2019 Honda CRF450L Guide

2019 Honda CRF450L

2019 Honda CRF450L 2019 Honda CRF450L 2019 Honda CRF450L 2019 Honda CRF450L 2019 Honda CRF450L

THE TRAILS ARE CALLING.

2019 Honda CRF450L:

This is the bike so many have been waiting for. The one serious riders have dreamed about. A true street-legal dirtbike that offers the reliability, refinement and quality of a Honda, along with the light weight, handling, and power of our best off-road machines. Introducing the new 2019 CRF450L. Sure, you’ve seen dual-sport bikes before, but this is something much, much more: a true trail-to-trail machine. Developed in tandem with our all-new 2019 CRF450X, it features a powerful 449cc Unicam engine, twin-spar aluminum CRF chassis, six-speed transmission, and premium suspension. Electric start? Naturally. All-LED lighting package? Of course. Until now, you’ve always had to choose between performance and reliability. No longer—with the CRF450L, you get the best of both worlds. And “best” is a word you’re going to hear a lot when you’re talking about this bike.

The trails are calling, and the all-new, road-legal CRF450L answers, expanding customers’ off-road possibilities by enabling access to the best riding trails on public lands, even when that means connecting them via asphalt roads. Based on the CRF450R, the durable CRF450L is a full-fledged off-road machine, but with street legality achieved via features like LED lighting, mirrors, and a dedicated exhaust system, making this bike equally at home in the woods, desert, or the roads in between.

TRAIL TO TRAIL . . . AND THEN SOME.





2019 Honda CRF450L Totalmotorcycle.com Key Features

Engineering
Fully Street Legal
The CRF450L is equipped with a catalytic converter and is fully street legal in all 50 states. That means you can ride it wherever it’s legal to operate a motor vehicle—in state and national parks, on the road, on public lands. Plus, you don’t need to haul your bike to the trailhead in a truck or on a trailer. Best of all, it makes finding gas a breeze.

Electric Start
An electric start system ensures trouble-free starting in all conditions. The electric starter also drives the clutch side of the crankshaft to provide superior lubrication to starter gears while producing a narrow engine with a short, strong crank.

Six-Speed Transmission
Like our CRF450X, the CRF450L rocks a six-speed gearbox. That gives you a low gear perfect for tight, slow situations, and a top gear that’s tall enough for highway riding to the next gas stop or trailhead.

Lithium-Ion Battery
Light, compact, and offering excellent performance—just like the CRF450L itself! Conventional batteries are heavy, but not this premium piece. It’s all part of why your new CRF450L performs as well as it does.

Inertia-Tuned Crank
We redesigned the CRF450L’s crank to have 13 percent more inertia than the CRF450R. Why? To smooth out power delivery and make the engine more user-friendly in tight, technical situations.

Dual Radiators
The CRF450L’s dual radiators feature a refined core area for superior heat dissipation compared with conventional dual-radiator designs. A coolant recovery tank is located in front of the engine between the frame downtubes for improved center of mass, and the tank is protected by a plastic skid plate.

Final-Drive Sprocket Damper
Designed to keep your bike quieter while not adding any weight, these unique drive sprockets are just another example of the CRF450L’s innovative engineering.

Electric Fan
The CRF450L is a “ride anywhere” type of bike, and because conditions vary so widely, we’ve equipped it with a light electric fan for the radiator. Rock crawling or riding on a hot Arizona single-track, it helps keep your engine running cool.

Titanium Fuel Tank
Holding 2.01 gallons, the CRF450L’s premium titanium tank is light and tough.

Skid Plate
The CRF450L’s factory skid plate is light, yet also offers the engine and lower-frame protection serious riders demand on a machine like this.

LED Headlight
The CRF450L features an all-LED lighting package, including the headlight. That’s a big deal, because it takes a lot of weight off the front end. And the lighting pattern is also specially designed for both on- and off-road situations.

LED Taillight
The LED taillight is integrated into the rear fender. It’s light, compact and rigid.

Performance
449cc Unicam Engine
Honda’s Unicam cylinder heads combine the best of single- and double-overhead-cam designs. The configuration contributes to a compact engine that saves weight over a comparable dual-overhead-camshaft motor and also permits a narrow included valve angle. This flattens the combustion chamber to facilitate ignition flame propagation, allowing a high compression ratio. Since less space is taken up in the cylinder head, the camshaft sits lower in the head for a more compact engine and a lower center of gravity.

Titanium Intake and Exhaust Valves
Lightweight titanium intake and exhaust valves permit use of smaller valve springs, reducing overall engine height.

Fuel Injection
The CRF450L features our proven fuel-injection system. It’s part of the reason the CRF450L offers such excellent torque and spot-on metering and response, especially in the critical low-rpm range. It also automatically compensates for elevation and weather changes.

Handling
Twin-Spar Chassis
This is the same design as our all-new CRF450X uses, and that’s a really big deal. It means the CRF450L is a true off-road bike, and not some compromise. The twin-spar aluminum frame is both light and stiff, and provides the basis for the CRF450L’s excellent handling. The chassis geometry is specially selected for responsiveness, and also is wider than the standard MX frame to accommodate the six-speed transmission.

IRC GP Tires
The CRF450L’s tires give you good off-road traction and on-road life. Tires are always a critical part of any on/off-road bike, and we’ve hooked you up with some great ones here.

Low Center of Gravity
The compact Unicam engine and Honda’s famous concentration on center-of-mass engineering help keep the CRF450L’s center of gravity low. That means the bike feels lighter, and it helps handling too.

Works-Style Front Brake
Compact twin-piston front brake caliper, anodized-aluminum brake pistons and lightweight 260mm front disc offer great stopping power while minimizing unsprung weight for improved turning and handling.

Works-Style Rear Brake
HRC works-type rear brake system uses a 240mm brake rotor combined with an integrated rear master-cylinder and fluid reservoir, a set-up that eliminates the separate reservoir and hose.

18-Inch Rear Wheel
The CRF450L’s 18-inch rear wheel gives you an excellent choice of on/off-road tires.

Comfort
Gear-Driven Counterbalancer
The Gear-Driven Counterbalancer reduces vibration and drives the water pump. Eight clutch plates provide the surface area necessary to handle the engine’s massive torque, while carefully matched clutch springs provide a light feel at the lever.

Works MX Styling
Having a hard time spotting the differences between our factory MX bikes and the new CRF450L? You’re excused. The “L” looks like our MX bikes because it’s derived from them—the smooth bodywork makes it easy to move around, and the in-mold graphics not only look cool but are durable, too.

Black Rims
They may not help you go faster, but the sweet black DID rims sure look good.

Superior Ergonomics
Placing the rider’s legs at the narrowest part of the frame helps improve comfort and handling.

Sidestand
Hey, a sidestand may seem like no big thing, but take a look at the one the CRF450L uses. Tucked up high and out of the way, this forged alloy piece is just another example of how the CRF450L gets it right.

Fuel Mileage Meter
An important feature for planning gas stops and calculating your bike’s range under varying conditions, the Fuel Mileage Meter shows current fuel mileage and average fuel mileage as well as fuel consumption. Displays in either miles or kilometers, and applies to both the A and B tripmeters. The Fuel Mileage Meter is in the same digital instrument display as the speedometer, odometer, tripmeters and digital clock.



Honda Broadens CRF Lineup with Expansive New-Model Launch
Largest performance off-road release yet includes new models for diverse applications

During a recent “CRF Collective” unveiling ceremony at Fox Racing headquarters, Honda announced its most far-reaching range of performance off-road models ever, expanding the group by three and significantly improving the four returning models. Leveraging the brand’s unparalleled experience in the manufacture of dirt bikes, Honda’s performance off-road lineup now includes CRF machines for riding applications including motocross, closed-course off-road, pure off-road, and even dual sport.

All seven models are based on the platforms of Honda’s revolutionary motocrossers, the CRF450R and CRF250R. Those two machines return for 2019 but with important updates, as does the closed-course off-road CRF450RX. In addition, Honda is offering a factory-replica version of its full-size motocrosser called the CRF450RWE (“Works Edition”). The trail-ready CRF450X is entirely new for 2019, and it’s joined by a road-legal CRF450L that enables customers to connect trails via asphalt. Finally, Honda is also introducing an all-new CRF250RX closed-course off-road machine.

“Honda’s history in off-road is something we’re very proud of, from the ’70s-era Elsinores, through the XRs of the ’80s and ’90s, to the post-millennial CRF models,” said Lee Edmunds, American Honda’s Manager of Motorcycle Marketing Communications. “For 2019, it’s exciting to build on that reputation with the most expansive lineup of CRF performance off-road models ever offered, and to reach a wide range of enthusiasts through motorcycles that are tailored to an equally diverse spectrum of riding environments. With this new lineup, there really is a CRF off-road performance machine for everyone.”

CRF450L
The trails are calling, and the all-new road-legal CRF450L answers, expanding customers’ off-road possibilities by enabling access to the best riding trails, even when that means connecting them via asphalt roads. Street legality is achieved via features like LED lighting, mirrors, and a dedicated exhaust system. Equally at home in the woods or desert, the CRF450L has a wide-ratio six-speed transmission for maximum adaptability, while a lightweight, 2.0-gallon tank offers great range. Compared to the CRF450R motocrosser, crank mass is up for tractability in technical conditions, where a large-capacity radiator keeps things cool.
•Color: Red
•Availability: September

CRF450RWE
For the 2019 model year, you don’t have to be Ken Roczen to enjoy a CRF450R with factory enhancements, as the new CRF450RWE features a number of upgrades based on the bikes in the Team Honda HRC race shop. Rocketing to the top step of the podium through the use of a specially designed cylinder head with hand-polished ports, Yoshimura titanium slip-on muffler, and special ECU settings, this new model offers increased low- and mid-range torque. It also features the same graphics as Roczen’s No. 94 race bike, including a Throttle Jockey factory seat cover. Upgraded black D.I.D LT-X rims are included, along with black triple clamps and a gold RK chain. Titanium nitride-coated fork legs and an updated, titanium nitride-coated shock shaft increase traction and bump absorption.
•Color: Red
•Availability: August

CRF450R
Already the industry’s top-selling motocrosser and the winner of the 2018 Daytona Supercross at the hands of MotoConcept’s Justin Brayton, the CRF450R receives a number of important updates for 2019. Better engine performance is achieved through a new combustion-chamber shape, as well as improved over-rev characteristics through a refined oil-management system. The frame and swingarm have been revised for optimized rigidity and weight reduction, while the braking system has been updated with a lightweight front brake caliper featuring a large-piston design. As a result of the weight-saving measures, the CRF450R is 1.76 lbs. lighter than its predecessor. For added performance and increased comfort, the 2019 model features new ECU settings, HRC launch control, a Renthal Fatbar® handlebar and adjustable handlebar position. Black rims and redesigned fork protectors are also new. This is how you convert the “Absolute Holeshot” into moto wins.
•Color: Red
•Availability: August

CRF450X
Having featured heavily in Honda-mounted teams winning 20 of the last 21 Baja 1000s, the CRF450X gets a complete overhaul for 2019, based on the modern CRF platform but with off-road-appropriate features. A true off-road machine that’s ready for racing or trail riding, this model features a headlight, taillight, and side stand, as well as an 18″ rear wheel and lightweight 2.0-gallon fuel tank. For maximum versatility in challenging terrain, the CRF450X also features a 49mm Showa fork with dedicated settings, wide-ratio six-speed transmission, and higher crank mass than the CRF450R.
•Color: Red
•Availability: October

CRF450RX
Currently campaigned by JCR Honda’s Trevor Bollinger and Trevor Stewart in GNCC and WORCS competition, respectively, the CRF450RX inherits the same performance-enhancing features of the 2019 CRF450R, including an updated cylinder head and refined oil-management system, while still featuring off-road-specific features like a 2.2-gallon resin fuel tank, 18-inch rear wheel, and aluminum side stand. Suspension is specially tailored to the CRF450RX and uses low-friction fork oil. For added performance and increased comfort, the 2019 model features new ECU settings, HRC launch control, a Renthal Fatbar handlebar, and adjustable handlebar position. Black rims and redesigned fork protectors are also new.
•Color: Red
•Availability: September

CRF250RX
Based on Honda’s successful 250cc motocrosser, the all-new CRF250RX joins the CRF450RX as a weapon for closed-course off-road competitions throughout America. Equipped with a larger-capacity, 2.2-gallon resin fuel tank, 18-inch rear wheel, and aluminum side stand, the RX makes quick work of challenging situations, its dedicated suspension and ECU settings helping the rider work through even the toughest trail sections. As with the CRF250R, HRC launch control, a Renthal Fatbar handlebar, and black rims are standard.
•Color: Red
•Availability: September

CRF250R
Newly introduced in 2018, the CRF250R has seen the GEICO Honda and TiLube Honda teams earn multiple wins in AMA Supercross and Arenacross competition, respectively, while also achieving success in amateur national races. For 2019, the model is revised with increased low-to-midrange engine performance for improved corner exiting. Inspired by the factory version, the Double Overhead Cam engine features updated cam profiles and intake- and exhaust-port profiles, a 50mm shorter right exhaust pipe, and a 2mm smaller throttle body. Riders can select from three engine modes for ideal performance depending on conditions, while HRC launch control has been adopted for improved race-start performance. A Renthal Fatbar handlebar sits in a four-position-adjustable top clamp, while the braking system has been updated with a lighter, CRF450R-inspired caliper with larger piston for optimum braking performance. Black rims are standard.
•Color: Red
•Availability: September

CRF150R / CRF150RB
Raced by Amsoil Honda hotshot Hunter Yoder on the amateur national circuit, Honda’s smallest motocross machine returns for 2019, featuring a Unicam four-stroke engine that offers a spread of ample, useable power and torque across the rev range. Suspension duties are handled by Showa, with a 37mm inverted fork and Pro-Link rear link system. In addition to the standard version, Honda offers the CRF150RB, which features larger wheels, a taller seat, a longer swingarm, and more rear-suspension travel.
•Color: Red
•Availability: August







2019 Honda CRF450L Totalmotorcycle.com Features and Benefits

•Lightweight, 2.0-gallon titanium fuel tank for long range
•Riding time maximized by lightweight, compact LED lighting system, featuring headlight with high-intensity projection for illuminating broad area
•Rear-view mirrors
•Lightweight lithium-ion battery with increased capacity compared to CRF450R, to power electrical components
•Lightweight, compact digital meter with black characters on a white liquid-crystal background is easily legible while riding

Engine/Drivetrain
•449.7cc Unicam® engine specially tailored for trail-to-trail riding
•Finger rocker arm contributes to compact layout while using dedicated design to attain off-road-specific power characteristics. DLC surface treatment reduces friction
•Dedicated valve timing for smooth power delivery in technical riding
•High crank inertia (up 12% over CRF450R) for tractable power delivery in technical terrain
•12.0:1 compression ratio
•New piston with three-ring design
•Wide-ratio six-speed transmission is ready for a wide variety of off-road terrain or road going
•Special clutch design enables light lever pull. Primary damper mechanism with friction springs suppresses engine torque fluctuations, ensuring smooth running
•Large-capacity radiators with high heat-exchange efficiency for strong performance in demanding off-road conditions
•Electric fan and thermostat control engine temperature in brutal conditions
•ECU with dedicated settings
•Noise emissions minimized via covers on the left and right crank cases
•Powerful AC generator for street-legal lighting
•Air cleaner box
•Dedicated single-muffler exhaust system provides great sound while meeting emissions requirements

Chassis/Suspension
•Aluminum twin-spar frame designed for nimble-yet-stable handling on trails
•Subframe designed to ensure optimum rigidity balance appropriate for carrying tools
•49mm Showa fork with dedicated settings for trail-to-trail riding
•Shock based on that of the CRF450R but with dedicated settings and link ratio for off-road riding
•Front brake uses design from CRF450R, but with better fade resistance thanks to thicker discs and large-capacity reservoir
•Endless sealed chain withstands the elements
•Front and rear sprockets, produced in durable steel material, feature damper system for smooth, quiet running
•Urethane injection in swingarm to reduce road noise
•Fuel tank cap with a cut-off valve prevents fuel from flowing out of tank if the bike is on its side
•LED turn signals with flexible mounts for durability
•Easily accessible electronic component box on left side of the frame
•Black 7/8″ Renthal handlebar with red pad
•Compact, lightweight handlebar switches
•In-mold graphics are resistant to peeling caused by washing or abrasion
•IRC GP-21F/GP-22R tires provide great balance of on- and off-road performance
•Black rims for strong presence







2019 Honda CRF450L – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $10399
USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

ENGINE
Engine Type
449cc liquid-cooled single-cylinder four-stroke

Bore And Stroke
96mm x 62.1mm

Compression Ratio
12.0:1

Valve Train
Unicam OHC, four-valve

Induction
Programmed Fuel Injection (PGM-FI), 46mm downdraft throttle body

Ignition
DC-CDI

DRIVE TRAIN
Transmission
Close-ratio six-speed

Final Drive
#520 Chain

CHASSIS / SUSPENSION / BRAKES
Front Suspension
49mm leading-axle inverted telescopic Showa coil-spring fork with rebound and compression damping adjustability

Rear Suspension
Pro-Link Showa single shock with adjustable spring preload, rebound and compression damping adjustability

Front Brake
Single 260mm disc with twin-piston caliper

Rear Brake
Single 240mm disc

Front Tire
IRC GP21 80/100-21 w/tube

Rear Tire
IRC GP22 120/80-18 w/tube

DIMENSIONS
Wheelbase
58.9 inches

Rake (Caster Angle)
28° 20′

Trail
4.6 inches

Seat Height
37.1 inches

Ground Clearance
12.4 inches

Fuel Capacity
2.01 gallons

Curb Weight
289 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride.)

Miles Per Gallon
TBD

OTHER
Available Colors
Red

Model ID
CRF450L





2019 Honda CRF450L – Totalmotorcycle.com Canada Specifications/Technical Details

TBA





2019 Honda CRF450L – Totalmotorcycle.com European Specifications/Technical Details

TBA





2019 Honda CRF450L – Totalmotorcycle.com Australian Specifications/Technical Details

TBA



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
