2015 EBR 1190SX Review

2015 EBR 1190SX on Totalmotorcycle.com

EBR introduces new 1190SX “Superfighter” sport bike…

Featuring the power and technology of a superbike, the EBR 1190SX is a true high-performance motorcycle with a racing heritage. Designed to be a dominating street machine, the 1190SX is equally at home carving canyons on the open road or taking on the concrete canyons of the city.

2015 EBR 1190SX www.Totalmotorcycle.com Key Features

Following the successful introduction of their 1190RX superbike, Erik Buell Racing has introduced the EBR 1190SX, a true naked streetfighter-style sport bike with uncompromised Superbike race-bred performance and handling.

Sharing the 1190RX’s V-Twin engine rated at 185 crankshaft horsepower and more than 100 lb.-ft. of torque, the new EBR 1190SX delivers the highest performance available in the streetfighter category. EBR founder and Chief Technical Officer Erik Buell is no stranger to streetfighter-style sport bikes, having defined the category with the introduction of the S1 Lightning in 1995. “The streetfighter classification, which was so revolutionary when we first came to market, is now being used by marketing people for all sorts of motorcycles, including some thinly-disguised standard bikes that have de-tuned or obsolete powertrains,” said Buell. “So, perhaps the appropriate new name for a bike like the 1190SX is, ‘Superfighter.’“

With much componentry carried over from the EBR 1190RX superbike, the 1190SX is a genuine high-performance motorcycle with a racing heritage. True to its “streetfighter” designation, however, the 1190SX is designed to be a dominating street machine. Featuring an athletic upright riding position and wider handlebars for nimble handling, and minimalist bodywork for lower weight, the 1190SX is equally at home carving canyons on the open road or taking on the concrete canyons of the city. As with all EBR sport bikes, the 1190SX features many Erik Buell signature innovations to optimize handling and performance, such as fuel in the frame for lower weight and centralized mass, hubless wheels and perimeter brake rotors for lower unsprung weight, and EBR’s proprietary Controlled Swirl Induction (CSI), which improves power and fuel economy, while lowering exhaust emissions.

The 1190SX is being introduced with a Manufacturer’s Suggested Retail Price (MSRP) of $16,995 and is available in white, red and black color schemes. Shipments to EBR dealers will begin in early July.

2015 EBR 1190SX Totalmotorcycle.com Features and Benefits

2015 EBR 1190SX – www.Totalmotorcycle.com International Specifications/Technical Details
MSRP Price: MSRP $16,995 USD

Engine
Type ET-V2: 72° V-Twin, Liquid Cooled, Four-stroke
Bore x Stroke 4.17 in. x 2.66in. (106 x 67.5 mm)
Displacement 72.6 cu in. (1190cc)
Compression Ratio 13.4 : 1
Fuel Delivery Electronic Fuel injection with 2 port injectors and 2 showerhead injectors
Exhaust Primary + Secondary
Peak Torque 101.6 ft-lbs. @ 8200 rpm (137.8 Nm @ 8200 rpm)
Peak Horsepower 185 hp @ 10,600 rpm

Drivetrain
Primary Drive Gear Drive 36/65
Final Drive 520 Z-ring chain, 16/41
Clutch Hydraulic actuation, vacuum operated slipper
Transmission Ratios:
1st 2.46
2nd 1.75
3rd 1.38
4th 1.17
5th 1.04
6th 0.96

Dimensions
Overall Length 80.3in. (2040mm.)
Overall Width 31.9in. (810mm)
Overall Height 42.8in. (1087mm)
Seat Height 32.5in. (826mm)
Ground Clearance 4.7in. (120mm)
Rake 22.4°
Trail 3.80in. (96.5mm)
Lean Angle 48°
Front Tire Pirelli Diablo Rosso Corsa 120/70 ZR-17
Rear Tire Pirelli Diablo Rosso Corsa 190/55 ZR-17
Fuel Capacity 4.5 gal (17.lL)
Weight (Wet, no fuel) 414lbs. (188kg)
Load Capacity 382lbs. (173kg)

Chassis
Frame Aluminum frame with integral fuel reservoir
Swingarm Optimized stiffness aluminum
Front Suspension Showa, inverted big piston front forks
Rear Suspension Showa, single shock without linkage
Front Wheel 17 x 3.5 Aluminum
Rear Wheel 17 x 6.0 Aluminum
Front Brake 386mm (15.19in.) Single perimeter rotor, 8 piston inside-out caliper
Rear Brake 220mm (8.66in.) Disc, 2-piston Hayes Performance Brakes Caliper

MSRP $16,995

Body Colors
Frost Bite White
Racing Red
Galactic Black

Secondary Body Color Charcoal

Engine Color Gunsmoke

Specifications and appearance are subject to change without prior notice.
