2004 Honda XR250R Review

2004 Honda XR250R

One of the greatest values in off-road motorcycling…

Are you a fan of those tight, technical trails nature loves to throw your way? Then the 2004 Honda XR250R is the perfect machine for you. Lighter, smaller, yet every bit as sophisticated as its XR400R sibling, it’s also one of the greatest values in off-road motorcycling.

2004 Honda XR250R Key Features

California version differs slightly due to emissions equipment.



2004 Honda XR250R – Specifications/Technical Details
USA MSRP Price: $4,699 USD
Canadian MSRP Price: See dealer for pricing in CDN

Weight 240.0 lbs.

Ground Clearance 12.4 in.

Wheelbase 55.1 in.

Seat Height 36.0 in.

Engine Air-cooled, dry-sump, single-cylinder, four-stroke, SOHC; four-valve RFVC

Displacement 249cc

Bore x Stroke 73.0mm x 59.5mm

Compression Ratio 10.2:1

Carburetion 30mm piston-valve

Fuel Capacity 2.4 gal., including 0.5-gal. reserve

Ignition Solid-state CD with electronic advance

Transmission Six-speed

Final Drive #520 O-ring-sealed chain; 13T/48T

Brakes Front: Single disc with twin-piston caliper
Rear: Single disc

Tires Front: 80/100-21
Rear: 100/100-18

Suspension Front: 41mm leading-axle Kayaba cartridge fork; 10.6-inch travel
Rear: Pro-Link Kayaba single-shock with spring-preload; 10.6-inch travel


Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary. All specifications can change without notice.
