2023 BMW R nineT Pure Guide

2023 BMW R nineT Pure

2023 BMW R nineT Pure 2023 BMW R nineT Pure 2023 BMW R nineT Pure 2023 BMW R nineT Pure

2023 BMW R nineT Pure: PURE AS WIND DRIVEN SNOW.

Introducing the 2023 BMW R nineT Pure…

PURIST, REDUCED, SELF-CONFIDENT

Reduced to the essential. But full of self-confidence. The BMW R nineT Pure. The powerful air/oil-cooled engine gives you goosebumps on the tarmac. Its classic roadster look with the compact fuel tank and slim rear reminds you of the early days of BMW Motorrad. The purist design and the many possibilities for customization invite you to create your very own personal bike. One that no one else rides. Give your ideas free rein and immerse yourself in the world of #Soulfuel with the R nineT Pure.

With the R nineT Pure, you get to live out your dream of motorcycling in classic roadster design. The centerpiece is the iconic air/oil-cooled boxer engine. It also has features such as the “Rain” and “Road” Ride Modes and an adjustable spring strut.

“The perfect bike to create your personal R nineT Pure.” Norbert Rebholz (Project manager R nineT)





2023 BMW R nineT Pure Totalmotorcycle.com Key Features

Standard equipment:

  • LED headlights
  • Speed indicator with on-board computer
  • Automatic Stability Control (ASC)
  • Ride Modes: Rain & Road
  • Drive train and final drive in Black
  • USB charging socket

Optional equipment

  • Heated grips
  • Paint sets
  • Spoked wheels

Optional accessories

  • counter with on-board computer
  • Handbrushed aluminum parts
  • Tail short
  • Tail Tracker
  • Function integrated turning signals
  • Cylinder head covers 2V-Style







2023 BMW R nineT Pure Totalmotorcycle.com Features and Benefits

HIGHLIGHTS FOR EVERY PERSONALITY
Choose your direction
Lend your R nineT Pure an individual design with one of three exciting colors. Which one do you want to start with?

  • Adjustable spring strut
  • Modern LED turn indicators
  • Twin-cylinder boxer engine
  • Compact tank
  • Classic round speedometer
  • Single-pipe exhaust system
  • Classically-painted front-wheel cover
  • LED headlights are standard equipment

Bring your idea to life
The R nineT Pure is your invitation to the customizing world, where the possibilities are endless. The high-quality Option 719 billet pack Classic II shows your love of detail. And with the Option 719 Wheel Classic, you’ll feel the tingling sensation a little more thanks to the tubeless spoked wheels.

TRIED-AND-TESTED DRIVE WHEEL

Enjoy every single mile
The air/oil-cooled Boxer engine boasts a mighty 1,170 cc displacement. With its 109 hp, it ensures exciting moments on every journey – whether in the city or beyond. Because in the 4,000–6,000 rpm range, it now runs even smoother thanks to its better-rounded power and torque curve.

  • 85lbs.-ft. max. torque at 6,000 rpm
  • 1,170cc capacity
  • 483lbs. unladen weight, road ready, fully fuelled
  • 31.7 inch seat height
  • Air/oil-cooled twin-cylinder four-stroke boxer engine

FEATURES FOR SAFE, FUN RIDING

Let off some steam
With the available Ride Modes Pro, you get the most out of your machine. This is because in Dynamic mode, the ASC and DTC control systems intervene later – making driving on dry tarmac much more dynamic. And with available adaptive headlights, you can enjoy the next bend even after dark. This is because it improves illumination of the inner section of the curve up to a lean angle of 25 degrees. This way, you can better see where you’re going.

3 year warranty
Ride on & on & on.

Get up to 3-years or 36,000 miles warranty on all new motorcycles.

  • Version Basic: Tealblue metallic matt no longer available.
  • Option 719: New color Underground uni/Lightwhite uni. Blackstorm metallic/Racing red no longer available.
  • Option 719: New color Pollux metallic/Lightwhite uni. Cosmic blue metallic/Lightwhite no longer available.
  • Colors
    • Teal Blue Metallic Matte removed.
    • Option 719 Underground / Light White replaces Blackstorm Metallic / Racing Red.
    • Option 719 Pollux Metallic / Light white replaces Cosmic Blue / Light White.
    • Mineral Gray remains unchanged.

    Equipment

    • No equipment changes.

    Individual Options – Spoked Wheels, Design Option Silencer, Low Suspension and Heated Grips.







2023 BMW R nineT Pure – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $10,995 USD
Canada MSRP Price: $13,845 CDN
Europe/UK MSRP Price: from £11,750 GBP (total selling price)

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Rated output

109 hp at 7,250 rpm

Max. torque

85.5 lbs. at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic port fuel injection

Emission Control

Closed-loop 3-way catalytic converter

Performance / fuel consumption

Maximum speed

over 124 mph

Fuel type

Unleaded super (premium)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Constant mesh 6-speed gearbox with helical gear teeth

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminum single-sided swing arm with BMW Motorrad paralever, central spring strut, spring preload continuously adjustable by handwheel, rebound damping continuously adjustable

Suspension travel, front / rear

4.7″ / 4.7″

Wheelbase

58.8”

Caster

4.1″

Steering head angle

63.4°

Wheels

Spoke wheels

Rim, front

3.50 x 17″

Rim, rear

5.50 x 17″

Tire, front

120/70 ZR 17

Tire, rear

180/55 ZR 17

Brake, front

Twin-disc brakes, diameter 12.6″, 4-piston calipers

Brake, rear

Single disc brake, diameter 10.4″, double-piston floating caliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

31.7”

Inner leg curve

70.3”

Usable tank volume

4.5 gal.

Reserve

app. 0.9 gal

Length

82.9”

Height (incl. mirrors)

48.8”

Width (incl. hand levers)

34.8”

Unladen weight, road ready, fully fueled

483 lbs.

1)

Permitted total weight

948 lbs.

Payload (with standard equipment)

465 lbs.

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable tank capacity.







2023 BMW R nineT Pure – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Rated output

80 kW (109 hp) at 7,250 rpm

Emission control

Closed-loop 3-way catalytic converter

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two overhead camshafts, four radially arranged valves and central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Max. torque

85.5 lbs-ft at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic intake pipe injection

Exhaust emission standards

EU 5

Performance / fuel consumption

Maximum speed

over 200 km/h

Fuel consumption per 100 km based on WMTC

5.1 l

CO2 emission based on WMTC

119 g/km

Fuel type

Super unleaded (max. 15% ethanol, E15), 95 ROZ/RON, 90 AKI

Electrical system

Alternator

Three-phase alternator with 720 W (nominal power)

Battery

12 V / 12 Ah, maintenance-free

Power transmission

Clutch

Single-disc dry clutch, hydraulically operated

Gearbox

Claw-shifted 6-speed gearbox with helical gears

Drive

Cardan

Chassis / brakes

Frame

Three-part frame concept consisting of front and two-part rear frame, co-supporting engine-transmission unit, pillion frame can be removed for solo operation

Front wheel location / suspension

Telescopic fork, diameter 43 mm

Rear wheel location / suspension

Cast aluminium single-sided swingarm with BMW Motorrad Paralever, central spring strut, spring preload fully adjustable by hook wrench, rebound damping adjustable

Suspension travel, front / rear

125 mm / 120 mm

Wheelbase

1,493 mm

Castor

105 mm

Steering head angle

63.4°

Wheels

Aluminium cast wheels

Rim, front

3.50 x 17″

Rim, rear

5.50 x 17”

Tire, front

120/70 ZR17

Tire, rear

180/55 ZR17

Brake, front

Twin disc brake, diameter 320 mm, 4-piston fixed caliper

Brake, rear

Single disc brake, diameter 265 mm, 2-piston floating caliper

ABS

BMW Motorrad ABS

Dimensions / weights

Seat height at unladen weight

31.7″

Inner leg curve at unladen weight

70.3″

Usable tank volume

17 l

Reserve

approx. 3.5 l

Length

2,105 mm

Height

1,240 mm (above mirror, at DIN unladen weight)

Width

865 mm (above hand lever)

Unladen weight, road ready, fully fuelled

219 kg

1)

Permitted total weight

430 kg

Payload (with standard equipment)

211 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.







2023 BMW R nineT Pure – Totalmotorcycle.com European Specifications/Technical Details

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Ratet output

80 kW (109 hp) at 7,250 rpm

Max. torque

116 Nm at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic intake pipe injection

Emission Control

Closed-loop 3-way catalytic converter, emission standard EU-5

Performance / fuel consumption

Maximum speed

over 200 km/h

Fuel consumption per 100 km based on WMTC

5.1 l

CO2 emission based on WMTC

119 g/km

Fuel type

Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah, maintenance-free

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Constant mesh 6-speed gearbox with helical gear teeth

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removeable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminum single-sided swingarm with BMW Motorrad paralever, central spring strut, spring preload continuously adjustable by handwheel, rebound damping continuously adjustable

Suspension travel, front / rear

120 mm / 120 mm

Wheelbase

1,493 mm

Castor

105 mm

Steering head angle

63.4°

Wheels

Spoke wheels

Rim, front

3.50 x 17″

Rim, rear

5.50 x 17″

Tyre, front

120/70 ZR 17

Tyre, rear

180/55 ZR 17

Brake, front

Twin-disc brakes, diameter 320 mm, 4-piston callipers

Brake, rear

Single disc brake, diameter 265 mm, double-piston floating calliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

805 mm

Inner leg curve

1,785 mm

Usable tank volume

17 l

Reserve

app. 3.5 l

Length

2,105 mm

Height (incl. mirrors)

1,240 mm

Width (incl. hand levers)

865 mm

Unladen weight, road ready, fully fuelled

219 kg

1)

Permitted total weight

430 kg

Payload (with standard equipment)

211 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable tank capacity.







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
