2016 Victory Gunner

Back to 2016 Victory Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2016 Victory Gunner
2016 Victory Gunner

2016 Victory Gunner
2016 Victory Gunner

2016 Victory Gunner
2016 Victory Gunner

2016 Victory Gunner
2016 Victory Gunner

2016 Victory Gunner
2016 Victory Gunner



2016 Victory Gunner Review

2016 Victory Gunner on www.Totalmotorcycle.com

Ready. Aim. Throttle…

You’ve wanted to step up to a true heavyweight cruiser. Do it in style with the Gunner, a powerful cruiser with throwback bobber style and street-smart attitude.

The Gunner comes in two colours; grey or green, with the official paint names of Suede Titanium Metallic and Suede Sagebrush Green Metallic.

” 106 cubic inch Freedom® V-Twin (1731cc)
” 139Nm at 2,800rpm
” 6-speed overdrive transmission17 litre tank
” Solo seat
” 635mm seat height
” 16 x 3.5″ front wheel with a Dunlop 491 E2-RWL tyre
” 16 X 3.5″ rear wheel with a Dunlop 491 E2-RWL tyre
” 296kg dry weight
” ABS standard

The Gunner comes in two colours for 2016; grey or green. The official paint names are Suede Titanium Metallic and Suede Sagebrush Green Metallic.

The footpegs are placed slightly further rearwards than the American version of the bike, giving riders in EMEA a sportier riding position.



All of the motorcycles in Victory Motorcycles’ cruiser category can now be fitted with performance Akrapovic exhausts.

Owners of the Gunner, Judge, Hammer S, Hammer 8-Ball, Vegas 8-Ball and the High-Ball can simply make a straight swap of their standard exhausts for these new Akrapovic ones.

The exhausts come in either matte black or chrome and have a two-year warranty.

Uroš Rosa, PhD and CEO Akrapovic d.d says: “This is a very a significant event for all of us here at Akrapovic, and we are extremely proud to be the performance exhaust of choice for Victory Motorcycles’ cruiser category. We have a history of creating innovative exhaust solutions using the latest technology, and it is this philosophy that we see in this collaboration. Victory Motorcycles has breathed new life into the American V-Twin cruiser market with its pioneering range of bikes, and we are delighted to align our own unique exhaust knowledge with them. Akrapovic will give part of its world and a whole new character to each and every bike fitted with one of its exhaust systems, and, through the performance, quality, design, technology, and unmistakable sound that we deliver with each exhaust system, all Akrapovic-equipped Victory Motorcycles cruisers will be bikes that stand out from the rest.”

Victory Motorcycles’ head of parts, apparel and accessories, Andreas Geisinger, said: “I was very excited to work with Akrapovic on this exclusive exhaust line for our Victory Motorcycles line up.

“Akrapovic, with their well-known class-leading quality and performance levels, goes perfectly with Victory Motorcycles’ push to produce machines with ‘Modern American Performance’. These handmade exhausts are like works of art.”







2016 Victory Gunner www.Totalmotorcycle.com Key Features

Low Seat Height & Relaxed Ergonomics

The 25” high seat lets your feet extend all the way to the ground, and keeps you comfortable and confident in heavy traffic or on the open road.


106 Cubic-Inch Freedom V-Twin

The Gunner is a display of true American engineering muscle. It’s just itching to unleash 110 ft-lb of torque from 106 cubic inches of Freedom V-Twin.


6-Speed Overdrive Transmission

Blow away everything on the road with this 6-Speed Overdrive Transmission. Shift smoothly, powerfully, and confidently whether on the highway or downtown.


24 Spoke Cast Aluminum Wheels

The Gunner’s aim is true on premium 24-spoke cast aluminum wheels.






2016 Victory Gunner www.Totalmotorcycle.com Features and Benefits


SUEDE TITANIUM METALLIC AND BLACK 2-TONE TANK The Victory Gunner’s distinctive bobber styling is enhanced by the premium Suede Titanium Metallic and Black paint, including the two-tone fuel tank


106 CUBIC-INCH FREEDOM® V-TWIN The Victory Freedom® 106/6 V-Twin is smooth, efficient – and extremely powerful. It’s fuel-injected, counter-balanced and delivers 103 ft-lb of torque you can use to own city streets and enjoy extended highway cruising with confidence and power to spare. It delivers instant throttle response and outstanding power you can unleash on demand.


103 FT-LBS OF TORQUE With the outstanding power of the Victory Freedom® 106/6 V-Twin, you’ll ride the Gunner with confidence – and with 103 ft-lb of torque on tap. Use the power to enjoy the best cruising, to head out onto the open road, and to manage traffic with passing power to spare.


ABS BRAKES Victory Anti-Lock Brakes give a rider greater confidence and peace of mind. When traction is compromised, the ABS immediately and automatically provides reliable braking to help you stop quickly


24 SPOKE CAST ALUMINUM WHEELS The lightweight 16″ front and rear wheels have such unique and powerful style that the Victory Gunner looks like it just rolled out of a custom shop.


LOW SEAT HEIGHT & RELAXED ERGONOMICS LOW SEAT HEIGHT & MID-MOUNTED CONTROLS. The comfortable Victory Gunner seat has a narrow straddle point so your legs extend directly to the pavement from the 25.0″ seat height, enhancing your confidence and control. The mid-mounted controls put the rider in an active, engaged riding position.


STREAMLINED SOLO SEAT The Victory Gunner seat is stylish and comfortable. This sleek solo seat offers the ideal combo of cushion and support. It also puts a rider in a position of confidence-inspiring control. The seat’s styling integrates with a smooth lines of the Victory Gunner, enhancing the bike’s throwback bobber style. For 2-up riding, add the accessory passenger seat – and pegs or floorboards – of your choice.


ADD VICTORY ACCESSORIES TO MAKE IT ALL YOURS Every rider can make the Victory Gunner truly their own with Victory Accessories. Add comfort, convenience, extra style, protection and more with Victory Accessories. Every Victory accessory undergoes the same rigorous testing as our motorcycles, so they install easily, fit properly, and deliver outstanding performance.


AKRAPOVIC EXHAUST (ACCESSORY) Designed, developed and manufactured exclusively for Victory Motorcycles, Akrapovic’s new twin silencer Slip-On system has been tuned to deliver optimum performance and enhance the thundering American V-twin soundtrack, for the full range of Victory Cruisers sharing the Freedom 106 (1731cc) motor. Akrapovic Slip-Ons fully satisfy EC noise and emission standards.













2016 Victory Gunner – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $12,999 USD


Specifications

ABS Not Equipped
Dry Weight 649 lb (294 kg)
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Charging System 48 Amps Max Output
Compression Ratio 9:4:1
Cooling Air & Oil
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Exhaust Dual-Staggered Slash-Cut with Common Volume
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Transmission/Final Drive Carbon Fiber Reinforced Belt
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission Type 6 Speed Overdrive/Constant Mesh
Valve Train 4 Valves per Cylinder, Hydraulic Lifters & Cam Chain Adjusters
Bore x Stroke (mm) 101 X 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Front Suspension Telescopic Fork/ 5.1″ (130mm)
Rear Suspension Single Monotube Gas/Preload Adjustable/3.0″ (75mm)

Brakes

Brake System Type Not Linked
Front Brakes Single 300 x 5mm/ Floating Rotor/ 4 Piston Caliper
Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper

Tires / Wheels

Front Tires Dunlop 491 E2-RWL
Front Wheel 16 x 3.5 in
Rear Tires Dunlop 491 E2-RWL
Rear Wheel 16 x 3.5 in

DIMENSIONS

Fuel Capacity (Litres) 4.5 gal / 17.0 ltr
GVWR 1151 lbs / 523 kg
Ground Clearance 4.7 in / 120 mm
Rake/Trail 32°/6.7 in (170.0 mm)
Seat Height 25.0 in / 635 mm
Wheelbase 64.8 in / 1647 mm
Overall Length (in./mm.) 93.4 in / 2372 mm

Features

Colors (Base) Matte Titianium, Suede Sagebrush Green Metallic










2016 Victory Gunner – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $15,499 CDN


Specifications

ABS Not Equipped
Dry Weight 649 lb (294 kg)
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Charging System 48 Amps Max Output
Compression Ratio 9:4:1
Cooling Air & Oil
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Exhaust Dual-Staggered Slash-Cut with Common Volume
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Transmission/Final Drive Carbon Fiber Reinforced Belt
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission Type 6 Speed Overdrive/Constant Mesh
Valve Train 4 Valves per Cylinder, Hydraulic Lifters & Cam Chain Adjusters
Bore x Stroke (mm) 101 X 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Front Suspension Telescopic Fork/ 5.1″ (130mm)
Rear Suspension Single Monotube Gas/Preload Adjustable/3.0″ (75mm)

Brakes

Brake System Type Not Linked
Front Brakes Single 300 x 5mm/ Floating Rotor/ 4 Piston Caliper
Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper

Tires / Wheels

Front Tires Dunlop 491 E2-RWL
Front Wheel 16 x 3.5 in
Rear Tires Dunlop 491 E2-RWL
Rear Wheel 16 x 3.5 in

DIMENSIONS

Fuel Capacity (Litres) 4.5 gal / 17.0 ltr
GCWR 1151 lbs / 523 kg
Ground Clearance 4.7 in / 120 mm
Rake/Trail 32°/6.7 in (170.0 mm)
Seat Height 25.0 in / 635 mm
Wheelbase 64.8 in / 1647 mm
Overall Length (in./mm.) 93.4 in / 2372 mm

Features

Color / Graphics Suede Titanium Metallic with Black
Colors (Base) Matte Titianium, Suede Sagebrush Green Metallic







2016 Victory Gunner – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £See Dealer GBP (On The Road inc 20% Vat)

Specifications

Dry Weight 652 lbs / 296 kg
Displacement 106 ci / 1731 cc

Engine

Battery 12 volts / 18 amp hours
Charging System 48 amps max output
Clutch Wet, multi-plate
Compression ratio 9.4 : 1
Cooling System Air / oil
Exhaust Staggered slash-cut dual exhaust with crossover
Final Drive Carbon Fiber Reinforced Belt
Fuel Capacity 17.0 ltr
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Primary Drive Gear drive with torque compensator
Transmission 6-speed overdrive constant mesh
Valve train Single overhead camshafts with 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters
Bore x Stroke 101 x 108 mm
Engine Type 4-stroke 50° V-Twin

Suspension

Front Suspension Conventional telescopic fork, 43 mm diameter, 5.1 in / 130 mm travel
Rear Suspension Single, mono-tube gas, cast aluminum with rising rate linkage, 3.0 in / 75 mm travel, preload adjustable spring

Brakes

Brake system type Conventional with ABS Standard
Front braking system 300mm floating rotor with 4-piston caliper
Rear braking system 300mm floating rotor with 2-piston caliper

Tires / Wheels

Front tire 130/90R16 Dunlop 491 E2-RWL
Front Wheel 16 x 3.5 in
Rear tire 140/90R16 Dunlop 491 E2-RWL
Rear Wheel 16 x 3.5 in

Chassis

Ground Clearance 4.7 in / 120 mm
GVWR 1,151 lbs / 523 kg
Rake/trail 32° / 6.7 in / 170 mm
Seat Heigh 25.0 in / 635 mm
Wheelbase 64.8 in / 1647 mm
Length 93.4 in / 2372 mm
Lean Angle 25.5°
Oil capacity 4.73 ltr

Features

Colors Suede Sagebrush Green Metallic, Suede Titanium Metallic




Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
