2023 BMW G310GS Guide

2023 BMW G310GS

2023 BMW G310GS 2023 BMW G310GS 2023 BMW G310GS 2023 BMW G310GS

2023 BMW G310GS: COSMIC COOL.

Introducing the 2023 BMW G310GS…

A THIRST FOR ADVENTURE EVERY DAY

Be spontaneous. Break the routine. With the BMW G 310 GS, your everyday life becomes an adventure. Thanks to the optimized engine with Ride by Wire and a slipper clutch, you can master the urban jungle and make trips into the surrounding areas. Your adventure doesn’t have to be big to be unforgettable. The key is to experience the #SpiritOfGS every day.

The G 310 GS stands for pure riding enjoyment – whether making daily rides around the city or trips into the surrounding areas. In the typical relaxed GS seat position, you have a perfect view of every adventure.







2023 BMW G310GS Totalmotorcycle.com Key Features

Standard equipment

  • BMW Motorrad ABS
  • Electric Ride by Wire throttle
  • Stainless steel exhaust system
  • LED headlight, turn indicators and rear light
  • Adjustable brake and clutch levers
  • Luggage carrier

Optional accessories

  • Low seat
  • High seat
  • Topcase light
  • Topcase, 30 l
  • Heated grips
  • 12 V and USB socket
  • New Version Basic Cosmic black 3. Polar white no longer available.
  • New Style Sport Polar white/Racing blue metallic. Style Triple Black no longer available.
  • New Style Rallye Kalamata metallic matt. Cyanite blue metallic no longer available.
  • Colors
    • Cosmic Black 3 replaces Polar White.
    • Style Sport Polar White/Racing Red replaces Triple Black.
    • Style Rallye Kalamata Dark Gold Metallic replaces Style Rallye Kyanite Blue Metallic.

    Equipment

    • No equipment changes.





2023 BMW G310GS Totalmotorcycle.com Features and Benefits

HIGHLIGHTS FOR THE URBAN JUNGLE
The G 310 GS is the perfect companion for discovering your city, beyond its borders and off the asphalt roads. Thanks to the comfortable GS ergonomics and high-quality equipment, this bike is designed for everyday riding.

  • Effortless single-cylinder engine
  • Adjustable clutch and brake levers
  • Typical GS flyline
  • Gold anodized inverted fork
  • License plate carrier with LED brake lights and flashing turn indicators
  • LED headlights are standard equipment
  • Suspension element
  • Convenient luggage carrier

Get your bike under control
The clutch and brake levers can be adjusted to four levels, conveniently adapting to the reach of your hands. This means that they move up to six millimeters closer to the handlebar. And you can effortlessly keep a grip on everything.

3 year warranty
Ride on & on & on.

  • POWERFUL DRIVE
  • 20lbs-ft maximum torque at 7,500 rpm
  • 313cc capacity
  • We see the technical drawing of the single-cylinder engine of the G 310 GS.
  • 3.0 gallon fuel tank capacity
  • 7.1 inches of suspension travel, front and rear.
  • Water-cooled, four-stroke single-cylinder engine

Feel the dynamics
The powerful single-cylinder engine now comes with standard Ride by Wire. This makes the throttle response even more effortless, and the engine maintains composure when you get under way thanks to automatic idling. You can rely on the self-reinforcing slipper clutch when starting up and switching gears. And because of its efficient design, the engine functions economically.

STRIKING DESIGN, INDIVIDUAL STYLE
The G 310 GS comes with a dark engine area in Titanium Gray Metallic. Which combination do you like best?

Individualize it the way you like
Now it’s your turn: Prepare your G 310 GS with a large selection of accessories for your daily adventure. Decide on one of our two suggestions or configure your own bike according to your own imagination.







2023 BMW G310GS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $5,695 USD
Canada MSRP Price: $6,895 CDN
Europe/UK MSRP Price: from £5,890 GBP (total selling price)

Engine

Type

Water-cooled, single-cylinder 4-stroke engine, four valves, two overhead camshafts and wet sump lubrication

Bore / stroke

80 mm x 62.1 mm

Capacity

313 cc

Rated output

34 hp at 9,250 rpm

Max. torque

20 lbs-ft at 7,500 rpm

Compression ratio

10.9 : 1

Mixture control

Electronic fuel injection

Emission control

Closed-loop 3-way catalytic converter

Performance / fuel consumption

Maximum speed

88 mph

Fuel type

Unleaded regular

Electrical system

Alternator

Three-phase alternator 308 W

Battery

12 V / 8 Ah

Power transmission

Clutch

Multi-disc oil bath (anti-hopping) with self-reinforcement

Gearbox

Constant mesh 6-speed gearbox integrated in crankcase

Drive

X-ring chain with shock absorption in the real wheel hub

Chassis / brakes

Frame

Tubular space frame

Front wheel location / suspension

Inverted fork, 41 mm

Rear wheel location / suspension

Cast aluminum dual swing arm, central spring strut, spring pre-load adjustable

Suspension travel, front / rear

7.1″ / 7.1″

Wheelbase

55.9″

Caster

3.9″

Steering head angle

63.3°

Wheels

Cast aluminum wheels

Rim, front

2.50 x 19″

Rim, rear

4.00 x 17″

Tire, front

110/80 R19

Tire, rear

150/70 R17

Brake, front

Single disc, diameter 11.8″, 4-piston fixed caliper, radially mounted

Brake, rear

Single disc, diameter 9.5″, single-piston floating caliper

ABS

BMW Motorrad ABS

Dimension / weights

Seat height

32.8”
(OE low seat: 32.3”, OE high seat: 33.4”

Inner leg curve

73.6”
(OE low seat: 72.4”, OE high seat: 74.8”)

Usable tank volume

3.0 gal.

Reserve

approx. 0.25 gal.

Length

81.7”

Height (excl. mirrors)

48.8”

Width (excl. mirrors)

34.6”

Unladen weight, road ready, fully fueled

386 lbs.

1)

Permitted total weight

760 lbs.

Payload (with standard equipment)

374 lbs.

1) According to Directive (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable tank capacity.











2023 BMW G310GS – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Rated output

25 kW (34 hp) at 9,250 rpm

Emission control

Closed-loop 3-way catalytic converter

Type

Water-cooled, single-cylinder, four-stroke engine with four rocker arm valves per cylinder, two overhead camshafts and wet-sump lubrication

Bore x stroke

80 mm x 62.1 mm

Capacity

313 cc

Max. torque

20.6 lbs-ft at 7,500 rpm

Compression ratio

10.9 : 1

Mixture control

Electronic injection

Exhaust emission standards

EU 5

Performance / fuel consumption

Maximum speed

143 km/h

Fuel consumption per 100 km based on WMTC

3.5 l

CO2 emission based on WMTC

80 g/km

Fuel type

Regular unleaded (max. 15% ethanol, E15), 91 ROZ/RON, 87 AKI

Electrical system

Alternator

Three-phase alternator with 308 W (nominal power)

Battery

12 V / 8 Ah, maintenance-free

Power transmission

Clutch

Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement

Gearbox

Claw-shifted 6-speed gearbox integrated in the transmission housing

Drive

Endless X-ring chain, jerk damping in the rear hub

Chassis / brakes

Frame

Tubular space frame

Front wheel location / suspension

Upside-down telescopic fork, diameter 41 mm

Rear wheel location / suspension

Die-cast aluminum swingarm, direct-attached central shock absorber, adjustable spring base

Suspension travel, front / rear

180 mm / 180 mm

Wheelbase

1,420 mm

Castor

98 mm

Steering head angle

63.3°

Wheels

Aluminium cast wheels

Rim, front

2.50 x 19″

Rim, rear

4.00 x 17″

Tire, rear

150/70 R17

Brake, front

Single disc brake, diameter 300 mm, 4-piston radial brake caliper

Brake, rear

Single disc brake, diameter 240 mm, 1-piston floating caliper

ABS

BMW Motorrad ABS

Dimensions / weights

Seat height at unladen weight

32.8″ (seat low: 32.3″; seat high: 33.5″)

Inner leg curve at unladen weight

74″ (seat low: 72.4″; seat high: 75″)

Usable tank volume

11.5 l

Reserve

approx. 1 l

Length

2,075 mm

Height

1,230 mm (without mirror, at DIN unladen weight)

Width

880 mm (above mirror)

Unladen weight, road ready, fully fuelled

175 kg

1)

Permitted total weight

345 kg

Payload (with standard equipment)

170 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.







2023 BMW G310GS – Totalmotorcycle.com European Specifications/Technical Details

Engine

Type

Water-cooled, single-cylinder 4-stroke engine, four valves, two overhead camshafts and cam followers, wet sump lubrication

Bore / stroke

80 mm x 62.1 mm

Capacity

313 cc

Ratet output

25 kW (34 hp) at 9,250 rpm

Max. torque

28 Nm at 7,500 rpm

Compression ratio

10.9 : 1

Mixture control

Electronic fuell injection

Emission control

Closed-loop 3-way catalytic converter, emission standard EU-5

Performance / fuel consumption

Maximum speed

143 km/h

Fuel consumption per 100 km based on WMTC

3.5 l

CO2 emission based on WMTC

80 g/km

Fuel type

Unleaded regular, minimum octane number 91 (RON)

Electrical system

Alternator

Three-phase alternator 308 W

Battery

12 V / 8 Ah, maintenance-free

Power transmission

Clutch

Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement

Gearbox

Constant mesh 6-speed gearbox integrated in crankcase

Drive

Endless X-ring chain with shock damping in rear wheel hub

Chassis / brakes

Frame

Tubular space frame

Front wheel location / suspension

Upside down fork, Ø 41 mm

Rear wheel location / suspension

Cast aluminium dual swing arm, central spring strut, spring pre-load adjustable

Suspension travel, front / rear

180 mm / 180 mm

Wheelbase

1,420 mm

Castor

98 mm

Steering head angel

63,3°

Wheels

Cast aluminium wheels

Rim, front

2.50 x 19″

Rim, rear

4.00 x 17″

Tyre, front

110/80 R19

Tyre, rear

150/70 R17

Brake, front

Single disc, diameter 300 mm, 4-piston fixed caliper, radially bolted

Brake, rear

Single disc, diameter 240 mm, single-piston floating caliper

ABS

BMW Motorrad ABS

Dimension / weights

Seat height

835 mm
(OA low seat: 820 mm, OE high seat: 850 mm)

Inner leg curve

1,870 mm
(OA low seat: 1,840 mm, OE high seat: 1,900 mm)

Usable tank volume

11.5 l

Reserve

approx. 1 l

Length

2,075 mm

Height (excl. mirrors)

1,230 mm

Width (excl. mirrors)

880 mm

Unladen weight, road ready, fully fuelled 1)

175 kg

1)

Permitted total weight

345 kg

Payload (with standard equipment)

170 kg

1) According to Directive (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable tank capacity.











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
