2024 Yamaha PW50: YOUR ONLY A KID ONCE.
Introducing the new 2024 Yamaha PW50…
THE PERFECT FIRST STEP
A fully automatic transmission and adjustable throttle control expands thrills along with skills. The world‑renowned PW50 ensures fun‑filled first ride experiences.
One of the industry’s best-selling mini-bikes, the affordable PW50 is a fantastic entry-level youth bike that’s helped young riders learn the ropes of motorcycling for decades.
During the past 40 years the iconic PW50 has introduced hundreds of thousands of kids – and their parents – to the fun and excitement of motorcycling. Designed with a strong focus on fun, simplicity and safety, this lightweight mini motorcycle is guaranteed to provide enjoyment for all the family – and make some treasured memories along the way!
They’re young only once, so you naturally want the very best for your child. And when you take a closer look at the Yamaha PW50 you’ll see that this high quality mini motorcycle comes with plenty of user-friendly features and uncomplicated technology that make it the favourite choice of many parents all around the world.
The perfect first step.
Everything about the legendary PW50 is designed to make riding safe, easy and enjoyable. There’s a throttle limiter that lets you adjust the top speed, and the compact chassis with plush suspension and low seat height ensure a comfortable ride with lightweight handling.
The zippy, fully-automatic 50cc engine delivers smooth acceleration – and the shaft drive and separate 2-stroke oil tank make maintenance simple. Designed to fit into the back of a car or small van, the lightweight PW50 is easy to transport – and with its Yamaha build quality this premium kids’ bike will give years of family fun!
Fully Automatic Transmission
Fully automatic transmission means no shifting required. The PW50 is a twist-and-go package.
ENTRY-LEVEL TWO-STROKE ENGINE
Gutsy 49cc two-stroke is built to thrill without intimidating beginners.
ADJUSTABLE RESTRICTOR
An adjustable throttle stop screw keeps the adult in charge to gradually increase speed as skills improve.
2024 Yamaha PW50 Totalmotorcycle.com Key Features
- Mikuni VM12SC carb
- Reed-valve intake system.
- Single-speed fully automatic transmission.
- Shaft drive system.
- Exclusive Autolube Oil Injection System.
- Fully-automatic 50cc 2-stroke engine
- Easy-to-adjust throttle limiter
- Low seat height and user-friendly controls
- Lightweight handling and compact dimensions
- Easy to own, simple to maintain
- Separate 2-stroke oil tank
- Strong, 3-spoke steel wheels
- Light and strong motocross-style bodywork
- Yamaha design, quality and reliability
- High-level exhaust with heat shield
Air-cooled, 49 cc, reed-valve, 2-stroke single is mildly tuned to deliver predictable power that gently eases the new rider up the off-road learning curve.
A class-lowest 485 mm (19.1″) seat height creates a handling-enhancing low centre of gravity and allows most riders to put both feet on the ground for added confidence.
2024 Yamaha PW50 Totalmotorcycle.com Features and Benefits
TOP FEATURES
Adjustable Restrictor
An adjustable throttle stop screw keeps the adult in charge to gradually increase speed as skills improve.
Entry-Level Two-Stroke Engine
Gutsy 49cc two-stroke is built to thrill without intimidating beginners.
Fully Automatic Transmission
Fully automatic transmission means no shifting required. The PW50 is a twist-and-go package.
Low Maintenance Requirements
Shaft final drive means no chain maintenance, while Yamaha’s exclusive autolube oil injection system eliminates the need for fuel/oil premixing.
Ultra-Low Seat Height
A seat only 18.7 inches high makes the PW50 the ideal choice for even the littlest riders in the group.
ADDITIONAL FEATURES
Comfortable Saddle
A thick seat enhances rider comfort.
Grippy Foot Pegs
Large, folding foot pegs with rubber grips provide excellent footing.
Racy Styling
Team Yamaha-inspired colors, graphics and front and side number plates create styling just like the bigger off-roaders.
CHASSIS/SUSPENSION
Dual Shocks
Dual rear shocks with 2 inches of travel smooth the trail to deliver confidence-inspiring ride quality.
Durable Knobby Tires
Durable 10-inch front and rear knobby tires provide excellent traction and superior wear.
Enclosed Drum Brakes
Front and rear drum brakes provide smooth, predictable stopping power.
Maintenance-Free Mag Wheels
Mag-style wheels mean there’s no need to tighten or replace spokes.
Quiet, Compact Exhaust
A quiet exhaust pipe, complete with a removable baffle, is routed away from the rider.
Robust Front Suspension
A large 26mm telescopic front fork with 2.4 inches of travel smooths out the bumps for responsive handling.
Simplified Servicing
The rear fender, seat and side panel unit remove quickly for easy maintenance.
Ultra-Low Seat Height
Low 18.7-inch seat height allows most kids to put both feet down for added confidence.
ENGINE
Convenient Oil Injection System
Exclusive autolube oil injection system eliminates the need for fuel/oil premixing.
Entry-Level Two-Stroke Engine
The 49cc air-cooled, case-reed-inducted, two-stroke single is tuned to deliver predictable power that gently eases the new rider up the off-road learning curve.
Fully Automatic Transmission
Single-speed automatic transmission allows the rider to simply twist the throttle and go, allowing him/her to concentrate on the ride ahead.
Maintenance-Free Shaft Drive
The class-exclusive shaft drive system is virtually maintenance free and comes fully enclosed for added durability.
*Manufacturer’s Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
**Fuel Economy is estimated.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2024 Yamaha PW50 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $1,849 USD
Canada MSRP Price: $2099 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)
ENGINE
| Engine Type | 49cc air-cooled 2-stroke; reed-valve induction |
| Bore x Stroke | 40.0mm x 39.2mm |
| Compression Ratio | 6.0:1 |
| Fuel Delivery | VM12 Carburetor |
| Ignition | CDI |
| Transmission | Wet centrifugal automatic |
| Final Drive | Shaft |
| Fuel Capacity | 0.5 gal |
CHASSIS
| Suspension/Front | 26mm telescopic fork; 2.4-in travel |
| Suspension/Rear | Unit swingarm; 2.0-in travel |
| Brakes/Front | Drum |
| Brakes/Rear | Drum |
| Tires/Front | 2.50-10-4PR |
| Tires/Rear | 2.50-10-4PR |
DIMENSIONS
| LxWxH | 49.0 in x 24.0 in x 27.8 in |
| Seat Height | 18.7 in |
| Wheelbase | 33.7 in |
| Rake (Caster Angle) | 25.5° |
| Trail | 2.0 in |
| Max. Ground Clearance | 3.7 in |
| Fuel Capacity | 0.5 gal |
| Wet Weight*** | 90 lb |
OTHER
| Warranty | 90 Day (Limited Factory Warranty) |
*Manufacturer’s Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
**Fuel Economy is estimated.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2024 Yamaha PW50 – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
| ENGINE | 2-stroke, air-cooled, reed-valve, single |
| DISPLACEMENT | 49cc |
| BORE AND STROKE | 40 x 39.2mm |
| COMPRESSION RATIO | 6.0:1 |
| MAXIMUM TORQUE | 0.36kg-m (2.6 ft-lb)@ 4,500 rpm |
| FUEL DELIVERY | Mikuni VM12SC |
| IGNITION / STARTING | CDI / Kick |
| TRANSMISSION | Single-speed automatic (no clutch) |
| FINAL DRIVE | Shaft |
CHASSIS
| SUSPENSION (FRONT) | 26 mm fork / 60mm (2.4″) wheel travel |
| SUSPENSION (REAR) | Unit swingarm / 50 mm (2″) wheel travel |
| BRAKES (FRONT) | Drum |
| BRAKES (REAR) | Drum |
| TIRES (FRONT) | 2.50-10 4PR |
| TIRES (REAR) | 2.50-10 4PR |
CRITICAL DATA
| LENGTH | 1,245 mm (49″) |
| WIDTH | 610 mm (24″) |
| HEIGHT | 705 mm (27.8″) |
| WHEELBASE | 855 mm (33.7″) |
| GROUND CLEARANCE | 95 mm (3.7″) |
| SEAT HEIGHT | 475 mm (18.7″) |
| FUEL CAPACITY | 2 litres (0.4 imp. gallons) |
| WET WEIGHT | 41 kg (90 lb) |
| COLOUR(S) | Yamaha Blue |
2024 Yamaha PW50 – Totalmotorcycle.com European Specifications/Technical Details
Engine
Engine type Reed valve, Single cylinder, Air-cooled, 2-stroke
Displacement 49cc
Bore x stroke 40,0 x 39,2 mm
Compression ratio 6,0 : 1
Lubrication system Separate lubrication
Clutch type Wet, centrifugal automatic
Ignition system CDI
Starter system Kick
Transmission system automatic
Final transmission Shaft
Fuel system Mikuni VM12/1
Chassis
Frame Steel tube backbone
Caster angle 25°30′
Trail 50 mm
Front suspension system Telescopic forks
Rear suspension system Unit Swing
Front travel 60 mm
Rear travel 50 mm
Front brake Mechanical leading trailing drum brake
Rear brake Mechanical leading trailing drum brake
Front tyre 2,50-10 4PR
Rear tyre 2,50-10 4PR
Dimensions
Overall length 1.245 mm
Overall width 610 mm
Overall height 705 mm
Seat height 475 mm
Wheel base 855 mm
Minimum ground clearance 95 mm
Wet weight (including full oil and fuel tank) 41 kg
Fuel tank capacity 2,0 L
Oil tank capacity 0,30 L
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
