2013 Yamaha PW50 2-Stroke

2013 Yamaha PW50 2-Stroke

2013 Yamaha PW50 2-Stroke

2013 Yamaha PW50 2-Stroke

2013 Yamaha PW50 2-Stroke

2013 Yamaha PW50 2-Stroke

2013 Yamaha PW50 2-Stroke Review

2013 Yamaha PW50 2-Stroke

Safety features like adjustable throttle and fully automatic transmission ensure your child’s first riding experience will be all smiles…

One of the industry’s best selling mini bikes the 2013 Yamaha PW50 is a fantastic entry level bike to help young riders learn the ropes at an affordable price.

The First Choice for First Timers.

With a seat height of just 19.1 inches, adjustable throttle and fully automatic transmission, the 2013 Yamaha PW50 ensures your kids first ride is as rewarding as his first steps.

Introduce your little ones to the fun and excitement of off road riding, with the legendary PW50.

In fact, this lightweight, easy-riding bike is one of the industry’s best-selling minis. An air-cooled, 49cc, 2-stroke engine gives you single-speed power that’s super reliable and easy to control. Just gas it and go. A removable, power-limiting exhaust restrictor allows parents or adult supervisors to increase power as a rider’s skill level improves. When learning is this much fun, they’ll really apply themselves! And check out the value pricing too!

IMPORTANT NOTE: Adult supervision and proper protective riding gear, including a helmet, are a must when a youngster is operating a PW50.



2013 Yamaha PW50 2-Stroke Key Features

49cc, 2-Stroke Single

Speed Limiter

Easy to use

Fully automatic transmission means no shifting required; the PW50 is a total twist-and-go package.

Torque-tuned, spunky little 49cc two-stroke is built to thrill without intimidating beginners.

A seat only 19.1 inches high makes this one the logical choice for the littlest rider in the group.

An adjustable throttle stop screw lets the adult in charge gradually increase speed as skills improve.

Shaft final drive makes chain maintenance a thing of the past.





2013 Yamaha PW50 2-Stroke Features and Benefits

Engine:

•Air-cooled, 49cc, reed-valve, 2-stroke single is mildly tuned to deliver predictable power that gently eases the new rider up the off-road learning curve.

•Reed-valve intake system smooths power delivery and widens the powerband.

•Single-speed fully automatic transmission means the rider simply twists the throttle to go. This allows a young rider to concentrate on the basics of riding without having to worry about clutching and shifting.

•Shaft drive system is virtually maintenance-free and comes fully enclosed for added protection and durability. There is no chain to worry about adjusting or lubricating.

•Exclusive Autolube Oil Injection System eliminates the need and hassle of fuel/oil premixing. This system precisely meters the exact amount of oil required by the engine.

•Washable foam air filter reduces tune-up costs.

•Maintenance-free CDI (capacitor discharge) ignition produces a hot spark for sure starts and reduced plug fouling.

•Quiet, environmentally friendly exhaust will keep the neighbours smiling.

•Exhaust pipe has been routed away from rider to avoid accidental contact burns. Heat shields also protect young riders from hot components.

Chassis and Suspension:

•Rugged steel backbone-type frame

•Class-lowest 485mm (19.1″) seat height creates a handling-enhancing low centre of gravity and allows most riders to put both feet on the ground for added confidence.

•22.5mm telescopic front fork with 60mm (2.4″) of travel smooths out the bumps.

•Dual rear shock suspension with 50mm (2″) of wheel travel delivers a plush, confidence-inspiring ride.

•Front and rear drum brakes provide strong stopping power. Hand-operated brake levers are similar to those used on bicycles for familiarity.

•Durable, mag-style wheels means there’s no need to tighten or replace spokes. They are easy to clean too!

•Knobby tires provide excellent traction in the dirt.

•Specially designed one-piece rear fender, side panels and seat can be easily removed for cleaning or maintenance.



Additional Features:

•Rugged plastic bodywork resists damage in the event of a tip over.

•Plush, motocross-style seat provides ample comfort.

•Team Yamaha-inspired colours, graphics, front and side number plates create styling just like the bigger YZ series of off-roaders.

•Large, folding footpegs with rubber grips provide excellent footing even in wet or muddy conditions.

•Premium-quality handgrips and levers are durable and comfortable.

•Heat shields on engine and exhaust protect young riders from hot components.

•Adjustable speed limiter screw on throttle housing restricts acceleration and top speed.

•Removable exhaust pipe restrictor allows parents to increase top speed as skills improve.

•Start/Run switch prevents unit from moving while in the start position.

•Easy-access handlebar-mounted choke lever.

•E10 compatible fuel system components

IMPORTANT NOTE: Adult supervision and proper protective riding gear, including a helmet, are a must when a youngster is operating a PW50.



---



2013 Yamaha PW50 2-Stroke – USA Specifications/Technical Details
US MSRP Price: $1,440 (Team Yamaha Blue/White) USD

Engine
Type 49cc air-cooled 2-stroke; reed-valve inducted
Bore x Stroke 40.0mm x 39.2mm
Compression Ratio 6.0:1
Fuel Delivery VM12 carburetor
Ignition CDI
Transmission Wet centrifugal automatic
Final Drive Shaft

Chassis
Suspension / Front Telescopic fork; 2.4-in travel
Suspension / Rear Unit swingarm; 2.0-in travel
Brakes / Front Drum
Brakes / Rear Drum
Tires / Front 2.50-10-4PR
Tires / Rear 2.50-10-4PR

Dimensions
Length 49.0 in
Width 22.6 in
Height 28.1 in
Seat Height 19.1 in
Wheelbase 33.7 in
Ground Clearance 4.1 in
Fuel Capacity .53 gal
Wet Weight*** 86 lb

Other
Warranty 90 Day (Limited Factory Warranty)

*Prices and specifications subject to change without notice. Please read your Owner’s Manual and all labels before operation.
**Fuel economy estimates are based on US EPA exhaust emission certification data obtained by Yamaha. Your actual mileage will vary depending on road
conditions, how you ride and maintain your vehicle, accessories, cargo, and operator/passenger weight.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel.





---



2013 Yamaha PW50 2-Stroke – Canadian Specifications/Technical Details
Canada MSRP Price: $1,299 CDN

Engine Air-cooled, reed-valve, 2-stroke single
Displacement 49cc
Bore and Stroke 40 x 39.2mm
Compression Ratio 6.0:1
Maximum Torque 0.36kg-m (2.6 ft-lb)@ 4,500 rpm
Fuel Delivery Mikuni VM12SC
Ignition / Starting CDI / Kick
Transmission Single-speed automatic (no clutch)
Final Drive Shaft

Suspension (Front) 22.5mm fork / 60mm (2.4″) wheel travel
Suspension (Rear) Unit swingarm / 50 mm (2″) wheel travel
Brakes (Front) Drum
Brakes (Rear) Drum
Tires (Front) 2.50-10
Tires (Rear) 2.50-10

Length 1,245mm (49″)
Width 575mm (22.6″)
Height 715mm (28.1″)
Wheelbase 855mm (33.7″)
Ground Clearance 105mm (4.1″)
Seat Height 485mm (19.1″)
Fuel Capacity 2 litres (0.4 imp. gallons)
Wet Weight 39kg (86 lb)
Colour(s) Yamaha Blue

± Fuel economy estimates are based on US EPA exhaust emission certification data obtained by Yamaha and converted into Canadian measurements. Your actual mileage will vary depending on road condition, how you ride, maintain your vehicle, accessories, cargo and operator/passenger weight.

Specifications, appearance, and price of product are subject to change without notice.

* MSRP does not include freight, PDI (Pre Delivery Inspection), pre-rigging (boats), or taxes. Dealer may sell for less. See your local dealer for out the door pricing.

---

2013 Yamaha PW50 2-Stroke – UK/Europe Specifications/Technical Details
UK/European MSRP Price: £ See dealer for Pricing.

More information to follow shortly



---

2013 Yamaha PW50 2-Stroke – Australian Specifications/Technical Details
AU MSRP Price: $TBA AUD

More information to follow shortly





Specifications, features and prices to change by manufacturer without notice. All information correct as of posted date.
