The cafe racer, reinvented.

Named after the famous racetrack where Triumph ruled the roost. Inspired by the Ton Up Boys of the 1960’s.

The Thruxton is Triumph’s sportiest Modern Classic, and authentic café racer delivering a unique Triumph experience.

Low rise bars, a sporting riding position, 18” spoked wheels, megaphone style exhuast and a race inspired stripe from tank to tail evoke memories of the Ace Café, racing in the streets, but underneath the engineering is pure 21st century, with a clean-running fuel injected 865cc parallel twin engine tuned for more performance and modern day reliability. The chassis too brings modern handling and braking thanks to adjustable 41mm forks and a 320mm floating front disc brake gripped by a twin piston caliper.

It’s a motorcycle to stir the hearts of those who remember it first time around and for young riders looking for that authentic retro experience that only Triumph can deliver.






Features and Benefits

Engine

The Thruxton’s 865cc, air-cooled, twin cylinder power plant, the most powerful of Triumph’s twin cylinder line-up, has a peak power output of 69bhp delivered at 7,400rpm and peak torque of 52ft.lbs arrives at 5,800rpm. The engine shares the same 360° firing interval as the Bonneville, as well as featuring ‘hot’ camshaft profiles and a compression ratio of 9.9:1.


Fueling

The Thruxton features a fuel injection system designed for clean running and to meet Euro 3 legislation. The retro styling remains uncompromised though, as fuel injectors are cleverly concealed by throttle bodies designed to look like traditional carbs.


Handlebars

The Thruxton’s handlebars are one-piece tubular chromed steel bars and are set to give a sporty riding position. The stylish bar-end mirrors, engineered specifically for the Thruxton, come as standard.


Chassis

Wrapping the motor is a precisely crafted chassis that inspires confidence; its harder edge delivering real sporting character. The sturdy, preload adjustable 41mm telescopic forks and twin rear shocks give superb suspension action and compliance while sharper steering geometry, a wheelbase of 56.7in and 18 inch aluminum-rimmed front wheel all aid steering input.


Brakes

A fully floating 320mm front disc and twin-piston brake caliper provide powerful, but sensitive, braking performance.







2010 Triumph Thruxton – USA Specifications
MSRP: $8,799 USD

Engine

Type
Air-cooled, DOHC, parallel-twin, 360 degree firing interval

Capacity
865cc

Bore/Stroke
90 x 68mm

Compression Ratio
9.9:1

Fuel System
Multipoint sequential electronic fuel injection with SAI



Transmission

Final Drive
X ring chain

Clutch
Wet, multi-plate

Gearbox
5-speed



Cycle Parts

Frame
Tubular steel cradle

Swingarm
Twin-sided, tubular steel

Front Wheel
36-spoke, 18 x 2.5in, aluminum rim

Rear Wheel
40-spoke, 17 x 3.5in, aluminum rim

Front Tyre
100/90 18

Rear Tyre
130/80 R17

Front Suspension
Kayaba 41mm forks with adjustable preload, 120mm travel

Rear Suspension
Kayaba chromed spring twin shocks with adjustable preload, 106mm rear wheel travel

Front Brakes
Single 320mm floating disc, Nissin 2 piston floating caliper

Rear Brakes
Single 255mm disc, Nissin 2 piston floating caliper



Dimensions

Length
84.6in

Width (Handlebars)
32.7in

Height
43.1in

Seat Height
32.3in

Wheelbase
56.7in

Rake/Trail
27 degree/97mm

Wet Weight
506lbs

Fuel Tank Capacity
4.2 US gal



Performance (Measured at crankshaft to DIN 70020)

Maximum Power
68bhp @ 7,400 rpm

Maximum Torque
51ft.lbs @ 5,800rpm



Colours

Tornado Red/White Stripe, Jet Black/Gold Stripe
Price

$8,799







2010 Triumph Thruxton – Canada Specifications
MSRP: Please contact your local Triumph dealer

Engine

Type
Air-cooled, DOHC, parallel-twin, 360 degree firing interval

Capacity
865cc

Bore/Stroke
90 x 68mm

Compression Ratio
9.9:1

Fuel System
Multipoint sequential electronic fuel injection with SAI



Transmission

Final Drive
X ring chain

Clutch
Wet, multi-plate

Gearbox
5-speed



Cycle Parts

Frame
Tubular steel cradle

Swingarm
Twin-sided, tubular steel

Front Wheel
36-spoke, 18 x 2.5in, aluminium rim

Rear Wheel
40-spoke, 17 x 3.5in, aluminium rim

Front Tyre
100/90 18

Rear Tyre
130/80 R17

Front Suspension
Kayaba 41mm forks with adjustable preload, 120mm travel

Rear Suspension
Kayaba chromed spring twin shocks with adjustable preload, 106mm rear wheel travel

Front Brakes
Single 320mm floating disc, Nissin 2 piston floating caliper

Rear Brakes
Single 255mm disc, Nissin 2 piston floating caliper



Dimensions

Length
2150mm (84.6in)

Width (Handlebars)
830mm (32.7in)

Height
1095mm (43.1in)

Seat Height
820mm (32.3in)

Wheelbase
1,490mm (56.7in)

Rake/Trail
27 degree/97mm

Wet weight
230kg (506lbs)

Fuel Tank Capacity
16 litres (4.2 US gal)



Performance (Measured at crankshaft to DIN 70020)

Maximum Power
69PS / 68bhp / 51kW @ 7400 rpm

Maximum Torque
69Nm / 51ft.lbs @ 5800rpm

Colours

Tornado Red/White Stripe, Jet Black/Gold Stripe








2010 Triumph Thruxton – UK Specifications
MSRP £NA OTR

Not available in the UK
