2014 Triumph Speed Triple ABS Review

The 2014 Triumph Speed Triple ABS on Totalmotorcycle.com

Lighter, sharper, more powerful and even wilder looking than ever…

The Speed Triple is the urban icon for attitude, aggressive looks and full-on sports bike performance. It’s the perfect performance package with high quality suspension, strong brakes, light weight, agile handling and plenty of power where you need it for real world sports road riding.



2014 Triumph Speed Triple ABS Totalmotorcycle.com Features and Benefits


Bodywork Stripped back bodywork, it looks muscular, hunched forward, mean and aggressive because that’s exactly what the Speed Triple is. Frame A thoroughly modern twin-tube, twin spar frame wrapped tight around a bulging powerhouse of an engine. The Speed Triple’s unmistakable structure is pure unadulterated Triumph. Exhaust The twin silencers beneath the short, stubby tail section of the Speed Triple leave the rear wheel fully exposed on the right by the cool, single-sided swingarm. Not for looks, for real world sports bike riding. It just happens to look great. Headlights The trademark twin pentagon headlights ensure there’s no mistaking what’s coming.




The power of the Speed Triple comes from a muscle-packed three-cylinder, 1050cc engine. Serious top end performance comes from a huge 135PS, backed up by 111Nm of peak torque with plenty more muscle lower down the rev range. Giving you instant thrust regardless of revs or gear. And, with our high tech fuel injection all the power comes smoothly and relentlessly, right when you ask for it.


The liquid-cooling, double overhead cams of the Speed Triple operate 12 valves and rev out beyond 10,000rpm.

And, we’ve finely tuned the three-into-two exhaust like a musical instrument to enhance the engine’s torque and make it snarl even more angrily as the revs build.




The Speed Triple introduced an all-new frame in 2011 to give you more forward weight distribution for sharper handling and exceptional front end feel.

And we’ve kept the geometry sharp, with a steep 22.8 degree steering angle, short 1435mm wheelbase and just 90.9mm of trail to give you breathtaking responsiveness and agility.


The upside down forks on the Speed Triple are high quality Showa units, 43mm in diameter with adjustable rebound and compression damping, while the centrally mounted, single rear shock also has adjustable spring preload. So you can set the Speed Triple up for a gentle outing or an on-the-edge track day and it’ll perform brilliantly.


To match the Speed Triple’s level of handling and power we fitted Brembo’s radial four-piston calipers, with the option of ABS, for outstanding stopping power and feel.

Wheels and tyres

We fitted lightweight cast aluminium wheels and a wide 6inch rim on the back to take the grippiest, sports-focused rubber the Speed Triple deserves.

Single-sided swingarm

The swingarm is aluminium and features an eccentric chain adjuster so that the rear wheel stays perfectly in line with the front for focussed, precise handling. swingarm is also incredibly stiff, resulting in a super-stiff chassis that’s rigid enough for the hardest track use and tough enough for real world roads.

Riding position

The Speed Triple is all about high performance precision and control. So the bars are low, the footrests high and set back and the seat is sculpted deep to hold you in a forward-leaning position.

As you take control of the Speed Triple you are in no doubt that it’s made for sports riding, but you can tell we built it for the real world too.



ABS The four piston, radially mounted Brembo front callipers, with optional electronic ABS make 100 calculations per second to prevent wheel lock up at either end. Immobiliser We’ve made sure your bike is protected by a coded key immobiliser system which disables the ignition if it detects an attempt to turn or force the ignition switch without the presence of the electronically coded correct key. Instruments/ computer A serious bike needs a high level of equipment so the Speed Triple, with its modern, single purpose chassis, is driven by the latest technology. The instrumentation is part digital, part analogue so that you are presented with the most intuitive display of information. We also added programmable gear change lights, service interval reminder, lap timer, trip computer and fuel gauge, everything the focussed performance rider needs.



Fly Screen

Factory colour matched Fly screen diverts air from the rider to reduce wind blast and increase comfort. Aggressively styled in line with the motorcycle, the fly screen is manufactured from high impact ABS for durability.

Formed Tank Bag

This substantial tank bag features pre-formed construction with expandable capacity from 20 to 30 litres. Features include water resistant zips, detachable map pocket, waterproof rain cover. Shoulder straps are included for converting the bag into a cool backpack for use off the bike.

Low Seat

With a 20mm reduction in seat height, the low seat makes it easier to get your feet to the ground, helping you feel confident and in control. Features premium fabrics and stitch detailing.

Seat Cowl

Factory colour match seat cowl offers a quick, easy change of look for solo riding.




Our confidence provides you with a two-year unlimited mileage warranty on your new Triumph Motorcycle and Genuine Accessories. Alongside the knowledge that we give you a 12 month unlimited warranty on replacement parts.

The Speed Triple carries 6,000 mile (10,000km) service intervals.




2014 Triumph Speed Triple ABS – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: Lunar Silver – $12,799 USD
Canada MSRP Price: $14,395 CDN
UK/European MSRP Price: £9,599.00 (VAT Included)

TYPE Liquidcooled, 12 valve, DOHC, inline 3cylinder
BORE 79.0
SYSTEM Multipoint sequential electronic fuel injection with SAI
EXHAUST Stainless Steel 3 into 1 into 2, twin high level stainless steel silencers.
FINAL DRIVE X ring chain
CLUTCH Wet, multiplate
GEARBOX 6speed

FRAME Aluminium beam twinspar
SWINGARM Singlesided, aluminum alloy with eccentric chain adjuster
FRONT WHEELS Cast aluminum alloy multispoke 17 x 3.5in
REAR WHEELS Cast aluminum alloy multispoke 17 x 6.0in
FRONT TIRES 120/70 ZR 17
REAR TIRES 190/55 ZR 17
FRONT SUSPENSION Showa 43mm upside down forks with adjustable rebound and compression damping, 120mm travel
REAR SUSPENSION Showa Monoshock with adjustable preload, rebound and compression damping, 130mm rear wheel travel
BRAKES FRONT Twin 320mm floating discs, Brembo 4piston 4pad radial calipers (ABS model available)
BRAKES REAR Single 255mm disc, Nissin single 2piston sliding caliper (ABS model available)

LCD multifunctional instrument pack with digital speedometer, fuel gauge, trip computer, analogue tachometer, lap timer, programmable gear change lights, service interval announcement display, TPMS ready.

Crystal White
Matt Caspian Blue

Speed Triple ABS
Phantom Black

MAX POWER EC 135PS @ 9400
MAX TORQUE EC 111NM @ 7750

urban -34.0us mpg
56mph/90kph – 50.0us mpg

Specifications, features and prices to change by manufacturer without notice. Information from Total Motorcycle.com; All information correct as of posted date.
