2010 Yamaha YZF450R
2010 Yamaha YZF450R

2010 Yamaha YZF450R
2010 Yamaha YZF450R

2010 Yamaha YZF450R
2010 Yamaha YZF450R

2010 Yamaha YZF450R
2010 Yamaha YZF450R

– 2010 Yamaha YZF450R

2010 Yamaha YZF450R

The YFZ with the perfect blend of power and handling for MX domination.

The 2010 Yamaha YFZ450R is a pure bred race machine. With a fuel injected 449cc 5-valve engine, an incredibly strong hybrid chassis with motocross-wide-track stance and super premium triple adjustable long travel suspension, the 2010 Yamaha 450R was made for the motocross track.

Designed to dominate the race track, the YFZ450R is sure to draw many checkered flags.

With a “wide-track” chassis and long travel suspension, the 450R provides incredible stability, confidence and control. The powerful 5-valve 449cc race engine is fuel injected with many components developed from our motocross bikes including the cylinder, cylinder head, cams and crank designs. .The engine is cradled by a hybrid aluminum chassis for optimized strength and rigidity, making the YFZ450R the most capable racer we’ve ever developed.



New for 2010:
” The wheel has been redesigned, with the inner lip rolled in. This increases the rigidity, allowing a reduction in weight while maintaining strength.


Key Features:
” The prestigious “ATV of the Year” Award from ATV Sport Magazine. “Best in Class” from ATV/SxS Illustrated. Winner of shootout after shootout. The YFZ450R took ’em all – in its first model year, right out of the starting gate. This is one amazing ATV!
” In ATV motocross, great power output doesn’t mean much without superior handling. YFZ450R delivers! The stance of the YFZ450R is motocross ready. The weldless frame is designed from lightweight aluminum, with a tension-steel bottom frame that lets the engine sit lower for excellent mass centralization. Suspension components have more travel, carefully chosen for best performance, and the front shock bodies feature Kashima coating for even smoother operation.
” Fatigue can sometimes be a racer’s worst competition. That’s why the YFZ450R’s designers made this ATV so comfortable. It boasts racer-friendly ergonomics with plenty of room to hang off in the corners, and the seat is padded just right to be more comfortable regardless of riding position. Handlebars are 4-position adjustable, too, so every rider can choose the best position, and the throttle has been designed for all day comfort.
” This 449cc engine uses titanium five-valve cylinder head technology, with a camshaft designed just for this machine to deliver abundant low to midrange torque for performance where you can really use it to take the lead – while still maintaining a super strong top end to let you pull away from the pack.
” The YFZ450R incorporates Yamaha Fuel Injection for precise fuel delivery. With big 42mm Mikuni® throttle body and 12-hole injector, this system provides exceptional atomization of the fuel for maximum power. The system also includes ISC (Idle Speed Control) for easy, reliable start-up and warming.
” This ATV is designed to make race prep easy. Body panels come off easily for service; there’s no need to remove the battery or other components to get the fenders off. The aluminum frame is bolted together, rather than welded, for maximum durability. And the oil tank is integrated with the crankcase so it’s easier to service the engine.
” The fuel-injected 449cc engine has superb power characteristics. Power delivery is smooth and strong off the line with lots of low and mid range where you need it.
” The crankcase holds a crankshaft that’s ready to handle the increased balance ratio, as well as a counterbalancer for superior vibration control. The crankcase also houses the oil tank, which helps to centralize mass for unmatched handling and makes maintenance easier.
” Camshafts are designed to maximize the torque available in the low and mid ranges.
” Fuel injection uses a 12-hole injector that provides exceptional atomization of the fuel for maximum combustion efficiency and power delivery. The system also uses a big, 42mm Mikuni® throttle body and includes ISC (Idle Speed Control) for easy, reliable start-up and warming.


” The chassis is very spacious, allowing room for even an aggressive racer to move around during the moto, and the ATV’s body panels that the rider contacts during operation are of a softer plastic material for greater comfort. The seat is narrow in the front, yet wide and padded in the rear to provide a more comfortable ride, even when hanging off on the side of the seat in a turn.
” Wheels are set motocross-spec wide, near the maximum allowable 50 inches, for great cornering ability. The Dunlop® tires are grippy with a great pattern for cornering, and at 20 inches in the rear and 21 inches in the front, provide much better ground clearance than the competition. That makes the YFZ450R fun to ride off-road, too.
” ProTaper® handlebars are mounted on 4-way clamps for exceptional adjustability. There are two sets of holes in the handlebar crown, and eccentric clamps so the rider can choose the standard setting, 10mm or 20mm forward, or 10mm back.
” Foot pegs are a generous 2.6 inches wide, something riders will appreciate every time they want to get up on the pegs, with good kick-up on the ends for solid footing.
” The frame is aluminum for lightweight, except for the frame member under the engine. Here tensioned steel is used for its combination of strength and thinness. This allowed the designers to sit the engine lower overall for excellent mass centralization for unmatched handling. The aluminum frame is bolted together, rather than welded, for maximum durability.
” The front frame is noticeably narrow at the A-arm mounting points. This dramatically reduces changes in camber as the long A-arms travel through their full range of motion. The front 44mm KYB® shocks have Kashima coating for smooth operation with superb bump absorption and excellent anti-bottoming characteristics. The 9.8 inches of wheel travel means this racer is up to even the most challenging tracks.
” The rear swingarm is crafted of strong, gravity-fed aluminum, and it’s matched to a fully adjustable 46mm KYB® piggyback shock absorber for excellent handling. Rear wheel travel is 11.0 inches for comfort even on tough terrain.
” For excellent stopping ability, YFZ450R features dual front hydraulic disc brakes and a trick looking, lightweight wave-type rear rotor.


Additional Features:
” The throttle lever requires low effort, and it’s very comfortable to use. That means less fatigue during all-day riding.
” The instrumentation is all business. The discrete panel on the fender in front of the rider gives vital indicators about low fuel, coolant temperature, check engine, and neutral gear via a straightforward LED display.




2010 Yamaha YZF450R – USA Specifications
MSRP* $8,499 (Team Yamaha Blue/White) Available from November 2009

Type 449cc, 4-Stroke Single, Liquid Cooled w/Fan, Titanium 5-Valve DOHC

Bore x Stroke 95mm x 63.4mm

Compression Ratio 11.6:1

Fuel Delivery Yamaha Fuel Injection (YFI) , 42mm

Ignition Digital TCI: Transistor Controlled Ignition

Starting System Electric

Transmission 5-Speed Manual Clutch

Drive Train 2WD; Sealed O-Ring Chain, Eccentric Adjustment

Suspension/Front Independent double wishbone, w/Kashima coated piggy back shocks, High/Low speed compression, rebound and threaded preload adjustment, 9.8-in travel

Suspension/Rear Cast aluminum swingarm w/piggyback High/Low speed compression, rebound and threaded preload adjustment, 11.0-in travel

Brakes/Front Dual ventilated hydraulic disc, twin piston

Brakes/Rear Wave-style ventilated hydraulic disc, twin piston

Tires/Front AT21x7-10 Radial

Tires/Rear AT20x10-9 Radial

L x W x H 70.7 x 48.8 x 41.9 in

Seat Height 31.9 in

Wheelbase 50.0 in

Ground Clearance 4.5 in

Fuel Capacity 2.6 gal

Wet Weight 405 lb

Lighting Dual 30W Krypton multireflector Headlights and 3.9/0.5W LED Brake light

Warranty 6 Month (Limited Factory Warranty)



2010 Yamaha YZF450R – Canada Specifications
Canadian MSRP* $11,499 CDN

Engine 4-Stroke Single, Liquid Cooled w/ Fan, Titanium 5-Valve DOHC
Displacement 449cc
Bore and Stroke 95mm x 63.4mm
Compression Ratio 11.6:1
Carburetion Yamaha Fuel Injection (YFI) , 42mm
Ignition TCI (Digital)
Starting Electric
Transmission 5-Speed, Manual Clutch
Final Drive 2WD; Sealed O-Ring Chain, Eccentric Adjustment

Suspension (Front) Independent Wide-Arc Double Wishbone, w/ 9.8″ of travel. Kashima coated Piggy Back shocks featuring High/Low Speed Compression, Rebound and Threaded Preload Adjustment
Suspension (Rear) Cast Aluminum Swing Arm, w/ 11.0″ of travel. Piggy Back shock featuring High/Low Speed Compression, Rebound and Threaded Preload Adjustment.
Brakes (Front) Dual Ventilated Hydraulic Disc , Twin Piston Calipers
Brakes (Rear) Wave Style Ventilated Hydraulic Disc, Twin Piston Caliper
Tires (Front) AT21x7-10 Dunlop KT351 Radial
Tires (Rear) AT20x10-9 Dunlop KT356 Radial

Length 1,795mm (70.7″)
Width 1,240mm (48.8″)
Height 1,065mm (41.9″)
Wheelbase 1,270mm (50.0″)
Ground Clearance 235mm (9.25″)
Seat Height 810mm (31.9″)
Wet Weight 184kg (405 lb)- ready to ride full of fuel and oil
Fuel Capacity 10.0 L
Colour(s) Racing Blue


Specifications, appearance, and price of product are subject to change without notice.

* MSRP does not include freight, PDI (Pre Delivery Inspection), pre-rigging (boats), or taxes. Dealer may sell for less.


ATV Safety Notes

– ATVs with engines 70 to 90cc are recommended for use only by riders 12 years and older and always with adult super vision. ATVs with engines 90cc or greater are recommended for use only by riders ages 16 years and older.

– Yamaha recommends that all ATV riders take an approved training course. For safety and training information, see your dealer or call the ATV Safety Institute at 1-800-887-2887.

– ATVs can be hazardous to operate. For your safety, always avoid paved surfaces. Never ride on public roads. Always wear a helmet, eye protection and protective clothing.

Never carry passengers. Never engage in stunt riding. Riding and alcohol/drugs don’t mix. Avoid excessive speed. And be particularly careful on difficult terrain. There are few joys in life equal to the free-spirited thrill and experience of ATV riding. And that’s why it’s important for all of us to do
our part as responsible riders. By following logical, common-sense rules, we can maintain season after season of unparalleled enjoyment of our sport.

– Please remember to “tread lightly.” Always ride in a responsible manner, respecting the environment as well as all state and local laws. The riders in this brochure are professionals; don’t attempt to emulate them. Prices and specifications subject to change without notice. Please read your Owner’s Manual and all labels before operation. All ATVs come with a six-month Limited Factory Warranty. See your dealer for details.
