EVERYTHING YOU LOVE ABOUT H-D TOURING, ONLY ON THREE WHEELS.

2018 Harley-Davidson Tri Glide Ultra:

The Tri Glide® Ultra motorcycle is everything you love about H-D® touring, only on three wheels. You get every feature, starting with the power of its Twin-Cooled™ Milwaukee-Eight® 107 engine. Other touring features include a four-speaker, premium BOOM!™ Box 6.5GT Infotainment System with GPS and color touchscreen, electronic cruise control and 6.8 cubic feet of storage space.

2018 Harley-Davidson Tri Glide Ultra Totalmotorcycle.com Key Features

How much motorcycle can you fit on three wheels? One look at the Tri Glide® Ultra motorcycle and you’ll have your answer.

Harley-Davidson Trike Story – Comfort. Cargo. Head turning style.

Built on a three-wheeled chassis for a confidence inspiring ride, the Harley-Davidson® Trike provides long haul comfort and the perfect combination of power and the unmistakable look, sound and head-turning style that can only be found in a Harley-Davidson® motorcycle.

2018 Harley-Davidson Tri Glide Ultra Totalmotorcycle.com Features and Benefits

THERE’S MORE THAN AN ADDED WHEEL AT WORK HERE

Milwaukee-Eight® V-Twin Engine

A powerful, smooth-running engine with crisp throttle response and a pure, soul-satisfying rumble.

Premium BOOM!™ Box 6.5 Infotainment System

A stylish 6.5-inch full-color touch screen display with hands-free mobile phone, media, and navigation. Delivers powerful, pure sound and dynamic full-range audio

6-Speed Cruise Drive® Transmission

Provides smooth, quiet shifting and reduces engine speed on the highway, so you get a better match between engine turnover and road speed.

Trunk and King Tour-Pak™ Storage

The integrated trunk offers 4.4 cubic feet and 50 pounds of storage capacity, while the waterproof, injection-molded Tour-Pak™ luggage carrier keeps things classy and neat with soft woven-nylon luggage liner and plenty of storage pockets.

Daymaker™ LED Headlamp and LED Foglamps

Darkness-defying headlight to see and be seen.

Batwing Fairing & Splitstream Air Vent

Designed to deliver smoother airflow and reduced head buffeting with a pressure-equalizing duct on the front. It opens and closes with one touch of a button.

2018 Harley-Davidson Tri Glide Ultra – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ USD

Pricing⁶

• Vivid Black $34,499
• Color $35,349
• Two-Tone $35,849
• Anniversary Color $36,249

Engine

• Engine ¹ Twin-Cooled™ Milwaukee-Eight^® 107
• Bore 3.937 in.
• Stroke 4.375 in.
• Displacement 107 cu in
• Compression Ratio 10.0:1
• Fuel System ³ Electronic Sequential Port Fuel Injection (ESPFI)
• Exhaust Chrome, 2-1-2 dual exhaust with tapered mufflers

Dimensions

• Length 105.1 in.
• Seat Height, Laden ⁷ 27.1 in.
• Seat Height, Unladen 28.9 in.
• Ground Clearance 4.9 in.
• Rake (steering head) (deg) 26
• Trail 3.94 in.
• Wheelbase 65.7 in.
• Tires, Front Specification MT90B16 72H
• Tires, Rear Specification P205/65R15 92T
• Fuel Capacity 6 gal.
• Oil Capacity (w/filter) 5 qt.
• Weight, As Shipped 1,204 lb.
• Weight, In Running Order 1,243 lb.
• Luggage Capacity -Volume 6.8 cu ft

Performance

• Engine Torque Testing Method J1349
• Engine Torque ² 114 ft-lb
• Engine Torque (rpm) 3,500
• Fuel Economy: Estimated City/Hwy ⁵ 42 mpg

Drivetrain

• Primary Drive Chain, 34/46 ratio
• Gear Ratios (overall) 1st 10.534
• Gear Ratios (overall) 2nd 7.302
• Gear Ratios (overall) 3rd 5.423
• Gear Ratios (overall) 4th 4.392
• Gear Ratios (overall) 5th 3.741
• Gear Ratios (overall) 6th 3.157

Chassis

• Wheels, Front Type ⁹ Black, 7-spoke Cast Aluminum
• Wheels, Rear Type Black, 7-spoke Cast Aluminum
• Brakes, Caliper Type 6 piston fixed front with 4-31.75 mm front pistons and 2-25.4 mm linked rear pistons, 31.75 mm single piston floating rear

Electric

• Lights (as per country regulation), Indicator Lamps ⁸ High Beam, running lights, front fender running lights, directional lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, gear indication, low fuel warning, reverse, park brake, miles to empty display, fog/aux lamp indicator
• Gauges 10% larger speedometer and tachometer with 68% wider numbers; 28% larger fuel and volt gauges with 30% wider numbers; display features odometer, trip A, trip B, range to empty, and gear indicator; and larger telltale indicators, including new reverse indicator light

Infotainment

• Infotainment system Boom!™ Box 6.5GT
• Type Color
• Watts Per Channel 25
• Speakers 4
• Speaker Size 5.25 inch/6.5 inch – P&A Upgrade
• Headset Specifications (if equipped) 16-64 ohms
• AM Standard
• FM Standard
• Weather Band (WB) Standard
• SD Card, Flash Drive and MP3 – via USB Connection Supported
• SiriusXM Presets 20 – P&A Upgrade (USA & Canada only)
• Languages ”English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese”
• Hands-free Mobile Phone – via Bluetooth Standard
• Voice Recognition Languages: Phone functions only ”English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese”
• Voice Recognition Languages: Tuner/Media/Navigation ”English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese”
• Rider/Passenger Intercom Standard
• Vehicle Information Screen (Air temperature, oil pressure and EITMS) Standard
• Text-to-Speech (TTS) Languages ”English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese”
• USB USB/MTP/iPod/iPhone
• Bluetooth Phone/Media Supported

• 1. Recommended 91 octane or higher fuel (R+M)/2.
• 2. Values shown are nominal. Performance may vary by country and region.
• 3. Recommended 91 octane or higher fuel (R+M)/2.
• 4. See motorcycle owner’s manual for complete details.
• 5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
• 6. Prices listed are the Manufacturer’s Suggested Retail Prices for base models. Options such as color are available at additional cost. Prices exclude tax, title, licensing, registration fees, destination charges, added accessories, and additional dealer charges, if any, and are subject to change. Harley-Davidson reimburses dealers for performing manufacturer-specified pre-delivery inspection and setup tasks. Dealer prices may vary.
• 7. Measurement reflects 180 lb. (81.7 kg) operator weight.
• 8. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
• 9. Standard and optional wheels may vary by country and region.

2018 Harley-Davidson Tri Glide Ultra – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See Dealer for Pricing in CDN

Pricing

• Vivid Black $ 41,999
• Color $ 42,999
• Two-Tone $ 43,549
• Anniversary Color $ 44,499

Dimensions

• Length 2,670 mm
• Seat Height, Unladen 735 mm
• Ground Clearance 125 mm
• Rake (steering head) (deg) 26
• Trail 100 mm
• Wheelbase 1,670 mm
• Tires, Front Specification MT90B16 72H
• Tires, Rear Specification P205/65R15 92T
• Fuel Capacity 22.7 l
• Oil Capacity (w/filter) 4.7 l
• Weight, As Shipped 546 kg
• Weight, In Running Order 564 kg
• Luggage Capacity -Volume 0.19 m³

Engine

• Engine ¹ Twin-Cooled™ Milwaukee-Eight™ 107
• Bore 100 mm
• Stroke 111.1 mm
• Displacement 1,746 cc
• Compression Ratio 10.0:1
• Fuel System ³ Electronic Sequential Port Fuel Injection (ESPFI)
• Exhaust Chrome, 2-1-2 dual exhaust with tapered mufflers

Drivetrain

• Primary Drive Chain, 34/46 ratio
• Gear Ratios (overall) 1st 10.534
• Gear Ratios (overall) 2nd 7.302
• Gear Ratios (overall) 3rd 5.423
• Gear Ratios (overall) 4th 4.392
• Gear Ratios (overall) 5th 3.741
• Gear Ratios (overall) 6th 3.157

Chassis

• Wheels, Front Type Black, 7-spoke Cast Aluminum
• Wheels, Rear Type ⁸ Black, 7-spoke Cast Aluminum
• Brakes, Caliper Type 6 piston fixed front with 4-31.75 mm front pistons and 2-25.4 mm linked rear pistons, 31.75 mm single piston floating rear

Performance

• Engine Torque Testing Method Twin-Cooled™ Milwaukee-Eight™ 107
• Engine Torque ² 154 Nm
• Engine Torque (rpm) 3,500
• Lean Angle, Right (deg.) 1,746 cc
• Fuel Economy: Estimated City/Hwy ⁵ 5.6 l/100 km

Electric

• Lights (as per country regulation), Indicator Lamps ⁷ High Beam, running lights, front fender running lights, directional lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, gear indication, low fuel warning, reverse, park brake, miles to empty display, fog/aux lamp indicator
• Gauges 10% larger speedometer and tachometer with 68% wider numbers; 28% larger fuel and volt gauges with 30% wider numbers; display features odometer, trip A, trip B, range to empty, and gear indicator; and larger telltale indicators, including new reverse indicator light

Infotainment

• Infotainment system Boom!™ Box 6.5GT
• Type Colour
• Watts Per Channel 25
• Speakers 4
• Speaker Size 5.25 inch/6.5 inch P&A Upgrade
• Headset Specifications (if equipped) 16-64 ohms
• AM Standard
• FM Standard
• SD Card, Flash Drive and MP3 – via USB Connection Supported
• SiriusXM Presets 20 – P&A Upgrade (USA & Canada only)
• Languages English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese
• Hands-free Mobile Phone – via Bluetooth Standard
• Voice Recognition Languages: Phone functions only English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese
• Vehicle Information Screen (Air temperature, oil pressure and EITMS) Standard
• Text-to-Speech (TTS) Languages English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese
• USB USB/MTP/iPod/iPhone
• Bluetooth Phone/Media Supported

• 1. Recommended 91 octane or higher fuel (R+M)/2.
• 2. Values shown are nominal. Performance may vary by country and region.
• 3. Standard and optional fuel systems may vary by country.
• 4. See motorcycle owner’s manual for complete details.
• 5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
• 6. Measurement reflects 180 lb. (81.7 kg) operator weight.
• 7. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
• 8. Standard and optional wheels may vary by country and region.

2018 Harley-Davidson Tri Glide Ultra – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ See Below for Pricing in  GBP (On The Road inc 20% Vat)

Pricing⁵

• Vivid Black £30,245
• Color £30,595
• Two-Tone £30,945
• Anniversary Color £31,745

Engine

• Engine ² Twin-Cooled™ Milwaukee-Eight^® 107
• Bore 100 mm
• Stroke 111.1 mm
• Displacement 1,745 cc
• Compression Ratio 10.0:1
• Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
• Exhaust Chrome, 2-1-2 dual exhaust with tapered mufflers

Dimensions

• Length 2,670 mm
• Seat Height, Unladen 735 mm
• Ground Clearance 125 mm
• Rake (steering head) (deg) 26
• Trail 100 mm
• Wheelbase 1,670 mm
• Tyres, Front Specification MT90B16 72H
• Tyres, Rear Specification P205/65R15 92T
• Fuel Capacity 22.7 l
• Oil Capacity (w/filter) 4.7 l
• Weight, As Shipped 546 kg
• Weight, In Running Order 564 kg
• Luggage Capacity -Volume 0.19 m³

Performance

• Engine Torque Testing Method EC 134/2014
• Engine Torque ³ 152 Nm
• Engine Torque (rpm) 3,250
• Fuel Economy Testing Method EC 134/2014
• Fuel Economy: Estimated Hwy/City 37 mpg
• CO2 Emissions Testing Method EC 134/2014
• CO2 Emissions 151 g/km

Drivetrain

• Primary Drive Chain, 34/46 ratio
• Gear Ratios (overall) 1st 10.534
• Gear Ratios (overall) 2nd 7.302
• Gear Ratios (overall) 3rd 5.423
• Gear Ratios (overall) 4th 4.392
• Gear Ratios (overall) 5th 3.741
• Gear Ratios (overall) 6th 3.157

Chassis

• Wheels, Front Type ⁷ Black, 7-spoke Cast Aluminium
• Wheels, Rear Type Black, 7-spoke Cast Aluminium
• Brakes, Caliper Type 6 piston fixed front with 4-31.75 mm front pistons and 2-25.4 mm linked rear pistons, 31.75mm single piston floating rear

Electric

• Lights (as per country regulation), Indicator Lamps ⁶ High Beam, running lights, front fender running lights, directional lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, gear indication, low fuel warning, reverse, park brake, miles to empt
• Gauges 10% larger speedometer and tachometer with 68% wider numbers; 28% larger fuel and volt gauges with 30% wider numbers; display features odometer, trip A, trip B, range to empty, and gear indicator; and larger telltale indicators, including new reverse indi

Infotainment

• Infotainment system Boom!™ Box 6.5GT
• Type Colour
• Watts Per Channel 25
• Speakers 4
• Speaker Size 5.25 inch/6.5 inch P&A Upgrade
• Headset Specifications (if equipped) 16 – 64 ohms
• AM Standard
• FM Standard
• MW Standard
• LW Standard
• SD Card, Flash Drive and MP3 – via USB Connection Supported
• Languages English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese
• Hands-free Mobile Phone – via Bluetooth Standard
• Voice Recognition Languages: Phone functions only English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese
• Vehicle Information Screen (Air temperature, oil pressure and EITMS) Standard
• Text-to-Speech (TTS) Languages English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, European Portugese
• USB USB/MTP/iPod/iPhone
• Bluetooth Phone/Media Supported

• 1. Availability of colours may vary from dealer to dealer and is subject to change without further notice.
• 2. Recommended 95 octane or higher fuel (R+M)/2.
• 3. Values shown are nominal. Performance may vary by country and region.
• 4. See motorcycle owner’s manual for complete details.
• 5. Prices shown are suggested retail prices only. Please contact your nearest dealer for further details.
• 6. Security system includes immobiliser and siren.
• 7. Standard and optional wheels may vary by country and region.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
