2020 Kawasaki Z125 Pro : REBELLIOUS STREET FIGHTER.
2020 Kawasaki Z125 Pro.
The Z125 PRO is a visually striking naked motorcycle with styling that’s a little on the dark side. It not only has edgy looks, but it’s also a blast to ride. It fits into that perfect package for those desiring a small motorcycle with plenty of capabilities, low price and great gas mileage. Thanks to the performance-oriented suspension, easy maneuverability and high fun level, it’s also a motorcycle you won’t soon outgrow. The Z125 PRO was built for the pureness of the riding experience. For 2020, the Z125 PRO is available in Metallic Matte Mysterious Gray, Pearl Storm White and Pearl Stardust White
Small on size but big on fun, the Kawasaki Z125 PRO motorcycle is a nimble streetfighter that makes a statement wherever it goes. With a 125cc engine, upright riding position and responsive street tires, it’s your invitation to the rebellious side of fun.
2020 Kawasaki Z125 Pro Totalmotorcycle.com Key Features
FUEL-INJECTED 125cc ENGINE
FOUR-SPEED MANUAL TRANSMISSION
OFFSET LAYDOWN SINGLE-SHOCK
DIGITAL LCD SCREEN WITH ANALOGUE TACHOMETER AND GEAR POSITION INDICATOR
Aggressive headlight design
Sharp LED taillight design
Distinctive shrouds and sharp lower cowl
Lightweight chassis
12-inch cast wheels
2020 Kawasaki Z125 Pro Totalmotorcycle.com Features and Benefits
2020 Kawasaki Z125 Pro – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3,199 USD
Canada MSRP Price: $3599 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
POWER
Engine 4-stroke, 1 cylinder, SOHC, 2-valve, air-cooled
Displacement 125cc
Bore x Stroke 56.0 x 50.6mm
Compression Ratio 9.8:1
Maximum Torque 7.1 lb-ft @ 6,000 rpm
Fuel System DFI® with 24mm throttle bodies
Ignition TCBI with electronic advance
Transmission 4-speed, return shift
Final Drive Sealed chain
PERFORMANCE
Front Suspension / Wheel Travel Telescopic fork/3.9 in
Rear Suspension / Wheel Travel Swingarm, single shock/4.1 in
Front Tire 100/90-12
Rear Tire 120/70-12
Front Brakes Single 200mm petal-style disc
Rear Brakes Single 184mm petal-style disc
DETAILS
Frame Type Backbone
Rake/Trail 26.0°/2.7 in
Overall Length 66.9 in
Overall Width 29.5 in
Overall Height 39.6 in
Ground Clearance 6.1 in
Seat Height 31.7 in
Curb Weight 224.8 lb**
Fuel Capacity 2.0 gal
Wheelbase 46.3 in
Color Choices Metallic Matte Mysterious Gray, Pearl Storm Gray, Pearl Stardust White
Warranty 12 Month Limited Warranty
Kawasaki Protection Plus™ (optional) 12, 24, 36 or 48 months
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). When equipped, California
evaporative emissions equipment adds approximately 2.2 lb.
2020 Kawasaki Z125 Pro – Totalmotorcycle.com Canadian Specifications/Technical Details
ENGINE
| Displacement | 125 cc |
| Type | 4-stroke, Single |
| Bore and stroke | 56 x 50.6 mm |
| Cooling | Air |
| Compression ratio | 9.8:1 |
| Valve system | SOHC, 2 Valves |
| Fuel system | Fuel injection: 24mm x 1 |
| Ignition | Digital |
| Lubrication | Forced lubrication (wet sump) |
BRAKES
| Front: type | Single 200 mm petal disc |
| Front: calipers | Single piston |
| Rear: type | Single 184 mm petal disc |
| Rear: calipers | Single-piston caliper |
DIMENSIONS
| Overall length | 1,700 mm |
| Overall width | 750mm |
| Overall height | 1,005 mm |
| Wheelbase | 1,175 mm |
| Ground clearance | 155 mm |
| Seat height | 805 mm |
| Curb mass** | 102 kg |
| Fuel capacity | 7.4 litres |
DRIVETRAIN
| Transmission | 4-speed, return |
| Final drive | Chain |
| Primary reduction ratio | 3.409 (75/22) |
| Gear ratio: 1st | 3.000 (36/12) |
| Gear ratio: 2nd | 1.938 (31/16) |
| Gear ratio: 3rd | 1.350 (27/20) |
| Gear ratio: 4th | 1.087 (25/23) |
| Final reduction ratio | 2.143 (30/14) |
| Clutch | Wet multi-disc, manual |
FRAME
| Type | Backbone, high-tensile steel |
| Wheel travel: front | 100 mm |
| Tire: front | 100/90-12 49J |
| Wheel travel: rear | 104 mm |
| Tire: rear | 120/70-12 51L |
| Caster (rake) | 26° |
| Trail | 69 mm |
| Steering angle (left/right) | 35° / 35° |
PERFORMANCE
| Maximum Power‡ | 7.1 kW {7.9 PS} @ 8,000 rpm |
| Maximum Torque‡ | 9.6 N.m {0.98 kgf.m} @ 6,000 rpm |
SUSPENSION
| Suspension, front | 30 mm inverted fork |
| Suspension, rear | Offset laydown single-shock with adjustable preload |
DETAILS
| Warranty | 12 months warranty |
2020 Kawasaki Z125 Pro – Totalmotorcycle.com European Specifications/Technical Details
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
