2017 Can-Am Spyder F3 Review

2017 Can-Am Spyder F3

2017 Can-Am Spyder F3

2017 Can-Am Spyder F3

2017 Can-Am Spyder F3 Review

2017 Can-Am Spyder F3 on www.Totalmotorcycle.com

The starting point for adventure with its cruising riding position and spirited performance at new attractive price….

The Spyder F3 model is a great starting point for your open road adventure, with its great engine, cruising riding position and bold style.

2017 Can-Am Spyder F3 www.Totalmotorcycle.com Key Features

Rotax 1330 ACE In-Line 3-Cylinder Engine

Semi-Automatic or Manual 6-Speed Transmission

VSS: Stability Control, Traction Control and Anti-Lock Brakes

Custom riding position with UFit System

High-Performance Brembo Braking System

SACHS Big-Bore shocks

2017 Can-Am Spyder F3 www.Totalmotorcycle.com Features and Benefits

Engine

1330 ace

transmission

SEMI-AUTOMATIC / MANUAL

storage

6.5 GAL. (24.4 L)

UFIT SYSTEM

TAILOR YOUR BIKE

The exclusive Spyder F3 UFit system lets you easily position the footpegs according to your height and choose the handlebar based on your preferred riding style — ensuring a truly customized riding experience. *Custom handlebar sold as an accessory.

SACHS BIG-BORE SHOCKS

ENGINEERED FOR A SMOOTHER RIDE

These premium wide-diameter shocks ensure a plush ride even on bumpy backcountry roads and are quiet at all speeds.

6-SPOKE WHEELS

BOLD, CONFIDENT LOOK

Designed specifically for the Spyder F3, these black painted wheels evoke boldness and confidence.

CARGO SPACE

BRING IT ALONG

Keep your gear safe and protected. The trademark lockable front cargo space features 6.5 gallons (24.4 L) gallons of watertight space.

2017 Can-Am Spyder F3 – www.Totalmotorcycle.com USA Specifications/
Technical Details
US MSRP Price: $16,999* USD (*Transport and preparation not included)

ENGINE
Type
Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled
with electronic fuel injection and electronic
throttle control
Bore & stroke . . . . . . . . . . . . 3.31 x 3.14 in. (84 x 80 mm)
Power . F3: 105 hp (78.3 kW) @ 6000 RPM
F3-S: 115 hp (85.8 kW) @ 7250 RPM
Torque 96 lb-ft. (130.1 Nm) @ 5000 RPM
CHASSIS
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel
F3: SACHS† Big-Bore shocks / 5.1 in. (129 mm)
F3-S: Gas-charged, FOX† PODIUM† shocks /
5.1 in. (129 mm)
Rear suspension Swing-arm
Rear shock type / Travel . SACHS shock / 5.2 in. (132 mm)
Electronic brake
distribution system Foot-operated, hydraulic 3-wheel brake
Front brakes 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper with
integrated parking brake
Parking brake Electrically actuated
Front tires MC165/55R15 55H
Rear tire . MC225/50R15 76H
Aluminum front rims
F3: 6-spoke, Deep Black, 15 x 5 in. (381 x 127 mm)
F3-S: 6-spoke, Machined Deep Black High-Gloss,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
DIMENSIONS
L x W x H 104 x 58.9 x 43.3 in.
(2,642 x 1,497 x 1,099 mm)
Wheelbase . 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance . 4.5 in. (115 mm)
Dry weight . 899 lb (408 kg)
Storage capacity . . . . . . . . . 6.5 gal (24.4 L)
Maximum vehicle load . 439 lb (199 kg)
Fuel capacity . 7.1 gal (27 L)
Reserve 1.20 gal (4.5 L) approx.
Fuel type Premium unleaded

FEATURES
Instrumentation
Multi-function LCD segment / analog gauge,
tachometer, odometer, trip & hour meters,
gear position, temperature, engine lights,
electronic fuel gauge, clock
Running lights . 2 halogen headlamps (55/60-W)
Cruise control F3-S: Electronic
Trims and parts Carbon Black and Black Gloss
SAFETY & SECURITY
SCS . Stability Control System
TCS Traction Control System
ABS . Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security System (D.E.S.S.™)
WARRANTY
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended B.E.S.T. available from
12 to 36 months

2017 Can-Am Spyder F3 – www.Totalmotorcycle.com Canadian Specifications/
Technical Details
Canada MSRP Price: $19,299* CDN (*Transport and preparation not included)

ENGINE
Type
Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled
with electronic fuel injection and electronic
throttle control
Bore & stroke . . . . . . . . . . . . 3.31 x 3.14 in. (84 x 80 mm)
Power . F3: 105 hp (78.3 kW) @ 6000 RPM
F3-S: 115 hp (85.8 kW) @ 7250 RPM
Torque 96 lb-ft. (130.1 Nm) @ 5000 RPM
CHASSIS
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel
F3: SACHS† Big-Bore shocks / 5.1 in. (129 mm)
F3-S: Gas-charged, FOX† PODIUM† shocks /
5.1 in. (129 mm)
Rear suspension Swing-arm
Rear shock type / Travel . SACHS shock / 5.2 in. (132 mm)
Electronic brake
distribution system Foot-operated, hydraulic 3-wheel brake
Front brakes 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper with
integrated parking brake
Parking brake Electrically actuated
Front tires MC165/55R15 55H
Rear tire . MC225/50R15 76H
Aluminum front rims
F3: 6-spoke, Deep Black, 15 x 5 in. (381 x 127 mm)
F3-S: 6-spoke, Machined Deep Black High-Gloss,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
DIMENSIONS
L x W x H 104 x 58.9 x 43.3 in.
(2,642 x 1,497 x 1,099 mm)
Wheelbase . 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance . 4.5 in. (115 mm)
Dry weight . 899 lb (408 kg)
Storage capacity . . . . . . . . . 6.5 gal (24.4 L)
Maximum vehicle load . 439 lb (199 kg)
Fuel capacity . 7.1 gal (27 L)
Reserve 1.20 gal (4.5 L) approx.
Fuel type Premium unleaded

FEATURES
Instrumentation
Multi-function LCD segment / analog gauge,
tachometer, odometer, trip & hour meters,
gear position, temperature, engine lights,
electronic fuel gauge, clock
Running lights . 2 halogen headlamps (55/60-W)
Cruise control F3-S: Electronic
Trims and parts Carbon Black and Black Gloss
SAFETY & SECURITY
SCS . Stability Control System
TCS Traction Control System
ABS . Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security System (D.E.S.S.™)
WARRANTY
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended B.E.S.T. available from
12 to 36 months

2017 Can-Am Spyder F3 – www.Totalmotorcycle.com European Specifications/ Technical Details
Europe/UK MSRP Price: £15,199 GBP (including Vat)

ENGINE
Type
Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled
with electronic fuel injection and electronic
throttle control
Bore & stroke . . . . . . . . . . . . 3.31 x 3.14 in. (84 x 80 mm)
Power . F3: 105 hp (78.3 kW) @ 6000 RPM
F3-S: 115 hp (85.8 kW) @ 7250 RPM
Torque 96 lb-ft. (130.1 Nm) @ 5000 RPM
CHASSIS
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel
F3: SACHS† Big-Bore shocks / 5.1 in. (129 mm)
F3-S: Gas-charged, FOX† PODIUM† shocks /
5.1 in. (129 mm)
Rear suspension Swing-arm
Rear shock type / Travel . SACHS shock / 5.2 in. (132 mm)
Electronic brake
distribution system Foot-operated, hydraulic 3-wheel brake
Front brakes 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper with
integrated parking brake
Parking brake Electrically actuated
Front tires MC165/55R15 55H
Rear tire . MC225/50R15 76H
Aluminum front rims
F3: 6-spoke, Deep Black, 15 x 5 in. (381 x 127 mm)
F3-S: 6-spoke, Machined Deep Black High-Gloss,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
DIMENSIONS
L x W x H 104 x 58.9 x 43.3 in.
(2,642 x 1,497 x 1,099 mm)
Wheelbase . 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance . 4.5 in. (115 mm)
Dry weight . 899 lb (408 kg)
Storage capacity . . . . . . . . . 6.5 gal (24.4 L)
Maximum vehicle load . 439 lb (199 kg)
Fuel capacity . 7.1 gal (27 L)
Reserve 1.20 gal (4.5 L) approx.
Fuel type Premium unleaded

FEATURES
Instrumentation
Multi-function LCD segment / analog gauge,
tachometer, odometer, trip & hour meters,
gear position, temperature, engine lights,
electronic fuel gauge, clock
Running lights . 2 halogen headlamps (55/60-W)
Cruise control F3-S: Electronic
Trims and parts Carbon Black and Black Gloss
SAFETY & SECURITY
SCS . Stability Control System
TCS Traction Control System
ABS . Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security System (D.E.S.S.™)
WARRANTY
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
