Welcome to a bike that combines middleweight agility with V-twin power – and tops it all off with aggressive and sporty styling. The 2011 Suzuki SV650SA comes complete with a full fairing, solo seat cover and ABS as standard equipment.

Middleweight sport bikes are known for their responsive handling, and the SV650SA is engineered to set the standard for its class. With its light and rigid aluminum-alloy truss frame and technically advanced suspension front and rear, it invites you to carve up the canyon roads with complete confidence.

The SV650SA offers an equal measure of V-twin excitement. It’s loaded with advanced designs, starting with a liquid-cooled, fuel-injected engine that boasts a wide powerband with crisp throttle response and strong acceleration in every gear. What’s more, its 90-degree V-twin design offers perfect primary balance, which results in smooth performance and comfortable open-road riding.

Take the winning formula of the SV with its lively V-Twin engine, innovative SDTV fuel injection and aluminium-alloy truss frame. Add a stylish and purposeful upper fairing, a mean dual-headlight stare and a sportier yet still comfortable riding position with clip-on bars and you have the SV650S.

As competent at direct access training as it is at club racing, the SV650 has a proven pedigree, delivering excitement to novice and experienced riders alike.





2011 Suzuki SV650SA ABS Features


Key Features

Antilock Brake System (ABS) monitors brake level input and wheel speed and matches stopping power to available traction.



Engine Features


Engine

Compact 645cc, 90-degree liquid-cooled V-twin, DOHC 8-valve engine tuned for strong low to mid rpm power.


EFI

Electronic fuel injection system featuring the Suzuki Dual Throttle Valve System (SDTV) – maintains optimum air velocity in the intake tract for smooth low-to-mid rpm throttle response and high torque output – includes Auto Fast Idle System (AFIS).

90-degree V-twin cylinder layout eliminates primary vibration without a counterbalancer, keeping the engine simple and compact.

Lightweight 2-into-1 exhaust system tuned for strong low and mid-range torque

Lightweight chain-driven DOHC, shim-under-bucket valve system with 31 mm intake valves and 25.5 mm exhaust valves.

Twin spark plug cylinder heads for optimum combustion and reduced emissions.





Transmission Features

High capacity liquid-cooling system enhances engine performance and durability – coolant routing is integrated with the clutch cover and engine case for a cleaner look and reduced weight.

Plastic outer clutch cover and engine sprocket cover for reduced weight and noise

Smooth-shifting 6-speed transmission with vertically staggered transmission shafts for a shorter, more compact crankcase





Chassis Features


Instrument Cluster

Compact instrument cluster includes analog tach, LCD speedometer, odometer/tripmeters and temperature gauge plus LCD clock and low fuel warning light.


ABS Brakes

Powerful ABS assisted dual hydraulic disc front brakes with 290 mm floating rotors and adjustable brake lever position


Sleek fairing

Sleek fairing features dual 60/55W headlights with running lights and folding mirrors


High Visibility Taillight

Steeply-angled tail section houses unique vertically-styled, high visibility LED taillight and compact rear fender.

Link-type single-shock rear suspension with 7-way adjustable preload.

41 mm front forks with 130 mm of wheel travel provides a smooth, compliant ride.

Anti-lock Braking System (ABS) for maximum braking performance in wet riding conditions.

Black-painted frame, swingarm and wheels for more sport appearance.

Box-section aluminum swingarm is lightweight with high torsional rigidity

Hinged fuel tank swings up for easy access to the airbox and throttle bodies.

Large under-seat storage area, passenger grab-bar and tie-down hooks.

Narrow, lightweight aluminum truss-style frame constructed with high-vacuum die-cast process for more consistent strength and fewer individual welded sections.

Single disc rear brake with 240 mm rotor.

Slim 17.0 L (3.74 Imp gal) fuel tank with low fuel warning light.

Wide radial tires mounted on lightweight, 3-spoke cast aluminum wheels








2011 Suzuki SV650SA ABS – United States of America Specifications
USA MSRP – $NA USD

Model may not be available in the USA






2011 Suzuki SV650SA ABS – Canadian Specifications
Canada MSRP – See dealer for pricing.

Chassis:
Brakes Front Disc brake, twin
Brakes Rear Disc brake
Colour White, Black
Curb Weight 203 kg (448 lbs)
Final Drive DID525V8, 114 links
Fuel Tank Capacity 17.0 L (4.5/3.7 US/Imp gal)
Ground Clearance 155 mm (6.1 in)
Overall Length 2085 mm (82.7 in)
Overall Width 730 mm (28.7 in)
Seat Height 800 mm (31.5 in)
Suspension Front Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Tires Front 120/60ZR17M/C (55W), tubeless
Tires Rear 160/60ZR17M/C (69W), tubeless
Transmission 6-speed constant mesh
Wheelbase 1430 mm (56.3 in)

Engine:
Bore Stroke 81.0 mm (3.189 in) x 62.6 mm (2.465 in)
Compression Ratio 11.5 : 1
Engine 645 cc (39.4 cu. in), 4-stroke, liquid-cooled, DOHC, 90-degree V-twin
Fuel System Fuel injection
Ignition Electronic ignition (Transistorized)
Lubrication Wet sump
Starter Electric

Warranty:
Warranty 12 Month unlimited mileage limited warranty

American Suzuki Motor Corporation makes every effort to present the most current specifications and product features. Because of our policy of continual improvement, changes may be made in equipment, availability, specifications and features without notice or obligation.






2011 Suzuki SV650SA ABS – European Specifications
GBP MSRP – £4,975 RRP* (£4,325 in Sept 2011 only)


DIMENSIONS AND WEIGHTS


Overall length:

2085mm (82.1in)

Overall width:

730mm (28.7in)

Overall height:

1170mm (46.1in)

Wheelbase:

1425mm (56.1in)

Seat height:

800mm (31.5in)

Kerb Mass:

196kg (432.1lbs)

Fuel capacity:

17.0litres (3.7 UK gallons)

ENGINE SPECIFICATIONS


Engine capacity:

645cc

Engine:

4-stroke, 2-cylinder, liquid-cooled, DOHC, 90° degree V-twin

Bore:

81mm x 62.6mm

Compression ratio:

11.5 : 1

Lubrication:

Wet sump

Ignition:

Electronic ignition (Transistorised)

Fuel system:

Fuel injection

Starter:

Electric

Transmission:

6-speed constant mesh

Drive:

Chain

CHASSIS SPECIFICATION


Front suspension:

Telescopic, coil spring, oil damped

Rear suspension:

Link, type, coil spring, oil damped

Front brakes:

Disc brake, twin

Rear brakes:

Disc brake

Front tyres:

120/60ZR17 M/C (55W) tubeless

Rear tyres:

160/60ZR17 M/C (69W) tubeless
