2016 Ducati 1299 Panigale S Review

2016 Ducati 1299 Panigale S on www.Totalmotorcycle.com

Where technology is a step ahead…

Bring the Superquadro engine with an unprecedented 116mm bore producing 205 hp of pure adrenaline and 106.7 lb-ft of stunning torque together with the semi-active suspension and electronic steering damper governed by the Öhlins Smart EC system and technology takes a giant leap forward. The 1299 Panigale S stands apart with its full LED headlights, carbon fiber mudguard and forged wheels. Undoubtedly the most thrilling superbike on the market.

The apex of performance

The new Superquadro engine is ingeniously incorporated into the Monoscocca chassis, providing the perfect platform from which to deliver its incredible 205 horsepower. The underside of the fuel tank, when mounted, seals the top of the frame which then becomes the airbox. Innovative engineering solutions such as these are used throughout the Panigale line, and take the dry weight of the 1299 Panigale/S down to 166.5 kg while the Panigale R sits at an incredible 162 kg. The total focus on light weight gives each Panigale a power-to-weight ratio that sets the reference in its class. Combined with advanced electronic controls and the finest brakes, suspension, and other components, this creates an incredibly potent package that takes riders to the very apex of performance. Precision riding, at the highest level, with the character and exhilaration that only a Ducati Superbike can provide.

Unequalled beauty

The beauty of speed translated into design. Pure racing spirit is channelled to the rider with a grasp of the 1299 Panigale’s handlebars. Large, aggressive air intakes feed the new Superquadro engine and signal no holds-barred competition.




The 1299 Panigale and Panigale R feature an advanced headlight with LED positioning lights, while the 1299 Panigale S uses a full LED headlight for the ultimate statement of technical cool. In the rear all models use a full LED taillight which accents the all-new split tail, while a perfectly integrated under-belly exhaust keeps the lines clean and pure. An award-winning integration of engineering and design, the Panigale gets the adrenaline flowing from the first glance.Power, agility, and sophistication, wrapped in the very best Italian style.



2016 Ducati 1299 Panigale S www.Totalmotorcycle.com Key Features





2016 Ducati 1299 Panigale S www.Totalmotorcycle.com Features and Benefits

Extreme bore/stroke ratio


The new Superquadro’s bore/stroke ratio of 1.91:1 sets an extreme example of the power-maximizing “oversquare” architecture used in the world’s most advanced racing engines. A short-stroke crankshaft and enormous pistons combined with large Desmodromically-actuated valves allow the Superquadro to breathe freely at high rpm, while a 1285cc combustion chamber ensures the ample torque that has made so many enthusiasts fall in love with Ducati’s signature L-twin power.

Precious elements


The clutch cover, cylinder head covers, and oil pan are all cast in a golden-color magnesium alloy to ensure the engine’s strength with the absolute lowest possible weight.

Crankcase


The crankcases, produced through a vacuum casting technology called Vacural®, ensure high strength at low weight along with a uniform wall thickness, and are designed to incorporate water jackets around the cylinder barrels. The engine uses wet barrels coated in Nicasil, which are inserted into the holes of the engine block’s housing during the initial stages of assembly. This design allows the head to be fastened directly onto the crankcase, combining the need for rigidity of the engine’s structure with a significant advantage in terms of compactness. Due to their thin structure, the cylinder barrels efficiently transfer heat to the coolant running along their walls. In addition to these barrels, the Superquadro’s crankcase stands out for the use of plain main bearings, previously utilised on the Ducati Desmosedici RR engine. These bearings allow the use of large-diameter crankshaft journals, which maximise rigidity and mechanical strength to optimise the internal rotating structure to the extreme power of the Superquadro.

High tech intake


The new Superquadro uses large intake valves fed by advanced oval-section throttle bodies, which emphasize high air flow for maximum power production. Independently controlled by the fully Ride-by-Wire system, the throttle bodies are each fitted with 2 fuel injectors: the first is set below the body and operates in lower rpm/load conditions, while the second is fitted above the throttle body and is called into action when it’s time for the Superquadro to unleash the full scope of its power and torque.

Essential Desmo


To control the large valves with the precise and efficient Desmodromic system, engineers chose a mixed gear and chain drive system. This chain drive accurately transmits the motion between crankshaft and camshaft, and thanks also to an automatic tensioning adjustment, offers excellent reliability with low routine maintenance costs.

Decompressor


At the end of the exhaust camshaft of each cylinder head is a centrifugal decompressor. On start-up, this device allows the profile of the cam opening lobe to be modified, slightly lifting a valve so that part of the combustion charge can escape the chamber during the engine’s compression phase. Once the engine fires, the increase in rpm and associated centrifugal force modify the decompressor, cancelling the valve lift effect to bring the engine to normal operating conditions. By temporarily reducing the compression effect of the piston during start-up, a much smaller and lighter starter motor and battery can be used, contributing significantly to the extreme light weight of the overall engine and motorcycle. This ingenious system further underlines the synergistic strength achieved by engineers and designers in the uncompromising creation of the Superquadro.

Transmission


During development of the first Superquadro engine, Ducati engineers took their design freedom to the limit by increasing the distance between centres of the six-speed gearbox shafts and allowing the use of gears with an increased diameter and superior strength for the transmission of power. The oil bath clutch, similar in design to that used on other Ducati models, is a progressive system which allows the load on its plates to be increased without increasing the effort required by the rider to pull the lever and disengage the clutch. This optimally satisfies the need for a high torque transmission which still provides optimum usability for the rider. In sport riding conditions with abrupt downshifting heavy engine braking, the same mechanism reduces the pressure on clutch plates and allows them to slip as in a racing system, preventing a loss of stability in the rear end and offering excellent modulability during hard braking into corners.

Fully Ride-by-Wire


The opening and closing of throttle butterflies on the Superquadro is controlled by a fully electronic Ride-by-Wire system. The absence of a mechanical connection between the twistgrip and the throttle bodies allows the engine ECU to regulate power delivery by directly adjusting the throttle; Ride-by-Wire makes it possible to have different power and delivery based on the selected Riding Mode, to alter the level of engine back-torque (EBC), and to control any slipping of the rear wheel (DTC).

Lubrication


The journals of the main bearings are lubricated by pressurised oil admitted through ducts inside the engine block. This serves to assure the efficient lubrication of the new crankshaft, followed by a rapid recovery of the oil thanks to a lobe pump that places the connecting rod compartment under vacuum, similar to the engines used in MotoGP. This pump is driven by gears built in a special high-strength techno-polymer and maintains the crankcase area below the pistons in controlled conditions of constant vacuum, thereby reducing resistance during the pistons’ downstroke as well as facilitating oil flow for rapid recovery.

Ohlins Smart EC semi-active suspension


The 1299 Panigale S features the world-exclusive Ohlins Smart EC semi-active suspension system. Consisting of an NIX-30 front fork, a TTX rear shock, and a steering damper, this system interfaces with the Bosch Inertial Platform and dynamically responds to changing road and riding conditions, allowing the best possible suspension performance and total motorcycle control. It operates in one of two modes: Fixed, which is non-active and allows the rider to set specific levels of front and rear compression and rebound, along with steering damper tension. These levels are maintained constant until the rider changes them again, exactly as a traditionally adjusted suspension system. Alternately, there is the Event Based mode, which is semi-active and allows the rider to select levels of suspension “behavior” ranging from Hard to Soft. In this mode, the system then dynamically adjusts compression, rebound, and damper tension in response to ride conditions, maintaining the overall “behavior” previously selected by the rider.

Monocoque Technology


The Panigale’s Monoscocca chassis forms its structural backbone – compact, rigid, lightweight, and multi-functional. Cast in aluminium, it attaches at its rear directly to the heads of the Superquadro engine and contains the steering head and bearings at its front. In addition to performing the function of a traditional frame, the Monoscocca also serves as the airbox and in this way significantly contributes to lowering the overall weight of the motorcycle. Housed inside it are the air filter, throttle bodies and fuel circuit complete with injectors, making it truly unique and a revolutionary advancement to the world of traditional motorcycle construction.

Tyres


All Panigales benefit from Pirelli’s Diablo Supercorsa SP tyres, the road version of the tyre used in the Superstock 1000 World Championship: 120/70 ZR17 at front and 200/55 x ZR17 at rear, which provide the contact patch necessary to effectively transmit the Superquadro’s power to the ground. Designed to maintain a precise line in straights and on curves, the rear 200/55 x ZR17 tyre maximises the area of contact and corner speed by combining 200 mm width with a high profile. The tyres have structures and compounds deriving directly from Pirelli’s experience in the Superbike World Championship, and feature casings specially studied to guarantee rigidity in extreme braking and shoulders that maximise the contact patch. In addition, a special double compound that uses the most advanced polymers facilitates the rapid heating of the tyres together with a constant grip.

Brakes


The 1299 Panigale features the finest brakes available – Brembo’s M50 Monoblock callipers. Sporting an extremely compact design and machined out of a single alloy block, the M50 callipers offer the ultimate in rigidity and deformation resistance during extreme braking.

Lacking nothing


With an aggressive design enhanced by full LED headlamps, a front mudguard in carbon fibre, forged Marchesini wheels, Ohlins Smart EC semi-active suspension and steering damper, and auxiliary handlebar control buttons, the 1299 Panigale S is bristling with features and technology that make it the complete package for performance riding.

Forged wheels


The 1299 Panigale S and Panigale R feature Marchesini tri-W spoke forged aluminium wheels, which have an eye-catching racing style and are strong and incredibly lightweight.

Ergonomics


The Panigale’s ergonomic dimensions assure a perfect integration between rider and motorcycle. The seat and handlebar positions are optimized to provide total control and comfort during sport and track riding, while the switchgear and dash are further designed to be intuitive, informative, and a pleasure to use. Grippy, machined-from-billet aluminium footpegs and a carefully-shaped seat with racing cover allow the rider to perfectly integrate with the Panigale, and focus only on the extraordinary sensations of the ride.

Carbon Parts


The 1299 Panigale S has a front mudguard made in the highest-quality carbon fibre, to accentuate its high-technology and premium nature. Light and stiff, carbon fibre saves precious grams of weight compared to an equivalent part in plastic; while at the same time making the 1299 Panigale’s style even more aggressive.

Auxiliary handlebar buttons


The 1299 Panigale S and Panigale R feature handlebar-mounted auxiliary control buttons, which allow the rider on-the-fly adjustment of a selected parameter among DTC, DWC, or EBC. Using these the rider can instantly fine-tune the motorcycle to changing track, road, weather, or tyre conditions without slowing down.

Full LED lighting


The 1299 Panigale S shows its technologically advanced nature with a bright, efficient, and stylish full-LED front headlight, along with LED brakelight, turn signals, and number plate light.

DDA+ GPS ready


The DDA+ GPS is the latest generation of the Ducati Data Analyzer, which integrates a GPS signal to create a “virtual finish line”. The system automatically detects, without any intervention by the rider, the conclusion of the lap and stops the chronometric time. Integration with the GPS signal also provides visualisation on the circuit map of the trajectories ridden and the main parameters of the vehicle: throttle opening, speed, rpm, gear engaged, engine temperature, DTC activation, and lean angle.
The 1299 Panigale and 1299 Panigale S are pre-configured to accept the DDA+ GPS, while the Panigale R includes the system as standard.

Total control


Ducati’s Riding Modes allow a rider to instantly vary key characteristics of the 1299 Panigale to suit different conditions or rider preferences – engine power and delivery, traction control, wheelie control, ABS, engine braking, and – exclusively on the 1299 Panigale S – suspension behaviour. Three pre-set configurations, Race, Sport, and Wet, are available to be selected by using buttons mounted on the handlebar. But these are only a starting point, as each configuration can be completely customized according to the specific level of each control parameter desired by the rider. With three custom setups ready at the push of a button, the Panigale superbikes become perfectly tailored partners to the rider’s unrelenting pursuit of speed.

Ducati Quick Shift up/down (DQS)


The Ducati Quick Shift up/down (DQS) is a race-derived electronic system that manages shifting of the gearbox in both up and down directions. It allows upshifts to be made under full acceleration without using the clutch, which gains precious fractions of a second that would otherwise be wasted in closing the throttle. It also allows clutchless downshifts, as the system performs a perfectly-timed auto-blip when the foot lever is depressed, engaging the gears smoothly and allowing the rider to concentrate only on braking and corner entry.

Bosch Inertial Platform


The 1299/S Panigale and Panigale R use the Bosch Inertial Platform, which is centered around an Inertial Measurement Unit (IMU). The IMU constantly monitors the motorcycle’s lean angle and fore/aft pitch, interfacing with the ABS, DWC, and on the 1299 Panigale S, the Ohlins Smart EC suspension – ensuring that these systems operate at maximum effectiveness regardless of the motorcycle’s position.

Engine Braking Control (EBC)



The engine braking control (EBC) system works in combination with the slipper clutch to prevent and manage any locking of the rear wheel during aggressive downshifting. The rider can select the level of engine braking felt from one of 3 levels, allowing them to perfectly customize the motorcycle’s feeling during deceleration and turn entry.

Ducati Wheelie Control (DWC)


First implemented on the incredible Ducati 1199 Superleggera, Ducati Wheelie Control (DWC) recognizes front-wheel lift and responds according to one of 8 rider-selectable levels, allowing the throttle to be maintained open without fear of the wheelie getting out of control. This allows for maximum possible acceleration, ensuring a formidable drive out of any corner.

LED lighting



Another detail that gives the Panigale its total racing look is the twin headlamp at front designed to be an integral part of the front air scoops, with integrated LED positioning lights. The double LED lights at rear harmoniously wrap around the air vents in the seat-tail assembly and, when turned on, create an alluring effect of signalling lights enhanced by stop lights. LED technology is also been used for the front and rear turn indicators as well as the number plate light.

Anti-Lock Braking System (ABS) 9.1 MP


The Bosch 9.1 MP ABS equips the 1299 Panigale/S and Panigale R as standard, and is a latest-generation system that performs combined braking with control rear wheel lift to guarantee the shortest braking distances and greatest stability in any conditions. Further, the system interfaces with the Bosch Intertial Control platform, allowing maximum braking even while the motorcycle is leaned over.

Ducati Traction Control (DTC)



Ducati Traction Control (DTC) is an advanced system that monitors and maintains control over slipping of the rear tyre and operates on the basis of eight different levels of intervention, each of which has been programmed to respond to a different tolerance to rear slipping. Each Riding Mode is assigned a preset level of activation, which can then be modified according to the riders’ desire.




Level 8 corresponds to an activation of the system with the slightest slipping, while Level 1, best used by expert riders and professionals, has a higher tolerance and thus allows a much higher amount of slip before intervening.

Optimized geometry


The 1299 Panigale and 1299 Panigale S benefit from the experience of Ducati Corse, and adopt a new geometry which uses a 24° steering head angle along with a swingarm pivot point 4mm lower compared to the previous generation of Panigale. This enhances the bike’s agility, and provides better rear traction in a wide variety of conditions.

Full TFT instrument panel



The instrument panel on the 1299 Panigale uses a full TFT display. The colour display’s configuration is variable and automatically adapts to variations in environmental light and to the selected Riding Mode. In the “Road” and “Wet” Riding Modes, speed takes centre stage and is displayed in large numbers in the middle of the display, whereas the two boxes containing “supplementary information” underneath provide data on total mileage and engine coolant temperature. In the “Race” Riding Mode, the display layout is automatically reconfigured, shifting the display of the vehicle’s speed in the lower information box at left and making room for the last lap time, centrally displayed in large numbers

For the first time on a Ducati motorcycle, the display features a “lean angle visualization,” allowing the rider to see their achieved lean angle displayed on the dash in real-time.

Transform and perform


On or off the track, you can transform your Superbike with two exclusive packages offering a host of high-performance accessories in tune with your needs. Turn your Superbike into the ultimate racing model with specific high-tech components or add features that will improve your experience when touring. Sport and Touring: choose one or both packs to complete the ideal set-up for your motorcycle.

Sport pack


Unleash the power. Make every detail count in terms of performance. Benefit from ultimate technologies in this selection of race-bred accessories. Maximise your experience with specially conceived ultralight, componentry and design elements which enhance the streamlined looks.
The package includes carbon fibre covers for ignition switch and rear shock absorber, an adhesive carbon tank protector, a carbon sprocket cover kit, carbon heel guards for rider footpegs, an aluminium tank plug and a carbon and aluminium alloy number plate holder. Black handlebar weights are also included

Touring pack


Take to the road. Feel safe and comfortable whatever your destination is. Enjoy the ride with a carefully chosen series of premium quality features designed to provide you with maximum convenience and peace of mind.
The package contains a water radiator protection grid kit, an anti-theft system, a rider comfort seat ideal for longer distance trips and soft tank bag.






2016 Ducati 1299 Panigale S – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See Dealer for pricing in USD

Type Superquadro: L-twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement 1,285 cc
Bore x Stroke 116 x 60.8 mm
Compression Ratio 12.6:1
Power 205 hp (150.8 kW) @ 10,500 rpm
Torque 106.7 lb-ft (144.6 Nm) @ 8,750 rpm
Fuel injection Mitsubishi electronic fuel injection system.Twin injectors per cylinder.Full ride-by-wire elliptical throttle bodies
Exhaust 2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum end caps
Emissions Euro 3
Gearbox 6 speed with Ducati Quick Shift (DQS) up/down
Ratio 1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24
Primary drive Straight cut gears, Ratio 1.77:1
Final drive Chain 525; Front sprocket 15; Rear sprocket 39
Clutch Slipper and self-servo wet multiplate clutch with hydraulic control
Frame Monocoque aluminum
Wheelbase 1,437 mm (56.57 in)
Rake 24°
Trail 96 mm (3.78 in)
Steering lock (total) 48°
Front suspension Öhlins NIX30 43mm fully adjustable USD fork with TiN treatment. Electronic compression and rebound damping adjustment with semi-active mode
Front wheel travel 120 mm (4.72 in)
Front wheel 3 spoke forged light alloy 3.50″ x 17″
Front tyre 120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear suspension Fully adjustable Öhlins TTX36 unit.Electronic compression and rebound damping adjustment with semi-active mode.Adjustable linkage: Progressive/flat.Aluminum single-sided swingarm
Rear wheel travel 130 mm (5.12 in)
Rear wheel 3 spoke forged light alloy 6.00″ x 17″
Rear tyre 200/55 ZR17 Pirelli Diablo Supercorsa SP
Front brake 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc EVO M50 4-piston calliperswith Cornering ABS Bosch 9.1MP
Rear brake 245 mm disc, 2-piston calliperwith Cornering ABS as standard
Fuel tank capacity 17 l (4.5 gallon US)
Dry weight 166.5 kg (367 lb)
*Wet weight 190.5 kg (420 lb)
Seat height 830 mm (32.68 in)
Max height 1130 mm (44.1 in)
Max length 2060 mm (81.1 in)
Instrumentation TFT
Ducati electronics DTC, DQS up/down, DES, EBC, Riding Modes, DWC, R-b-W, Cornering ABS, auto tyre and final ratio calibration
Warranty 2 years unlimited mileage
Versions Dual seat
Additional equipment Full LED lighting, Öhlins Smart EC with semi-active steering damper, Auxiliary adjustment buttons, DDA+ with GPS-ready














2016 Ducati 1299 Panigale S – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $26695 See Dealer for pricing in CDN

Type Superquadro: L-twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement 1,285 cc
Bore x Stroke 116 x 60.8 mm
Compression Ratio 12.6:1
Power 205 hp (150.8 kW) @ 10,500 rpm
Torque 106.7 lb-ft (144.6 Nm) @ 8,750 rpm
Fuel injection Mitsubishi electronic fuel injection system.Twin injectors per cylinder.Full ride-by-wire elliptical throttle bodies
Exhaust 2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum end caps
Emissions Euro 3
Gearbox 6 speed with Ducati Quick Shift (DQS) up/down
Ratio 1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24
Primary drive Straight cut gears, Ratio 1.77:1
Final drive Chain 525; Front sprocket 15; Rear sprocket 39
Clutch Slipper and self-servo wet multiplate clutch with hydraulic control
Frame Monocoque aluminum
Wheelbase 1,437 mm (56.57 in)
Rake 24°
Trail 96 mm (3.78 in)
Steering lock (total) 48°
Front suspension Öhlins NIX30 43mm fully adjustable USD fork with TiN treatment. Electronic compression and rebound damping adjustment with semi-active mode
Front wheel travel 120 mm (4.72 in)
Front wheel 3 spoke forged light alloy 3.50″ x 17″
Front tyre 120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear suspension Fully adjustable Öhlins TTX36 unit.Electronic compression and rebound damping adjustment with semi-active mode.Adjustable linkage: Progressive/flat.Aluminum single-sided swingarm
Rear wheel travel 130 mm (5.12 in)
Rear wheel 3 spoke forged light alloy 6.00″ x 17″
Rear tyre 200/55 ZR17 Pirelli Diablo Supercorsa SP
Front brake 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc EVO M50 4-piston calliperswith Cornering ABS Bosch 9.1MP
Rear brake 245 mm disc, 2-piston calliperwith Cornering ABS as standard
Fuel tank capacity 17 l (4.5 gallon US)
Dry weight 166.5 kg (367 lb)
*Wet weight 190.5 kg (420 lb)
Seat height 830 mm (32.68 in)
Max height 1130 mm (44.1 in)
Max length 2060 mm (81.1 in)
Instrumentation TFT
Ducati electronics DTC, DQS up/down, DES, EBC, Riding Modes, DWC, R-b-W, Cornering ABS, auto tyre and final ratio calibration
Warranty 2 years unlimited mileage
Versions Dual seat
Additional equipment Full LED lighting, Öhlins Smart EC with semi-active steering damper, Auxiliary adjustment buttons, DDA+ with GPS-ready














2016 Ducati 1299 Panigale S – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: See Dealer for pricing in GBP (On The Road inc 20% Vat)

Engine
Type
Superquadro L-Twin, 4 Desmodromically actuated valves per cylinder, liquid cooled
Displacement
1285cc
Bore x Stroke
116×60.8mm
Compression ratio
12.6:1
Power
150.8 kW (205 hp) @ 10,500 rpm
Torque
144,6 Nm (106.7 lb-ft) @ 8,750 rpm

Technical data referring to power and torque was measured on an engine test stand at Ducati.
Fuel injection
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies.
Exhaust
2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum end caps

Transmission

Gearbox
6 speed with DQS Ducati Quick Shift up/down
Primary drive
Straight cut gears, Ratio 1.77:1
Ratio
1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24
Final drive
Chain; Front sprocket 15; Rear sprocket 39
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control

Chassis

Frame
Monocoque Aluminium
Front suspension
Öhlins NIX30 43mm fully adjustable USD fork with TiN treatment. Electronic compression and rebound damping adjustment with semi-active mode
Front wheel
3-spoke W shape forged light alloy 3.50″ x 17″
Front Tyre
120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear suspension
Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with semi-active mode. Adjustable linkage: Progressive/flat. Aluminium single-sided swingarm
Rear wheel
3 spoke W shape forged light alloy 6.00″ x 17″
Rear tyre
200/55 ZR17 Pirelli Diablo Supercorsa SP
Front wheel travel
120mm (4.72in)
Rear wheel travel
130mm (5.12in)
Front brake
2 x 330mm semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers with cornering ABS as standard equipment
Rear brake
245mm disc, 2-piston caliper with cornering ABS as standard equipment
Instrumentation
Digital unit with TFT colour display:

Dimensions and weight

Dry weight
166.5kg (367lb)

Weight data refers to the dry weight of the motorcycle without battery, lubricants and coolants for liquid-cooled models.
Wet weight (KERB)
190.5kg(420lb)

Kerb weights indicate total bike weight with all operating consumable liquids and a fuel tank filled to 90% of capacity (as per EC standard 93/93).
Seat height
830mm (32.68in)
Wheelbase
1437mm (56.6in)
Rake
24°
Trail
96mm (3.78in)
Fuel tank capacity
17l – 4.5 gallon (US)
Number of seats
Dual seat

Equipments

Standard Equipment
Riding Modes, Power Modes, Cornering ABS, DTC, DQS up/down, DWC, EBC, Fully RbW, Auto tyre calibration, Full LED lighting, Ohlins Smart EC with semi-active steering damper, Auxiliary adjustment buttons, DDA+ with GPS-ready
Additional equipments
Passenger seat and footpegs Kit

Warranty

Warranty
24 months unlimited mileage
Maintenance service intervals
7,500m
Valve clearance check
24,000m

Emissions and Consumption

Standard
Euro 3













*Starting at MSRP is the manufactured suggested price and excludes delivery, setup, tax, title, license, and additional fees and expenses. Bikes may be shown with optional accessories. Final sale price determined by an authorized dealer. Specifications and MSRP are subject to change.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
