST THE BEGINNING.
The Can-Am DS 90™ youth ATV delivers all the safety features you demand for your children, without compromising their fun. Your kids will love not having to shift gears or get off the vehicle to go into reverse, thanks to the CVT transmission with Forward/Neutral/Reverse. They’ll also appreciate the smooth ride and better control in the bumps from the long travel suspension. Best of all, so will you.
Key Features:
Standard package key features:
89.5cc 4-stroke engine (CARB “Green Label” certified)
Fully automatic Continuously Variable
Transmission (CVT) with F/N/R
Long travel suspension
Built-in throttle limiter
Key-operated ignition switch
Electric start with a backup kick-start
Full floorboards
0.7 US gal. (2.7 l) storage compartment
DS 90 FEATURES
89.5cc 4-stroke engine CVT Transmission Long travel suspension Built-in throttle limiter Key-operated ignition switch Electric start with a backup kick-start Full floorboards Day lights 0.7 US gal. (2.7 L) storage compartment Available Colors: Yellow
DS90X has all the standard DS 90 features except the headlights, PLUS:
Double A-arm with HPG piggyback shocks
Rear HPG piggyback shock
Black aluminum rims
Manufacturer Suggested Retail Price (MSRP): $3,949 CAD/$3,349 USD
2009 Can-Am Youth 90 – Specifications
American MSRP $2,499 USD
Canadian MSRP $2,999 CDN
Engine
Type : 89.5cc, single, air-cooled, SOHC, 2-valve
Bore & Stroke : 49.5 x 48 mm
EFI System/Carburetor : Carburetion, Keihin
Starting System : Electric & kick start
Transmission : Automatic CVT, Forward, Neutral & Reverse
Drive Train : Chain driven / solid axle
Chassis
Frame : DS 90
Front Suspension Type : Independent A-arm
Travel : 3.4 in (86 mm)
Rear Suspension Type : Swingarm
Travel : 6.3 in (160 mm)
Front Brake : Double drum
Rear Brake : Drum
Tires/Front : 19 x 7 x 8 in. 483 x 178 x 203 mm
Tires/Rear : 457 x 241 x 203 in. 18 x 9,5 x 8 mm
Wheels : Steel
Dimensions
L x W x H (in) : 59.8 x 35.5 x 36.8 in
L x W x H (mm) : 1.525 x 0.89 x 0.939 mm
Wheelbase : 39 in (1 mm)
Seat Height : 27 in (685 mm)
Ground Clearance : 8.3 in (211 mm)
Dry Weight : 245 lbs (111 kg)
Storage : Front storage 0.7 US gal. (2.7L)
Fuel Capacity : 1.6 US gal. (6 L)
Features
Instrumentation : Reverse, neutral
Anti-Theft : N/A
Electrical : N/A
Lighting : Day lights
DC Outlet : N/A
Color(s) available : Yellow
