2023 Indian Springfield: EVERY ROAD IS YOURS.
Introducing the 2023 Indian Springfield…
With a combination of the renowned power from the Thunderstroke 116 V-Twin Engine, world class engineering, and premium touring features, the Indian Springfield is built for the long haul.
Style meets comfort. A nod to the classic Indian Motorcycle style with modern amenities for long-haul comfort.
CLASSIC V-TWIN STYLE
Classic American style abounds with an iconic lit headdress adorning the balanced front fender. Premium, jewel-like chrome details and finishes command attention.
2023 Indian Springfield Totalmotorcycle.com Key Features
Air-Cooled V-Twin
The award-winning Thunderstroke power plant delivers exceptional torque. And three ride modes—Tour, Standard, and Sport—give your bike the feel that’s right for you.
Classic American Styling
Whether you choose to cover the bike in chrome or black out the finishes, the Indian Springfield embraces the legacy of America’s first motorcycle company.
Superior Handling
With the Indian Springfield’s cast aluminum frame, low seat height, and ergonomic controls, riders will be instantly comfortable—and inspired.
Secure Storage
The hard saddlebags are sturdy and nearly bottomless. Plus, there’s remote locking, so you can know your stuff is always safe.
AN INDIAN SPRINGFIELD FOR EVERYONE
There’s an Indian Motorcycle for everyone. Build your own in our 3D motorcycle configurator.
2023 LINEUP: A Diverse Range for Any Rider
Touting a wider range of models and options than ever before, the 2023 Indian Motorcycle line offers a model suited for any rider and a host of new upgrades, including:
- All Thunderstroke and PowerPlus models receive a new clutch – improving the overall feel and forgiveness. This new slipper clutch reduces engine drag which provides a smoother down shifting experience and comfortable ride while improving your ability to maintain traction when facing poor road conditions. Lastly, the larger friction zone and decreased lever effort reduces your clutch fatigue, which can be beneficial in urban areas or when riding in traffic.
- Indian Springfield, Chieftain, Indian Challenger, Roadmaster and Indian Pursuit models feature a redesigned LED headlight, which improves reach and spread of light — helping the rider see what lies ahead, while also improving their visibility to other motorists on the road.
- Integrated buttons on the Heated Seats and Heated and Cooled Seats for PowerPlus and heavyweight Thunderstroke models now feature haptics, which allow riders to feel the button’s responsive when wearing gloves.
Indian Pursuit with Premium Package models now offer Lower Fairing Storage compartments as standard.
- Models with the four-inch round touchscreen display can now tie their RIDE COMMAND account from the Indian Motorcycle app or website to their bike, allowing app and web-accessible features like vehicle health, vehicle locator and ride tracking.
Across the line, Indian Motorcycle has introduced an array of new paint colors, including Sagebrush Smoke on Chief Dark Horse and Stryker Red Metallic on Scout Bobber Sixty, Chief Bobber and Roadmaster Limited models. Spirit Blue Metallic is a new color option on Chieftain Limited and Indian Pursuit models, while Titanium Smoke is introduced to Indian Challenger Dark Horse models.
2023 Indian Springfield Totalmotorcycle.com Features and Benefits
THUNDERSTROKE 116 V-TWIN ENGINE
Powered by the award-winning air-cooled Thunderstroke 116, delivering 171 Nm of torque for impressive acceleration and passing power.
KEEP IT. AND KEEP IT GOING.
Remote-locking hard saddlebags provide secure storage for weekend getaways or quick trips around town. The frame is trunk-compatible to add extra storage if needed.
HIT THE ROAD IN STYLE
With modern tech, a long list of premium features and accessories, the Springfield was designed for travelling in style and comfort.
RIDE YOUR WAY
Quick-release clear windshield manages airflow and reduces fatigue but detaches in seconds to preserve the bike’s clean and classic look. Chrome highway bars provide even more comfort on longer trips.
FEATURES GALORE
A long list of modern amenities like keyless ignition, cruise control and USB charging mean no compromises to function in a timeless design.
CUSTOMISABLE RIDE
Choose between three ride modes – Tour, Standard, and Sport – for an experience that’s customised to your riding style.
STOP AND GO COMFORT
Rear Cylinder Deactivation automatically shuts off the rear cylinder when the bike is stopped for more comfort in slow-moving traffic. Then when you hit the throttle, the rear cylinder seamlessly kicks back up to full power.
2023 Indian Springfield – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $22,499 USD
Canada MSRP Price: $27,199 CDN
Europe/UK MSRP Price: £24,895 GBP (On The Road inc 20% Vat)
Engine & Drivetrain
Bore x Stroke
3.976 in x 4.449 in (101 mm x 113 mm)
Compression Ratio
9.5:1
Displacement
111 cu in (1,811 cc)
Drive/Driven Clutch
Wet, Multi-Plate, Assist
Electronic Fuel Injection System
Closed loop fuel injection / 54 mm bore
Engine Type
Air-cooled Thunderstroke 111
Exhaust
Split Dual Exhaust w/ Cross-over
Gear Ratio (1st)
9.403 : 1
Gear Ratio (2nd)
6.411 : 1
Gear Ratio (3rd)
4.763 : 1
Gear Ratio (4th)
3.796 : 1
Gear Ratio (5th)
3.243 : 1
Gear Ratio (6th)
2.789 : 1
Peak Torque
119 ft-lbs
Peak Torque RPM
3,000 rpm
Transmission/Final Drive
2.2 : 1
Transmission/Primary Drive
Gear Drive Wet Clutch
Dimensions
Fuel Capacity
5.5 gal (20.8 L)
Ground Clearance
5.6 in (142 mm)
GVWR
1385 lbs (628 kg)
Lean Angle
31°
Overall Height
56.6 in (1439 mm)
Overall Length
101.7 in (2,583 mm)
Overall Width
42.5 in (1,080 mm)
Rake/Trail
25° / 5.2 in (133 mm)
Seat Height
26 in (660 mm)
Weight (As Shipped / Running Order)
797 lbs (362 kg) / 829 lbs (376 kg)
Wheelbase
67.0 in (1,701 mm)
Brakes
Front Brakes
Dual 300mm floating rotors with 4-piston calipers
Rear Brakes
Single / 300 mm Floating Rotor / 2 Piston Caliper
Tires / Wheels
Front Tires
Metzeler Cruisetec 130/80B17 65H
Front Wheel
Highlight Machine Tour 17 in x 3.5 in
Rear Tires
Metzeler Cruisetec 180/60R16 80H
Rear Wheel
Highlight Machine Tour 16 in x 5 in
Suspension
Front Fork Tube Diameter
46 mm
Front Suspension
Telescopic Fork
Front Travel
4.7 in (119 mm)
Rear Suspension
Single Shock w/ Air adjust
Rear Travel
4.5 in (114 mm)
Features
Color / Graphics
Spirit Blue Metallic / Silver Quartz Metallic, Bronze Pearl Metallic / Silver Quartz Metallic
Factory Warranty
2 Years, Unlimited Miles
Gauges
Tank-mounted electronic speedometer with odometer; dual tripmeters; digital tachometer; ambient air temperature; fuel range; average fuel economy; battery voltage; gear position display; real-time clock; vehicle trouble code readout; heated grip level (if heated grips installed); low engine oil pressure; and 9 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, and MPH or km/h unit designation; tank-mounted electronic fuel gauge with low fuel LED indicator
Infotainment
N/A
Lights
LED Headlamp/Driving, LED Tail/Brake/Turn Signal
Standard Equipment
Quick Release Windshield; Genuine Leather Seat; Remote-Locking Hard Saddlebags, Highway Bars; Tire Pressure Monitoring; Light Bar; Selectable Ride Modes, ABS; Cruise Control; Keyless Ignition; Indian® Script Tank Badge; 12v Charging Port
2023 Indian Springfield – Totalmotorcycle.com Canada Specifications/Technical Details
Engine & Drivetrain
Bore x Stroke
3.976 in x 4.449 in (101 mm x 113 mm)
Compression Ratio
9.5:1
Displacement
111 cu in (1,811 cc)
Drive/Driven Clutch
Wet, Multi-Plate, Assist
Electronic Fuel Injection System
Closed loop fuel injection / 54 mm bore
Engine Type
Air-cooled Thunderstroke 111
Exhaust
Split Dual Exhaust w/ Cross-over
Gear Ratio (1st)
9.403 : 1
Gear Ratio (2nd)
6.411 : 1
Gear Ratio (3rd)
4.763 : 1
Gear Ratio (4th)
3.796 : 1
Gear Ratio (5th)
3.243 : 1
Gear Ratio (6th)
2.789 : 1
Peak Torque
119 ft-lbs
Peak Torque RPM
3,000 rpm
Transmission/Final Drive
2.2 : 1
Transmission/Primary Drive
Gear Drive Wet Clutch
Dimensions
Fuel Capacity
5.5 gal (20.8 L)
Ground Clearance
5.6 in (142 mm)
GVWR
1385 lbs (628 kg)
Lean Angle
31°
Overall Height
56.6 in (1439 mm)
Overall Length
101.7 in (2,583 mm)
Overall Width
42.5 in (1,080 mm)
Rake/Trail
25° / 5.2 in (133 mm)
Seat Height (Laden)
26 in (660 mm)
Weight (As Shipped / Running Order)
797 lbs (362 kg) / 829 lbs (376 kg)
Wheelbase
67.0 in (1,701 mm)
Brakes
Front Brakes
Dual 300mm floating rotors with 4-piston calipers
Rear Brakes
Single / 300 mm Floating Rotor / 2 Piston Caliper
Tires / Wheels
Front Tires
Metzeler Cruisetec 130/80B17 65H
Front Wheel
Highlight Machine Tour 17 in x 3.5 in
Rear Tires
Metzeler Cruisetec 180/60R16 80H
Rear Wheel
Highlight Machine Tour 16 in x 5 in
Suspension
Front Fork Tube Diameter
46 mm
Front Suspension
Telescopic Fork
Front Travel
4.7 in (119 mm)
Rear Suspension
Single Shock w/ Air adjust
Rear Travel
4.5 in (114 mm)
Features
Color / Graphics
Spirit Blue Metallic / Silver Quartz Metallic, Bronze Pearl Metallic / Silver Quartz Metallic
Factory Warranty
2 Years, Unlimited Miles
Gauges
Tank-mounted electronic speedometer with odometer; dual tripmeters; digital tachometer; ambient air temperature; fuel range; average fuel economy; battery voltage; gear position display; real-time clock; vehicle trouble code readout; heated grip level (if heated grips installed); low engine oil pressure; and 9 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, and MPH or km/h unit designation; tank-mounted electronic fuel gauge with low fuel LED indicator
Infotainment
N/A
Lights
LED Headlamp/Driving, LED Tail/Brake/Turn Signal
Standard Equipment
Quick Release Windshield; Genuine Leather Seat; Remote-Locking Hard Saddlebags, Highway Bars; Tire Pressure Monitoring; Light Bar; Selectable Ride Modes, ABS; Cruise Control; Keyless Ignition; Indian® Script Tank Badge; 12v Charging Port
2023 Indian Springfield – Totalmotorcycle.com Europe Specifications/Technical Details
Engine
Engine Type Thunderstroke 116
Displacement 1890 cc
Bore x Stroke 103.2mm x 113mm
Compression Ratio 11.0:1
Electronic Fuel Injection System Closed loop fuel Injection / 54mm bore
Performance
Peak Torque RPM 3000 rpm
Peak Torque 171 Nm
Drivetrain
Primary Drive Gear Drive Wet Clutch
Clutch Wet, Multi-Plate, Assist
Gear Ratio (Overall)
1st 9.403 : 1
2nd 6.411 : 1
3rd 4.763 : 1
4th 3.796 : 1
5th 3.243 : 1
6th 2.789 : 1
Final Drive 2.2 : 1
Suspension
Suspension: Front – Type/Travel Telescopic Fork / 119 mm
Suspension: Rear – Type/Travel Single Shock w/Air adjust / 114mm / 45.7mm ride in
Chassis
Brakes/Front Dual 300mm floating rotors with 4 Piston Calliper
Brakes/Rear Single / 300 mm Floating Rotor / 2 Piston Calliper
Front Tyres Metzeler Cruisetec 130/80B17 65H
Rear Tyres Metzeler Cruisetec 180/60R16 80H
Wheels Highlight Machined Tour 17″ x 3.5″ / 16″ x 5″
Exhaust Split dual exhaust w/ cross-over
Dimensions
Wheelbase 1701 mm
Seat Height 660 mm
Ground Clearance 142 mm
Overall Length 2583 mm
Overall Width 1080 mm
Overall Height 1439 mm
Lean Angle 31°
Rake 25°
Trail 133 mm
Fuel Capacity 20.8 liters
GVWR 628 kg
Weight (Empty tank / full of fuel) 362kg / 376 kg
Features
Colour / Graphics Spirit Blue Metallic OVER Silver Quartz Metallic, Silver Quartz Metallic / Bronze Pearl Metallic
Standard
Standard Equipment Quick Release Windshield; Genuine Leather Seat; Remote-Locking Hard Saddlebags, Highway Bars; Tyre Pressure Monitoring; Light Bar; Selectable Ride Modes, ABS; Cruise Control; Keyless Ignition; Indian® Script Tank Badge; 12v Charging Port
Lights LED Headlamp/Driving, LED Tail/Brake/Turn Signal
Electrical
Gauges Tank-mounted electronic speedometer with odometer; dual tripmeters; digital tachometer; ambient air temperature; fuel range; average fuel economy; battery voltage; gear position display; real-time clock; vehicle trouble code readout; heated grip level (if heated grips installed); low engine oil pressure; and 9 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, and MPH or km/h unit designation; tank-mounted electronic fuel gauge with low fuel LED indicator
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
