2022 Yamaha Super Tenere ES Guide

2022 Yamaha Super Tenere ES

2022 Yamaha Super Tenere ES 2022 Yamaha Super Tenere ES 2022 Yamaha Super Tenere ES 2022 Yamaha Super Tenere ES 2022 Yamaha Super Tenere ES

2022 Yamaha Super Tenere ES: GO BEYOND.

Introducing the new 2022 Yamaha Super Tenere ES…

Rugged, durable and built for superior long distance adventure touring and exploring beyond the pavement.

Sophistication is the name of the game with the Super Ténéré ES. Does the convenience of adjusting your suspension without ever getting off your bike sound interesting? With the simple push of a button, you can adjust both preload and damping settings. Add heated grips and a cruise control system to the mix and you have a machine that is truly worthy of being called the Ultimate Transcontinental Adventurer.





2022 Yamaha Super Tenere ES Totalmotorcycle.com Key Features
  • 1199cc, liquid-cooled, DOHC, 4-valve, inline twin produces serious torque and horsepower.
  • 26 degree engine slant
  • DOHC 4-valve cylinder head design
  • 2- spark plugs per cylinder
  • 42,000 km valve adjustment interval
  • Short skirt, forged aluminum pistons

Compact & Powerful Engine
With an exceptionally compact 1199cc parallel twin and a unique 270° crank for excellent torque and traction, the Super Ténéré ES is built for adventure. Engine mass is kept low for great handling. Narrow two-cylinder inline engine is slim and compact for carving tight lines in twisty mountain roads.

Electronic Suspension
Electronically adjusted suspension makes finding the right setting as easy as pushing a button. With four pre-load settings, three damping presets and an additional seven fine-tuning damping adjustments, the Super Ténéré ES suspension can be dialed perfectly to meet the needs of the rider, passenger and cargo amount and terrain.

All-Purpose Drivetrain
Wide-ratio six-speed transmission has the right gear, whether on the open highway or off-road. The durable enclosed shaft drive is protected from the elements while providing a direct, responsive connection to the rear wheel.

Advanced Fuel Injection
Twin downdraft throttle body fuel injection with YCC-T (Yamaha Chip Controlled Throttle) delivers optimum throttle control and acceleration. Two-position “D-Mode” (Drive Mode) throttle response allows the rider to adjust mapping for conditions or preferences.

Traction Control
Traction control lets the rider get on the gas with confidence. This very advanced system regulates ignition timing, fuel injection and throttle valve opening based on wheel spin, providing a smooth response that is not abrupt like the competitors. Three modes are available to match rider preference, including off.

Assured Braking
The Super Ténéré ES has both an anti-lock braking system (ABS) and Unified Braking System (UBS). With UBS, squeezing the front brake lever also provides some rear-wheel braking while pressing the rear brake first overrides UBS for traditional separate front and rear braking action.

Convenience & Comfort
Whether riding across town or crossing a continent, rider comfort and convenience are important. Super Ténéré ES delivers with its cruise control, adjustable seat height and windshield, tunable front and rear suspension, low-maintenance shaft drive, centerstand and more.



STORAGE

The Super Ténéré ES comes standard with water-resistant, 32-litre anodized aluminum side cases. Tough and roomy, these cases are capable of carrying and protecting just about anything you throw at them. The locking system uses the bike’s ignition key, eliminating the need for an extra set of keys.



PERFORMANCE

The Super Ténéré ES is built for adventure, with an exceptionally compact 1,199 cc parallel twin using a unique 270° crank for excellent torque and traction. Engine mass is kept low for great handling. The narrow inline twin-cylinder engine is slim and compact for carving tight lines in twisty mountain roads.



COMFORT

In addition to the KYB electronic suspension, the Super Ténéré ES also comes with heated grips, cruise control and a four-position adjustable windscreen. Balance your adventurous side with convenience and comfort on the Super Ténéré ES!









2022 Yamaha Super Tenere ES Totalmotorcycle.com Features and Benefits

ENGINE

  • Crossplane Crankshaft Engine
    The 1199cc parallel twin, liquid-cooled engine features a unique 270° crossplane crankshaft for superior traction. It’s almost like having a big-bore thumper without the uncomfortable vibration.
  • Adventure-Ready Motor
    The compact engine design uses a dry-sump oil supply inside the crankcase to boost ground clearance while a side-mounted radiator makes the Super Ténéré ES surprisingly narrow, protecting it from rocks and debris.
  • Advanced Fuel Injection
    The downdraft twin bore fuel injection system with 12-hole injectors is tuned for on- or off-road adventures and is equally made for at-home commuting as it is on long stretches of open highway.
  • Traction Control
    Proven YCC-T fly-by-wire technology allows for an advanced traction control system by regulating ignition timing and fuel injection volume and throttle valve opening based on rear wheel spin. Three rider-selected modes are available to match conditions and the rider’s preference.
  • Cruise Control
    The Super Ténéré ES includes a cruise control system powered by the YCC-T. The rider can easily select or adjust a set speed to ease long-distance touring on the highway.
  • D-Mode Throttle
    Yamaha’s D-Mode throttle offers two response settings: “T-mode” for Touring and general riding to give a softer response and “S-mode” for Sport riding for when the rider wants the most performance possible.
  • All-Purpose Drivetrain
    Wide-ratio six-speed transmission has gear ratios optimized for everything from slow dirt roads to higher speed sport riding. The durable enclosed shaft drive is protected from the elements while providing a direct, responsive connection to the rear wheel.



CHASSIS/SUSPENSION

  • Electronic Suspension
    Electronically adjusted suspension makes finding the right setting as easy as pushing a button. With four pre-load settings, three damping presets and an additional seven fine-tuning damping adjustments, the Super Ténéré ES suspension can be perfectly dialed to meet the needs of the rider, passenger and cargo amount and terrain.
  • Robust Steel Chassis
    The steel frame is designed to reduce rider fatigue during long rides. Using a steel main frame offers the best balance of strength and flexibility, so it can help absorb jolts from uneven road surfaces.
  • Assured Braking
    The ABS and Unified Brake System (UBS) work together to help prevent wheel lock during braking. This system allows the rider to operate front and rear brakes together by simply pulling the front brake lever, which is especially helpful when riding while standing on the pegs. Applying the rear brake first overrides UBS to provide traditional separate front and rear brake control.
  • Customizable Comfort
    The Super Ténéré ES comes equipped with both adjustable windshield and seat height. One inch of seat height adjustment provides a lower height for shorter riders or a roomier riding position for taller riders in the high position while the windscreen can be easily adjusted 2.3 inches vertically without tools.
  • Adventure-Ready Ergonomics
    The grooved foot pegs show Yamaha’s attention to detail. While the rider is seated, rubber cushions provide excellent comfort. When the rider stands to tackle more technical riding conditions, the rubber compresses which lets the rider’s boots contact the metal foot peg surface.



ADDITIONAL FEATURES

  • Luggage Ready
    The optional flexible luggage system design has three possible setups: standard with no top case or side bags, top case installed, or side cases installed. Included in the bike’s design, these accessories enhance the look of the Super Ténéré ES.
  • Beefy Controls
    Wraparound handlebar brush guards come standard and are attached to a tough rubber-mounted handlebar.
  • Standard Centerstand
    Both side stand and centerstand are provided for complete parking convenience.











2022 Yamaha Super Tenere ES – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $16299 USD
Canada MSRP Price: $19299 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)

Engine Type 1199cc liquid-cooled inline 2-cylinder; DOHC; 8 valves
Bore x Stroke 98.0mm x 79.5mm
Compression Ratio 11.0:1
Fuel Delivery Fuel Injection with YCC-T
Ignition TCI: Transistor Controlled Ignition
Transmission 6-speed; multi-plate wet clutch
Final Drive Shaft
Suspension / Front 43mm inverted fork; electronically adjustable
compression and rebound damping; 7.5-in travel
Suspension / Rear Monoshock; electronically adjustable preload and
rebound damping; 7.5-in of travel
Brakes / Front Dual 310mm hydraulic disc, Unified Brake System and ABS
Brakes / Rear 282mm single disc, Unified Brake System and ABS
Tires / Front 110/80R19
Tires / Rear 150/70R17
L x W x H 88.8 in x 38.6 in x 55.5 in
Seat Height 33.3 or 34.3 in
Wheelbase 60.6 in
Rake (Caster Angle) 28.0°
Trail n/a
Maximum Ground Clearance n/a
Fuel Capacity 6.1 gal
Fuel Economy** 43 mpg
Wet Weight*** 584 lb
Warranty 1 Year (Limited Factory Warranty)
Color Matte Raven Black







2022 Yamaha Super Tenere ES – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE Liquid-cooled, DOHC, 8-valves (4-valves / cyl), inline twin
DISPLACEMENT 1199 cc
BORE AND STROKE 98 x 79.5 mm
COMPRESSION RATIO 11:1
MAXIMUM TORQUE 11.9 kg-m (86 ft-lbs.) @ 6,000 rpm
ENGINE MANAGEMENT YCC-T, D-Mode, Traction Control & Cruise Control
FUEL DELIVERY Mikuni 46 mm throttle body F.I
ESTIMATED FUEL CONSUMPTION± 18.2kpl / 51.4mpg (Imp.)
LUBRICATION Dry sump
IGNITION / STARTING TCI / Electric
TRANSMISSION 6-speed
FINAL DRIVE Shaft

CHASSIS
SUSPENSION (FRONT) Electronically adjustable KYB inverted 43mm fork / 190 mm (7.5″) wheel travel
SUSPENSION (REAR) Electronically adjustable KYB link Monocross / 190 mm (7.5″) wheel travel
BRAKES (FRONT) Dual 310 mm discs / 4-piston calipers / ABS equipped & unified
BRAKES (REAR) 282 mm disc / single piston caliper / ABS equipped & unified
TIRES (FRONT) 110/80R19 (tubeless)
TIRES (REAR) 150/70R17 (tubeless)

CRITICAL DATA
LENGTH 2,255 mm (88.8″)
WIDTH 980 mm (38.6″)
HEIGHT 1,410 mm (55.5″) to 1470mm (57.9″)
WHEELBASE 1,540mm (60.6″)
RAKE / TRAIL 28 degrees / 126 mm
GROUND CLEARANCE 190 mm (7.5″)
SEAT HEIGHT 845 mm (33.3″) or 870 mm (34.3″)
FUEL CAPACITY 23 litres (5.1 Imp. gal.)
WET WEIGHT 265 kg (584 lbs)
COLOUR(S) Ceramic Ice
Tech Black







2022 Yamaha Super Tenere ES – Totalmotorcycle.com European Specifications/Technical Details

TBA





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
