2019 Norton Atlas Ranger:


Engine type: Norton Designed 650cc parallel twin. 270 degree firing order. Chain driven double overhead cams with idler gear.

Bore & stroke: 82mm x 61.5mm Compression ratio: 11.5:1

Fuel injection: Electronic fuel injection system. 4 fuel injectors. Full drive-by-wire system.

Euro 4: Full compliance including secondary air injection and EVAP.



Power: 84bhp @ 11,000rpm Torque: 64Nm



Lighting: Full LED lighting system including super bright high and low beam, daytime running lights, rear lamp and indicators.



Chassis type: Twin tube seamless steel perimeter chassis with aluminium swingarm mount.

Swingarm: Braced twin spar cast aluminium.

Wheelbase: 1470mm

Dry weight: 178kg

Headstock angle: 24.2 degrees

Fuel tank: Composite fuel tank with 15L capacity.

Yokes: Forged top and bottom.

Front wheel: 19 inch spoke wheel with Titanium coloured aluminium rim and 120/70 R19 Avon Trekrider tyre.

Rear wheel: 17 inch spoke wheel with Titanium coloured aluminium rim and 170/60 R17 Avon Trekrider tyre.

Bodywork: High mudguard, brushed aluminium rear panels.

Others: Factory fit sump guard, screen kit, headlamp guard. Braced handle bars.

Seat height: 867mm



Front brakes: 2 x 320mm full floating Brembo discs. Radially mounted twin Brembo monoblock callipers with ABS. Brembo master cylinder.

Rear brakes: Single 245mm Brembo disc. Brembo twin piston rear calliper with ABS. Brembo master cylinder.



Front suspension: 50mm diameter Roadholder USD forks. Preload, compression and rebound adjustable. 200mm wheel travel.

Rear suspension: Roadholder monoshock with rising rate linkage and piggyback reservoir. Adjustable preload. 200mm wheel travel.







2019 Norton Atlas Ranger Totalmotorcycle.com Key Features

250 bikes exclusively released at Motorcycle Live (NEC, UK). £500 deposit secures (fully refundable) for a 2019 delivery.




2019 Norton Atlas Ranger Totalmotorcycle.com Features and Benefits





2019 Norton Atlas Ranger – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: from $ USD
Canada MSRP Price: from $ CDN
Europe/UK MSRP Price: from € 6390 Euros (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU


Norton Atlas revealed with two new models. UK deliveries set to commence in May 2019 with European bikes set to release later in 2019, followed by USA, Australia late 2019.
