2013 Kawasaki KLX110L Review

2013 Kawasaki KLX110L

Manual Clutch and Taller Seat Height

If Kawasaki’s popular KLX™ 110 puts smiles on the faces of both children and adults, the KLX 110L widens the grin substantially. Building on the appeal of the smaller KLX110 and its push-button starter, the KLX110L takes a good thing and enhances it even further. Making this particular brand of Kawasaki fun accessible to an even wider range of riders, the L-model incorporates several key features to make it perfect for those slightly larger, slightly more experienced riders.

The L-model is taller than the standard KLX110, due to its 2.4-inch longer fork that has 5.5 inches of travel and a longer shock out back, which offers 5.2 inches of wheel travel. This results in a seat height of 28.7 inches – nearly 2 inches higher than that of the standard KLX110. Naturally, the suspension comes with optimal spring and damping settings, giving those slightly larger riders the ability to push the KLX110L as hard as they choose.

More experienced riders often demand the superior control of a manual clutch, so the KLX110L gets one to complement its four-speed gearbox. This combination lets more aggressive riders wring every drop of performance from the 111cc four-stroke engine. Convenient push-button electric starting helps make the KLX110L easily accessible to a wide range of riders.

The Kawasaki design team outfitted the KLX110L with a fuel tank, seat, side panels, shrouds and fenders that mimic the race winning KX™450F’s. An MX-style seat is part of the package, along with a handlebar shape optimized to provide excellent comfort and control to a wide variety of riders. In other words, this one’s for kids of all ages.

The KLX110L can be customized with Authentic Kawasaki Accessories available at Kawasaki dealers.


2013 Kawasaki KLX110L Features and Benefits

At A Glance…

• Push-button electric starting
• Manual clutch
• Four-speed manual transmission
• Longer suspension than a standard KLX110
• 28.7” seat height is 1.9” taller than a standard KLX110
• Powerful 111cc engine
• KX-inspired styling
• Roomy ergonomics

Air-Cooled, Four-Stroke 111cc Engine

• All 2013 KLX 110 and 110Ls feature valve timing, free-flowing muffler and ignition system for up to 15 percent more power and torque than pre-2010 KLX110 models
• Push-button electric starting makes it easier than ever to get rolling, while a reshaped kickstarter is included as a back-up
• Starter button and kill switch are located on the left handlebar for easy access
• KACR (Kawasaki Automatic Compression Release) keeps one exhaust valve open for easy starting
• KLX 110L’s compact, lay-down engine design is ideal for engine cooling and a low center of gravity
• An ignition timing inspection hole allows easy maintenance
• Choke knob on the 18mm carburetor is easy to operate with gloves on

Four-speed Manual Transmission

• Four ratios are spaced to help exploit engine power: While the overall top-gear ratio is nearly the same as pre-2010 KLX110s, that extra gear is combined with a short final drive ratio to effectively tighten the gaps between each gear, while also widening the available range of operating speeds
• A manual clutch makes it easier to squeeze maximum performance out of the powerful little engine
• Shift drum cam groove and positioning spring result in optimal shift feel and positive gear engagement under all conditions

Security Features and Parental Controls

• For added security, the KLX110L will only start in neutral
• The engine-off switch is within easy reach on the left handlebar
• A screw-type throttle limiter allows adult supervisors to control kids’ speed while they learn

Capable Chassis

• 30mm telescopic fork with 5.5 inches of travel is tuned for optimal wheel and chassis control
• Tapered roller bearings in the lower steering stem add durability
• The 110L’s handlebar shape suits a wide variety of rider sizes
• Stiffer spring and damping rates on the longer rear shock help control the rear wheel through 5.2 inches of more firmly damped travel, with greater resistance to bottoming
• 14-inch front and 12-inch rear knobby tires on strong, steel rims provide great off-road traction and durability, and keep seat height low
• Rigid rear brake rod allows excellent braking and pedal feel

Big KX™ Style, Built to Last

• The high-tensile steel backbone frame is strong, lightweight and built to take years of abuse
• Four strategically placed heat shields provide protection from the exhaust pipe
• A 28.7-inch seat height accommodates a broad range of riders
• KX450F-style fuel tank, seat, shrouds, side panels and fenders look fast even sitting still
• KX-style half-waffle grips provide better control and comfort
• A convenient side stand makes life easier

Additional Features

• A USFS-approved spark arrester comes as standard equipment
• The KLX110L meets California “Green Sticker” requirements for year-round riding fun



2013 Kawasaki KLX110L – USA Specifications/Technical Details
US MSRP Price: $2,399 USD

Engine Four-stroke, SOHC, two-valve single

Displacement 111cc

Bore x Stroke 53.0 x 50.6mm

Compression ratio 9.5:1

Cooling System Air

Carburetion Mikuni PB18

Ignition CDI

Transmission Four-speed

Final drive Chain

Frame Type Backbone frame, high-tensile steel

Rake/Trail 24.2 degrees / 1.9 in.

Front suspension / wheel travel 30mm hydraulic telescopic fork / 5.5 in.

Rear suspension / wheel travel Swingarm with single hydraulic shock / 5.2 in.

Front Tire Size 2.50×14

Rear Tire Size 3.00×12

Front brakes / rear brakes Mechanical Drum / Mechanical drum

Overall length 61.4 in.

Overall width 25.6 in.

Overall height 39.0

Ground clearance 10.4 in.

Seat height 28.7 in.

Curb weight 168 lbs.

Wheelbase 42.3 in.

Fuel capacity 1.0 gal.

Color Choices Lime Green

Warranty 6 months

Good Times™ Protection Plan 12, 24 or 36 months



2013 Kawasaki KLX110L – Canadian Specifications/Technical Details
Canada MSRP Price: TBA CDN

Type 4-stroke, Single
Displacement 112cc
Bore and Stroke 53.0 x 50.6 mm
Cooling Air
Compression Ratio 9.5:1
Valve System SOHC, 2 valves
Fuel System Keihin PB18 carburetor
Ignition Digital DC-CDI
Starting Electric & Primary Kick
Lubrication Forced lubrication (wet sump)


Transmission 4-speed, constant mesh, return shift
Final Drive Chain
Primary Reduction Ratio 3.409 (75/22)
Gear Ratio: 1st 3.000 (36/12)
Gear Ratio: 2nd 1.938 (31/16)
Gear Ratio: 3rd 1.350 (27/20)
Gear Ratio: 4th 1.087 (25/23)
Final Reduction Ratio 2.923 (38/13)
Clutch Wet multi-disc


Type High-tensile steel backbone
Wheel Travel: Front 140 mm (5.5 in.)
Tire: Front 2.50-14 4PR
Wheel Travel: Rear 132 mm (5.2 in.)
Tire: Rear 3.00-12 4PR
Caster (Rake) 24.2°
Trail 47 mm (1.9 in.)
Steering Angle (Left/Right) 45° / 45°


Suspension, Front 30 mm telescopic fork
Suspension, Rear Single shock


Front: Type Drum (90 mm)
Rear: Type Drum (110 mm)


Overall Length 1,560 mm (61.4 in.)
Overall Width 650 mm (25.6 in.)
Overall Height 990 mm (39.0 in.)
Wheelbase 1,075 mm (42.3 in.)
Ground Clearance 265 mm (10.4 in.)
Seat Height 730 mm (28.7 in.)
Curb Mass (without saddlebags)† 76 kg (167.6 lbs.)
Fuel Capacity 3.8 litres (0.8 gal.)
† Without saddlebags and minimum height


Maximum Power‡ 5.4 kW {7.3 PS} @ 7,500 rpm
Maximum Torque‡ 8.0 N·m {0.82 kgƒ·m} @ 4,000 rpm
‡ Power / Torque figures measured at the crankshaft.


Warranty 6 months warranty


Good Times Protection Plan 24 or 36 months (Kawasaki GTPP coverage begins after the standard limited warranty expires)


Lime GreenKLX110DDF TBA

* The Manufacturer’s Suggested Retail Price does not include freight, pre-delivery inspection or applicable taxes. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice.
The specifications mentioned here apply to and have been achieved by production models under standard operating conditions. We intend only to give a fair description of the vehicle and its performance capabilities but these specifications may not apply to every machine supplied for sale. Kawasaki Heavy Industries, Ltd. reserves the right to alter specifications without prior notice. Equipment illustrated and specifications may vary to meet individual markets. Available colours may vary by market.


2013 Kawasaki KLX110L – United Kingdom Specifications/Technical Details
UK MSRP Price: £TBA (Prices are recommended and inclusive of VAT @ 20% and delivery)



2013 Kawasaki KLX110L – Australia Specifications/Technical Details
Australia MSRP Price: $TBA AU
