2021 KTM 65 SX Guide

2021 KTM 65 SX

2021 KTM 65 SX 2021 KTM 65 SX

2021 KTM 65 SX : FAST HAS NO AGE LIMIT.

Introducing the 2021 KTM 65 SX…

The KTM 65 SX is a fully-fledged race machine for young pilots aged between 8 and 12 years. This little flyer features the latest WP XACT front forks with revolutionary AER technology, ultra-cool graphics and a power delivery that sets the benchmark in its class. Like its larger counterparts, the KTM 65 SX has READY TO RACE ride dynamics, quality equipment and superior craftsmanship, providing winning performance to young competitors.





2021 KTM 65 SX Totalmotorcycle.com Key Features







2021 KTM 65 SX Totalmotorcycle.com Features and Benefits

Cooling

An intelligent cooling circuit with integrated crankcase cooling and two radiators improves the heat dissipation and ensures a constant temperature balance for consistent, high performance.

Engine

The KTM 65 SX features cutting-edge 2-stroke technology and an easy-to-shift 6-speed transmission with a hydraulic clutch. Benefitting from a reworked ignition curve, the cylinder, with its pressure-controlled exhaust valve, continues to provide class-leading power and plenty of torque.

Brakes

The front and rear brakes have massive 4 piston calipers that grip lightweight wave brake discs – 198 mm front and 160 mm rear. The hydraulic brake system is easy to control and ensures the best deceleration and the highest standard when it comes to performance.

Frame

The modern frame is made from lightweight, high strength chromoly steel profiles and combines maximum longitudinal stiffness with optimum torsional rigidity. It guarantees easy handling and precise cornering, but also outstanding stability.

Swingarm

The KTM 65 SX is fitted with a lightweight cast aluminum swingarm. Conceived using the latest in calculation and simulation software, the focus of the design was for minimum weight, optimum stiffness and precisely defined flexibility. In addition, it features a robust 2-compound chain guide, similar to the full-size models.

Wheels

Like the full-size KTM Factory racers, the 65 SX has super lightweight, black anodized, aluminum rims providing the highest strength and durability. The OEM MAXXIS knobby tires grip superbly on any surface.

Front suspension

The KTM 65 SX is the first model in its class to be fitted with a modern, fully adjustable air fork: the WP XACT fork with AER technology. The upside-down front fork with a 35 mm tube diameter and 215 mm of travel ensures outstanding comfort, damping characteristics and directional stability. Another main benefit for junior riders is that the air spring fitted in the left fork leg can be adjusted perfectly to the rider’s weight using a simple air pump.

Rear suspension

The high quality WP XACT shock absorber is linked directly to the swingarm, providing excellent damping performance. It is fully adjustable, meaning you can set the damping perfectly to suit the rider’s preference and track conditions. The shock absorber allows for 270 mm of rear wheel travel.

Brakes

The front and rear brakes have massive 4 piston calipers that grip lightweight wave brake discs – 198 mm front and 160 mm rear. The hydraulic brake system is easy to control and ensures the best deceleration and the highest standard when it comes to performance.

Frame

The modern frame is made from lightweight, high strength chromoly steel profiles and combines maximum longitudinal stiffness with optimum torsional rigidity. It guarantees easy handling and precise cornering, but also outstanding stability.





2021 KTM 65 SX – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $5099 USD
Canada MSRP Price: $ 5899 CDN
Europe/UK MSRP Price: £ 4249 (On The Road inc 20% Vat)

ENGINE

  • TRANSMISSION6-speed
  • STARTERKickstarter
  • STROKE40.8 mm
  • BORE45 mm
  • CLUTCHWet, multi-disc clutch, Formula hydraulics
  • DISPLACEMENT64.9 cm³
  • DESIGN1-cylinder, 2-stroke engine

CHASSIS

  • WEIGHT (WITHOUT FUEL)53 kg
  • TANK CAPACITY (APPROX.)3.5 l
  • FRONT BRAKE DISC DIAMETER198 mm
  • REAR BRAKE DISC DIAMETER160 mm
  • FRONT BRAKEDisc brake
  • REAR BRAKEDisc brake
  • CHAIN1/2 x 1/4″
  • FRAME DESIGN25CrMo4 steel central-tube frame
  • FRONT SUSPENSIONXACT 35 WP Upside-Down fork, Ø 35 mm
  • GROUND CLEARANCE280 mm
  • REAR SUSPENSIONXACT WP mono shock
  • SEAT HEIGHT750 mm
  • STEERING HEAD ANGLE64.5 °
  • SUSPENSION TRAVEL (FRONT)215 mm
  • SUSPENSION TRAVEL (REAR)270 mm







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
