2013 Triumph Tiger Explorer

Back to 2013 Triumph Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2013 Triumph Tiger Explorer
2013 Triumph Tiger Explorer

2013 Triumph Tiger Explorer
2013 Triumph Tiger Explorer

2013 Triumph Tiger Explorer
2013 Triumph Tiger Explorer

2013 Triumph Tiger Explorer
2013 Triumph Tiger Explorer

2013 Triumph Tiger Explorer
2013 Triumph Tiger Explorer

2013 Triumph Tiger Explorer
2013 Triumph Tiger Explorer



2013 Triumph Tiger Explorer Review

2013 Triumph Tiger Explorer

Tiger Explorer. All-new bike. All-new excitement.

The ultimate choice for the long haul adventurer. Class-leading handling. The journey doesn’t have to end when the Tarmac does. Brand new, 1215cc engine, with shaft drive of course. A Triumph to take on the world.





2013 Triumph Tiger Explorer Features and Benefits

The Tiger Explorer brings a whole new level of performance and specification to the adventure touring sector.

The thoroughly modern powerplant utilises a new ride-by-wire electronic throttle system, allowing Triumph engineers to endow the Tiger Explorer with a number of high-tech rider aids for added rider safety and comfort. Cruise control, traction control and ABS are all standard fitment on the Tiger Explorer. A tough shaft drive system has been developed for the Tiger Explorer, allowing virtually maintenance free touring, and the latest Triumph has been designed to go 10,000 miles between servicing – ideal for those long distance adventures.

Triumph’s reputation for delivering best-in-class handling continues with the Tiger Explorer, which offers a combination of excellent low-speed balance and composed high speed capability. The strong tubular steel trellis frame bears a strong visual resemblance to other models in the Triumph family, while the single-sided rear swingarm showcases the 17” 10-spoke rear wheel. Adjustable 46mm front forks allow the rider to tailor the Tiger Explorer to their individual needs and riding conditions, with the long-travel suspension and 19” front wheel giving the Tiger Explorer the capability to cope with unpaved roads.

All-new instrumentation and switchgear is both comprehensive and intuitive. The LCD instrument pack is thumb operated via switches on the handlebars and features a comprehensive onboard computer, including an ambient air temperature indicator with ice warning. The instrumentation also comes pre-configured for Triumph’s tyre pressure monitoring system, available as an optional accessory.

A comprehensive range of accessories is headlined by high quality luggage developed especially for the Tiger Explorer. The two-box pannier system provides 60 litres of luggage space, while the top box offers a further 35 litres of capacity, enough for a full-face helmet.








2013 Triumph Tiger Explorer Key Features

Engine

Powered by an all-new 1215cc three-cylinder engine producing a class-leading 137Ps with 121Nm of torque for effortless overtaking combined with an exciting top end growl, the Tiger Explorer sports a high-specification that will see it set a new benchmark in the adventure touring class.


Rider aids

Electronic cruise control, traction control and switchable ABS brakes give Explorer riders peace of mind, and come as standard equipment.


Chassis

Tough steel chassis and adjustable sturdy 46mm forks have been designed to cope with the worst that the conditions can throw at it, while 19” front wheel offers excellent on road agility and handling characteristics.


Ergonomics

Designed to offer maximum comfort for rider and pillion, the Tiger Explorer comes with adjustable rider seat height, handlebar position and screen for day long comfort in the saddle.


High-capacity generator

Class leading 950w generator allows the simultaneous running of multiple electrical accessories, including heated rider and pillion seats, heated grips, high power fog lights and a top box with integrated power supply for charging on the move. The bike also comes fitted with a power socket situated close to the ignition, which can be used to power a GPS unit or items of heated clothing.


Comprehensive instrumentation

Handlebar operated instrument pack is Triumph’s most comprehensive yet. In addition to the large digital speed readout and analogue tachometer, the on-board computer displays a host of practical information including gear indicator, fuel consumption and an ambient air temperature indicator.


Shaft drive

Low maintenance drive shaft for hassle free long distance touring.







2013 Triumph Tiger Explorer – USA Specifications/Technical Details
US MSRP Price: $15,699

Engine and Transmission

Type Liquid-cooled, 12 valve, DOHC, in-line three-cylinder
Capacity 1215cc
Bore/Stroke 85 x 71.4mm
Fuel System Ride by wire, fuel injection
Exhaust Stainless steel 3 into 1 , side mounted stainless steel silencer
Final Drive Shaft
Clutch Wet, multi-plate
Gearbox 6-speed
Oil Capacity 4.0 liters (1.1 US gals)

Chassis, Running Gear and Displays

Frame Tubular steel trellis frame
Swingarm Single-sided, cast aluminium alloy with shaft drive
Wheel Front Cast aluminium alloy 10-spoke 19 x 2.5in
Rear Cast aluminium alloy 10-spoke 17 x 4.0in
Tire Front 110/80 R 19
Rear 150/70 R 17
Suspension Front
KYB 46mm upside down forks, adjustable preload, 190mm travel

Rear
KYB monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment, 194mm rear wheel travel

Brakes Front
“Twin 305mm floating discs, Nissin 4-piston calipers, Switchable ABS

Rear
Single 282mm disc, Nissin 2-piston sliding caliper, Switchable ABS

Instrument Display/Functions
LCD instrument pack with digital speedometer, analogue tachometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, air temperature, frost warning, hazard warning lights, trip computer, Tyre pressure monitoring system

Dimensions and Capacities

Length 2248mm/88.4in
Width (handlebars) 962mm (37.9in)
Height without mirrors 1410mm/55.5in
Seat Height 837mm (32.9in) – 857mm (33.7in)
Wheelbase 1530mm/60.2in
Rake/Trail 23.9 degree/105.5mm
Fuel Tank Capacity / Efficiency 20 litres/5.3 US gals
Wet Weight (ready to ride) 259kg/570lbs

Performance (measured at crankshaft to 95/1/EC)

Maximum Power 137PS/135bhp/101kW @ 9300rpm
Maximum Torque 121Nm/89 ft.lbs @ 6400rpm
Fuel Efficiency 38 City / 57 Highway *Estimated from fuel economy tests on a sample motorcycle conducted under ideal laboratory conditions. Actual mileage may vary based upon personal riding habits, weather, vehicle condition, and other factors.

Price

MSRP $15,699* Price is MSRP, and excludes tax, title, license, options, handling, pre-delivery, and destination charges. Specifications and MSRP are subject to change without notice. Actual price determined by dealer.


Specifications and MSRP are subject to change without notice. Actual price determined by dealer.








2013 Triumph Tiger Explorer – Canadian Specifications/Technical Details
Canada MSRP Price: On The Road $17,499


Engine and Transmission

Type Liquid-cooled, 12 valve, DOHC, in-line three-cylinder
Capacity 1215cc
Bore/Stroke 85 x 71.4mm
Fuel System Drive by wire, fuel injection
Exhaust Stainless steel 3 into 1 , side mounted stainless steel silencer
Final Drive Shaft
Clutch Wet, multi-plate
Gearbox 6-speed
Oil Capacity 4.0 litres (1.1 US gals)

Chassis, Running Gear and Displays

Frame Tubular steel trellis frame
Swingarm Single-sided, cast aluminium alloy with shaft drive
Wheel Front Cast aluminium alloy 10-spoke 19 x 2.5in
Rear Cast aluminium alloy 10-spoke 17 x 4.0in
Tyre Front 110/80 R 19
Rear 150/70 R 17
Suspension Front
KYB 46mm upside down forks, 190mm travel

Rear
KYB monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment, 194mm rear wheel travel

Brakes Front
“Twin 305mm floating discs, Nissin 4-piston calipers, Switchable ABS

Rear
Single 282mm disc, Nissin 2-piston sliding caliper, Switchable ABS

Instrument Display/Functions
LCD instrument pack with digital speedometer, analogue tachometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, air temperature, frost warning, hazard warning lights, trip computer, Tyre pressure monitoring system

Dimensions and Capacities

Length 2248mm/88.4in
Width (handlebars) 885mm (34.8in)
Height without mirrors 1410mm/55.5in
Seat Height 837mm (32.9in) – 857mm (33.7in)
Wheelbase 1530mm/60.2in
Rake/Trail 23.9 degree/105.5mm
Fuel Tank Capacity 20 litres/5.3 US gals
Wet Weight (ready to ride) 259kg/570lbs

Performance (measured at crankshaft to 95/1/EC)

Maximum Power 137PS/135bhp/101kW @ 9300rpm
Maximum Torque 121Nm/89 ft.lbs @ 6400rpm
Fuel Efficiency 38 City / 57 Highway *Estimated from fuel economy tests on a sample motorcycle conducted under ideal laboratory conditions. Actual mileage may vary based upon personal riding habits, weather, vehicle condition, and other factors.

Price

On The Road $17,499 *Price is MSRP, and excludes tax, title, license, options, handling, pre-delivery, and destination charges. Specifications and MSRP are subject to change without notice. Actual price determined by dealer.




2013 Triumph Tiger Explorer – Europe/UK Specifications/Technical Details
European MSRP Price: See Dealer
UK RRP: On The Road £11,199 (Factory fitted spoked wheel option £11,499)

Engine and Transmission

Type Liquid-cooled, 12 valve, DOHC, in-line three-cylinder
Capacity 1215cc
Bore/Stroke 85 x 71.4mm
Fuel System Drive by wire, fuel injection
Exhaust Stainless steel 3 into 1 , side mounted stainless steel silencer
Final Drive Shaft
Clutch Wet, multi-plate
Gearbox 6-speed
Oil Capacity 4.0 litres (1.1 US gals)

Chassis, Running Gear and Displays

Frame Tubular steel trellis frame
Swingarm Single-sided, cast aluminium alloy with shaft drive
Wheel Front Cast aluminium alloy 10-spoke 19 x 2.5in
Rear Cast aluminium alloy 10-spoke 17 x 4.0in
Tyre Front 110/80 R 19
Rear 150/70 R 17
Suspension Front
KYB 46mm upside down forks, 190mm travel

Rear
KYB monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment, 194mm rear wheel travel

Brakes Front
“Twin 305mm floating discs, Nissin 4-piston calipers, Switchable ABS

Rear
Single 282mm disc, Nissin 2-piston sliding caliper, Switchable ABS

Instrument Display/Functions
LCD instrument pack with digital speedometer, analogue tachometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, air temperature, frost warning, hazard warning lights, trip computer, Tyre pressure monitoring system

Dimensions and Capacities

Length 2248mm/88.4in
Width (handlebars) 962mm (37.9in)
Height without mirrors 1410mm/55.5in
Seat Height 837mm/32.9in – 857mm/33.7in
Wheelbase 1530mm/60.2in
Rake/Trail 23.9 degree/105.5mm
Fuel Tank Capacity 20 litres/5.3 US gals
Wet Weight (ready to ride) 259kg/570lbs

Performance (measured at crankshaft to 95/1/EC)

Maximum Power 137PS/135bhp/101kW @ 9300rpm
Maximum Torque 121Nm/89 ft.lbs @ 6400rpm
Fuel Efficiency

Price

On The Road £11,199 (Factory fitted spoked wheel option £11,499)


All specifications are provisional and subject to change without notice.






2013 Triumph Tiger Explorer – Australia Specifications/Technical Details
Australia MSRP Price: See Dealer for pricing in AUD

Engine and Transmission

Type Liquid-cooled, 12 valve, DOHC, in-line three-cylinder
Capacity 1215cc
Bore/Stroke 85 x 71.4mm
Fuel System Drive by wire, fuel injection
Exhaust Stainless steel 3 into 1 , side mounted stainless steel silencer
Final Drive Shaft
Clutch Wet, multi-plate
Gearbox 6-speed
Oil Capacity 4.0 litres (1.1 US gals)

Chassis, Running Gear and Displays

Frame Tubular steel trellis frame
Swingarm Single-sided, cast aluminium alloy with shaft drive
Wheel Front Cast aluminium alloy 10-spoke 19 x 2.5in
Rear Cast aluminium alloy 10-spoke 17 x 4.0in
Tyre Front 110/80 R 19
Rear 150/70 R 17
Suspension Front
KYB 46mm upside down forks, 190mm travel

Rear
KYB monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment, 194mm rear wheel travel

Brakes Front
“Twin 305mm floating discs, Nissin 4-piston calipers, Switchable ABS

Rear
Single 282mm disc, Nissin 2-piston sliding caliper, Switchable ABS

Instrument Display/Functions
LCD instrument pack with digital speedometer, analogue tachometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, air temperature, frost warning, hazard warning lights, trip computer, Tyre pressure monitoring system

Dimensions and Capacities

Length 2248mm/88.4in
Width (handlebars) 885mm (34.8in)
Height without mirrors 1410mm/55.5in
Seat Height 837mm/32.9in – 857mm/33.7in
Wheelbase 1530mm/60.2in
Rake/Trail 23.9 degree/105.5mm
Fuel Tank Capacity 20 litres/5.3 US gals
Wet Weight (ready to ride) 259kg/570lbs

Performance (measured at crankshaft to 95/1/EC)

Maximum Power 137PS/135bhp/101kW @ 9300rpm
Maximum Torque 121Nm/89 ft.lbs @ 6400rpm


All specifications are provisional and subject to change without notice.
