2021 BMW R18 Blechmann Guide

2021 BMW R18 Blechmann

2021 BMW R18 Blechmann 2021 BMW R18 Blechmann 2021 BMW R18 Blechmann 2021 BMW R18 Blechmann 2021 BMW R18 Blechmann

2021 BMW R18 Blechmann : LIVE YOUR LIFE A QUARTER MILE AT A TIME.

2021 BMW R18 Blechmann Guide.

A strong character needs a strong name. “Blechmann” is a name as strong as metal. It is also the nickname of Bernhard Naumann, a renowned customizer from Austria. Together with BMW Motorrad he presents his latest creation: The Blechmann R 18.

With the new BMW R 18, BMW Motorrad presented the brand’s first series production bike for the cruiser segment in April 2020. Like no other BMW motorcycle before it, this model stands entirely in the tradition of historical BMW motorcycles – both technically and with regard to its design. It is based on illustrious models such as the BMW R 5 and shifts the focus back to the motorcycle essentials. Reason enough for Bernhard Naumann to change as little as possible on the frame and the technology and to use only the original mounting points for the creation of the Blechmann R 18.







2021 BMW R18 Blechmann Totalmotorcycle.com Key Features

Defining customizing.
Blechmann does not perceive his work to be that of a classic customizer. “My work begins by removing parts of the original version until a white canvas remains. As the construction progresses, the design develops. I call this ‘rapid-prototyping-Blechmann-style’ “, says the customizer. This is what makes his workshop unique.

Mostly, Blechmann works alone on his craftsmanship and designs. If necessary, he gets support from hand-picked professionals. “You can’t do anything in this world on your own. I am more than glad to have a reliable personnel infrastructure”.





2021 BMW R18 Blechmann Totalmotorcycle.com Features and Benefits

The Blechmann R 18 in detail.
When starting off with a new creation, Bernhard Naumann never uses sketches in advance. He gathers his inspiration while working on the bike itself. “I draw my design directly on the object using the final material. This allows me to directly respond to the requirements and to keep an eye on the proportions at all times”, explains the designer.

For the Belchmann R 18, he initially “put the cart before the horse” in order to be able to correctly assess the proportions for the front fairing. The sporty single-seater is based on the original supporting structure of the rear fender, seat and pillion. The rear light is from Kellermann. The fuel tank has been extensively modified: For one thing, it is narrower making it sportier and exposes the engine even more. On the other hand, it features knee cut-outs, which further support the athletic line. The original steering tube was used as the basis for the stub handlebar.

Next, Blechmann customized the headlights. As with his last BMW custom bike “Giggerl”, a conversion of the BMW R nineT, the headlights were to have a subtle kidney-shaped design this time. Analogous to the classic boxer engine, Blechmann placed a filament lamp prominently in the center. Here, too, the steering angle and the forward-tilted headlamp determine the basic layout of the custom bike. Bernhard Neumann perfected his personalization efforts with discreet black paint and classic white BMW Motorrad pin-stripes. In total, the team around Blechmann worked 450 hours on his version of the BMW R 18.









2021 BMW R18 Blechmann – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ Concept Model USD
Canada MSRP Price: $ Concept Model CDN
Europe/UK MSRP Price: £ Concept Model GBP (On The Road inc 20% Vat)

2021 BMW R18 Blechmann is a concept model. The specs below are for the normal BMW R18 for reference.



Engine

Design

Air/oil cooled two-cylinder four-stroke boxer engine with two chain-driven camshafts above the drive shaft.

Bore x stroke

107.1 mm x 100.0 mm

Capacity

1,802 cc

Nominal capacity

91 hp at 4,750 rpm

Max. torque

116 lbs-ft at 3,000 rpm

Compression ratio

9.6 :1

Fuel preparation

Electronic intake pipe fuel injection, BMS-K+ electronic engine management with overrun cut-off and twin-spark ignition.

Emission control

Regulated three-way catalytic converter

Mileage / consumption

Maximum speed

over 111 mph

Fuel type

Super plus lead-free (max. 15% ethanol, E15) Gasoline (min. 90 AKI Octane Rating, max. 15% ethanol content)

Electrical system

Alternator

Permanent magnet generator 600 W (nominal capacity)

Battery

12 V / 26 Ah, maintenance-free

Power transmission

Clutch

Single-disc dry clutch

Gears

6-speed transmission

Secondary drive

Shaft drive

Suspension / brakes

Frame

Double-cradle steel frame

Front suspension / spring elements

Telescopic fork

Rear suspension / spring elements

Steel swingarm with central shock strut

Spring travel, front / rear

4.7” / 3.5”

Wheelbase

68.1”

Castor

5.9”



Steering head angle

57.3°

Wheels

Spoke wheel

Rim dimensions, front

3.5″ x 19″

Rim dimensions, rear

5.0″ x 16″

Tire, front

120/70 R 19

Tire, rear

180/65 B16

Brake, front

Twin disc brake, diameter 300 mm, four-piston fixed callipers

Brake, rear

Single disc brake, diameter 300 mm, four-piston fixed caliper

ABS

BMW Motorrad Integral ABS (partially integral)

Dimensions / weights

Seat height, unladen

27.2”

Rider step length, unladen

64.2”

Usable tank capacity

approx. 4.23 gal

of which reserve

1 gal

Length

96.1″

Height (excluding mirrors)

44.3″

Height (above mirror, at DIN empty weight)

48.5″

Width (with mirror)

38.0″

Unladen weight, fully fuelled/road-ready

761 lbs

1)

Max. permitted weight

1,234.6 lbs

Max. load (with standard equipment)

474 lbs

1) As defined in EU directive 93/93/EEC, filled with all operating fluids, fuelled to at least 90% of usable tank capacity









2021 BMW R18 Blechmann – Totalmotorcycle.com Canada Specifications/Technical Details

2021 BMW R18 Blechmann is a concept model. The specs below are for the normal BMW R18 for reference.



Design

Air/oil cooled two-cylinder four-stroke boxer engine with two chain-driven camshafts above the drive shaft.

Bore x stroke

107.1 mm x 100 mm

Capacity

1802 cm³

Nominal capacity

67 kW at 4750 rpm

Max. torque

158 Nm at 3000 rpm

Compression ratio

9.6 :1

Fuel preparation

Electronic intake pipe fuel injection, BMS-K+ electronic engine management with overrun cut-off, twin-spark ignition: BMS-O with e-gas

Emission control

Regulated three-way catalytic converter

Mileage / consumption

Maximum speed

over 180 km/h

Consumption per 100 km based on the WMTC

5.6 l/100km

Fuel type

Super plus lead-free (max. 15% ethanol, E15) ROZ 95 90 AKI

Electrical system

Alternator

Permanent magnet generator 600 W (nominal capacity)

Battery

12 V / 26 Ah, maintenance-free

Power transmission

Clutch

Single-disk dry clutch

Gears

6-gear shifting claw transmission in separate transmission housing

Secondary drive

Shaft drive

Suspension / brakes

Frame

Double-cradle steel frame with screwed-on underbeams

Front suspension / spring elements

Telescopic fork

Rear suspension / spring elements

Steel swinging fork with central shock strut

Spring travel, front / rear

120 mm / 90 mm

Wheelbase

1731 mm

Castor

150 mm

Steering head angle

57,3°

Wheels

Spoke wheel (front only)

Rim dimensions, front

3,5″ x 19″

Rim dimensions, rear

5,0″ x 16″

Tire, front

120/70 R 19

Tire, rear

180/65 B16

Brake, front

Twin disc brake, diameter 300 mm, 4-piston fixed callipers

Brake, rear

Single disc brakes, diameter 300 mm, four-piston fixed calipers

ABS

BMW Motorrad Integral ABS (partially integral)

Dimensions / weights

Seat height, unladen

690 mm

Rider step length, unladen

1630 mm

Usable tank capacity

approx. 16 l

of which reserve

approx. 4 l

Length

2440 mm

Height (excluding mirrors)

1126 mm

Height (above mirror, at DIN empty weight)

1232 mm

Width (with mirror)

964 mm

Unladen weight, fully fuelled/road-ready

345 kg

1)

Max. permitted weight

560 kg

Max. load (with standard equipment)

215 kg

1) As defined in EU directive 93/93/EEC, filled with all operating fluids, fuelled to at least 90% of usable tank capacity









2021 BMW R18 Blechmann – Totalmotorcycle.com European Specifications/Technical Details

2021 BMW R18 Blechmann is a concept model. The specs below are for the normal BMW R18 for reference.



Engine

Design

Air/oil cooled two-cylinder four-stroke boxer engine with two chain-driven camshafts above the drive shaft.

Bore x stroke

107.1 mm x 100 mm

Capacity

1802 cm³

Nominal capacity

67 kW (91 hp) at 4750 rpm

Max. torque

158 Nm at 3000 rpm

Compression ratio

9.6 :1

Fuel preparation

Electronic intake pipe fuel injection, BMS-K+ electronic engine management with overrun cut-off, twin-spark ignition: BMS-O with e-gas

Emission control

Regulated three-way catalytic converter

Mileage / consumption

Maximum speed

over 110mph

Consumption per 100 km based on the WMTC

5.6 l/100km

Fuel type

Super plus lead-free (max. 15% ethanol, E15) ROZ 95 90 AKI

Electrical system

Alternator

Permanent magnet generator 600 W (nominal capacity)

Battery

12 V / 26 Ah, maintenance-free

Power transmission

Clutch

Single-disk dry clutch

Gears

6-gear shifting claw transmission in separate transmission housing

Secondary drive

Shaft drive

Suspension / brakes

Frame

Double-cradle steel frame with screwed-on underbeams

Front suspension / spring elements

Telescopic fork

Rear suspension / spring elements

Steel swinging fork with central shock strut

Spring travel, front / rear

120 mm / 90 mm

Wheelbase

1731 mm

Castor

150 mm

Steering head angle

57,3°

Wheels

Spoke wheel (front only)

Rim dimensions, front

3,5″ x 19″

Rim dimensions, rear

5,0″ x 16″

Tyre, front

120/70 R 19

Tyre, rear

180/65 B16

Brake, front

Twin disc brake, diameter 300 mm, four-piston fixed calipers

Brake, rear

Single disc brakes, diameter 300 mm, four-piston fixed calipers

ABS

BMW Motorrad Integral ABS (partially integral)

Dimensions / weights

Seat height, unladen

690 mm

Rider step length, unladen

1630 mm

Usable tank capacity

approx. 16 l

of which reserve

approx. 4 l

Length

2440 mm

Height (excluding mirrors)

1126 mm

Height (above mirror, at DIN empty weight)

1232 mm

Width (with mirror)

964 mm

Unladen weight, fully fuelled/road-ready

345 kg

1)

Max. permitted weight

560 kg

Max. load (with standard equipment)

215 kg

1) As defined in EU directive 93/93/EEC, filled with all operating fluids, fuelled to at least 90% of usable tank capacity







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
