2008 Harley-Davidson Fire/Rescue TLE Sidecar

You are here: HomeNew 2008 Models — 2008 Harley-Davidson Motorcycle Models

2008 Harley-Davidson Fire/Rescue TLE Sidecar
Back to 2008 Harley-Davidson Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2008 Harley-Davidson Fire/Rescue TLE Sidecar
2008 Harley-Davidson Fire/Rescue TLE Sidecar

– 2008 Harley-Davidson Fire/Rescue TLE Sidecar

2008 Harley-Davidson Fire/Rescue TLE Sidecar

Fire departments are using Harley-Davidson Fire/Rescue motorcycles for Emergency Support.

A Harley-Davidson Fire/Rescue motorcycle becomes even more versatile and practical with the addition of a Harley-Davidson sidecar. The sidecar is available in a wide range of solid and two-tone colors.




US SPECIFICATIONS:

2008 Harley-Davidson Fire/Rescue TLE Sidecar



DIMENSIONS U.S. IMPERIAL UNITS


LENGTH 78.4 in.

WIDTH

SIDECAR WIDTH 23.5 in.

WIDTH FROM BRACKET TO SIDECAR WHEEL 53.3 in.

OVERALL HEIGHT 42.1 in.

WEIGHT

WEIGHT 234 lbs.

GROSS AXLE WEIGHT RATING 300 lbs.




WHEELS/TIRES
WHEELS

FRONT Black, 9-spoke cast aluminum

REAR Black, 9-spoke cast aluminum

TIRE SIZE

FRONT (D402F) MT90B16

REAR (D402) MT90B16


ELECTRICAL
LIGHTS Directional signal, tail lights, fender tip lamp


CHASSIS
FRAME Easy toe in/out adjustment

BRAKES Single disc; hydraulic disc brake on third wheel

SUSPENSION Single leaf-spring


COLOR OPTIONS

Fire Engine Red


Consult your Harley-Davidson dealer regarding ABS-equipped models.

Availability may vary from dealer to dealer, and is subject to change without notice.

Harley-Davidson reserves the right to discontinue models or change specifications at any time without incurring any obligations. Vehicle specifications may vary from country to country depending on local laws, and some models are not available in certain countries.









DIMENSIONS METRIC UNITS

LENGTH 1989.2 mm

WIDTH

SIDECAR WIDTH 596.4 mm

WIDTH FROM BRACKET TO SIDECAR WHEEL 1351.5 mm

OVERALL HEIGHT 1069.1 mm

WEIGHT

WEIGHT 106.14 kg

GROSS AXLE WEIGHT RATING 136.2 kg




WHEELS/TIRES
WHEELS

FRONT Black, 9-spoke cast aluminum

REAR Black, 9-spoke cast aluminum

TIRE SIZE

FRONT (D402F) MT90B16

REAR (D402) MT90B16


ELECTRICAL
LIGHTS Directional signal, tail lights, fender tip lamp


CHASSIS
FRAME Easy toe in/out adjustment

BRAKES Single disc; hydraulic disc brake on third wheel

SUSPENSION Single leaf-spring


COLOR OPTIONS
Fire Engine Red


Consult your Harley-Davidson dealer regarding ABS-equipped models.

Availability may vary from dealer to dealer, and is subject to change without notice.

Harley-Davidson reserves the right to discontinue models or change specifications at any time without incurring any obligations. Vehicle specifications may vary from country to country depending on local laws, and some models are not available in certain countries.
