2014 Aprilia RSV4 Factory APRC

Back to 2014 Aprilia Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2014 Aprilia RSV4 Factory APRC
2014 Aprilia RSV4 Factory APRC

2014 Aprilia RSV4 Factory APRC
2014 Aprilia RSV4 Factory APRC

2014 Aprilia RSV4 Factory APRC
2014 Aprilia RSV4 Factory APRC

2014 Aprilia RSV4 Factory APRC
2014 Aprilia RSV4 Factory APRC

2014 Aprilia RSV4 Factory APRC
2014 Aprilia RSV4 Factory APRC



2014 Aprilia RSV4 Factory APRC Review

2014 Aprilia RSV4 Factory APRC on Totalmotorcycle.com

WINNING IDENTITY…

Right from the start, the Aprilia RSV4 Factory set the benchmark in the supersport category and has evolved year after year without losing any of the extraordinary dynamic balance which helped it win five WSBK titles.

FROM ITS SUCCESS IN SBK, WHERE THE RSV4 WON 5 WORLD TITLES IN ONLY 4 YEARS, APRILIA IS PROUD TO INTRODUCE THE NEW RSV4 RANGE, THE MAXIMUM EXPRESSION OF TECHNOLOGY APPLIED TO A SUPERSPORT BIKE.

A TRUE LEGEND IN ITS SEGMENT WHICH, FROM THE TIME IT APPEARED ON THE SCENE, HAS DOMINATED THE WORLD SBK TRACKS AS WELL AS SPECIALISED PRESS COMPARATIVE TRACK TESTING.

NO ONE HAS BEEN ABLE TO KNOCK IT FROM THE TOP STEP OF THE PODIUM AND NOW IT WILL BE EVEN MORE DIFFICULT: THE TWO NEW RSV4 VERSIONS, R ABS AND FACTORY ABS, ARE THE FASTEST, MOST POWERFUL AND SAFEST RSV4 UNITS EVER BUILT.

NEW EXTREMELY ADVANCED BRAKING SYSTEM WITH MULTIMAP ABS (WHICH CAN BE DISENGAGED), POWER INCREASED TO 184 HP, HIGHLY REFINED ADVANCED aPRC: APRILIA RSV4 R ABS AND FACTORY ABS CONFIRM THEIR POSITION AS THE TOP DOGS IN THE SECTOR.

From the time it appeared on the scene, it was clear to all its rivals that the Aprilia RSV4 was the bike to beat.

Unmistakeable in its design lucidity and applied technology, the RSV4 is conceived around a 65° V4 engine never before seen on a factory sport bike, a frame which is the heir to a dynasty that has won 18 titles and 143 Grand Prix races in the 250 GP class, enhanced by the most advanced applied electronics systems to manage the engine and the bike’s dynamic performance. This is a true vocation of Aprilia, which was the first manufacturer to adopt the Ride-By-Wire system as standard equipment (the multimap power management system), but above all the first to patent the aPRC dynamic control system, still today the only one with the exclusive self-calibration and wheelie control features.

This technological first is consolidated today with the new RSV4 ABS range: Aprilia RSV4 R ABS and Factory ABS are the models which, for the quantity and quality of new content and improvements, undoubtedly represent the most important advancements ever made on this extraordinary model.

From day one, the RSV4 Factory has been the benchmark in the supersport bike category. Year after year it has evolved without losing any of the incredible dynamic balance which took it to five WSBK titles, and, in 2012 to be nominated winner in a comparison of all sports bikes organised by the best known motorcycle magazines in the world. The ABS on the Aprilia RSV4 Factory signals yet another stage in the evolution of a dynasty of winning bikes. The aim was to improve on the previous version which was already seen as the absolute best and to consolidate the use of well proven technology. Better performance with better safety too. The Aprilia RSV4 Factory ABS becomes not only more powerful but also more ergonomic, stable and better under braking. It is also safer on the track and in road use thanks to the adoption of an exceptional new braking system fitted with multi-map ABS that can be adjusted or even disabled on the move.





2014 Aprilia RSV4 Factory APRC Totalmotorcycle.com Key Features

The new frontier in technology

The new Aprilia RSV4 R ABS and Factory ABS represent the cutting-edge of modern technology and achieve the objective of perfecting what was already top of the line in the previous versions, loved and appreciated by bikers and riders all over the world, not only because of their frame and chassis qualities, but also thanks to the advanced dynamic control systems adopted. aPRC (Aprilia Performance Ride Control) is the well known dynamic control suite derived directly from the winning technology in world Superbike, the most complete and refined of those currently available on the market.

On the new RSV4 R ABS and Factory ABS bikes, the aPRC system has been further developed and refined in order to adapt even better to the specific needs of enthusiasts on the street and professional riders on the track. Now the behaviour of the system is even more uniform, guaranteeing a high level of support in turns and high speed without penalising traction coming out of slow turns.

The new aPRC system, standard equipment on the Aprilia RSV4 R and Factory ABS includes:
– aTC: Aprilia Traction Control, the traction control system that can be adjusted on the fly, without closing the throttle, to 8 levels thanks to a practical joystick on the left handlebar, gains even higher performing and refined operating logic;
– aWC: Aprilia Wheelie Control, which can be adjusted to three levels, has been recalibrated for better performance in level 1;
– aLC: Aprilia Launch Control, for use on the track only, with 3 settings;
– aQS: Aprilia Quick Shift, a system for extremely fast gear changes without shutting the throttle and using the clutch.








2014 Aprilia RSV4 Factory APRC Totalmotorcycle.com Features and Benefits

ENGINE

The first high performance narrow V four cylinder engine in the world; the most revolutionary engine ever made by Aprilia is incomparable thanks to its unique “total electronics” package, itsincredible lightness and super compact size, reaches a new stage in evolution. The engine has been updated and improved with particular attention paid to reducing internal friction and increasing casing ventilation. The exhaust system too has been remodelled to provide maximum performance working in combination with a finely tuned electronic management system. This brings the maximum power of the 65° V4 to 184 CV with torque now arriving at 117 Nm. The 3 distinct mappings (Track, Sport and Road), were matched to the new power and torque specifications of the V4 to provide even fuller and in-depth power output at any engine speed.




Superbike frame
STABILITY AND CONTROL


In keeping with consolidated Aprilia traditions, the aluminium frame of the RSV4 R exploits thestrength and flexibility of cast and pressed components, which are welded together to form one structure, sets new benchmarks in terms of balance and dynamic efficiency. Torsional and flexional rigidity have been optimised to give the rider absolute control. This means that the Aprilia RSV4 R is not just a bike with devastating performance, but one whose greatest strength is precisely the incredible ease with which any rider can access its full potential. The swingarm also uses the same constructional technology as the frame and offers the same perfect balance between flexional and torsional stiffness to contribute to the extraordinary handling capabilities of the RSV4 R. The Factory version comes with Ohlins multi-adjustable suspension, ultralight forged alloy wheels and numerous finishing touches in carbon fibre and magnesium. The degree to which the suspension can be set is infinite: The RSV4 Factory is the only bike that offers adjustments to rake (through interchangeable bushes), swingarm height, swingarm spindle height and engine position in the frame, as standard. Exactly the same as seen on the best race bikes. The Aprilia RSV4 Factory ABS also features as standard a new front braking system with Brembo M430 monobloc radial calipers and a new radial pump on the handlebars. The rear brake caliper has been replaced by a more evolved, efficient system to optimise performance with the new front brake.



aPRC
THE NEW FRONTIER IN TECHNOLOGY


aPRC (Aprilia Performance Ride Control), which comes as standard, is the well-known system control package that comes directly from race winning experience gained in the Superbike series. It is the most complete, sophisticated package there is out of those currently on the market. aPRC includes:
• aTC: Aprilia Traction Control, automatically adjusts to different types of tyres, with 8 settings that can be conveniently selected on the move from a joystick on the left handlebar without closing the throttle;
• aWC: Aprilia Wheelie Control, with three settings;
• aLC: Aprilia Launch Control, for use on the track only, with 3 settings;
• aQS: Aprilia Quick Shift, for ultra-fast gear shifting without closing the throttle or using the clutch.
On the Aprilia RSV4 Factory ABS, the aPRC system has been further developed: it now integrates even better with the full Ride by Wire electronic multi-map V4 engine management system to meet the specific needs of both road users and professional race riders. The performance of the system provides smoother power delivery for improved high speed cornering but does not penalise traction on exiting low speed bends. In addition to this second generation aPRC, the new RSV4 also adopts a highly advanced ABS multi-map system that ensures not just maximum safety on the road but even better performance on the track.

Discover more!

Aerodynamic efficiency
COMFORT AND PERFORMANCE


The Aprilia RSV4 is both the new and the future generation of supersports bikes: the key concept is to eliminate excess bodywork and leave only what is strictly necessary for aerodynamic efficiency. The sheer beauty of its technical components enhances a bike whose compactnesswould only have been possible in recent times on a smaller engined machine or a Grand Prix prototype. The technology used for the frame and engine is state-of-the-art and their combination makes the RSV4 the perfect companion for any rider wishing to push and improve their limits thanks to the feel provided by this technology.
The most obvious aesthetic change on the RSV4 Factory ABS is the new fuel tank which has been modified not just to facilitate positioning the ABS but also to improve range and rider comfort. The tank capacity is now 18.5 litres (was 17) and pads on the side of the tank provide increased feel for the rider under braking and while cornering. This solution was taken directly from the RSV4s that race in the Superbike series.




The new aPRC system integrates even better with the electronic full Ride-by-Wire multimap management of the powerful V4 engine.

In addition to the second generation aPRC system, both the new RSV4 versions come standard with an highly advanced ABS, the antilock braking system designed and developed to guarantee not only maximum safety on the road, but also the best performance on the track. Aprilia worked in close cooperation with Bosch to define the best calibration of the ABS 9MP unit, which represents the maximum in refinement and technology currently available. The system, weighing in at just 2 kg, can be disengaged and adjusted to 3 different levels by easily accessing the sophisticated instrumentation control menu:

– Level 1: dedicated to the track (but also approved for street use), it acts on both wheels and guarantees maximum possible performance, even in the most intense braking situations at any speed. This setting takes nothing away from the pleasure and performance of “pushing the envelope”.
– Level 2: dedicated to sport riding on the street, it works on both wheels and is combined with an advanced tip over prevention system (RLM – Rear Lift-up Mitigation) which has progressive action based on the vehicle speed.
– Level 3 Rain: dedicated to riding on surfaces with poor grip, it acts on both wheels and is combined with the advanced tip over prevention system.

Each of these 3 ABS mappings can be combined with any of the 3 engine maps (Track, Sport, Road), in order to allow riders with different experience and skill levels to find the best possible combination for their style.

In their details, the ABS models in the new Aprilia RSV4 range can be distinguished by the different front mudguard finish (only the R version), a brand new satin-finish for the headlight assembly and the new exhaust silencer bottom.

The most evident aesthetic change has to do with the new fuel tank, which has been modified not only to facilitate placement of the ABS control unit, but also to increase riding range and to improve rider ergonomics: in fact, the total capacity went from 17 to 18.5 litres, while the side panels introduce lines which increase the rider’s feeling during braking and in turns. This solution was borrowed directly from the Aprilia RSV4 used in the World Superbike championship.


Higher chassis and engine performance

With the goal of improving the already exceptional deceleration capacity of the RSV4, the new Aprilia RSV4 R ABS and Factory ABS models have a brand new front braking system, which is dressed up with refined Brembo M430 radial mounted monoblock callipers and the new radial master cylinder on the handlebar.

The rear brake calliper was replaced with a more advanced and more efficient one, perfecting the combination with the new front brake. In the braking phase, as delicate as it is important, optimum weight distribution is fundamental: for this purpose the RSV4 Factory ABS engine benefits from different positioning within the frame.

The possibility of adjusting the position of the engine within the frame is a peculiarity which is usually reserved for racing bikes and which sets the RSV4 apart from all the other bikes in the segment. This, together with a different adjustment of the swingarm pivot, guarantees greater stability and control of the bike in more intense braking situations; at the same time, it allowed the height of the saddle off the ground to be lowered to 840 mm, to the advantage of riders of all sizes.

The close derivation of the Aprilia RSV4 R ABS and Factory ABS models from the racing world can be clearly seen in the engine specifications, the first high performance mass production narrow V4 in the world, the most revolutionary and powerful engine ever built by Aprilia. This is an engine which is made unique and unmistakeable thanks to the use of “total” electronics, thanks to its record light weight and extremely compact size.

The engine in the new RSV4 ABS bikes has been upgraded and improved with particular attention given to reducing internal friction and casing ventilation. This brings the maximum power of the 65° V4 to 184 HP, with torque now arriving at 117 Nm, also due to a redesigned exhaust system and fine tuned electronic management. The 3 distinct mappings (Track, Sport and Road), were matched to the new power and torque specifications of the V4 in order to obtain even more full and rich power output at any engine speed.


Colors and versions

The new Aprilia RSV4 range consists of two models: the RSV4 R ABS and RSV4 Factory ABS. For 2014, the RSV4 R ABS is offered in classic black matt Competition matt black and in the new Formula red; RSV4 Factory ABS is now available in the only one and new color Absolute black.











2014 Aprilia RSV4 Factory APRC – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $20,499 USD


ENGINE
Type Aprilia V4 longitudinal 65°, 4-strokes, liquid cooling system, double overhead camshaft (DOHC), four valves per cylinder
Capacity 999.6 cc
Max power (at crankshaft) 184 hp (135,3 kW) at 12.500 rpm
Max torque (at crankshaft) 86.2 lb-ft 117 Nm at 10.000 rpm
Fuel system Airbox with front dynamic air intakes. Variable length intake ducts controlled via ECU. 4 Weber-Marelli Ø48-mm throttle bodies with 8 injectors and latest generation Ride-by-Wire engine management. Choice of three different engine maps selectable by the rider with bike in motion: T (Track), S (Sport), R (Road)
Exhaust system 4 into 2 into 1 layout, single oxygen sensor, lateral single silencer with engine control unit-controlled butterfly valve and integrated trivalent catalytic converter.
TRANSMISSION
Gearbox 6-speed cassette type gearbox
Lubrication Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Clutch Multiplate wet clutch with mechanical slipper system. Gear lever with Aprilia Quick Shift electronic system ‘AQS’
Traction management APRC System ‘Aprilia Performance Ride Control’, which includes Traction Control (ATC), Wheelie Control (AWC), Launch Control (ALC), all of which can be configured and deactivated independently through the race display.
CHASSIS / SUSPENSION / BRAKES
Frame Aluminium dual beam chassis with pressed and cast sheet elements.
Front suspension Öhlins adjustable steering damper.
Ø43mm Öhlins upside down units fully adjustable (Tin). Wheel travel: 120 mm
Rear suspension Aluminum alloy swingarm. ÖHLINS piggyback shock absorber with adjustable spring preload, compression, rebound damping and length. Wheel travel: 130 mm
Front brake Double Ø320mm lightweight stainless steel floating discs. New M430 Brembo monobloc radial calipers with 4 opposed Ø30 mm pistons. Sintered pads. New radial master cylinder. Metal braided brake line.
Rear brake Ø220 mm disc. New Brembo floating caliper with 2 insulated Ø 32 mm pistons. Sintered pads. Master cylinder with integral reservoir. Metal braided brake line
ABS Multi-map Bosch 9MP ABS (3 maps selectable), deactivable and with RLM (Rear wheel Lift-up Mitigation).
Wheels Aprilia forged aluminum alloy rims, completely machined, 5 split spokes. Front:3.5”X17” Rear: 6.00”X17”
Front tire Radial tubeless – 120/70 ZR 17
Rear tire Radial tubeless – 200/55 ZR 17 (homologated option 190/50 ZR 17; 190/55 ZR 17)
DIMENSIONS
Max. Length 80.3 in. (2040 mm)
Max. Width 29 in. (735 mm) at the handlebar
Max. Height 44 in. (1120 mm)
Seat height 33 in. (840 mm)
Dry weight 398 lbs (181 kg)
Fuel tank capacity 4.9 gal. (18,5 lt)
WARRANTY / ROADSIDE ASSISTANCE / APPROVAL
Warranty All 2014 and newer Aprilia Scooters include a 2-year unlimited-mileage warranty. *Limits are outlined in the warranty booklet. See dealer for details
Roadside Assistance 1 Free Year of Road Side Assistance provided by Road America.
Approval EPA and CARB








2014 Aprilia RSV4 Factory APRC – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $20,795 CDN

ENGINE
Type Aprilia V4 longitudinal 65°, 4-strokes, liquid cooling system, double overhead camshaft (DOHC), four valves per cylinder
Capacity 999.6 cc
Max power (at crankshaft) 184 hp (135,3 kW) at 12.500 rpm
Max torque (at crankshaft) 86.2 lb-ft 117 Nm at 10.000 rpm
Fuel system Airbox with front dynamic air intakes. Variable length intake ducts controlled via ECU. 4 Weber-Marelli Ø48-mm throttle bodies with 8 injectors and latest generation Ride-by-Wire engine management. Choice of three different engine maps selectable by the rider with bike in motion: T (Track), S (Sport), R (Road)
Exhaust system 4 into 2 into 1 layout, single oxygen sensor, lateral single silencer with engine control unit-controlled butterfly valve and integrated trivalent catalytic converter.
TRANSMISSION
Gearbox 6-speed cassette type gearbox
Lubrication Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Clutch Multiplate wet clutch with mechanical slipper system. Gear lever with Aprilia Quick Shift electronic system ‘AQS’
Traction management APRC System ‘Aprilia Performance Ride Control’, which includes Traction Control (ATC), Wheelie Control (AWC), Launch Control (ALC), all of which can be configured and deactivated independently through the race display.
CHASSIS / SUSPENSION / BRAKES
Frame Aluminium dual beam chassis with pressed and cast sheet elements.
Front suspension Öhlins adjustable steering damper.
Ø43mm Öhlins upside down units fully adjustable (Tin). Wheel travel: 120 mm
Rear suspension Aluminum alloy swingarm. ÖHLINS piggyback shock absorber with adjustable spring preload, compression, rebound damping and length. Wheel travel: 130 mm
Front brake Double Ø320mm lightweight stainless steel floating discs. New M430 Brembo monobloc radial calipers with 4 opposed Ø30 mm pistons. Sintered pads. New radial master cylinder. Metal braided brake line.
Rear brake Ø220 mm disc. New Brembo floating caliper with 2 insulated Ø 32 mm pistons. Sintered pads. Master cylinder with integral reservoir. Metal braided brake line
ABS Multi-map Bosch 9MP ABS (3 maps selectable), deactivable and with RLM (Rear wheel Lift-up Mitigation).
Wheels Aprilia forged aluminum alloy rims, completely machined, 5 split spokes. Front:3.5”X17” Rear: 6.00”X17”
Front tire Radial tubeless – 120/70 ZR 17
Rear tire Radial tubeless – 200/55 ZR 17 (homologated option 190/50 ZR 17; 190/55 ZR 17)
DIMENSIONS
Max. Length 80.3 in. (2040 mm)
Max. Width 29 in. (735 mm) at the handlebar
Max. Height 44 in. (1120 mm)
Seat height 33 in. (840 mm)
Dry weight 398 lbs (181 kg)
Fuel tank capacity 4.9 gal. (18,5 lt)
WARRANTY / ROADSIDE ASSISTANCE / APPROVAL
Warranty All 2014 and newer Aprilia Scooters include a 2-year unlimited-mileage warranty. *Limits are outlined in the warranty booklet. See dealer for details
Roadside Assistance 1 Free Year of Road Side Assistance provided by Road Canada
Approval Transport Canada and Environment Canada








2014 Aprilia RSV4 Factory APRC – Totalmotorcycle.com European/UK Specifications/Technical Details
UK/European MSRP Price: £16,932.00 GBP (On The Road).

Engine
Aprilia 65°cc longitudinal V four stroke. Double overhead camshaft; four
valves per cylinder. 3 maps Ride by Wire system, aTC (aprilia Traction Contol), aWC (aprilia Wheelie Control), aLC (aprilia launch Control) and aQS (aprilia Quick Shift).
Displ acement
999.6 cc
Maximum power
184 HP (135,3 kW) @ 12.500 rpm
Maximum torque
11,9 kgm (117 Nm) @ 10.000 rpm
Cooling
Liquid cooling
Front suspension
43mm Öhlins upside down fully adjustable, with Tin surface treatment.
Wheel travel: 120 mm
Rear suspension
Aluminium alloy swingarm. ÖHLINS piggyback shock absorber with
adjustable lenght, spring preload and compression + rebound damping.
Wheel travel: 130 mm
Front brake
Double Ø320 mm lightweight stainless steel floating discs. M 430
Brembo monobloc radial calipers with 4 opposed pistons. Sintered pads.
Radial master cylinder. Metal braided brake line. 9MP Bosch multi-map
ABS: Track, Sport, Rain.
Rear brake
Ø220 mm disc. Brembo caliper with 2 insulated pistons. Sintered pads.
Rear master cylinder with integrated oil tank. Metal braided brake line.
9MP Bosch multi-map ABS: Track, Sport, Rain.
Front tyre
Radial tubeless – 120/70 ZR 17
Rear tyre Radial tubeless – 200/55 ZR 17 (homologated option 190/50 ZR 17; 190/55 ZR 17)
Seat height
840 mm
Fuel tank
18,5 lt (4 lt reserve)
Emissions
Euro 3 homologation

Specifications, features and prices to change by manufacturer without notice. All information correct as of posted date.
