2015 Suzuki Hayabusa Review

2015 Suzuki Hayabusa on www.Totalmotorcycle.com

The Ultimate Sport, In Timeless Styling…

More than a decade ago, Suzuki developed a machine so unique that it instantly attracted a devoted following around the world. Like its namesake, the Japanese peregrine falcon, the Hayabusa is famed for cutting through the air with incredible agility and performance.

Through countless engineering refinements of the original design, the Hayabusa spirit has endured. In 2014, the model received Brembo Monobloc high-performance calipers and an Antilock Brake System*. Its incomparable performance delivers a fun and sporty ride at any speed, setting the bar high for rivals and defining the “Ultimate Sport Bike.” The radically original yet timeless styling also reflects the spirit of the person who owns a Hayabusa. Its sensational power, speed, smooth ride and overwhelming presence continue to fascinate owners and onlookers alike. Because the Hayabusa is, and always will be, the ultimate sport bike.

*The ABS is a supplemental device for brake operation, not a device for shortening stopping distance. Always remember to reduce speed sufficiently before approaching curves.





2015 Suzuki Hayabusa www.Totalmotorcycle.com Key Features

1 Lighter and more rigid than conventional bolt-together calipers, the Hayabusa’s top-of-the-line radial-mount Brembo Monobloc front brake calipers deliver better feedback to the rider. Piston diameter was enlarged from 32-30mm to 32-32mm. Larger pistons help apply greater force to the brake disc, which results in increased initial bite and a more controlled feeling

2 The standard equipment Antilock Brake System (ABS) unit features a lightweight, compact design. The ABS enhances brake performance by helping prevent, to a certain extent, wheel locking due to changes in road conditions or excessive braking, by matching stopping power to available traction.

3 A 1340cc in-line 4-cylinder fuel injected, DOHC liquid-cooled engine with 16-valves and Twin Swirl Combustion Chambers (TSCC) provides phenomenal power and broad torque delivering breath taking acceleration.

4 S-DMS (Suzuki Drive Mode Selector) allows the rider to choose from three different engine settings depending on riding conditions or rider preferences.

5 KYB inverted cartridge forks feature a Diamond-Like Carbon (DLC) coating surface treatment on the 43mm stanchion tubes to reduce friction and increase reaction to small surface irregularities. Spring preload, compression damping and rebound damping are fully adjustable.

6 The Hayabusa’s instrument cluster features four analog meters for speedometer, tachometer, fuel gauge and water temperature with an S-DMS mode indicator, gear position indicator and adjustable engine-rpm indicator.

7 Vertically stacked twin headlights provide increased light intensity, improved light distribution and match the elegant flow of the Hayabusa styling.







2015 Suzuki Hayabusa www.Totalmotorcycle.com Features and Benefits

ENGINE FEATURES
A 1340cc in-line 4-cylinder fuel injected, DOHC liquid-cooled engine with 16-valves and Twin Swirl Combustion Chambers (TSCC) provides phenomenal power and broad torque delivering breath taking acceleration.

Lightweight aluminum alloy pistons with a compression ratio of 12.5:1 are used for maximum performance in all connditions. Hard, smooth chrome-nitride Physical Vapor Deposition (PVD) coating on the upper compression and oil control rings on each piston reduces friction while improving cylinder sealing.

Suzuki Composite Electrochemical Material (SCEM) cylinder plating improves heat transfer, durability and ring seal.

Lightweight titanium valves allow the use of light valve springs and high lift while maintaining accurate valve control. Iridium spark plugs are used for high combustion efficiency.

Curved radiator with a compact, dense-core design and engine-management-computer-controlled two ring-type electric fans mounted on the rear of the radiator, increasing the control accuracy and keeping engine temperature stable.

The Hayabusa’s engine is fed by tapered, 44mm double barrel Suzuki’s SDTV (Suzuki Dual Throttle Valve) throttle bodies utilizing dual 12-hole, fine-spray injectors per cylinder and ram air intake with large volume airbox. This precise, carefully controlled system improves combustion efficiency results in improved power delivery and a more linear response.

Idle Speed Control (ISC) system improves cold starting and helps maintain stable engine idle under various conditions.

Suzuki Pulsed-secondary AIR-injection (PAIR) system ignites unburned hydrocarbons and reduces carbon monoxide emissions.

S-DMS (Suzuki Drive Mode Selector) allows the rider to choose from three different engine settings depending on riding conditions or rider preferences.

TRANSMISSION FEATURES
An optimized 6-speed transmission features oil spray to the 4th, 5th, and 6th gears to reduce wear and mechanical noise during highway cruising.

Suzuki Clutch Assist System (SCAS) serves as back-torque-limiting system for smooth downshifts and also contributes to a light clutch pull.

CHASSIS FEATURES
A lightweight and rigid twin-spar aluminum frame minimizes weight while maintaining high torsional strength.

KYB inverted cartridge forks feature a Diamond-Like Carbon (DLC) coating surface treatment on the 43mm stanchion tubes to reduce friction and increase reaction to small surface irregularities. Spring preload, compression damping and rebound damping are fully adjustable.

A bridged aluminum alloy swingarm features a cross-sectional shape for increased rigidity, which also helps cope with improved rear tire grip and increased engine output. The Hayabusa’s fully adjustable rear shock absorber has a 43mm piston and 14mm rod diameter.

Large 310mm (12.2 inch) dual-floating-disc front brakes with efficient, race-proven aluminum-piston, radial-mount Brembo calipers, and 260mm (10.2 inch) single-disc rear brake with single-piston brake caliper work together with a new ABS system offering superior braking performance

ADDITIONAL FEATURES
The Hayabusa’s instrument cluster features four analog meters for speedometer, tachometer, fuel gauge and water temperature with an S-DMS mode indicator, gear position indicator and adjustable engine-rpm indicator.

Vertically stacked twin headlights provide increased light intensity, improved light distribution and match the elegant flow of the Hayabusa styling.

Advanced aerodynamics offering superb wind protection both for normal and completely tucked-in seating positions.

The tire’s profile and compound were developed through a variety of testing to achieve a high level of stability and handling.










2015 Suzuki Hayabusa – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $14599 USD


Engine
Engine 1340cc, 4-stroke, Liquid-cooled, 4-cylinder, DOHC
Bore x Stroke 81.0 mm x 65.0 mm (3.19 in x 2.56 in)
Compression Ratio 12.5 : 1
Fuel System Suzuki Fuel Injection
Starter Electronic
Lubrication Wet sump
DriveTrain
Transmission 6-speed, constant mesh
Final Drive Chain
Chassis
Suspension Front Inverted telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Brembo, Disc, twin
Brakes Rear Disc
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 190/50ZR17M/C (73W), tubeless
Fuel Tank Capacity 5.5 US
Color Glass Sparkle Black / Metallic Thunder Gray, Pearl Vigor Blue / Metallic Mystic Silver
Electrical
Ignition Electronic ignition (Transistorized)
DimensionsandCurbWeight
Overall Length 2190 mm (86.2 in)
Overall Width 735 mm (28.9 in)
Wheelbase 1480 mm (58.3 in)
Ground Clearance 120 mm (4.7 in)
Seat Height 805 mm (31.7 in)
Curb Weight 266 kg (586 lbs)
Warranty
Warranty
12 month unlimited mileage limited warranty.






2015 Suzuki Hayabusa – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $15399 CDN

Engine FEATURES
Type 4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement 1340cc
Bore x Stroke 81.0 mm x 65.0 mm (3.19 in x 2.56 in)
Compression Ratio 12.5 : 1
Fuel System Suzuki Fuel Injection
Starter Electric
Lubrication Wet sump
Ignition Electronic ignition (Transistorized)
DRIVETRAIN FEATURES
Transmission 6-speed, constant mesh
Final Drive Chain
CHASSIS FEATURES
Suspension Front Inverted telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Brembo, Disc, twin
Brakes Rear Disc
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 190/50ZR17M/C (73W), tubeless
Fuel Tank Capacity 21.0 L (5.5 US gal.)
DIMENSIONs
Overall Length 2190 mm (86.2 in)
Overall Width 735 mm (28.9 in)
Overall Height 1,165 mm (45.9 in)
Wheelbase 1480 mm (58.3 in)
Ground Clearance 120 mm (4.7 in)
Seat Height 805 mm (31.7 in)
Curb Weight 266 kg (586 lbs)
Warranty
Standard Warranty 12 Month unlimited mileage limited warranty








2015 Suzuki Hayabusa – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £11299 GBP (On The Road inc 20% Vat)

Dimensions and Weights


Overall length: 2190mm (86.2in)
Overall width: 735mm (28.9in)
Overall height: 1165mm (45.9in)
Wheelbase: 1480mm (58.3in)
Seat height: 805mm (31.7in)
Fuel capacity: 21.0litres (4.6 UK gallons)
Ground clearance: 120mm (4.7in)

Engine Specifications


Engine capacity: 1340cc
Engine: 4-stroke, 4-cylinder, liquid cooled, DOHC
Bore: 81.0mm x 65.0mm
Compression ratio: 12.5:1
Ignition: Electronic ignition (Transisorised)
Transmission: 6-speed constant mesh
Drive: Chain
Power: 145.00kW @ 9500rpm (194.00hp)†
Torque: 155.00N.m @ 7200rpm (114.00lb.ft)†

Chassis Specification

Front suspension: Inverted telescopic, coil spring, oil damped
Rear suspension: Link type, coil spring, oil damped
Front brakes: Disc, twin
Rear brakes: Disc
Front tyres: 120/70ZR17M/C (58W), tubeless
Rear tyres: 190/50ZR17M/C (73W), tubeless


Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary.
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
