2013 KTM 50SX Review

2013 KTM 50SX

THE PERFECT LAUNCHPAD INTO THE MX WORLD

A real KTM for the smallest of future MX champions. The 40 kg (87.7lb), lightweight 2013 KTM 50 SX sets standards in terms controllability and racing fun. It has everything including a high-quality chassis with easily applied disc brakes, top-quality components wherever you look, a powerful, reliable engine with easy-to-operate centrifugal clutch.



2013 KTM 50SX Features and Benefits

ADJUSTABLE AUTOMATIC TRANSMISSION

The new, centrifugally controlled, multi-disc automatic clutch makes riding the 2013 KTM 50 SX the easiest thing in the world. Completely redesigned by KTM, the 50 gram lighter clutch delivers significantly improved and more controllable acceleration. Furthermore, it can still be quickly and easily adjusted to the specific requirements of both track and rider using the “KTM clicker system” – in a matter of seconds and with no special tools required.

WP CHASSIS

The high-quality, upside-down front fork from WP Suspension, with 35 mm (1.38 in) diameter outer tubes and 185 mm (7.28 in) suspension travel, provides excellent ride stability and guarantees optimum damping properties and supreme responsiveness. At the rear wheel, a WP shock absorber hinged directly to the swingarm also supplies 205 mm (8.07 in) suspension travel and excels with superior and reliable damping, even on the highest of jumps.

ENGINE

The modern, extremely compact, 2-stroke engine clearly sets the benchmark in its class with its very controllable power. Equipped with a newly developed automatic clutch, the 2013 KTM 50 SX even easier to master. Thanks to the 3-shaft concept, the crankshaft in the KTM engine is closer to the bike’s center of gravity, which not only benefits the handling; it also allows a flatter and thus flow-optimized inflow angle of the intake membrane for maximum performance.

OPTIONAL RESTRICTOR KIT

To enable adaptation of the race-ready performance of the 2013 KTM 50 SX to the needs of the youngest beginners as well, a power-reduction kit including a smaller carburator is available from the PowerParts range, with which the engine can be restricted to a moderate 5.5 hp.

BRAKES

Both at the front and rear, optimally dimensioned disc brakes from FORMULA ensure the best possible deceleration on the 2013 KTM 50 SX. The exclusive, self-cleaning wave-type brake discs stand for the ultimate in race technology and outstanding safety.

WATER COOLING

The KTM 50 SX’s liquid-cooling system, with two large radiators and additional cooling for the crankcase, prevents the engine overheating, even under the most extreme loads.








2013 KTM 50SX – USA Specifications/Technical Details
US MSRP Price: See dealer for pricing in USD

ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake
Displacement 49.0 cm³ (2.99 cu in)
Bore 39.5 mm (1.555 in)
Stroke 40 mm (1.57 in)
Starting aid Kickstarter
Gearbox Rigid 1-stage reduction gear
Engine lubrication Mixture oil lubrication
Primary transmission 33:61 straight cut spur gear
Secondary drive ratio 11:40
Cooling Water-cooled
Clutch Multi-disc automatic clutch on the main shaft/centrifugal force
Ignition SELETTRA 2p D36
CHASSIS
Frame Central tube frame of chrome molybdenum steel tubing, powder-coated
Fork WP Suspension USD 35
Shock absorber WP Suspension 3614 BAEM
Suspension travel Front 205 mm (8.07 in)
Suspension travel Rear 185 mm (7.28 in)
Brake system Front Disc brake with four-pot brake caliper
Brake system Rear Disc brake with two-pot brake caliper
Brake disc diameters Front 160 mm (6.3 in)
Brake disc diameters Rear 140 mm (5.51 in)
Chain 1/2 x 3/16″
Steering head angle 66°
Wheelbase 1,032±10 mm (40.63±0.39 in)
Ground clearance unloaded 252 mm (9.92 in)
Seat height unloaded 684 mm (26.93 in)
Fuel tank capacity, approx. 2.3 l (2.4 qt.)
Super unleaded gasoline, mixed with 2-stroke engine oil (1:60)
Weight without fuel, approx. 41.5 kg (91.5 lb.)






2013 KTM 50SX – Canadian Specifications/Technical Details
Canada MSRP Price: See dealer for pricing in CDN

ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake
Displacement 49.0 cm³ (2.99 cu in)
Bore 39.5 mm (1.555 in)
Stroke 40 mm (1.57 in)
Starting aid Kickstarter
Gearbox Rigid 1-stage reduction gear
Engine lubrication Mixture oil lubrication
Primary transmission 33:61 straight cut spur gear
Secondary drive ratio 11:40
Cooling Water-cooled
Clutch Multi-disc automatic clutch on the main shaft/centrifugal force
Ignition SELETTRA 2p D36
CHASSIS
Frame Central tube frame of chrome molybdenum steel tubing, powder-coated
Fork WP Suspension USD 35
Shock absorber WP Suspension 3614 BAEM
Suspension travel Front 205 mm (8.07 in)
Suspension travel Rear 185 mm (7.28 in)
Brake system Front Disc brake with four-pot brake caliper
Brake system Rear Disc brake with two-pot brake caliper
Brake disc diameters Front 160 mm (6.3 in)
Brake disc diameters Rear 140 mm (5.51 in)
Chain 1/2 x 3/16″
Steering head angle 66°
Wheelbase 1,032±10 mm (40.63±0.39 in)
Ground clearance unloaded 252 mm (9.92 in)
Seat height unloaded 684 mm (26.93 in)
Fuel tank capacity, approx. 2.3 l (2.4 qt.)
Super unleaded gasoline, mixed with 2-stroke engine oil (1:60)
Weight without fuel, approx. 41.5 kg (91.5 lb.)

Prices and specifications subject to change without notice.



2013 KTM 50SX – UK/Europe Specifications/Technical Details
UK/European MSRP Price: £2,795.00 GBP.

ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake
Displacement 49.0 cm³
Bore 39.5 mm
Stroke 40 mm
Starting aid Kickstarter
Transmission Rigid 1-stage reduction gear
Engine lubrication Mixture oil lubrication
Primary gear ratio 33:61 straight cut spur gear
Final drive 11:40
Cooling system Liquid cooling system
Clutch 3-lining automatic clutch on the main shaft / centrifugal force
Ignition system SELETTRA 2p D36
CHASSIS
Frame Central tube frame of chrome molybdenum steel tubing, powder-coated
Forks WP Suspension USD 35
Shock absorber WP Suspension 3614 BAEM
Suspension travel Front 205 mm
Suspension travel Rear 185 mm
Brake system Front Disc brake with four-pot brake caliper
Brake system Rear Disc brake with two-pot brake caliper
Brake discs – diameter Front 160 mm
Brake discs – diameter Rear 140 mm
Chain 1/2 x 3/16″
Steering head angle 66°
Wheel base 1,032±10 mm
Ground clearance (unloaded) 252 mm
Seat height (unloaded) 684 mm
Total fuel tank capacity approx. 2.3 l
Unleaded premium fuel, mixed with 2-stroke engine oil (1:60)
Weight without fuel approx. 41.5 kg

Prices and specifications subject to change without notice.




2013 KTM 50SX – Australian Specifications/Technical Details
AU MSRP Price: See dealer for Pricing in AUD

Engine
Engine Type1-cylinder 2-stroke engine, water cooled, with reed intake
Displacement49.0cm³
Bore / Stroke3
Starter / BatteryKickstarter
TransmissionRigid 1-stage reduction gear
Fuel ManagementDell’Orto PHBG 19 BS
LubricationMixture oil lubrication
Primary Ratio33:61 straight cut spur gear
Final Drive11:40
CoolingLiquid cooling system
Clutch3-lining automatic clutch on the main shaft / centrifugal force
IgnitionSelettra 2p D36

Chassis
FrameCentral tube frame of chrome molybdenum steel tubing, powder coated
Sub-Frame steel
Handlebaraluminium tapered
Front SuspensionWP Suspension USD 35
Rear SuspensionWP Suspension 3614 BAEM
Suspension Travel – Front / Rear200/185mm
Front / Rear BrakesDisc brake 160mm front / 140mm rear
Front / Rear Rims1.6 x 12″ / 1.6 x 10″ aluminium
Front / Rear Tyres60/100-12″ / 2.75 x 10
Chain1/2 x 3/16″
Silenceraluminium
Steering Head Angle66º
Wheel Base1032 ± 10mm
Ground Clearance252mm
Seat Height684mm
Tank Capacity approx.2.3l
Weight Without Fuel approx.41.5kg

Specifications, features and prices to change by manufacturer without notice. All information correct as of posted date.
