2020 Kawasaki KLX110L Guide

2020 Kawasaki KLX110L

2020 Kawasaki KLX110L 2020 Kawasaki KLX110L 2020 Kawasaki KLX110L 2020 Kawasaki KLX110L

TALL RIDERS REJOICE!

2020 Kawasaki KLX110L:

The biggest challenge in enjoying the KLX110 or KLX110L’s amazing off-road capabilities is figuring out who’s going to ride it first – because its compact dimensions, simple-to-use features, and choice of 2 models were designed for a wide range of beginning riders aged 13 and up.





2020 Kawasaki KLX110L Totalmotorcycle.com Key Features

The Kawasaki KLX® family of off-road motorcycles are widely popular for their low maintenance, easy-to-ride character, and incredible capabilities while on trails. The five models consist of two engine configurations and are built to suit a variety of riders.

The KLX®250 dual-purpose motorcycle is built to take riders to new places. Borrowing notes from the KX™ line and Kawasaki’s racing heritage, this 2020 street legal, dual purpose motorcycle is designed to cut through the busy traffic of an inner city or climb up a back trail to see the city from a more beautiful view.

The KLX®140 motorcycle is available in three model variations, and is designed to provide a natural terrain experience with memories to last a lifetime. The powerful 144cc, four-stroke, air-cooled, single-cylinder engine features an electric starter and keyless ignition. Its broad and smooth high-revving 144cc engine utilizes a manual clutch and five-speed transmission to offer an efficient and user-friendly feel. The KLX140 uses a 17” front and 14” rear wheel, while the mid-sized KLX®140L motorcycle is equipped with a 19” front and 16” rear wheels to accommodate taller riders, providing extra ground clearance on the KLX140L. The KLX®140G comes equipped with full-size off-road wheels and tires, using a 21” front and 18” rear.

The KLX®110 is a great motorcycle for a new rider who is looking to experience dirt for the first time. A high-tensile steel frame, 30mm telescopic fork, and single rear shock provide easy handling and maximum longevity. It also incorporates an automatic centrifugal clutch system that allows easy take off and shifting through the gears, helping the rider maintain focus on the terrain and to make the most of the 112cc single-cylinder, four-stroke engine. The bigger KLX®110L motorcycle has a taller seat height (28.7” compared to 26.8” for the KLX110), longer suspension travel and an extra 1.9” of ground clearance and a four-speed transmission with a manual clutch.





2020 Kawasaki KLX110L Totalmotorcycle.com Features and Benefits
  • Taller seat height (28.7-inch) and higher ground clearance (10.4-inch)
  • Sporty styling
  • Four-speed transmission with manual clutch







2020 Kawasaki KLX110L – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2499 USD
Canada MSRP Price: $2949 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

Power

Engine

4-stroke, 1-cylinder, SOHC, air-cooled

Displacement

112cc

Bore x Stroke

53.0 x 50.6mm

Compression Ratio

9.5:1

Fuel System

Keihin PB18

Ignition

DC-CDI

Transmission

4-speed, return shift, manual clutch

Final Drive

Chain

Performance

Front Suspension / Wheel Travel

30mm hydraulic telescopic fork/5.5 in

Rear Suspension / Wheel Travel

Swingarm with single hydraulic shock/5.2 in

Front Tire

2.50×14

Rear Tire

3.00×12

Front Brakes

Mechanical Drum

Rear Brakes

Mechanical Drum

Details

Frame Type

Backbone frame, high-tensile steel

Rake/Trail

24.2°/1.9 in

Overall Length

61.4 in

Overall Width

25.6 in

Overall Height

39.0 in

Ground Clearance

10.4 in

Seat Height

28.7 in

Curb Weight

167.5 lb**

Fuel Capacity

1.0 gal

Wheelbase

42.3 in

Color Choices

Lime Green

Warranty

6 Months

Kawasaki Protection Plus™ (optional)

12, 24, or 36 months

**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

KAWASAKI CARES: Read Owner’s Manual and all on-product warnings. Always wear a helmet, eye protection and proper apparel. Never ride under the influence of drugs or alcohol. Adhere to the maintenance schedule in your Owner’s Manual. ©2019 Kawasaki Motors Corp., U.S.A.

Specifications subject to change.









2020 Kawasaki KLX110L – Totalmotorcycle.com  Canadian Specifications/Technical Details

Engine

Displacement112cc
Type4-stroke, Single
Bore and stroke53.0 x 50.6 mm
CoolingAir
Compression ratio9.5:1
Valve systemSOHC, 2 valves
Fuel systemKeihin PB18 carburetor
IgnitionDigital DC-CDI
LubricationForced lubrication (wet sump)
StartingElectric & Primary Kick

Brakes

Front: typeDrum (90 mm)
Rear: typeDrum (110 mm)

Dimensions

Overall length1,560 mm (61.4 in.)
Overall width650 mm (25.6 in.)
Overall height990 mm (39.0 in.)
Wheelbase1,075 mm (42.3 in.)
Ground clearance265 mm (10.4 in.)
Seat height730 mm (28.7 in.)
Curb mass**76 kg (167.6 lbs.)
Fuel capacity3.8 litres (0.8 gal.)

Drivetrain

Transmission4-speed, constant mesh, return shift
Final driveChain
Primary reduction ratio3.409 (75/22)
Gear ratio: 1st3.000 (36/12)
Gear ratio: 2nd1.938 (31/16)
Gear ratio: 3rd1.350 (27/20)
Gear ratio: 4th1.087 (25/23)
Final reduction ratio2.923 (38/13)
ClutchWet multi-disc

Frame

TypeHigh-tensile steel backbone
Wheel travel: front140 mm (5.5 in.)
Tire: front2.50-14 4PR
Wheel travel: rear132 mm (5.2 in.)
Tire: rear3.00-12 4PR
Caster (rake)24.2°
Trail47 mm (1.9 in.)
Steering angle (left/right)45° / 45°

Performance

Maximum Power5.4 kW {7.3 PS} @ 7,500 rpm
Maximum Torque8.0 N·m {0.82 kgƒ·m} @ 4,000 rpm

Suspension

Suspension, front30 mm telescopic fork
Suspension, rearSingle shock

Details

Warranty6 months warranty







2020 Kawasaki KLX110L – Totalmotorcycle.com European Specifications/Technical Details







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
