2021 Yamaha MT-09 SP Guide

2021 Yamaha MT-09 SP

2021 Yamaha MT-09 SP 2021 Yamaha MT-09 SP 2021 Yamaha MT-09 SP 2021 Yamaha MT-09 SP 2021 Yamaha MT-09 SP 2021 Yamaha MT-09 SP

2021 Yamaha MT-09 SP : PREMIUM SPECIFICION AND EXCLUSIVE FINISH.

Introducing the new 2021 Yamaha MT-09 SP…

The Dark Side of Japan never sleeps. It’s the inspiration behind every Yamaha MT. And the exclusive MT-09 SP is the latest masterpiece to emerge from the Darkness. Featuring exclusive R1M-inspired colours as well as premium suspension and Cruise Control, the ultimate 3-cylinder Hyper Naked is ready to inspire and excite.

Challenge the Darkness
Its 889cc EU5 CP3 engine produces even more linear torque at lower rpm for awesome acceleration – while its R1-type 6-axis IMU and lean-sensitive electronic rider aids give you precision control in the wet and dry. And with fully adjustable 41mm front forks and a high specification Öhlins rear shock, the all-new chassis is sharper than ever.

As well as the exclusive Icon Performance colours the MT-09 SP comes equipped with a special double stitched seat for the ultimate fit – and the brushed anodized swingarm, anodized black handlebars and levers and clear-smoked brake reservoirs add to the model’s premium looks and feel.



The Dark Side of Japan
Since 2013 the Dark Side of Japan has been the inspiration behind the development of Yamaha’s MT models that have brought a whole new level of excitement and dynamism to Europe’s thrill-seeking riders. Designed and built by people who eat, breathe and sleep motorcycles, Yamaha’s MT models have created their own dynamic Hyper Naked category and introduced a huge number of riders to a new kind of two-wheel experience.

With their torque-rich engine performance, agile handling and naked good looks, each and every MT is designed to deliver a sporty, thrilling and rewarding ride that reinforces every motorcyclist’s passion for two wheels. With over a quarter of a million MTs sold in Europe since the first model arrived seven years ago, the Yamaha Hyper Naked range is helping to make motorcycling an even more exciting, accessible and attractive lifestyle choice.

New MT-09 SP: Sharper, smarter and more exclusive
With its all-new engine and chassis, and a radical, new coverless body design that exposes its brutal and muscular good looks, the 2021 MT-09 is the purest and most exciting Hyper Naked to date. But for those riders who demand the highest specification, Yamaha have created the MT-09 SP, an even sharper, smarter and more exclusive motorcycle that features an aggressive supersport-influenced finish with premium suspension.

Dedicated SP colours and graphics
The MT-09 SP’s exclusive new R1M-influenced Icon Performance colour features a blue/black multi-toned paint scheme on the fuel tank and air ducts to give an even more aggressive and exclusive look to this top-of-the-range Hyper Naked. The premium finish is enhanced with seamless water-transfer graphics, and the supersport-style colours reinforce the bike’s pure-sports character and highlights the close technological links with the R1M – the most advanced high-performance production Yamaha ever built.

Cruise Control system
In addition to the comprehensive electronic rider aids featured on the standard MT-09, the premium MT-09 SP is also equipped with a Cruise Control system that enhances the overall riding experience.

For a more relaxing ride on the highway, SP riders can choose to activate this Cruise Control system at speeds of at least 50km/h and in 4th gear and above. After the speed has been set it can be increased in 2km/h increments by single pushes of the switch, or can be steadily increased by holding down the switch – and the system is cancelled whenever the brakes, clutch or throttle are used. As well as helping to give an easier ride on longer journeys, the SP’s Cruise Control is also a useful feature that can help riders observe prevailing speed limits without having to constantly check their speedometer.

Premium KYB® front suspension package
Featuring 41mm tubes with a tough DLC (Diamond Like Coating) that ensures ultra-smooth and responsive suspension action, the premium specification KYB® front forks feature full adjustability for preload, rebound and compression damping – enabling the SP rider to achieve the ultimate set-up to suit different riding situations. In addition, these state-of-the-art front forks are also equipped with low and high-speed compression damping adjusters for accurate tuning of the suspension.

Öhlins rear shock absorber
To match the high grade front suspension, the rear suspension system features a premium specification Öhlins rear shock absorber. Offering the rider full adjustability for compression and rebound damping – and equipped with a remote preload adjuster that enables quick and easy setting – this SP-exclusive rear suspension brings supersport handling precision to the Hyper Naked class.

Double-stitched seat
The MT-09 SP’s exclusive double-stitched seat with its contrasting stitching has been developed to give the rider an unrivalled feeling of unity when aboard this premium Hyper Naked. The shape of the seat and fuel tank – as well as the overall ergonomics – have been developed through Kanno Hyoka – that is to say, evaluating motorcycle performance based on test rider perceptions and feedback. This exhaustive process ensures that the finished product enhances the total riding experience.

Anodized brushed aluminium swingarm
Another feature that is exclusive to the MT-09 SP is the beautifully finished swingarm that features a special brushed and anodized surface that perfectly complements the new Crystal Graphite frame. Together with other unique details – such as the yellow spring on the Öhlins rear shock absorber and black drive sprocket– the SP’s swingarm reinforces the premium feel and pure sporty looks of this class-leading Hyper Naked.

SP-specific chassis components
SP-specific features such as the anodized black handlebars and levers, as well as clear-smoked front and rear brake fluid reservoirs and a black drive sprocket reaffirm the MT-09 SP’s status as the most exclusive Hyper Naked in the class.







2021 Yamaha MT-09 SP Totalmotorcycle.com Key Features

Back in 2013 Yamaha changed the landscape of the motorcycle world with the introduction of the original MT-09. With its sharp focus on linear torque, lightweight agility and brutal naked looks, the bike was an instant success. Over the next decade the MT Hyper Naked range grew rapidly – and to complete the line-up, the exclusive SP model was created.

  • All-New 890cc Liquid-Cooled 3-Cylinder DOHC Fuel-Injected Engine
    The MT-09 SP features a newly developed 890cc liquid-cooled 3-cylinder, DOHC, 4-valve-per-cylinder fuel-injected (YCC-T) engine with a downdraft intake. The bore × stroke of 78 mm × 62.1 mm and 11.5:1 compression ratio provide outstanding torque with strong power delivery characteristics. Almost all of the fundamental parts of the engine, from the pistons and connecting rods to the crankshaft, camshafts and crankcase, have all been redesigned with a reduction in weight. The combination of improved combustion efficiency and lighter weight results in an impressive fuel efficiency of 49 MPG.
  • Premium KYB and Öhlins Suspension
    The MT-09 SP’s KYB front suspension can be individually adjusted on each side for compression and rebound damping. Adjustments for high and low speed compression damping can also be made, giving riders more detailed settings to choose from. The 41mm inner tubes’ DLC coating provides excellent sliding characteristics and also adds to the exterior’s quality appearance. The MT-09 SP’s rear shock features a premium Öhlins shock absorber with a remote preload adjuster, completing this class-leading suspension package.
  • Cruise Control
    The MT-09 SP features a cruise control system for easy, relaxed riding. Cruise control can be set when going at least 31 mph (or 50 kmh) and in 4th gear or higher. After the cruise speed is set, the speed can be increased or decreased in increments of 1 mph (or 2 kmh) with single pushes of the switch or by continuously holding down the switch. Cancel the cruise control by braking or by using the clutch or the throttle. The “Resume” function reengages the system and returns the bike to its previous set speed.
  • Unique Styling
    The MT-09 SP features special colors and graphics, a distinguished seat cover with its stylish, contrasting stitching, a clear-coated silver swingarm and clear-smoked front and rear brake fluid reservoirs that bring out the bike’s pure mechanical beauty. Together, these features showcase the MT-09 SP’s high quality, exclusive look among the MT lineup while linking the bike to the colorway found only on the YZF-R1M. In addition, the levers, handlebars and drive sprocket are a sleek black to further complement the MT-09 SP’s design to give the rider the feeling of being one with the machine.
  • Lightweight Aluminum Frame
    The MT-09 SP’s lightweight aluminum frame showcases the MT’s signature “agility.” To ensure both straight-line stability and handling performance, the balance of longitudinal, lateral and torsional rigidity have been improved. Most notably, the lateral rigidity has been increased by approximately 50% for even more straight-line stability. The all-new frame is manufactured using the latest in Yamaha’s controlled filling (CF) die casting technology which contributes to the MT-09 SP’s light weight
  • 6-Axis IMU
    The MT-09 SP features a newly developed 6-axis Inertial Measurement Unit (IMU) that retains the base performance of proven IMU in the YZF-R1 but is 50% smaller and 40% lighter due to a thorough review of the sensor layout. The engine control unit (ECU) that receives and reflects the data from the IMU is equipped with three rider aids: a Traction Control System (TCS), Slide Control System (SCS) and front-wheel LIFt control system (LIF). All three systems work together to help the rider concentrate on riding to better extract the machine’s potential. Each of the systems can also be turned on or off and have their levels of intervention adjusted to preference. With this best-in-class electronic control technology, the 2021 MT-09 gives you the ultimate control in varying weather and surface conditions.
  • 3.5-inch Full-Color TFT Instrument Display
    The MT-09 SP’s 3.5-inch full-color TFT display features a bar-type tachometer that changes colors as rpm rises or falls, a clock and displays for remaining fuel, average mileage, water temperature, air temperature and a gearshift indicator (color reversed for gear in use). Easily switch between displays and information with the handlebar switches.





SP-specific features (italic):

  • Dedicated ‘Icon Performance’ YZF-R1M-inspired colours
  • Cruise Control system
  • Premium KYB® front suspension package
  • Öhlins rear shock absorber
  • Double-stitched seat
  • Anodized brushed aluminium swingarm
  • Anodized black levers, handlebars and black rear sprocket
  • Clear-smoked front and rear brake fluid reservoirs



MT-09 SP & MT-09 features:

  • New 889cc inline 3-cylinder 40-valve DOHC liquid-cooled EU5 engine
  • More power at all engine speeds
  • 7% increase in maximum torque at lower rpm
  • 4PS increase in maximum power
  • New 2.3kg lighter CF die-cast aluminium Deltabox chassis
  • Lower 189kg wet weight – 4kg reduction and the lightest in 900cc naked class
  • Shorter wheelbase for more dynamic handling
  • New lightweight aluminium swingarm
  • Bare and beautiful ‘coverless’ new generation MT styling
  • Premium quality throughout, with Crystal Graphite frame finish
  • Full LED lighting with Y-shape brand signature icon front and rear
  • New Quick Shift system with up and downshift functions
  • Refined A&S clutch
  • Light and compact new 6-axis IMU
  • Lean-sensitive rider aids: TCS, SCS and LIFt with three intervention modes
  • ABS and Brake Control system (BC)
  • D-MODE switchable engine running modes
  • New ultra-light SpinForged 17-inch 10-spoke wheels
  • Larger 180/70-17 rear tyre with 120/70-17 front tyre
  • Full colour 3.5-inch TFT instruments with remote handlebar switch
  • Radial front master cylinder, 298mm dual front discs









2021 Yamaha MT-09 SP Totalmotorcycle.com Features and Benefits

New Features

Rider Benefit

Dedicated SP colours Exclusive Icon Performance colours highlight the MT-09 SP’s close links with the R1M supersport
Cruise Control System Cruise Control can be activated above 50 km/h in 4th gear or higher, making it easy to observe speed limits and providing added relaxation on the highway
Premium fully-adjustable suspension Equipped with a DLC coating for super-smooth suspension action, the high specification front forks feature full adjustability together with separate adjusters for high and low speed compression damping, allowing the rider to achieve the ultimate set-up. At the rear an Öhlins shock offers full adjustability for outstanding handling performance
Double-stitched seat Featuring stylish contrasting stitching, the specially developed seat is shaped to give an instant feeling of fit for outstanding rider/machine unity
Brushed aluminium swingarm The exclusivity of the MT-09 SP is further highlighted by the anodized brushed aluminium finish of the lightweight swingarm



MT-09 SP & MT-09

New Features

Rider Benefit

6-axis IMU plus lean-sensitive rider aids Light and compact 6-axis IMU derived from R1. With lean-sensitive TCS, SCS & LIFt, plus BC systems. The most advanced electronic rider aids give extreme control in varying weather and surface conditions
Full-colour 3.5-inch TFT instruments Comprehensive information displayed in a clear, modern and precise format. Enables rider to control the intervention level of the electronic aids via handlebar switches
Compact, bifunctional LED headlight Projector headlight with multiple LEDs for broad, powerful and evenly spread low and high beams. LED position lights project a signature Y-shape icon to underline the pure, next generation MT looks
Quick Shift System Fast and smooth upshifting, new downshift function and refined A&S clutch give greater chassis stability for enhanced controllability during deceleration
Lightweight SpinForged wheels Yamaha’s lightest ever Aluminium production bike wheels reduce total unsprung weight by 700g for more responsive suspension action; reduced gyroscopic moment of inertia for more agile handling
New larger-capacity 889cc EU5 engine Substantially increased torque at lower rpm, increased power, lower weight, EU5 compliant
All-new die-cast aluminium Deltabox chassis 2.3kg lighter, shorter wheelbase for increased agility, higher rigidity for a more stable and dynamic ride
Next generation design and styling Coverless minimalist design, bare and beautiful looks, dynamic style, purest MT DNA, brutal yet sophisticated. Premium Crystal Graphite frame finish highlights pure mechanical beauty
Radial front master cylinder R1 type radial front master cylinder delivers linear stopping power with the highest degree of controllability

ENGINE

  • All-New 890cc Liquid-Cooled 3-Cylinder DOHC Fuel-Injected Engine
    The MT-09 SP features a newly developed 890cc liquid-cooled 3-cylinder, DOHC, 4-valve-per-cylinder fuel-injected (YCC-T) engine with a downdraft intake. The bore × stroke of 78 mm × 62.1 mm and 11.5:1 compression ratio provide outstanding torque with strong power delivery characteristics. Almost all of the fundamental parts of the engine, from the pistons and connecting rods to the crankshaft, camshafts and crankcase, have all been redesigned with a reduction in weight. The combination of improved combustion efficiency and lighter weight results in an impressive fuel efficiency of 49 MPG.
  • Efficient Fuel Delivery System
    The fuel delivery system has been completely redesigned from the former MT-09. The fuel injectors were attached directly to the cylinder head, but the fuel injectors of the MT-09 SP are now attached to the throttle valve side of the throttle bodies. The injectors now spray at the back of the intake valve heads to promote atomization of the fuel and reduce adhesion of fuel particles to the port walls, producing outstanding combustion efficiency. The throttle valve is operated using the Yamaha Chip Controlled Throttle (YCC-T) electronic system which has been widely proven on YZF series models as well as the earlier MT-09 models.
  • Lightweight Forged Pistons
    The lightweight forged pistons allow for smooth, high-revving power.
  • Fracture-Split Connecting Rods
    The forged connecting rods are made using the fracture-split method—where the big-end ring of the connecting rod is purposefully fractured and then reassembled—to ensure an unparalleled degree of manufacturing accuracy. This creates a pair of perfectly matching halves that produce a much more precise mating surface when the rods are bolted together again around the crankshaft.
  • Offset and Direct-Plated Cylinders
    The CP3 engine mounts its three cylinder bores forward, towards the exhaust side. This offset reduces the piston to cylinder wall friction, creating more power and improved fuel economy while the direct-plated ceramic-composite cylinder bores provide excellent heat dissipation and reduced friction.
  • Symmetrical Muffler with Dual Outlets
    The muffler on the MT-09 SP contributes to a lower overall weight and mass centralization but also produces a low-frequency exhaust note at low speeds. The exhaust tailpipes are left-right symmetrical which directs sound pressure to both sides of the machine, creating an exhaust note that delivers a sense of torque to the rider. The stainless steel header pipes are each given a different curvature and length for an excellent pulse effect.
  • Harmonious Intake System
    The intake system suits the new engine and provides linear response when the rider opens and closes the throttle. The three intake ducts also contribute to the excellent engine sound at midrange and high rpm. These ducts are designed with different cross sections and lengths so that the intake sounds they produce individually resonate harmoniously at varying wavelength ranges. At the same time, the sound pressure has also been tuned to create a pleasing sound in the mid- and high-rpm range. The result is an air cleaner box that achieves both good intake efficiency and a pleasing sound that enhances the feeling of acceleration.
  • Assist and Slipper Clutch
    The MT-09 SP features an Assist and Slipper (A&S) clutch that has specifications selected to best match the new engine for a lighter clutch lever pull and smoother chassis behavior during downshifts.
  • Optimized Transmission Ratios
    The transmission ratios have been optimized, with the gear ratios for 1st and 2nd gear slightly higher than on previous MT-09s (1st gear: from 2.666 to 2.571; 2nd gear: from 2.000 to 1.947). Working in combination with the increased momentum of inertia of the crankshaft and the fuel injection settings, the transmission provides the right balance of a powerful torque feeling and ease of use, from acceleration to stopping.



CHASSIS/SUSPENSION

  • Lightweight Aluminum Frame
    The MT-09 SP’s lightweight aluminum frame showcases the MT’s signature “agility.” To ensure both straight-line stability and handling performance, the balance of longitudinal, lateral and torsional rigidity have been improved. Most notably, the lateral rigidity has been increased by approximately 50% for even more straight-line stability. The all-new frame is manufactured using the latest in Yamaha’s controlled filling (CF) die casting technology which contributes to the MT-09 SP’s light weight
  • Aluminum Die Cast Subframe
    The MT-09 SP employs a controlled filling aluminum die-cast subframe that reduces weight, contributing to the model’s signature feeling of agility.
  • Lightweight, High-Rigidity Swingarm
    The MT-09 SP features a newly developed swingarm that uses a welded box shape of aluminum plate to achieve both high rigidity and is 250g lighter than former MT-09 models. The MT-09 SP’s swingarm pivot structure connects to the frame from the outside. Together, with the changes to the chassis’ rigidity and thorough engineering of the shapes of parts and components around the seat, this design showcases the MT-09 SP’s slim feel while still delivering outstanding straight-line stability at high speeds with greater cornering stability.
  • Lightweight Spin Forged Aluminum Wheels
    The MT-09 SP employs lightweight wheels. Manufactured using Yamaha-exclusive spinforging technology, these wheels contribute to outstanding handling. With a notable 11% decrease in the momentum of inertia at the rear, these wheels make for a big contribution to the MT-09 SP’s agile handling character.
  • Braking for Sporty Riding
    To support more spirited, sporty riding, the 2021 MT-09’s state-of-the-art brake features a radial Nissin master cylinder for the front brake. The piston in the master cylinder moves in a direction parallel to brake lever travel, contributing to a more linear supply of hydraulic pressure for excellent controllability. Following the YZF-R1, the 2021 MT-09 SP is only the second Yamaha model to use this technology that can be controlled with just a fingertip.
  • Adjustable Riding Position
    The riding position was designed to accommodate riders of varying physiques. The handlebars and footpegs can be adjusted to two different positions, allowing riders to set a position that gives them a secure feeling the moment they get on the bike. The handlebar clamps can be rotated 10mm forward, and the footpeg mounts can be raised 14mm higher as well as 4mm rearward.
  • Premium KYB and Öhlins Suspension
    The MT-09 SP’s KYB front suspension can be individually adjusted on each side for compression and rebound damping. Adjustments for high and low speed compression damping can also be made, giving riders more detailed settings to choose from. The 41mm inner tubes’ DLC coating provides excellent sliding characteristics and also adds to the exterior’s quality appearance. The MT-09 SP’s rear shock features a premium Öhlins shock absorber with a remote preload adjuster, completing this class-leading suspension package.



ADDITIONAL FEATURES

  • Next-Generation Design
    2021 represents the 3rd generation of the MT-09. And with the MT-09 SP, the designers sought to better express the major advances made with the machine’s performance by visually accentuating the pure power of the bike. The minimalist design concept delivers an exterior with everything but the essentials stripped away to highlight lightness and agility while simulating the rider’s senses.
  • Unique Styling
    The MT-09 SP features special colors and graphics, a distinguished seat cover with its stylish, contrasting stitching, a clear-coated silver swingarm and clear-smoked front and rear brake fluid reservoirs that bring out the bike’s pure mechanical beauty. Together, these features showcase the MT-09 SP’s high quality, exclusive look among the MT lineup while linking the bike to the colorway found only on the YZF-R1M. In addition, the levers, handlebars and drive sprocket are a sleek black to further complement the MT-09 SP’s design to give the rider the feeling of being one with the machine.
  • Full LED Lighting
    A compact designed bifunctional (low and high beam in one) LED headlight with excellent beam spread is featured on the MT-09 SP. The edges of the beam have a softer contrast to be easy on the eyes while emitting a soft and even spread of illumination. Instead of the conventional “mono-focus” type headlight, this bike utilizes a projector design with a built-in internal lens in addition to the thick outer lens. Since the MT-09 SP uses not one but multiple LEDs to produce light, it can project a complex distribution of illumination across a broad field. The position lights use LEDs and light-guides to create an impressive, distinctive new front face design for the MT-09 SP while the turn signals and newly designed LED taillight are LED as well.
  • Ready to Accessorize
    A rear fender eliminator, fly screen, comfort seat, engine guards and more can all be added to the MT-09 SP to support and enhance the look of the bike.



ELECTRONICS

  • 6-Axis IMU
    The MT-09 SP features a newly developed 6-axis Inertial Measurement Unit (IMU) that retains the base performance of proven IMU in the YZF-R1 but is 50% smaller and 40% lighter due to a thorough review of the sensor layout. The engine control unit (ECU) that receives and reflects the data from the IMU is equipped with three rider aids: a Traction Control System (TCS), Slide Control System (SCS) and front-wheel LIFt control system (LIF). All three systems work together to help the rider concentrate on riding to better extract the machine’s potential. Each of the systems can also be turned on or off and have their levels of intervention adjusted to preference. With this best-in-class electronic control technology, the 2021 MT-09 gives you the ultimate control in varying weather and surface conditions.
  • Rider-Supporting Traction Control System
    The Traction Control System (TCS) has three modes: Mode 1, Mode 2 and Mode M for manual settings. Each mode integrates the three rider support systems by changing the degree of intervention for the TCS, SCS and LIF all at once. With Mode M, the user can select his/her preferred levels of intervention for the TCS, SCS and LIF individually.
  • Lean Angle-Sensitive Traction Control System
    The Traction Control System (TCS) detects the difference in speed between the front and rear wheels and helps to efficiently extract drive force from the rear tire during acceleration. The TCS on the MT-09 SP uses this data for the lean angle, estimated by the IMU to adjust the degree of intervention by the TCS. As the lean angle increases, so does the amount of TCS intervention (1 = little intervention; 2 = moderate intervention; 3 = strong intervention).
  • Lift Control System (LIF)
    The LIFt Control System (LIF) smooths the machine’s behavior during starts and acceleration. When the IMU predicts front-wheel lift, the system adjusts the engine’s output to compensate and assist the rider. On the MT-09 SP, the system settings are focused on providing smooth behavior once the intervention ceases. The LIFt system’s intervention is set up to work together with the other rider aids, and with Mode M, the level of intervention can be chosen manually by the rider.
  • MotoGP®-Developed Slide Control System (SCS)
    The MT-09 SP features the Slide Control System (SCS), just like the one on the acclaimed YZF-R1. When the IMU predicts that a sideward slide is occurring at the rear tire, the SCS responds by adjusting the power output to help the rider focus on riding. The degree of intervention is pre-set for the TCS with Mode 1 and Mode 2, but Mode M allows for the level of intervention to be selected or for the system to be turned off.
  • Brake Control System with ABS
    With the Brake Control (BC) system, data for the front and rear wheel speed as well as data from the IMU is compiled and calculated in real-time in the hydraulic unit assembly (including the ABS control unit) to independently control and modulate the front and rear brake pressure. The rider can select between two intervention modes: BC1 and BC2. BC1 is a standard ABS-active mode that accommodates hard emergency braking in upright, straight-line braking conditions while BC2 controls the brake pressure in addition to ABS and operates in situations where machine behavior is likely to become unsettled, such as unavoidable panic braking mid-corner.
  • Quick Shift System for Clutchless Upshifts and Downshifts
    The QSS on the MT-09 SP enhances the sport riding experience by enabling super-fast upshifts for outstanding acceleration. The downshift allows for smoother shifting that stabilizes the chassis – even when cornering – and gives a more controlled feeling when decelerating. When the sensor on the shift rod detects movement in the gearshift pedal, adjustments are made in the engine output according to ECU calculations to instantly cancel out the drive torque of the engaged gear to promote swifter shifting of gears.
  • Ride-by-Wire YCC-T Throttle System with New APSG
    The MT-09 SP’s Yamaha Chip Controlled Throttle (YCC-T) electronically governs the throttle valves and features the new Accelerator Position Sensor Grip (ASPG) ride-by-wire unit that reduces weight while providing excellent throttle feel at the same time. With the APSG, the degree of throttle opening is detected by a sensor and magnet and reflected with signals to the throttle valve motor. For good operational feel, the APSG is comprised of a spring, slider and gear and produces varying degrees of friction (resistance) to recreate a natural throttle feel during use. The construction of the APSG for the MT-09 SP is the same as the one on the 2020 YZF-R1/R1M but has model-specific settings for the degree of friction and throttle opening.
  • 3.5-inch Full-Color TFT Instrument Display
    The MT-09 SP’s 3.5-inch full-color TFT display features a bar-type tachometer that changes colors as rpm rises or falls, a clock and displays for remaining fuel, average mileage, water temperature, air temperature and a gearshift indicator (color reversed for gear in use). Easily switch between displays and information with the handlebar switches.
  • Cruise Control
    The MT-09 SP features a cruise control system for easy riding. Cruise control can be set when going at least 31 mph (or 50 kmh) and in 4th gear or higher. After the cruise speed is set, the speed can be increased or decreased in increments of 1 mph (or 2 kmh) with single pushes of the switch or by continuously holding down the switch. Cancel the cruise control by braking or by using the clutch or the throttle. The “Resume” function reengages the system and returns the bike to its previous set speed.









2021 Yamaha MT-09 SP – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9399 USD
Canada MSRP Price: Starting at $10799 CDN
Europe/UK MSRP Price: £  GBP (On The Road inc 20% Vat)

Engine Type 890cc liquid-cooled, DOHC, inline 3-cylinder; 4
valves per cylinder
Bore x Stroke 78.0mm x 62.1mm
Compression Ratio 11.5:1
Fuel Delivery Fuel injection with YCC-T
Ignition TCI: Transistor Controlled Ignition
Transmission 6-speed; multiplate assist and slipper clutch
Final Drive Chain
Suspension / Front 41mm KYB inverted fork, adjustable preload,
high/low speed compression and rebound; 5.1-in
travel
Suspension / Rear Öhlins single shock, adjustable preload,
compression and rebound damping; 4.8-in travel
Brakes / Front Dual 298mm hydraulic disc; ABS
Brakes / Rear 245mm hydraulic disc; ABS
Tires / Front 120/70ZR17M/C
Tires / Rear 180/55ZR17M/C
L x W x H 82.3 in x 31.3 in x 46.9 in
Seat Height 32.5 in
Wheelbase 56.3 in
Rake (Caster Angle) 25.0°
Trail 4.3 in
Maximum Ground
Clearance
5.5 in
Fuel Capacity 3.7 gal
Fuel Economy** 49 MPG
Wet Weight*** 419 lb
Warranty 1 Year (Limited Factory Warranty)
Color Raven / Liquid Metal







2021 Yamaha MT-09 SP – Totalmotorcycle.com Canada Specifications/Technical Details

TBA







2021 Yamaha MT-09 SP – Totalmotorcycle.com European Specifications/Technical Details

Engine

Engine type

Liquid-cooled, 4-stroke, 4-valves, 3-cylinder, DOHC

Displacement

890cc

Bore x stroke

78.0 × 62.1 mm

Compression ratio

11.5 : 1

Maximum power

87.5kW (119.0PS) at 10,000 rpm

Maximum torque

93.0Nm (9.5kg-m) at 7,000 rpm

Lubrication system

Wet sump

Clutch type

Wet, Multiple Disc

Ignition system

TCI

Starter system

Electric

Transmission system

Constant Mesh, 6-speed

Final transmission

Chain

Fuel consumption

5.0 L/100km

CO2 emission

116 g/km

Fuel system

Fuel Injection

Chassis

Frame

Diamond

Caster angle

25º

Trail

108 mm

Front suspension system

Telescopic fork

Rear suspension system

Swingarm, (link suspension)

Front travel

130 mm

Rear travel

122 mm

Front brake

Hydraulic dual disc, Ø 298mm

Rear brake

Hydraulic single disc, Ø 245mm

Front tyre

120/70 ZR17M/C (58W) Tubeless

Rear tyre

180/55 ZR17M/C (73W) Tubeless

Dimensions

Overall length

2,090 mm

Overall width

795 mm

Overall height

1,190 mm

Seat height

825 mm

Wheel base

1,430 mm

Minimum ground clearance

140 mm

Wet weight (including full oil and fuel tank)

190 kg

Fuel tank capacity

14 L

Oil tank capacity

3.50 L







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
