The Monster 796 is the perfect synthesis between sports performances, aesthetics and daily riding pleasure. Cared for in each single detail, it is the ideal bike for each riding style and represents the utmost evolution of the Monster family.


Urban Icon

The Monster family introduces the 796, an exciting addition to the line-up that combines the user-friendliness of the 696 with the sports character of the 1100. Delivering 87hp (64kW), a dry weight of just 167kg (368lb) and optional ABS, the stylish new Monster 796 returns the magic of mid-range to the Monster family.

With the brand new Desmodue 796 engine at the heart of the machine, a single-sided swingarm and revised ergonomics, the Monster 796 perfectly balances lifestyle performance with everyday functionality to enhance the original Monster spirit.

Dressed in Ducati red, arctic white silk or diamond black silk with a bright red Trellis frame, the Monster 796 can be further personalised with an additional 10 colour schemes available in ‘Logomania’ the innovative Monster Art program.

The Monster 796 opens a new road to the world of Ducati Monster and becomes the ‘urban icon’ of hand-built Italian naked motorcycles.


Monster ART

‘Logomania’ is the second collection of the innovative Monster Art project and a stunning tribute to famous Ducati logos and colour schemes that span more than 50 years of authentic brand heritage.

Changing the colour and character of any model in the current Monster line-up in just 10 minutes, is the genius of the Monster Art program and a feature that passionately supports the Monster culture of customisation.

Consisting of tank panels, micro-bikini fairing, single-seat cover and front mudguard, the kits have now become a modern canvas in the world of motorcycle art and a unique method of Monster personalisation.


Monster Story

In 1992 Ducati unveiled a new prototype that was to become an icon. Ducati’s creation awed the crowds and the world’s media of that year’s Cologne International Motorcycle show. The 900 Monster was a motorcycle that created a truly new niche – dramatically styled, minimalist in stature yet bristling with innovative engineering solutions.

The Monster’s radical styling has also provided the inspiration for an entire after-market sector specialising in hot-rod parts for this legendary machine. For this reason, rarely do you see two Monsters the same. This radical and refreshing design departure also influenced other manufacturers but, as the old adage states: imitation is the highest form of flattery…

The Monster is characterised by a long and successful history, by its introduction during the years of numerous cylinders and uncountable colour options, but above all by a constant technological evolution that this year brings us to the birth of two new versions: the Monster 696, Monster 796 and the Monster 1100, representative of a new era of Monster.

Less is Monster

The ‘less-is-more’ philosophy behind all Monsters underlines Ducati’s never-ending pursuit of genuinely compact, high performance motorcycles, but these new models have succeeded in being even more ‘pared down’ than their predecessors.

Every single component has been redesigned and redeveloped so now more than ever, form follows function. With any details detracting from the Monster concept being eliminated, ‘less-is-more’ also means ‘less-is-Monster’. Less weight plus more torque equals fun-filled riding.



ENGINE

Power & torque curves

The Monster 796 produces 84hp (64kW)@ 8250rpm of power and a torque to 58lb-ft (78Nm) @ 6250rpm.

Lightweight crankcases
The new crankcases hug the gearbox internals much closer to create a smaller and more compact outer profile and achieve considerable weight savings over previous cases.

796 Desmodue
The 796 engine is a completely brand new, lightweight Desmodue power unit designed to provide the torquey, smooth and enjoyable character famous of all Desmodromic L-Twins.

Crankshaft
The crankshaft assembly uses a lightweight 848-type flywheel and has a 66mm stroke instead of the 696’s 57.2mm.

APTC clutch
The APTC ‘wet’ clutch gives a ‘slipper’ type action that prevents destabilizing of the rear-end under aggressive down-shifting and also gives the extra benefit of a super-light feel at the lever, a great benefit in stop-start city traffic or during longer journeys. The 21-plate oil-bath clutch (11 friction and 10 steel) represents a power-enhancing weight reduction over the ‘dry’ system as well as having a quieter operation and requiring less maintenance.

Exhaust system
Providing a deep and rich exhaust tone within current noise and emissions regulations is no mean feat, but the Monster definitely provides the L-Twin sound famous of Ducati. Its bold, high-level twin mufflers also make a striking style statement.
The exhaust system on Monster 796 has one Lambda probe dedicated to each cylinder, enabling precise fuelling for a smoother power delivery as well as complying with current emission regulations.

Desmodromics
The incredible valve performances of our engines are only possible because of Ducati’s unique Desmodromic system, where valve closure is activated mechanically.

At high rpm it would be almost impossible for the valve to follow the steep closure profile of the cam lobe if it were relying upon a normal valve spring. With the Desmo system, the valve is closed mechanically with the same accuracy as it is opened, enabling steep cam profiles and radical cam timings.

This system is used on every single Ducati power unit including our world-beating Superbike and Desmosedici MotoGP engines.



CHASSIS

Lightweight construction
Every carefully selected component of the Monster 696 has a net benefit to the overall light weight of the machine. The dry weight of 161kgs (355lb) has dramatic effects on not just manoeuvrability and ease of use, but also by contributing directly to increased performance, braking and acceleration.

Ergonomics
The Monster 796 features a new seat designed with a comfort-enhancing shape, further accentuated with stylish red stitching.
Furthermore, the rear sub-frame has been constructed ready to accept the new accessory grab-handles designed not only to provide a confidence-inspiring grip for the passenger, but also to blend into the natural line of the rear-end.

Single-sided swingarm
The beautifully shaped single-sided swingarm gives the Monster a ‘tough’ look while ensuring higher rigidity, reduced weight and enhanced road holding.
The swingarm is chill-cast using aluminium in its most noble form. Gravity cast and heat treated, the component achieves the best mechanical characteristics as well as reduced final weight for improved handling.

Lightweight 5-spoke wheels
The extremely lightweight aluminium alloy Y-shaped, 5-spoke wheels reduce unsprung weight and improve agility. The 3.50×17 front wheel is fitted with a 120/70ZR tyre while the rear 5.50×17 wheel has a 180/55ZR. The result is lightweight, precise steering that is extremely responsive at all speeds while giving the vehicle exceptional stability.

Sachs rear suspension
At the rear, a Sachs monoshock unit with progressive linkage provide a wide spectrum of both spring and damping settings.

Brembo brakes
The latest in Brembo braking hardware delivers exceptional braking power front and rear to improve rider safety. At the front, 320mm floating discs are gripped by four-piston, radially mounted callipers, while a 245mm floating rear disc works in combination with a twin-piston calliper.

This powerful braking set-up offers unrivalled feel and feedback making the 796 safer across a broader spectrum of riding abilities.

Monster Trellis
An immensely strong but light tubular steel Trellis frame with aluminium rear sub-frame is the visual and structural backbone of the Monster. Delivering unparalleled rigidity with minimal mass, the chassis design is pure Ducati in its ingenuity and simplicity. A separate, all aluminium sub-frame saves weight and adds a pleasing continuity with the aluminium footrest hangers and matte finished swingarm.

Seat height
The riding position of the Monster 796 has been specifically designed to put you firmly in control. The seat height is only 800 mm (31.5in), making it easier for get both feet firmly planted on the ground.

Showa forks
Outstanding control and road holding is provided by some of the best suspension components in the business. 43mm Showa inverted forks offer a pliant 120mm (4.7in) of finely controlled travel.



EQUIPMENT

Headlight
The triple-parabola headlight on the Monster utilises the latest optical technology and advanced construction techniques to provide an incredibly compact lighting package. In spite of its compact size, the headlight throws a broad and deep beam to provide excellent visibility and make night riding safer. Viewed from the side, its discrete silhouette mimics the radical shape of the fuel tank.

Empowering Controls
The Monster 796 has enhanced comfort and control with 20mm higher bar-risers gripping sturdy tapered section aluminium handlebars.
Integral type Brembo master cylinders are used for both the clutch and brake systems and maintain a clean handlebar arrangement for the rider. They are fitted with user-friendly 4-point adjustable levers that provide easy-to-reach control for all hand sizes and the APTC clutch offers a super-light lever action ideal for use in the city.

Monster Style
Refined and sophisticated, the Monster 796 is proud to show its unmistakable style as the ‘Italian ambassador’ in the world of motorcycling.
The large diameter tube construction flows into the cast aluminium rear sub-frame which matches the matte black rear swingarm and footrest hangers.

The 17″ wheels in the five ‘Y-shape’ mount a stylish pin-stripe for 60° of the circumference of the rim which creates a full circle of red when in motion.

The bright white illuminated display, the stylish red stitching of the new seat, the italian flag and the new Ducati logo on the front mudguard complete the clean and minimalist style of this new urban icon.

M796 ABS
The Ducati Monster 796 is available with ABS (anti-lock braking system).
Unlike the majority of motorcycle ABS set-ups, this system has the advantage of ensuring a more natural braking ‘feel’ for the rider.
The Monster 796 ABS is equipped with ABS, the single seat cover and the neat micro-bikini fairing.

DDA ready
The instrument display also doubles as a control panel for the activation of the Ducati Data Analyser (DDA) system, which is available as an accessory from Ducati Performance. The bike has been built ‘system-ready’ for the data acquisition kit, which consists of special DDA software and a memory key that slots into a plug under the seat. The same plug also doubles as the connection for a handy new battery charger available as an accessory from Ducati Performance.

Stopwatch
The digital display is programmed with a stopwatch function that, when enabled, can be triggered by using the high-beam flash button and each recorded time stored in a memory. After your journey or track session, the times or lap times can be recalled from the memory and scrolled through by using the instrumentation buttons on the left-hand switchgear.

Instrumentation
Visually simple digital instrumentation provides an array of data on command or, at a glance, just speed and revs. Information available at your fingertip include: scheduled maintenance warning, oil temperature, trip odometer, lap time, fuel reserve, warning light for low oil pressure, turn signals, over-rev warning, immobilizer and neutral warning light.

LED taillight
A LED rear light unit satisfies the minimalist, weight-saving design ethos found throughout the Monster 796. The specially designed strip of LEDs are enhanced by a special diffuser lens to deliver outstanding light clarity and incredible longevity.








2010 Ducati Monster 796 – International Specifications
MSRP $9,995 [ABS $10,995] ($11,495 CDN/ ABS $ 12,495 CDN)

Chassis
FRAME
Tubular steel Trellis frame
WHEELBASE
1450mm (57.1in)
RAKE
24°
FRONT SUSPENSION
Showa 43mm upside-down forks
FRONT WHEEL TRAVEL
120mm (4.7in)
FRONT WHEEL
Y-shaped, 5-spoke in light alloy 3.50 x17
FRONT TYRE
120/70 ZR17 Pirelli Diablo Rosso
REAR SUSPENSION
Progressive linkage with preload and rebound Sachs adjustable monoshock
REAR WHEEL TRAVEL
148mm (5.8in)
REAR WHEEL
Y-shaped, 5-spoke in light alloy 5.50 x 17
REAR TYRE
180/55 ZR17 Pirelli Diablo Rosso
FRONT BRAKE
2 x 320mm discs, 4-piston radial caliper
REAR BRAKE
245mm disc, 2-piston caliper
FUEL TANK CAPACITY
15l – 3.8gallon (US) / 13.5l – 3.6gallon (US) ABS version
DRY WEIGHT
167kg (369lb) / 169kg (373lb) ABS version

INSTRUMENTS
Digital unit displaying: Speedometer, rev counter, clock, scheduled maintenance warning, oil temperature, trip fuel, air temperature, lap time, warning light for low oil pressure, fuel level, fuel reserve, neutral, turn signals, overrev, immobilizer. Ready for DDA system

WARRANTY
2 years unlimited mileage
BODY COLOUR (FRAME/WHEEL)
Red (red / back) – Arctic white silk (red / back) – Diamond black silk (red / back) – Monster Art colours (red / back)

VERSIONS
Dual seat

SEAT HEIGHT
800mm (31.5in)



DDA

DDA
DDA system-ready for Ducati Performance accessory



DTC

DTC
Not available on this model



ABS

ABS
Available upon request



Engine

TYPE
L-Twin cylinder, 2 valve per cylinder Desmodromic, air cooled
DISPLACEMENT
803cc
BORE X STROKE
88 x 66 mm
COMPRESSION RATIO
11:1
POWER
64kW – 87hp @ 8250rpm
TORQUE
8.0kgm – 58lb-ft @ 6250rpm
FUEL INJECTION
Siemens electronic fuel injection, 45mm throttle body
EXHAUST
Lightweight 2-1-2 system with catalytic converter with twin lambda probes



Transmission

GEARBOX
6 speed
RATIO
1st 32/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26
PRIMARY DRIVE
Straight cut gears; Ratio 1.85:1
FINAL DRIVE
Chain; Front sprocket 15; Rear sprocket 39
CLUTCH
APTC wet multiplate with hydraulic control



Emissions

STANDARD
Euro 3 (Europe version) – USA: follows the US Federal Regulation





DUCATI PRESS RELEASE



Monster 796 Urban IconThe Monster family introduces the 796, an exciting addition to the line-up that combines the user-friendliness of the 696 with the sports character of the 1100. Delivering 87hp (64kW), a dry weight of just 167kg (368lb) and optional ABS, the stylish new Monster 796 returns the magic of mid-range to the Monster family.

With the brand new Desmodue 796 engine at the heart of the machine, a single-sided swingarm and revised ergonomics, the Monster 796 perfectly balances lifestyle performance with everyday functionality to enhance the original Monster spirit.

Dressed in Ducati red, arctic white silk or diamond black silk with a bright red Trellis frame, the Monster 796 can be further personalised with an additional 10 colour schemes from the innovative Monster Art program, which features the latest collection, ‘Logomania’.

Launched as an early entry model year 2011, the Monster 796 opens a new road to the world of Ducati Monster and becomes the ‘urban icon’ of hand-built Italian naked motorcycles.


Monster spec
Ducati have continued to listen to its passionate Monster owners and used their valuable feed-back in the design of the new Monster 796. The riding position has been revised by reducing the 1100’s seat height by a full 10mm (0.4in) to 800mm (31.5in) and the combination of redesigning the seat shape and raising the handlebars by 20mm (0.8in) has improved posture and increased comfort. Combined with a dry weight of just 167kg (368lb), thanks to its new lightweight engine, and the option of being equipped with ABS, the new naked inspires confidence to make life simpler in the city.

Suspension up front is handled by user-friendly 43mm Showa forks, while the sporty Ducati single-sided rear swingarm is controlled by a single rear Sachs unit, with adjustable spring preload and return damping for passenger load optimisation.

In pure Monster style, the entire chassis set-up is unified into a sturdy, great handling package by a bright red Trellis frame. Lightweight and with incredible torsional stiffness, the large diameter tube construction flows into the cast aluminium rear sub-frame which matches the matte black rear swingarm and footrest hangers.

Twin 320mm semi-floating discs are gripped by radially mounted 4-piston Brembo callipers to provide powerful and progressive front-end braking with rider-friendly ‘feeling’, while the rear is equipped with a 245mm disc and 2-piston calliper, also by Brembo. The Monster 796 offers the added option of ABS to further underline the model’s focus on ease of use and everyday security.

The 17” wheels are in the five ‘Y-shape’ spoked style and produced in lightweight aluminium to keep the unsprung weight low and handling, braking and acceleration performances high. To differentiate the 796, the wheels sport a stylish pin-stripe for 60° of the circumference of the rim which creates a full circle of red when in motion. They roll on the same 180/55 rear and 120/70 Pirelli Diablo Rosso tyres enjoyed on the 1100.


Desmodue engine
The brand new 796 Desmodue power unit uses fully redesigned crankcases to save an incredible 1.2kg (2.64lb) over the 696 castings, and are responsible for the major part of the impressive 1.9kg (4.2lb) total saving over the 696 power unit. The clutch and alternator outer casings of the new engine are finished in carbon grey.

The crankshaft is designed with a lightweight 848-type flywheel and uses a 66mm stroke instead of the 696’s 57.2mm, helping to maximise power to an impressive 87hp (64kW) @ 8250rpm and torque to 58lb-ft (78Nm) @ 6250rpm while maintaining the smooth and enjoyable character, famous of all Desmodromic L-Twins. An oil cooler is fitted to protect power delivery by maintaining optimum efficiency.

The 803cc swept volume is compressed to a ratio of 11:1 – compared to the 696’s 10.7:1 – then injected and ignited by Siemens controlled electronics. The 2-1-2 catalytic exhaust system uses twin lambda probes and regulating valve to provide finer fuel mapping and Euro 3 conformity. The system’s lightweight and compact design is achieved by using 1mm thick tubing and terminates in the Monster’s signature twin lateral mufflers, stylishly updated with the latest style of heat guards.

An APTC ‘wet’ clutch gives a ‘slipper’ type action that prevents destabilising of the rear-end under aggressive down-shifting and also gives the extra benefit of a super-light feel at the lever, a great benefit in stop-start city traffic. The oil-bath clutch represents a power-enhancing weight reduction over the ‘dry’ system as well as having a quieter operation and requiring less maintenance.

The new easy-to-own Monster 796 offers competitive service intervals of 12,000 kilometres (7,500 miles).


Controls
The Monster 796 has enhanced comfort and control with 20mm higher bar-risers gripping sturdy tapered section aluminium handlebars.

Integral type Brembo master cylinders are used for both the clutch and brake systems and maintain a clean handlebar arrangement for the rider. They are fitted with user-friendly 4-point adjustable levers that provide easy-to-reach control for all hand sizes and the APTC clutch offers a super-light lever action ideal for use in the city.

Looking clean and minimalist in true Monster style, the bright white illuminated display provides all essential data by default, and far more by scrolling with the left-hand switchgear. Data includes speed, revs, time, scheduled maintenance, oil temperature and battery voltage, while warning lights illuminate for oil pressure, fuel reserve, turn indicators, high beam and neutral selection. In addition, the instruments present a reserve fuel trip, immobiliser status and automatic light-off function after 60 seconds with the key on as well as a memory to store lap times recorded by using the high-beam flash button as a stopwatch.

The display also doubles as a control panel for the activation of the Ducati Data Analyser (DDA) system, which is available as an accessory from Ducati Performance. The Monster 796 has been built ‘system-ready’ for the data acquisition kit, which consists of a special DDA software and memory key that slots into a USB style plug under the seat. The same plug also doubles as the connection for a handy new ‘battery maintainer’ available as an accessory from Ducati Performance.


New Monster, new features
While the Monster 796 is fitted with the micro-bikini fairing and single seat cover as standard, it also features a new seat designed with a comfort-enhancing shape, further accentuated with stylish red stitching. Furthermore, the rear sub-frame has been constructed ready to accept new accessory grab-handles designed to provide a confidence-inspiring grip for the passenger, while blending into the natural line of the rear-end.


Monster 796 in 13 colours
The new Monster 796 comes in traditional Ducati red, new arctic white silk or diamond black silk with all three colours against a red Trellis frame and black wheels, which feature a new red flash around 60° of the rim side, creating a red stripe at speed. Monster Art extends the 3 standard colours to 13 with the new collection, ‘Logomania’. Further aesthetic enhancements come from the footrest hangers finished in matte black to match the rear sub-frame and single-sided swingarm, new Ducati logo on the front mudguard and the Tricolore displayed proudly on the single-seat cover and fuel tank.
