2012 Polaris Ranger Diesel
Back to 2012 Polaris ATV Quad Models Index Page
Click photos to enlarge. They make great desktop wallpaper.
2012 Polaris Ranger Diesel
2012 Polaris Ranger Diesel
2012 Polaris Ranger Diesel
– 2012 Polaris Ranger Diesel
2012 Polaris Ranger Diesel Review
RANGER® DIESEL – Diesel Power
The 2012 RANGER® DIESEL has all the Xtreme Performance features of the RANGER XP, and is perfect for those who need diesel power. It features an isolation-mounted, fuel-efficient 24 HP YANMAR® diesel engine.
2012 Polaris Ranger Diesel Highlights
– 40% more range than comparable gas model.
– NEW! Improved dash/seat sealing for increased cab comfort.
– 90% of peak torque is available at 1600 RPM for incredible low-speed pulling.
– On-Demand True AWD maximizes traction.
– 55-amp Alternator to Run Many Hard-Working Electrical Accessories
– 90% of Peak Torque Available at 1,600 RPM for Low-Speed Pulling
– 40% More Fuel Range Than Comparable Gas Model (RANGER XP)*
– Powerful Headlight Beams With High/Low Switch Operation (60/55 W)
– Driver and Passenger Side Nets
– Certified Roll-Over Protective Structure (ROPS).
2012 Polaris Ranger Diesel Features
ON-DEMAND TRUE ALL WHEEL DRIVE WITH VERSATRAC TURF MODE
True AWD keeps you moving, automatically engaging all four wheels when you need more forward traction and reverting back to 2WD when you don’t. When in 2WD, the VersaTrac Turf Mode switch unlocks the rear differential for easier, tighter turns that won’t tear up your grass.
FUEL EFFICIENT DIESEL POWER
All of the features of RANGER XP, but with an isolation-mounted, fuel efficient YANMAR® diesel power plant for low vibration and lower-speed torque. Plus a fully sealed transmission and plenty of horsepower to get the job done.
MONSTROUS 1-TON TOWING
The strength to tow 2,000 lbs., far more than the competition, means you can tackle the toughest jobs with confidence. Features a standard 2″ hitch receiver.
LARGE DUMP BOX WITH LOCK & RIDE CARGO SYSTEM*
Pallet-size rear dump box has gas-assist dumping operation and features exclusive Lock & Ride cargo system that accommodates many hard-working accessories that go on and off in seconds.
SUPERIOR ERGONOMICS
Cab ergonomics deliver outstanding driver and passenger comfort, including tilt steering with the highest range of motion (10″), extra legroom, and easy cab slide-through design for three adults to get in and out quickly.
INDEPENDENT REAR SUSPENSION (IRS) AND HIGH GROUND CLEARANCE
In rough terrain, our legendary smooth IRS and a full 12″ of ground clearance combine to keep the ride smooth for you and your passengers, as well as your gear and equipment.
FULLY ADJUSTABLE SUSPENSION
The only 4-corner adjustable suspension system. Dual A-Arm with exclusive top mounting-point adjustability. Adjust to softer setting for trail riding or stiffer for heavy-duty work. Front: 9.6″ suspension travel. Rear: 9″ suspension travel.
2012 Polaris Ranger Diesel – USA Specifications
US MSRP: $12,999 USD
ENGINES
Engine Type 3-Cylinder Diesel
Displacement 904cc – 24hp
Fuel System Indirect Injection
Cooling Liquid
DRIVETRAIN
Transmission/Final Drive Automatic PVT H/L/N/R; Shaft
Drive System On-Demand True AWD/2WD/ VersaTrac Turf Mode
Engine Braking System/ Active Descent Control Not Equipped
SUSPENSION
Front Suspension Dual A-Arm 9.6″ (24.4 cm) Travel
Rear Suspension Dual A-Arm, IRS 9″ (22.9 cm) Travel
BRAKES
Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake Hand-Actuated
TIRES/WHEELS
Front Tires / Model 25 x 10-12; 489
Rear Tires / Model 25 x 11-12; 489
Wheels Stamped Steel
DIMENSIONS
Wheelbase 76″ (193 cm)
Dry Weight 1,435 lb (652 kg)
Overall Vehicle Size (LxWxH) 114 x 60 x 76″ (290 x 152 x 193 cm)
Ground Clearance 12″ (30.5 cm)
CAPACITIES
Fuel Capacity 9 gal (34.1 L)
Bed Box Dimensions (LxWxH) 36.5 x 54 x 11.5″ (93 x 137 x 29 cm)
Box Capacity N.A./1,000 lb (453.6 kg)
Payload Capacity 1,500 lb (680.4 kg)
Hitch Towing Rating 2,000 lb (907.2 kg)
Hitch/Type Standard/2″ Receiver
FEATURES
Cargo System Lock & Ride
Lighting 55W low/ 60W high, LED Tail
Electronic Power Steering Not Equipped
Instrumentation Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Gear Indicator, Fuel Gauge, Hi-Temp, DC Outlets (2)
2012 Polaris Ranger Diesel – Canadian Specifications
Canadian MSRP: $14,799 CDN
ENGINES
Engine Type 3-Cylinder Diesel
Displacement 904cc – 24hp
Fuel System Indirect Injection
Cooling Liquid
DRIVETRAIN
Transmission/Final Drive Automatic PVT H/L/N/R; Shaft
Drive System On-Demand True AWD/2WD/ VersaTrac Turf Mode
Engine Braking System/ Active Descent Control Not Equipped
SUSPENSION
Front Suspension Dual A-Arm 9.6″ (24.4 cm) Travel
Rear Suspension Dual A-Arm, IRS 9″ (22.9 cm) Travel
BRAKES
Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake Hand-Actuated
TIRES/WHEELS
Front Tires / Model 25 x 10-12; 489
Rear Tires / Model 25 x 11-12; 489
Wheels Stamped Steel
DIMENSIONS
Wheelbase 76″ (193 cm)
Dry Weight 1,435 lb (652 kg)
Overall Vehicle Size (LxWxH) 114 x 60 x 76″ (290 x 152 x 193 cm)
Ground Clearance 12″ (30.5 cm)
CAPACITIES
Fuel Capacity 9 gal (34.1 L)
Bed Box Dimensions (LxWxH) 36.5 x 54 x 11.5″ (93 x 137 x 29 cm)
Box Capacity N.A./1,000 lb (453.6 kg)
Payload Capacity 1,500 lb (680.4 kg)
Hitch Towing Rating 2,000 lb (907.2 kg)
Hitch/Type Standard/2″ Receiver
FEATURES
Cargo System Lock & Ride
Lighting 55W low/ 60W high, LED Tail
Electronic Power Steering Not Equipped
Instrumentation Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Gear Indicator, Fuel Gauge, Hi-Temp, DC Outlets (2)
