2016 Piaggio MP3 500 Sport ABS
Back to 2016 Piaggio Scooter Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2016 Piaggio MP3 500 Sport ABS

2016 Piaggio MP3 500 Sport ABS

2016 Piaggio MP3 500 Sport ABS

2016 Piaggio MP3 500 Sport ABS

2016 Piaggio MP3 500 Sport ABS

2016 Piaggio MP3 500 Sport ABS Review

2016 Piaggio MP3 500 Sport ABS on www.Totalmotorcycle.com

INCREASED TECHNOLOGY AND INCREASED SAFETY. STANDARD ABS & ASR…

The Piaggio MP3 500 ABS, with aggressive styling and performance, is the three-wheeler for people who want to stand out. Riding has never been this easy, enjoyable, secure and fast. When you take 20% less braking distance required and pair it with a lean angle of 40-degrees, you get a perfect machine for impeccable road holding in all riding conditions.

Freedom: All the riding pleasure of a motorcycle. The wind protection, carrying ability and comfort of a Tourer, with the practicality of a scooter.

Agile: Fast and nimble with high grip levels. The two front wheels offer road holding abilities on either wet or dry roads that a single front wheel cannot match.

Fun: City or mountain road, the MP3 is designed for every riding situation to deliver maximum riding fun and exhilaration.

Smart: ABS and ASR fitted as standard, USB & 12v charging, Smartphone connectivity, LED lighting, large seat storage and option top cases for additional carrying capacity.



PIAGGIO MP3, THE FIRST SCOOTER IN THE WORLD WITH DOUBLE FRONT WHEEL, HAS REVOLUTIONISED METROPOLITAN MOBILITY

PIAGGIO MP3 500 NOTCHES UP A FURTHER DEVELOPMENT:
GREATER SAFETY VIA ABS AND ASR TRACTION CONTROL, MORE COMFORT FOR RIDER AND PASSENGER, MORE SPACE, UTMOST TECHNOLOGY ON BOARD AND A HIGH-PERFORMANCE ENGINE WITH REDUCED CONSUMPTION.

PIAGGIO MP3 500 CAN BE RIDDEN WITH A STANDARD CAR DRIVER’S LICENSE

In 2006 Piaggio brought the future to today inventing a new form of transport. With Mp3, Piaggio reinvented city transport. Piaggio Mp3 was the world’s first 3-wheel scooter, the concrete response to the demand for easy-to-handle, extremely safe city vehicles to get about in the city or reach the city centre from the ever growing suburbs. The two front wheels and the exclusive patented suspension system joining them combine the safety of a car with the simplicity and practicality of a scooter and the fun of a motor cycle with dynamic riding when turning. Therefore Piaggio Mp3 is able to satisfy a truly global demand: from drivers looking for a more practical yet safe alternative to the experienced motorcyclist able to appreciate the advantages and technical features of a vehicle that has, on its own, created a new market segment of which it is the undisputed leader.

Piaggio Mp3 500, the current flagship of the three-wheeler vehicle range offered by the Piaggio Group, is available in two versions, Business and Sport, able to satisfy every need of urban, metropolitan and out-of-town mobility and can be ridden with a normal car driving license.

Chassis and functionality

The chassis of the Piaggio MP3 has been designed with the dual objective of, on the one hand, ensuring excellent stability and riding precision and, on the other, increasing vehicle usability, obtaining the best Piaggio Mp3 ever built in terms of dynamic qualities, safety standards and rider and passenger comfort. The space available improves ergonomics and optimizes the use of the load space in the under seat compartment.

The shapes and forms help to increase on-board comfort. The saddle is of lavish dimensions: flat and comfortable also for two people. with ergonomic benefits, starting from the position of the legs, more extended and relaxed. In particular the handlebars-saddle-footplate triangulation is larger, making riding easier and improving vehicle control. And it’s not only the rider who benefits. Conceived as an alternative to the car, the Piaggio Mp3 also provides additional passenger comfort: with increased space, and a more relaxed sitting position, plus the advantages of a pull-out footplate. The large compartment under the seat, fitted with 12 volt plug, courtesy light and mat, has been redesigned for additional uses, due to the regular, almost rectangular shape, without indentations or partitions, so every square centimetre can be used, for example to store two flip up helmets or a laptop holder. As before the seat opens electrically with power-assisted shock absorber for smooth, safe opening. The flat streamlined tail fairing for an easily assembled box (just one of the many accessories available), further increasing the already exceptional load capacity of the Piaggio Mp3.

Utmost safety with ABS and ASR

Piaggio Mp3 has been the first 3-wheeled scooter. Today the Piaggio MP3 is confirmed as the absolute benchmark in terms of safety, thanks to the ABS anti-lock braking system supplemented by ASR (Acceleration Slip Regulation) traction control.
The ASR system is an electronic traction control device regulating the driving wheel slippage. The ASR can be switched off simply and it guarantees safety by preventing the slippage of the rear wheel on slippery or wet roads and uneven surfaces, for excellent rear tyre grip and road holding in all conditions. The Piaggio Group is the first manufacturer to use rear wheel traction control for a scooter, in-house developed technology, based on racing experience and subsequently adapted and built into city vehicles.

The ABS system maximizes active safety preventing wheel blockage under braking and providing full control of the vehicle at all times. Developed specifically for the Piaggio Mp3, it uses a Continental control unit and three channels controlling the three wheels individually modulating only the braking force to prevent grip loss. The Piaggio Mp3 adopts disc brakes on all three wheels, with 258 mm front discs, helping to increase their power and efficiency and reducing stopping distances. Excellent safety and ability to absorb road roughness is provided by the 13-inch front wheels.

This is the resounding success due to the Mp3 exclusive Piaggio dual independent tilting front wheel technology, thanks to the four bar linkage suspension which the leading Group in Europe designed and developed before any other manufacturer in the world to ensure maximum riding pleasure in complete safety. This is the original project patented by Piaggio, with a roll mechanism comprising four aluminium alloy arms, fitted on four hinges on the central sleeve and two side sleeves connected to the arms by pins and ball bearings. Inside the side sleeves, the right-hand and left-hand steering tube rotates in a classic single-arm set-up.
The blocking mechanism of the front suspension, a distinguishing feature of the 3-wheel Italian scooter, transforms the balance of the Piaggio Mp3 from dynamic to static. Start up the Piaggio Mp3 and it stays in balance on the three wheels without the need for a stand (fitted nonetheless). To resume normal operation accelerate or use the dedicated push button. This means you never need to put your foot in the ground and you can park the Piaggio Mp3 anywhere, easily and without effort.

Piaggio Mp3 style

The style of the Piaggio Mp3 500 has clear references to the car world, which it closely resembles for the refinement of the finishes and the high level of perceived quality. The Centro Stile Piaggio Group has characterised it with distinctive modern and very personal features. The front shield is supplemented by the protective tinted windshield, height adjustable in three positions. The headlights and indicators consist of high efficiency daytime lights with 7 LEDs, adapted from the auto industry and modernizing the look of the front of the scooter. The 13″ wheel rims boast an elegant 5 split spoke design: reminiscent of saloon cars and luxury autos.
The handlebars integrate with the complete set of modern instruments in two conventional round panels and a multi-purpose digital panel with data on fuel consumption (average and current), average and maximum speed, fuel gauge, travel time, ambient temperature and ice alarm. The instrument panel also includes a clock, dual mapping of the engine CPU, total and trip counter and battery voltage reader. The 11 lights on the instrument panel display the functioning of the headlights, dipped headlights, indicators, reserve fuel, oil pressure, warning (injection), immobilizer, ABS, ASR and four emergency lights. In the centre part, just beneath the display, a series of 4 warning lights are placed which indicate: roll lock warning, engine shut-down, no roll and hand brake. Push buttons under the handlebars are to open the saddle and switch off the ASR.

The attention to detail is also noticeable in the leg shield back plate that adopts two padded shock-resistant elements matching the saddle colour, right in front of the rider’s knees. Complete with pull-out hook for bags. The compartment above the instruments has a drawer and USB connection, ideal for recharging a smartphone and other devices.
The rear of the Piaggio MP3 is modern, sporty and elegant at the same time. The line was inspired by the latest generation of Piaggio GT maxi-scooters. The truncated tail is streamlined and dynamic and accommodates the stop and tail lights implemented using LED technology, highlighting the sports character of the Piaggio Mp3, reflected in its exceptional road holding and tilt while turning. Passenger comfort is ensured by the saddle, exceptionally comfortable. and by the ergonomic aluminium handle integrated in the luggage rack.

2016 Piaggio MP3 500 Sport ABS www.Totalmotorcycle.com Key Features

The new Piaggio MP3 – the ideal commuter scooter debuts in the 500cc version with powerful yet highly economical engine. Because of its three-wheeled design it’s actually classed as a tricycle, and can therefore be ridden on any road, with a standard car licence. It is the first ‘three-wheeler’ in the world to boast an anti-lock braking system (ABS) integrated with ASR traction control (Acceleration Slip Regulation) – A Piaggio Group exclusive and technological first in this category.

The two front wheels are larger in diameter – now 13 inches – with a new design which benefits both the dynamic handling and the more dynamic look of the MP3’s front end, which has become even more prominent.

The new 500cc engine adopts the ‘ride-by-wire’ engine control system that gives the rider the option to switch between two maps – ‘’standard’’ and ‘’eco’’. Fuel consumption is down by 15% on the standard map and a further 10% on the eco, making this vehicle up to 25% more fuel efficient. This new model also boasts PMP* (Piaggio Multimedia Platform) allowing you to connect through a Bluetooth, iOS or Android smartphone, in order to open up new and different functions including average fuel consumption and navigation to your nearest authorised service centre.

*PMP (Piaggio Multimedia Platform) is optional and only available as an accessory.





2016 Piaggio MP3 500 Sport ABS www.Totalmotorcycle.com Features and Benefits

New engine with top technology

Since its launch the Piaggio Mp3 has always provided top motoring performance in absolute safety through its exclusive dual front-wheel technology. A combination of 3-wheeler and high-performance engine which gives the Piaggio Mp3 its undisguised sports character and cornering fun nipping through city streets and sweeping round country roads.

The 500cc engine – an example of robustness and reliability that is at the top of the range of high performance scooter engines – is a concentration of technology.
4-valve, liquid-cooled with electronic fuel injection, it is the most powerful engine in its class, and is fitted with a multimap “Ride-by-Wire” electronic acceleration system which improves the power supply and hence the rideability of the Piaggio Mp3, allowing the rider to choose between optimum performance and fuel saving by changing the engine mapping via a pushbutton on the handlebar. The result is a great fluidity of engine operation at low revs.
This is due to the single-shaft timing system which uses roller tappets and optimizes the timing diagram to reduce mechanical noise and improve reliability. The intake line is calibrated for an optimum air/fuel ratio (filling coefficient). The duct improves the torque at low revs, guaranteeing an exceptionally smooth ride at all revs, and reducing fuel consumption. The exhaust system layout has been designed to reduce noise and make the sound more harmonic. Finally, the setting of the CVT gearbox also helps to reduce fuel consumption and mechanical noise, ensuring smoother starts through a more gradual clutch.

Piaggio multimedia platform connected at all times by smartphone

The sophisticated Piaggio Multimedia Platform, available from among the many dedicated accessories for the Piaggio Mp3, illustrated in the catalogue, connects your smartphone to the on-board electronic system, turning it into a multi-purpose instrument, a computer able to display simultaneously data such as speed, revs, engine power and torque in real time, as well as acceleration in a straight line, tilt in cornering, average and current fuel consumption, average speed and battery voltage among a host of other functions. A smartphone connected with the Piaggio Multimedia Platform can also be used to display maps and routes or to find the location, for example, of petrol stations or support services. The tyre status control function (only available for Mp3 500 equipped with the ABS/ASR) synergically exploits the vehicle’s sensors and the iPhone to monitor tyre wear and air, warning the user before any potentially critical situations arise; the function of general analysis shows the overall vehicle status.

Two versions different characters, same safety

Piaggio Mp3 It is available in the Business and Sport versions, characterised by dedicated configurations colour range.

Piaggio Mp3 500 Business – sober and elegant

The Business version, elegant and city-friendly, characterized by a “Business”plate on the rear part of the tail, distinguishes itself through some prestige details, such as the chrome-plated exhaust pipe, the saddle with dual lining, dedicated rear-view mirrors and the finish in gunmetal grey of the central tunnel, the handlebars and the passenger handles. The elegance of Piaggio Mp3 500 Business is highlighted by the two chrome-plated versions available: Bianco Iceberg, Nero Universo and Marrone Mercurio.

Piaggio Mp3 500 Sport – sporting and dynamic

The Sport version of Piaggio Mp3 500 is distinguished by the “Sport”plate on the rear of the tail and the numerous items with shiny black finish, such as the protection of the end of the exhaust pipe, the passenger handles, the handlebars and moulding of the central tunnel. The black saddle of the Sport version has a lining in two different materials.
There are three dedicated colour schemes for the Sport version of the new Piaggio Mp3 500: Nero Carbonio, Argento Cometa and Grigio Titanio.

A complete range of accessories

To enhance the role of the metropolitan three-wheeler commuter, a wide range of accessories is available.
The large rear top box, which can be unhooked rapidly, with 50 litre capacity, can house two full-face helmets. The upper shield is painted the same colour as the vehicle and has a comfortable backrest to make the passenger’s ride more enjoyable. Also available is the set of semi-rigid panniers with quick release system, to allow maximum load with minimum encumbrance.
For daily use and in all environmental conditions, the windshield accessory, in high quality anti-chip material, guarantees optimum protection from the air and weather. A great deal of care is put into aesthetics, with rods with the same finish as other vehicle details.
In addition the leg-covering fabric, an increasingly important accessory for commuters whatever the season and irrespective of the weather conditions, was designed to provide maximum warmth and protection against the rain on the new Mp3. The fabric is designed for the vehicle and for perfect safety, and is stable even at high speeds. The leg cover is predisposed for the heating module that, together with heated grips, significantly improves driving comfort in the colder months.
The rider is also protected by a further function of the Piaggio Mp3: thermal and waterproof protection for the hands, the Tunnel Bag, placed simply behind the leg shield back plate, electronic anti-theft systems and the Comfort Gel saddle, which has gel inserts under the lining to provide maximum comfort to the rider and passenger.
With the Mp3 a new range of helmets is available, with hi-tech design, providing safety, comfort and maximum protection.
Helmets in the PJ line include interesting technical and stylistic features, with innovative head design and exclusive side fastening and a large, protective visor.
The breathable interior fittings can be removed and washed. The PJ range of helmets has two configurations: PJ with dual visor (normal and sunscreen) and PJ1 with recessed sunscreen visor.





---



2016 Piaggio MP3 500 Sport ABS – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8999 USD

ENGINE TYPE
Single-cylinder, MASTER, 4-stroke, 4-valve
CYLINDER CAPACITY
492.7 cc
BORE X STROKE
94 mm x 71 mm
MAX POWER AT SHAFT
40.1 hp
MAX TORQUE
45.5 Nm at 5,000 rpm
MAX SPEED
89 mph
FUEL TANK CAPACITY
3.2
GAS MILEAGE
55 mpg
DISTRIBUTION
n/a
COOLING SYSTEM
Liquid
LUBRICATION
Wet sump
IGNITION
Electric
GEARS
‘Twist ‘n go’ automatic CVT
CLUTCH
Automatic centrifugal dry
CHASSIS
Double cradle in high strength steel tubes
FRONT SUSPENSION
Articulated quadrilateral consisting of four aluminum arms sustaining two steering tubes, and leading arm suspension geometry with offset wheel axle. Stroke: 95mm. Electro-hydraulic suspension locking system.
REAR SUSPENSION
Two dual effect hydraulic shock absorbers, preload adjustable to four positions. Stroke: 108 mm
FRONT BRAKE
Stainless steel double disc, 240 mm
REAR BRAKE
Stainless steel disc, 280 mm
FRONT TIRE
13″
REAR TIRE
140/70, 14″
LENGTH
85″
WIDTH
30.5
WHEELBASE
61″
SEAT HEIGHT
30.9″
DRY WEIGHT
577
TYPE APPROVAL
EPA and CARB
ABS
YES
COLORS
Silver, Black



---



2016 Piaggio MP3 500 Sport ABS – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $9195 CDN

ENGINE TYPE
Single cylinder, 4-stroke
CYLINDER CAPACITY
492.7 cc
BORE X STROKE
94 mm x 71 mm
MAX POWER AT SHAFT
40 hp
MAX TORQUE
42.23 Nm at 5,550 rpm
MAX SPEED
89 km/h
FUEL TANK CAPACITY
12 liters
KILOMETERS PER LITER
55 kilometers per liter
DISTRIBUTION
n/a
COOLING SYSTEM
Liquid
LUBRICATION
Wet sump
IGNITION
Electric
GEARS
‘Twist ‘n go’ automatic CVT
CLUTCH
Automatic centrifugal dry
CHASSIS
Double cradle in high strength steel tubes
FRONT SUSPENSION
Articulated quadrilateral consisting of four aluminum arms sustaining two steering tubes, and leading arm suspension geometry with offset wheel axle. Stroke: 95mm. Electro-hydraulic suspension locking system.
REAR SUSPENSION
Two dual effect hydraulic shock absorbers, preload adjustable to four positions. Stroke: 108 mm
FRONT BRAKE
Stainless steel double disc, 240 mm
REAR BRAKE
Stainless steel disc, 280 mm
FRONT TIRE
Tubeless 110/70
REAR TIRE
140/70
LENGTH
2.205 mm
WIDTH
775 mm
WHEELBASE
1540 mm
SEAT HEIGHT
790 mm
DRY WEIGHT
n/a
TYPE APPROVAL
EPA and CARB
ABS
Yes
COLORS
Graphite Black, Matte Silver

---



2016 Piaggio MP3 500 Sport ABS – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £7735 GBP (On The Road inc 20% Vat)

Engine MASTER 4-stroke single cylinder
Engine capacity 493 cm3
Bore x Stroke 94 x 71 mm
Power 29.5 kW (40.1 HP) at 7,250 rpm
Torque 45.5 Nm at 5,250 rpm
Timing system Single overhead cam shaft (SOHC) with 4 valves and roller tappets
Fuel system: Electronic injection
Ignition Electronic with inductive exhaust and variable advance integrated in the injection CPU. Closed loop system with Lambda probe for the exhaust. Electronic immobilizer, block of injection. (STD and ECO). Traction control (ASR)pump when the vehicle is tilted. Twin spark ignition. Dual map for butterfly valve management
Cooling Liquid
Lubrification Wet sump
Starter Electric
Gearbox CVT with torque server
Clutch Automatic, centrifugal dry clutch
Frame Double cradle in high strength tubular steel
Front Suspension Articulated quadrilateral – Stroke: 85 mm. Electrical and hydraulic plant to block suspension
Rear suspension Dual hydraulic shock absorber with pre-adjusted spring in one of 4 positions – Stroke: 108 mm
Front brake Two 258 mm discs
Rear brake 240 mm Ø disc
Front wheel rim Aluminium alloy 13″ x 3.00
Rear wheel rim Aluminium alloy 14″ x 4.50
Front tyre Tubeless 110/70-13″
Rear tyre Tubeless 140/70-14”
Length/Width 2,205 mm / 775 mm
Wheelbase 1,550 mm
Saddle height 790 mm
Fuel tank capacity 12 litres (including 1.8 litre reserve)

*MSRP excludes destination & vehicle preparation charges.
