2023 Yamaha YZ125X Guide

2023 Yamaha YZ125X

2023 Yamaha YZ125X 2023 Yamaha YZ125X 2023 Yamaha YZ125X 2023 Yamaha YZ125X

2023 Yamaha YZ125X: TWO‑STROKE TRAILBLAZER.

Introducing the new 2023 Yamaha YZ125X…

The all‑new YZ125X sets the standard for light, fast two‑stroke fun! The perfect entry into the world of XC and enduro competition.

The YZ125X sets the standard for light, fast two-stroke fun! The perfect entry into the world of XC and enduro competition. For 2023, the YZ125X is all new from the ground up with a completely redesigned engine, improved fueling system, and new ergonomics to add a thrilling level of performance to this trail blazer!

POWERFUL NEW 125 CC ENGINE

A completely redesigned liquid-cooled 125cc two-stroke engine boasts improved usability and increased mid- and top-end power over the 2022 model for a thrilling new level of performance.

IMPROVED RIDER ERGONOMICS

To increase rider confidence in challenging cross country conditions, new smoothly integrated body panels, more narrow fuel tank design, slimmer shroud width and flatter seat all combine to enable greater freedom of movement forward and back, allowing the rider to easily shift body weight for better control.



CROSS COUNTRY- SPECIFIC FEATURES

Cross country focused suspension setup and Dunlop® Geomax AT81 tires, 18-inch rear wheel, sealed O-ring chain, a standard side stand and fuel tank petcock with reserve position are perfect for GNCC® racing.







2023 Yamaha YZ125X Totalmotorcycle.com Key Features
  • Two-Stroke Power: Tuned for Enduro Racing
    The YZ125X is optimized for the unique demands of Hare Scrambles and GNCC® racing. The powerful new Yamaha Power Valve System (YPVS™)-equipped 125cc two-stroke engine is mated to a six-speed transmission for the ultimate cross country powerplant.
  • Lightweight Aluminum Frame
    Ultra-lightweight YZ125-spec aluminum semi-double cradle frame is engineered to provide the perfect balance of rigidity and flex for competition-ready handling character and composure.
  • Industry-Leading Suspension
    Yamaha’s renowned Speed Sensitive System KYB® spring-type front fork is matched with a high performance KYB® long-travel rear shock, both fully adjustable and tuned for the specific demands of cross country racing.
  • GNCC®-Specific Features
    Cross country focused suspension setup, optimized YPVS™ settings, lightweight Excel® wheels paired with Dunlop® Geomax MX33 tires, sealed O-ring chain, standard side stand and fuel tank petcock with reserve position all combine to make the perfect GNCC® racer.







2023 Yamaha YZ125X Totalmotorcycle.com Features and Benefits

ENGINE

  • Powerful New 125cc Two-Stroke Engine
    The new YZ125X’s two-stroke engine represents an increase in power and usability over the 2022 model. Nearly every functional part of the engine is new—from the cylinder body, cylinder head, piston, piston pin, connecting rod, crankcase and expansion chamber, to a revised cylinder port shape and updated cylinder port timing. It’s a change that is immediately apparent at the first crack of the throttle and throughout the entire rpm range.
  • Tuned for GNCC® Competition
    The YZ125X utilizes a revised compression ratio, revised YPVS™ timing and a model-specific digital CDI unit compared to its motocross sibling—all focused on creating a broad, usable power delivery specifically suited to cross country and enduro-style competition.
  • New Air Intake Design
    Updated intake design allows for a straighter, more efficient draw of air into the intake tract.
  • Improved Fueling
    New high-precision Hitachi Astemo® Keihin PWK38S carburetor features a power jet, throttle position sensor and 3D-map-controlled CDI unit for precise ignition timing. The result is clean, crisp throttle response, superior rideability and excellent over-rev character.
  • Revised Close-Ratio Transmission
    Revised close-ratio six-speed transmission has wider transmission gear tooth width and new, optimized gear ratios for maximum performance.
  • Narrow Exhaust Pipe
    The compact exhaust expansion chamber provides both horizontal and vertical clearance on tight, technical trails while still providing excellent exhaust efficiency.
  • High-Capacity Radiator
    Large-capacity radiator with dark louvers deliver an aggressive look and maximum cooling efficiency for demanding racing conditions.



CHASSIS/SUSPENSION

  • Lightweight Frame
    Race-proven, highly developed aluminum semi-double cradle frame is engineered to provide the perfect balance of rigidity and flex for competition-ready handling character and composure. Removable aluminum rear subframe is constructed of square-section tubing for reduced weight.
  • Industry-Leading KYB® Fork
    Tuned for the demands of cross country racing, the Speed Sensitive System 48mm inverted KYB® fork includes a leaf spring in the mid-speed valve for more precise damping and increased comfort, while offering up 11.8 inches of travel. Additionally, a newly adopted scraper between the dust and oil seal improves reliability in cross country conditions.
  • Advanced KYB® Shock
    Revised fully adjustable KYB® rear shock features reduced-friction Kashima Coat™ internals, separate adjusters for high- and low-speed compression damping, a full lock oil rebound system for increased comfort, and 12.4 inches of travel. It all adds up to fantastic rear wheel control and class-leading capability.
  • New Brake System
    An updated high performance braking system features larger front pistons, a more rigid caliper and a redesigned 270mm front rotor with a 30% increase in pad contact area, all combining to provide exceptional braking power and feel. The redesigned rear rotor maintains the same braking power while dropping outer diameter from 245mm to 240mm, reducing unsprung weight with no compromise on performance.
  • Premium Excel® Wheels & Dunlop® Tires
    Slick blue Excel® rims provide exceptional durability and a premium look. They come wrapped in newly sized high performance Dunlop® Geomax MX33 tires for improved cornering traction, stability and feel.



ADDITIONAL FEATURES

  • Cross Country Ergonomics
    A racy “gripper”-type seat and narrow fuel tank combined with a tapered aluminum handlebar and adjustable mounts create greater freedom of movement and more comfortable ergonomics for riders.
  • Cross Country Features
    The YZ125X is focused on enduro competition with an 18-inch rear wheel, larger rear sprocket, side stand, sealed O-ring chain, reserve fuel petcock, and newly adopted scraper between the fork’s dust and oil seal, all adding up to exceptional cross country performance.



NEW FOR 2023

  • Powerful New 125cc Two-Stroke Engine
    A completely redesigned liquid-cooled 125cc two-stroke engine boasts improved usability and increased mid- and top-end power over the 2022 model for a thrilling new level of performance.
  • Improved Fueling
    New high-precision Hitachi Astemo® Keihin PWK38S carburetor features a power jet, throttle position sensor and 3D-map-controlled CDI unit for precise ignition timing. The result is clean, crisp throttle response, superior rideability and excellent over-rev character.
  • New Brake System
    To match increased engine performance, an updated high performance braking system features larger front pistons, a more rigid caliper and a redesigned 270mm front rotor with a 30% increase in pad contact area, all combining to provide exceptional braking power and feel. The redesigned rear rotor maintains the same braking power while dropping outer diameter from 245mm to 240mm, reducing unsprung weight with no compromise on performance.
  • Revised Suspension Damping
    Taking the YZ125X’s class-defining suspension and handling characteristics to the next level, new front fork internals and revised suspension settings further improve bump absorption, cornering performance and comfort to better withstand the grueling demands of cross country and enduro-style racing.
  • Improved Rider Ergonomics
    To increase rider confidence in challenging cross country conditions, new smoothly integrated body panels, more narrow fuel tank design, slimmer shroud width and flatter seat all combine to enable greater freedom of movement forward and back, allowing the rider to easily shift body weight for better control.
  • Bold New YZ Styling
    Along with the slimmer, more aggressive bodywork, a new front and rear fender design and new radiator shrouds all integrate with a bold new graphics scheme to highlight the YZ family pedigree. Premium Yamaha graphics are now embedded to provide excellent durability and scratch resistance.







2023 Yamaha YZ125X – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $7099 USD
Canada MSRP Price: $8399 CDN
Europe/UK MSRP Price: from £ NA GBP (On The Road inc 20% Vat)

Engine Type 125cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke 54.0 mm x 54.5 mm
Compression Ratio 7.8~10.2:1
Fuel Delivery Hitachi Astemo® Keihin PWK38S
Transmission 6-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® Speed-Sensitive System inverted fork;
fully adjustable, 11.8-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.4-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 240mm
Tires / Front 80/100-21 Dunlop® Geomax MX33F
Tires / Rear 110/100-18 Dunlop® Geomax MX33
L x W x H 84.8 in x 32.5 in x 50.8 in
Seat Height 38.2 in
Wheelbase 57.3 in
Rake (Caster Angle) 26.4°
Trail 4.4 in
Maximum Ground
Clearance
14.0 in
Fuel Capacity 1.8 gal
Wet Weight 212 lb
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue





2023 Yamaha YZ125X – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE 2-stroke, liquid-cooled, reed-valve, single
DISPLACEMENT 125 cc
BORE AND STROKE 54.0 x 54.5 mm
COMPRESSION RATIO 7.8~10.2:1
FUEL DELIVERY Hitachi Astemo® Keihin PWK38S
IGNITION / STARTING CDI / Kick
TRANSMISSION Constant mesh, 6-speed
FINAL DRIVE Chain

CHASSIS
SUSPENSION (FRONT) Fully adjustable 48 mm KYB inverted fork / 300 mm (11.8″) travel
SUSPENSION (REAR) Fully adjustable KYB link Monocross / 315 mm (12.4″) travel
BRAKES (FRONT) 270 mm floating disc / twin piston caliper
BRAKES (REAR) 240 mm disc / single piston caliper
TIRES (FRONT) 80/100-21
TIRES (REAR) 110/100-18

CRITICAL DATA
LENGTH 2,154 mm (84.8″)
WIDTH 825 mm (32.5″)
HEIGHT 1,290 mm (50.8″)
WHEELBASE 1,455 mm (57.3″)
GROUND CLEARANCE 356 mm (14″)
SEAT HEIGHT 970 mm (38.2″)
FUEL CAPACITY 8 litres (1.8 imp. gallons)
WET WEIGHT 96 kg (212 lb)
COLOUR(S) Team Yamaha Blue







2023 Yamaha YZ125X – Totalmotorcycle.com European Specifications/Technical Details

NA







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
