2023 BMW R nineT Urban G/S Guide

2023 BMW R nineT Urban G/S

2023 BMW R nineT Urban G/S 2023 BMW R nineT Urban G/S 2023 BMW R nineT Urban G/S 2023 BMW R nineT Urban G/S

2023 BMW R nineT Urban G/S: DO-IT-ALL EVERYTHING.

Introducing the 2023 BMW R nineT Urban G/S…

AUTHENTIC, STRIKING, BALANCED

As the crow flies? No, the detour is the destination. And when it comes to gravel, the R nineT Urban G/S is also in its element. Its design is reminiscent of the first G/S models, the legendary BMW R 80 G/S. And with it, the idea that simply anything is possible. The geometry with the upright, relaxed seating position, the well-balanced handling and the boxer with its unmistakable sound, challenge you to rewrite history with the R nineT Urban G/S – your history. Personal, individual and truly #Soulfuel.

The design of the R nineT Urban G/S makes you immediately think of the first G/S models. At that time they were absolute pioneers in terms of technology and design. And even today the R nineT Urban G/S boasts impressive technical data and progressive equipment.

“The bike that brings back memories. Jump on and off you ride, it really is better to travel than to arrive. ” – Ulli Sengenberger





2023 BMW R nineT Urban G/S Totalmotorcycle.com Key Features

Standard equipment

  • LED headlight and turn indicators
  • Speed indicator with on-board computer content
  • Automatic Stability Control (ASC)
  • Ride Modes: Rain & Road
  • Drive train and final drive in black
  • USB charging socket



Optional equipment

  • Ride Modes Pro (incl. Ride Mode: Dirt)
  • Cruise control and heated grips
  • Adaptive Headlight
  • Cross spoked wheels I & II



Optional accessories

  • counter with on-board computer
  • Tail short
  • Tail Tracker
  • Function integrated turning signals
  • Cylinder head covers 2V-Style







2023 BMW R nineT Urban G/S Totalmotorcycle.com Features and Benefits

TRADITION – NEWLY DESIGNED
A look back and yet forward
The typical G/S look was a must-have in the 80s. The colors of the R nineT Urban G/S are an unrivaled reminder of this time.

  • Classic round instrument speedometer
  • Classic color scheme
  • Boxer engine
  • Tank shape and snorkel cover
  • Distinctive front
  • Double-flow exhaust system with heat protection
  • Roughly toothed footrests
  • LED headlight and turn indicators

Colour, graphic and surface design R nineT
Create your own legend
There is nothing more beautiful than strong role models. And this applies to design, too. Nevertheless, the R nineT Urban G/S offers you several possibilities to become unforgettable yourself. With the Option 719 billet pack Classic, you can immediately see the quality and love for the craft. And the gold anodized cross-spoked wheels really get your individuality going.

THIS ONE KNOWS HOW TO HAVE FUN

For any punchline
Power through the city traffic or prefer to take a spontaneous trip over gravel roads? The air/oil-cooled boxer takes your ideas on board. And makes for very fun travel. Its drivability is balanced and full of exciting dynamics whenever it matters. The optimized torque curve provides you dynamic pulling power between 4,000 and 6,000 rpm. And this is exactly where you get the most spontaneous ideas. The peak torque is still 85 lbs-ft. at 6,000 rpm.

  • 85lbs-ft. torque at 6,000 rpm
  • 492lbs. unladen weight, road ready, fully fueled
  • 1,170cc capacity
  • 33.5in. seat height
  • Air/oil-cooled twin-cylinder four-stroke boxer engine

COMFORT? OF COURSE

The bendier routes
The R nineT Urban G/S boasts balanced drivability. In the new Dirt Mode of the driving modes Pro, you can now let the control systems ASC or DTC take effect much later: for gravel and dirt roads off the beaten track. And the adaptive headlights provide optimum illumination of the inside of corners at heel angles between 7° and 25°.

3 year warranty
Ride on & on & on.

Get up to 3-years or 36,000 miles warranty on all new motorcycles.

  • Option 719: New color Underground uni/Lightwhite uni. Blackstorm metallic/Racingred no longer available.

Colors

  • Light White is added.
  • Imperial Blue Metallic is added.

Equipment

  • No equipment changes.

All US R nineT Urban G/S automatically add Select Package.

ZSL Select Package – Ride Modes Pro, heated Grips, Cruise Control, Adaptive Headlight, MSR Dynamic Engine Control and Dynamic Traction Control.

Individual Options – Design Option Silencer, Design Option Gold Spoke Wheels, Black Cross Spoke Wheels, Chrome Header Pipe, Off-Road Tires, Low Seat and Billet Packs.









2023 BMW R nineT Urban G/S – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $12,995 USD
Canada MSRP Price: $15,045 CDN
Europe/UK MSRP Price: from £12,350 GBP (total selling price)

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Rated output

109 hp at 7,250 rpm

Max. torque

85 lbs-ft.  at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic port fuel injection / digital engine management with overrun cutoff, twin-spark ignition

Emission Control

Closed-loop 3-way catalytic converter

Performance / fuel consumption

Maximum speed

over 124 mph.

Fuel type

Unleaded super(premium)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Claw-shifted six-speed transmission with helical-cut splines

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminum single swing arm with BMW Motorrad Paralever; central spring strut, spring preload steplessly adjustable by hook wrench, rebound-stage damping adjustable

Suspension travel, front / rear

4.9″ / 5.5″

Wheelbase

60.1”

Caster

4.33”

Steering head angle

61.5°

Wheels

Cast wheels

Rim, front

3.00 x 19″

Rim, rear

4.50 x 17″

Tire, front

120/70 R 19

Tire, rear

170/60 R 17

Brake, front

Twin-disc brakes, diameter 12.6″, 4-piston callipers

Brake, rear

Single disc brake, diameter 10.4″, double-piston floating calliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

33.5”

Inner leg curve

74.4”

Usable tank volume

4.5 gal.

Reserve

0.9 gal.

Length

85.6”

Height (incl. mirrors)

52.5”

Width (incl. hand levers)

34.1”

Unladen weight, road ready, fully fueled

491.6 lbs.

1)

Permitted total weight

947.9 lbs

Payload (with standard equipment)

456.3 lbs.

1) With all fluids, with standard equipment and fueled with at least 90% of usable tank volume.







2023 BMW R nineT Urban G/S – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Rated output

80 kW (109 hp) at 7,250 rpm

Emission control

Closed-loop 3-way catalytic converter

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two overhead camshafts, four radially arranged valves and central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Max. torque

85.5 lbs-ft at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition

Exhaust emission standards

EU 5

Performance / fuel consumption

Maximum speed

over 200 km/h

Fuel consumption per 100 km based on WMTC

5.1 l

CO2 emission based on WMTC

119 g/km

Fuel type

Super unleaded (max. 15% ethanol, E15), 95 ROZ/RON, 90 AKI

Electrical system

Alternator

Three-phase alternator with 720 W (nominal power)

Battery

12 V / 12 Ah, maintenance-free

Power transmission

Clutch

Single-disc dry clutch, hydraulically operated

Gearbox

Claw-shifted 6-speed gearbox with helical gears

Drive

Cardan

Chassis / brakes

Frame

Three-part frame concept consisting of front and two-part rear frame, co-supporting engine-transmission unit, pillion frame can be removed for solo operation

Front wheel location / suspension

Telescopic fork, diameter 43 mm

Rear wheel location / suspension

Cast aluminium single-sided swingarm with BMW Motorrad Paralever, central spring strut, spring preload fully adjustable by hook wrench, rebound damping adjustable

Suspension travel, front / rear

125 mm / 140 mm

Wheelbase

1,527 mm

Castor

110.6 mm

Steering head angle

61.5°

Wheels

Aluminium cast wheels

Rim, front

3.00 x 19“

Rim, rear

4.50 x 17“

Tire, front

120/70 R19

Tire, rear

170/60 R17

Brake, front

Twin disc brake, diameter 320 mm, 4-piston fixed caliper

Brake, rear

Single disc brake, diameter 265 mm, 2-piston floating caliper

ABS

BMW Motorrad ABS

Dimensions / weights

Seat height at unladen weight

33.5″

Inner leg curve at unladen weight

74.4″

Usable tank volume

17 l

Reserve

approx. 3.5 l

Length

2,175 mm

Height

1,330 mm (above mirror, at DIN unladen weight)

Width

865 mm (above hand lever)

Unladen weight, road ready, fully fuelled

223 kg

1)

Permitted total weight

430 kg

Payload (with standard equipment)

207 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.







2023 BMW R nineT Urban G/S – Totalmotorcycle.com European Specifications/Technical Details

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Ratet output

80 kW (109 hp) at 7,250 rpm

Max. torque

116 Nm at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition

Emission Control

Closed-loop 3-way catalytic converter, emission standard EU-5

Performance / fuel consumption

Maximum speed

over 200 km/h

Fuel consumption per 100 km based on WMTC

5.1 l

CO2 emission based on WMTC

119 g/km

Fuel type

Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah, maintenance-free

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Claw-shifted six-speed transmission with helical-cut splines

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removeable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminum single-sided swingarm with BMW Motorrad paralever, central spring strut, spring preload continuously adjustable by handwheel, rebound damping continuously adjustable

Suspension travel, front / rear

125 mm / 140 mm

Wheelbase

1,527 mm

Castor

110.6 mm

Steering head angle

61.5°

Wheels

Cast wheels

Rim, front

3.00 x 19″

Rim, rear

4.50 x 17″

Tyre, front

120/70 R 19

Tyre, rear

170/60 R 17

Brake, front

Twin-disc brakes, diameter 320 mm, 4-piston callipers

Brake, rear

Single disc brake, diameter 265 mm, double-piston floating calliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

850 mm

Inner leg curve

1,890 mm

Usable tank volume

17 l

Reserve

app. 3.5 l

Length

2,175 mm

Height (incl. mirrors)

1,330 mm

Width (incl. hand levers)

865 mm

Unladen weight, road ready, fully fuelled

223 kg

1)

Permitted total weight

430 kg

Payload (with standard equipment)

207 kg

1) According to guideline VO (EU) 168/2013 with all fluids, with standard equipment and fuelled with at least 90% of usable tank volume.





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
