2017 Victory Vision Review

2017 Victory Vision on www.Totalmotorcycle.com

UNIQUELY AMERICAN, UNIQUELY VICTORY…

What if you cast off all convention and set out to build the ultimate American touring bike without any rules or restrictions on how that bike had to look, feel or act? The result would be the Victory Vision – America’s most comfortable touring bike. The Vision’s full-coverage fairing, sculpted in the wind tunnel, provides unprecedented comfort and protection. And because the fairing is mounted to the frame and not the handlebars, steering remains light and predictable. Underneath the innovative bodywork are the same capable underpinnings as all the Victory baggers and tourers, including the extra-rigid cast aluminum frame, air-adjustable rear suspension, and of course a gleaming example of the same four-valve overhead-cam Freedom® 106 V-Twin that delivers such unexpectedly brisk acceleration. Add to that a power windshield that turns wind resistance into your plaything, standard ABS and cruise control that instill confidence, a heated seat and heated grips that keep you rolling year round, and 29 gallons of storage capacity with enough room for two no matter where adventure takes you.

Stand out and stand apart.

2017 Victory Vision www.Totalmotorcycle.com
Key Features

It’s two-piece aluminum frame and fixed fairing deliver America’s most capable
V-twin touring bike.

• Power Adjustable Windscreen, Heated Hand Grips & Two-Zone Heated
Seats
• Standard Linked ABS Brakes & Cruise Control
• 29 Gallons of Storage Capacity

2017 Victory Vision www.Totalmotorcycle.com
Features and Benefits

Heated Handgrips & Individual Heated Seats

Ride in any condition. Heated handgrips and seats with passenger-specific
settings will keep you rolling year round.

29 Gallons of Trunk & Saddlebag Space

It’s a big country. Pack for any climate with 29 gallons of trunk space
— enough room for two no matter where adventure takes you.

Standard linked ABS brakes

Put slippery situations in the rearview with linked front and rear ABS. Braking
power is automatically controlled to minimize your braking distance.

Adjustable Power Windscreen

The Adjustable Power Windscreen raises and lowers with a push of a button
delivering exactly the right amount of wind protection in any elements.

2017 Victory Vision – www.Totalmotorcycle.com
USA Specifications/Technical Details
US MSRP Price: Available in Gloss Black ($21,099) and Gloss Blue Fire ($22,099).

Specifications

ABS/Cruise Control Equipped
Curb Weight 900 lbs / 408 kg
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Valve Train SOHC – 4 Valves per Cylinder/Hydraulic Lifters & Cam Chain
Adjusters
Transmission Type 6 Speed Overdrive/Constant Mesh
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission/Final Drive Carbon Fiber Reinforced Belt
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Exhaust Dual-Large Bore Slash-Cut with Common Volume
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Cooling Air / Oil
Compression Ratio 9.4 : 1
Charging System 48 Amps Max Output
Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Bore x Stroke (mm) 101 x 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Rear Suspension Single Monotube Air Adjustable Shock: 4.7″ (120mm) travel

Front Suspension Telescopic Fork/ 5.1″ (130mm)

Brakes

Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper
Front Brakes Dual 300 x 5mm/ Floating Rotor/ 3 Piston Caliper
Brake System Type Semi-Linked w/ ABS

Tires / Wheels

Rear Wheel 16 x 5.0 in
Rear Tires Dunlop D418 Elite 3 180/60R16 M/C 80H
Front Wheel 18 x 3.5 in
Front Tires Dunlop D418F Elite 3 130/70R18 63H

DIMENSIONS

Wheelbase 65.7 in / 1670 mm
Seat Height 26.5 in / 673 mm
Rake/Trail 29.0° / 5.4 in / 137 mm
Ground Clearance 5.8 in / 148 mm
GVWR 1414 lbs / 642 kg
Fuel Capacity (Litres) 6.0 gal / 22.7 ltr
Overall Length (in./mm.) 106.4 in / 2702 mm

Features

Colors (Base) Gloss Black, Gloss Blue Fire
Color Swatch Gloss Black
Comfort Heated Dual-zone Seat, Heated grips, Adjustable Power Windshield

2017 Victory Vision – www.Totalmotorcycle.com
Canadian Specifications/Technical Details
Canada MSRP Price: $24,999 CDN

ABS Equipped
Dry Weight 900 lbs / 408 kg
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Valve Train SOHC – 4 Valves per Cylinder/Hydraulic Lifters & Cam Chain
Adjusters
Transmission Type 6 Speed Overdrive/Constant Mesh
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission/Final Drive Carbon Fiber Reinforced Belt
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Exhaust Dual-Large Bore Slash-Cut with Common Volume
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Cooling Air / Oil
Compression Ratio 9.4 : 1
Charging System 48 Amps Max Output
Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Bore x Stroke (mm) 101 x 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Rear Suspension Single Monotube Air Adjustable Shock: 4.7″ (120mm) travel

Front Suspension Telescopic Fork/ 5.1″ (130mm)

Brakes

Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper
Front Brakes Dual 300 x 5mm/ Floating Rotor/ 3 Piston Caliper
Brake System Type Semi-Linked w/ ABS

Tires / Wheels

Rear Wheel 16 x 5.0 in
Rear Tires Dunlop D418 Elite 3 180/60R16 M/C 80H
Front Wheel 18 x 3.5 in
Front Tires Dunlop D418F Elite 3 130/70R18 63H

DIMENSIONS

Wheelbase 65.7 in / 1670 mm
Seat Height 26.5 in / 673 mm
Rake/Trail 29.0° / 5.4 in / 137 mm
Ground Clearance 5.8 in / 148 mm
GCWR 1414 lbs / 642 kg
Fuel Capacity (Litres) 6.0 gal / 22.7 ltr
Overall Length (in./mm.) 106.4 in / 2702 mm

Features

Comfort Heated Dual-zone Seat, Heated grips, Adjustable Power Windshield

Colors (Base) Gloss Black, Gloss Blue Fire
Color / Graphics Gloss Black

2017 Victory Vision – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £TBA GBP (On The Road inc 20% Vat)

TBA
