2020 Ducati Multistrada 1260 Pikes Peak Guide

2020 Ducati Multistrada 1260 Pikes Peak

2020 Ducati Multistrada 1260 Pikes Peak 2020 Ducati Multistrada 1260 Pikes Peak 2020 Ducati Multistrada 1260 Pikes Peak 2020 Ducati Multistrada 1260 Pikes Peak

BEYOND BOUNDARIES.

2020 Ducati Multistrada 1260 Pikes Peak:

The Pikes Peak version – which draws its inspiration from the legendary American hill climb race – really brings out the sports character of the Multistrada 1260.

The Pikes Peak International Hill Climb, also known as the “The Race to the Clouds”, is held in an area of the Rocky Mountains some 16 km west of Colorado Springs. A distance of 20 kilometres separates the starting line, at an altitude of 2,862 metres, from the finishing line at 4,300 m. It’s an incredibly tough competition: Ducati has already won it three times.

Developed on the technical foundations of the Multistrada 1260 S, the Pikes Peak version benefits from the 1262 cc Euro 4 compliant Ducati Testastretta DVT engine and new chassis dimensions, which include a new front end geometry and a longer swingarm. Along with a race-inspired colour scheme, the Multistrada 1260 Pikes Peak comes equipped with new forged aluminium wheels, which are lighter than those of the Multistrada 1260 S. In addition, the bike is fitted with the Öhlins fork and Öhlins TTX36 shock, which can both be adjusted mechanically.

In addition to the silencer and nose fairing, fitted as standard, a carbon fibre Ducati Performance silencer by Termignoni (EU type-approved) and a low racing-type carbon fibre screen are also available for the Pikes Peak version. Further carbon fibre components include the front mudguard, hands free cover and front side panels, while the red-stitched seat has been specially designed to bring out this Multistrada’s racing spirit.

Thanks to the 1262 cc Euro 4 compliant Ducati Testastretta DVT engine, the Multistrada 1260 Pikes Peak offers an even more enjoyable riding experience. 85% of the torque is in fact already available below 3,500 rpm with, compared to the previous model, 18% increase at 5,500 rpm. This makes the Multistrada 1260 the motorcycle in its category with the highest torque values at 4,000 rpm, that is the most frequently used rev range.

This level of performance is easy to manage too, thanks to the new Ride by Wire which allows for an even smoother fuel supply, and to the DQS (Ducati Quick Shift) Up & Down, which contributes to an improved riding experience thanks to seamless and accurate gear meshing during both upshifting and downshifting.

The Multistrada 1260 Pikes Peak is equipped as standard with the Inertial Measurement Unit (IMU), developed by Bosch, which dynamically measures pitch and roll angles and acceleration along the 3 axes, raising performance and safety standards even further. Equipped with Cornering ABS, Cornering Lights (DCL) on the full-LED headlight, Ducati Wheelie Control (DWC), Ducati Traction Control (DTC), Vehicle Hold Control (VHC) and Cruise Control, the Multistrada 1260 Pikes Peak is a concentrate of technology that also features, as standard, a Bluetooth module; the latter, via the Ducati Multimedia System (DMS), lets riders connect the bike to a smartphone and manage key multimedia functions (incoming calls, text messaging, music) via the switchgears and display information on the TFT dashboard, which has been renewed both in terms of graphics and logic.

Like other bikes in the family, the Multistrada 1260 Pikes Peak can mount one or more Ducati Performance accessory packages. Also available – in addition to individual items – are the Touring Pack (which includes heated grips, panniers and centre stand), the Urban Pack (with top case, tank bag with tank lock and USB hub to charge electronic devices), the Enduro Pack (consisting of supplementary LED lights and Ducati Performance components by Touratech: engine crash bars, radiator crash bars, sump guard, a broader kickstand base and off-road footpegs).









2020 Ducati Multistrada 1260 Pikes Peak Totalmotorcycle.com Key Features

Multistrada 1260 Pikes Peak

• Colours
o Pikes Peak livery, Ducati red chassis and black wheel rims
• Equipment
o New 1260 cc Ducati Testastretta DVT engine
o Adjustable Öhlins fork and adjustable TTX36 shock
o Ducati Performance exhaust by Termignoni
o Carbon fibre screen (in addition to the standard one)
o Aluminium forged wheels
o Carbon fibre front mudguard
o Carbon fibre hands free cover
o Carbon fibre front side panels
o Red seat stitching
o Inertial Measurement Unit (IMU) by Bosch
o Bosch-Brembo ABS 9.1ME Cornering braking system
o 330 mm front discs with Brembo M50 4-piston radial calipers
o Electronic cruise control
o Ducati Multimedia System (DMS)
o Riding Modes
o Ride-by-Wire Power Modes (PM)
o Ducati Wheelie Control (DWC)
o Ducati Traction Control (DTC)
o Vehicle Hold Control (VHC)
o Height-adjustable rider’s seat
o Full LED headlight with Ducati Cornering Lights (DCL)
o Dashboard with full-TFT 5” colour screen







2020 Ducati Multistrada 1260 Pikes Peak Totalmotorcycle.com Features and Benefits

Expand your comfort zone
The new Multistrada 1260 truly maximizes the concept of versatility: The new 1262 cc Ducati Testastretta DVT engine extends powers even in low gear, the new chassis and cutting-edge electronics improve control and ease of driving in any condition and on any road.

The maximum on any road
New engine. Greater usability and control. The new Multistrada 1260 takes you into a brand new “comfort zone”, where the pleasure of driving becomes a sense of well-being, traveling is turned into an experience and performance becomes pure emotion.

Elegant and unique

The new Multistrada 1260 reaches completely new quality and finish standards. The sleek surfaces, flowing design, and graceful lines between the front and rear distinguish the aesthetics of the model. The new Y-shaped 5 spoke wheels complete the look and give the Multistrada 1260 a bold stance.

New Testastretta DVT 1262

The new Multistrada 1260 is equipped with a new Ducati Testastretta DVT 1262 cm3 Euro 4 engine making everyday use even more pleasurable thanks to increased torque at low and mid-range engine speeds. The new Multistrada 1260 has the highest available torque in it’s class at 4000 rpm, providing immediate and powerful acceleration.

Even more comfort for your travels

New chassis measurements including a longer swing arm, and new shape at the front end makes tackling curves much more effective and ensures maximum stability even with full panniers and a passenger aboard.

Technological reference point

The new Multistrada 1260 also stands as a technological point of reference. Maximum safety is achieved with the IMU (Inertial Management Unit) which manages the ABS and Cornering Light. Also included is the Ducati Traction Control, Ducati Wheelie Control, the highly acclaimed Skyhook suspension and the Vehicle Hold Control for easy uphill starts.

The road, a free mind

The new Multistrada 1260 has lengthened maintenance intervals. Oil changes are scheduled for every 15000 km, while the valve clearance should be inspected every 30000km (Desmo Service). The extended service intervals allow you to enjoy even the longest rides without any worries.









2020 Ducati Multistrada 1260 Pikes Peak – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ 25,795 USD
Canada MSRP Price: $ 28,095 CDN
Europe/UK MSRP Price: £ 21,195 GBP (On The Road inc 20% Vat)
MULTISTRADA1260 Pikes Peak
ENGINE
Ducati Testastretta DVT with Desmodromic Variable Timing, L-twin cylinder, 4 valves per
TYPEcylinder, Dual Spark, liquid cooled
DISPLACEMENT1,262 cc
BORE X STROKE106 x 71.5 mm
COMPRESSION RATIO13.0:1
POWER158 hp (116 kW) @ 9,500 rpm
TORQUE95 lb-ft (13.2 kgm, 129 Nm) @ 7,500 rpm
FUEL INJECTIONElectronic fuel injection system, Øeq56 mm elliptical throttle bodies with Ride-by-Wire system
EXHAUSTStainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
TRANSMISSION
GEARBOX6 speed with Ducati Quick Shift up/down (DQS)
PRIMARY DRIVEStraight cut gears, ratio 1.84:1
RATIO1=37/15, 2=30/17, 3=27/20, 4=24/22, 5=23/24,
6=22/25
FINAL DRIVEChain, front sprocket Z15, rear sprocket Z40
Light action, wet, multiplate clutch with hydraulic control, self-servo action on drive, slipper action
CLUTCHon over-run
CHASSIS
FRAMETubular steel Trellis frame
FRONT SUSPENSIONÖhlins Ø48 mm fully adjustable usd fork with TiN treatment
FRONT WHEEL3-spoke Ѱ-shape forged light alloy 3.5″ x 17″
FRONT TYREPirelli Scorpion Trail II 120/70 ZR 17
Fully adjustable Öhlins TTX36 unit, aluminium single-sided swingarm
REAR SUSPENSION
REAR WHEEL3-spoke Ѱ-shape forged light alloy 6.00″ x 17″
REAR TYREPirelli Scorpion Trail II 190/55 ZR 17
WHEEL TRAVEL (FRONT/REAR)170 mm / 170 mm (6.7 in / 6.7 in)
2 x Ø330 mm semi-floating discs, radially mounted Brembo monobloc M50 Evo 4-piston callipers, radial master cylinder, Cornering ABS
FRONT BRAKE
REAR BRAKEØ265 mm disc, 2-piston floating calliper,
Cornering ABS
INSTRUMENTATION5″ color TFT display
DIMENSIONS AND WEIGHTS
DRY WEIGHT206 kg (454 lb)
KERB WEIGHT*229 kg (505 lb)
SEAT HEIGHTAdjustable 825 – 845 mm (32.5 – 33.3 in)
WHEELBASE1,585 mm (62.4 in)
RAKE25°
TRAIL111 mm (4.4 in)
FUEL TANK CAPACITY20 l (5.3 US gal)
NUMBER OF SEATS3
EQUIPMENT
Riding Mode, Power Mode, Cornering ABS, Ducati Traction Control (DTC), Ducati Cornering Lights (DCL), Vehicle Hold Control (VHC), Ducati Wheelie Control (DWC)
SAFETY EQUIPMENT
Ducati Skyhook Suspension Evo (DSS),  Ducati Quick Shift up/down (DQS), Cruise control, Hands- Free, Backlit handlebar switches, 5″ color TFT display, Full-LED headlight, Auto-off turn indicators, Ducati Multimedia System (DMS), Ducati Performance by Termignoni homologated exhaust, Carbon fibre windscreen, Öhlins suspension, Carbon fibre front mudguard, Carbon fibre side panels, Hands-Free carbon fiber cover
STANDARD EQUIPMENT
PROVIDED EQUIPMENTPlexiglass windscreen
Tyre pressure monitoring system (TPMS), Antitheft system
READY FOR
WARRANTY AND MAINTENANCE
WARRANTY24 months, Unlimited mileage
MAINTENANCE SERVICE INTERVALS15,000 km (9,000 miles) / 12 months
DESMOSERVICE30,000 km (18,000 miles)
EMISSIONS AND CONSUMPTION (Only for countries where Euro 4 standard applies)
STANDARDEuro 4
CO2 EMISSIONS120 g/km
CONSUMPTION5.2 l/100 km
*Kerb weights indicate total bike weight with all operating consumable liquids and a fuel tank filled to 90% of capacity (as per EU Regulation 44/2014 Annex XI).
2020 Ducati Multistrada 1260 Pikes Peak – Totalmotorcycle.com Canada Specifications/Technical Details
MULTISTRADA1260 Pikes Peak
ENGINE
Ducati Testastretta DVT with Desmodromic Variable Timing, L-twin cylinder, 4 valves per
TYPEcylinder, Dual Spark, liquid cooled
DISPLACEMENT1,262 cc
BORE X STROKE106 x 71.5 mm
COMPRESSION RATIO13.0:1
POWER158 hp (116 kW) @ 9,500 rpm
TORQUE95 lb-ft (13.2 kgm, 129 Nm) @ 7,500 rpm
FUEL INJECTIONElectronic fuel injection system, Øeq56 mm elliptical throttle bodies with Ride-by-Wire system
EXHAUSTStainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
TRANSMISSION
GEARBOX6 speed with Ducati Quick Shift up/down (DQS)
PRIMARY DRIVEStraight cut gears, ratio 1.84:1
RATIO1=37/15, 2=30/17, 3=27/20, 4=24/22, 5=23/24,
6=22/25
FINAL DRIVEChain, front sprocket Z15, rear sprocket Z40
Light action, wet, multiplate clutch with hydraulic control, self-servo action on drive, slipper action
CLUTCHon over-run
CHASSIS
FRAMETubular steel Trellis frame
FRONT SUSPENSIONÖhlins Ø48 mm fully adjustable usd fork with TiN treatment
FRONT WHEEL3-spoke Ѱ-shape forged light alloy 3.5″ x 17″
FRONT TYREPirelli Scorpion Trail II 120/70 ZR 17
Fully adjustable Öhlins TTX36 unit, aluminium single-sided swingarm
REAR SUSPENSION
REAR WHEEL3-spoke Ѱ-shape forged light alloy 6.00″ x 17″
REAR TYREPirelli Scorpion Trail II 190/55 ZR 17
WHEEL TRAVEL (FRONT/REAR)170 mm / 170 mm (6.7 in / 6.7 in)
2 x Ø330 mm semi-floating discs, radially mounted Brembo monobloc M50 Evo 4-piston callipers, radial master cylinder, Cornering ABS
FRONT BRAKE
REAR BRAKEØ265 mm disc, 2-piston floating calliper,
Cornering ABS
INSTRUMENTATION5″ color TFT display
DIMENSIONS AND WEIGHTS
DRY WEIGHT206 kg (454 lb)
KERB WEIGHT*229 kg (505 lb)
SEAT HEIGHTAdjustable 825 – 845 mm (32.5 – 33.3 in)
WHEELBASE1,585 mm (62.4 in)
RAKE25°
TRAIL111 mm (4.4 in)
FUEL TANK CAPACITY20 l (5.3 US gal)
NUMBER OF SEATS3
EQUIPMENT
Riding Mode, Power Mode, Cornering ABS, Ducati Traction Control (DTC), Ducati Cornering Lights (DCL), Vehicle Hold Control (VHC), Ducati Wheelie Control (DWC)
SAFETY EQUIPMENT
Ducati Skyhook Suspension Evo (DSS),  Ducati Quick Shift up/down (DQS), Cruise control, Hands- Free, Backlit handlebar switches, 5″ color TFT display, Full-LED headlight, Auto-off turn indicators, Ducati Multimedia System (DMS), Ducati Performance by Termignoni homologated exhaust, Carbon fibre windscreen, Öhlins suspension, Carbon fibre front mudguard, Carbon fibre side panels, Hands-Free carbon fiber cover
STANDARD EQUIPMENT
PROVIDED EQUIPMENTPlexiglass windscreen
Tyre pressure monitoring system (TPMS), Antitheft system
READY FOR
WARRANTY AND MAINTENANCE
WARRANTY24 months, Unlimited mileage
MAINTENANCE SERVICE INTERVALS15,000 km (9,000 miles) / 12 months
DESMOSERVICE30,000 km (18,000 miles)
EMISSIONS AND CONSUMPTION (Only for countries where Euro 4 standard applies)
STANDARDEuro 4
CO2 EMISSIONS120 g/km
CONSUMPTION5.2 l/100 km
*Kerb weights indicate total bike weight with all operating consumable liquids and a fuel tank filled to 90% of capacity (as per EU Regulation 44/2014 Annex XI).



2020 Ducati Multistrada 1260 Pikes Peak – Totalmotorcycle.com European Specifications/Technical Details
MULTISTRADA1260 Pikes Peak
ENGINE
Ducati Testastretta DVT with Desmodromic Variable Timing, L-twin cylinder, 4 valves per
TYPEcylinder, Dual Spark, liquid cooled
DISPLACEMENT1,262 cc
BORE X STROKE106 x 71.5 mm
COMPRESSION RATIO13.0:1
POWER158 hp (116 kW) @ 9,500 rpm
TORQUE95 lb-ft (13.2 kgm, 129 Nm) @ 7,500 rpm
FUEL INJECTIONElectronic fuel injection system, Øeq56 mm elliptical throttle bodies with Ride-by-Wire system
EXHAUSTStainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
TRANSMISSION
GEARBOX6 speed with Ducati Quick Shift up/down (DQS)
PRIMARY DRIVEStraight cut gears, ratio 1.84:1
RATIO1=37/15, 2=30/17, 3=27/20, 4=24/22, 5=23/24,
6=22/25
FINAL DRIVEChain, front sprocket Z15, rear sprocket Z40
Light action, wet, multiplate clutch with hydraulic control, self-servo action on drive, slipper action
CLUTCHon over-run
CHASSIS
FRAMETubular steel Trellis frame
FRONT SUSPENSIONÖhlins Ø48 mm fully adjustable usd fork with TiN treatment
FRONT WHEEL3-spoke Ѱ-shape forged light alloy 3.5″ x 17″
FRONT TYREPirelli Scorpion Trail II 120/70 ZR 17
Fully adjustable Öhlins TTX36 unit, aluminium single-sided swingarm
REAR SUSPENSION
REAR WHEEL3-spoke Ѱ-shape forged light alloy 6.00″ x 17″
REAR TYREPirelli Scorpion Trail II 190/55 ZR 17
WHEEL TRAVEL (FRONT/REAR)170 mm / 170 mm (6.7 in / 6.7 in)
2 x Ø330 mm semi-floating discs, radially mounted Brembo monobloc M50 Evo 4-piston callipers, radial master cylinder, Cornering ABS
FRONT BRAKE
REAR BRAKEØ265 mm disc, 2-piston floating calliper,
Cornering ABS
INSTRUMENTATION5″ color TFT display
DIMENSIONS AND WEIGHTS
DRY WEIGHT206 kg (454 lb)
KERB WEIGHT*229 kg (505 lb)
SEAT HEIGHTAdjustable 825 – 845 mm (32.5 – 33.3 in)
WHEELBASE1,585 mm (62.4 in)
RAKE25°
TRAIL111 mm (4.4 in)
FUEL TANK CAPACITY20 l (5.3 US gal)
NUMBER OF SEATS3
EQUIPMENT
Riding Mode, Power Mode, Cornering ABS, Ducati Traction Control (DTC), Ducati Cornering Lights (DCL), Vehicle Hold Control (VHC), Ducati Wheelie Control (DWC)
SAFETY EQUIPMENT
Ducati Skyhook Suspension Evo (DSS),  Ducati Quick Shift up/down (DQS), Cruise control, Hands- Free, Backlit handlebar switches, 5″ color TFT display, Full-LED headlight, Auto-off turn indicators, Ducati Multimedia System (DMS), Ducati Performance by Termignoni homologated exhaust, Carbon fibre windscreen, Öhlins suspension, Carbon fibre front mudguard, Carbon fibre side panels, Hands-Free carbon fiber cover
STANDARD EQUIPMENT
PROVIDED EQUIPMENTPlexiglass windscreen
Tyre pressure monitoring system (TPMS), Antitheft system
READY FOR
WARRANTY AND MAINTENANCE
WARRANTY24 months, Unlimited mileage
MAINTENANCE SERVICE INTERVALS15,000 km (9,000 miles) / 12 months
DESMOSERVICE30,000 km (18,000 miles)
EMISSIONS AND CONSUMPTION (Only for countries where Euro 4 standard applies)
STANDARDEuro 4
CO2 EMISSIONS120 g/km
CONSUMPTION5.2 l/100 km
*Kerb weights indicate total bike weight with all operating consumable liquids and a fuel tank filled to 90% of capacity (as per EU Regulation 44/2014 Annex XI).

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
