2022 Yamaha YZ250FX: YOUR POWER. YOUR WAY.
Introducing the new 2022 Yamaha YZ250FX…
This Cross Country racer has all the features to win including the smartphone Power Tuner app that adjusts the bike’s settings to fit your style and the track.
This Cross Country racer has all the features to win including the smartphone Power Tuner app that adjusts the bike’s settings to fit your style and the track. Based on the championship-winning YZ250F and boasting a wide range of cross-country features, the YZ250FX is a true “out-of-the-box” hare scramble/cross-country competition machine.
The new 2022 Yamaha YZ250FX boasts a number of improvements pulled directly from the Supercross dominating YZ250F motocrosser, handing cross country and enduro enthusiasts an extremely capable, competition-ready machine straight out of the box. From stronger engine performance, to the highly refined cross-country-tuned chassis, to an improved high performance brake setup, the new 2022 YZ250FX is squarely aimed at winning races at all levels of XC competition.
Building on the already potent liquid-cooled 250cc four-stroke engine, the new YZ250FX churns out even stronger mid- to high-range power thanks to an improved air intake, wider intake port, redesigned exhaust camshaft and improved muffler design. Ensuring power gets down precisely when you need it, a six-speed transmission features gearing ratios optimized for cross country demands, and a large-diameter heavy-duty clutch means enhanced durability in extreme racing conditions. To keep the power in check, an updated lightweight braking system features larger front pistons, a more rigid caliper, a redesigned 270mm front rotor with a 30% increase in pad contact area and higher friction pad material, all combining to provide exceptional braking power and feel. The redesigned rear rotor maintains the same braking power while dropping outer diameter from 245mm to 240mm, further reducing unsprung weight with no compromise on performance.
The YZ250FX comes preloaded with two optimized engine maps—one for fast, aggressive high-traction conditions and one with a smoother engine character for extreme, low-traction conditions—which can be easily selected on-the-fly with a handlebar-mounted map switch. Maps can be altered using Yamaha’s innovative Power Tuner app, allowing riders to make fueling and ignition timing changes instantly and upload them to the bike for the ultimate track-side tuning.
The highly developed aluminum bilateral beam frame is taken straight from the class-leading YZ250F, then further tuned for cross country performance with improvements to the engine mounting brackets. Already known for its unmatched suspension performance, the new YZ250FX features high-spec KYB® fully adjustable spring-type forks with speed-sensitive damping and a linkage-type KYB® rear shock both tuned specifically for cross country racing. It all contributes to the model’s trademark front-end feel and exceptional cornering performance.
Adding to the long list of features that increase cross country capability, comfort and convenience are the push-button electric starter, modified balancer weight for reduced vibration, large 2.16-gallon fuel tank for increased range, fuel level warning indicator, heavy-duty composite engine guard, rubber-mounted handlebar clamps, 18-inch rear wheel, sealed O-ring chain and a folding aluminum kickstand. Finally, a sharp new graphics scheme highlights the YZ lineage with premium Yamaha Blue and dark blue embedded graphics, providing excellent durability and scratch resistance.
2022 Yamaha YZ250FX Totalmotorcycle.com Key Features
- All-New Hare Scramble/GNCC® Racer
Based on the championship-winning YZ250F that features Yamaha’s revolutionary front-intake, rear-exhaust, liquid-cooled, DOHC 4-stroke power plant with an added sixth gear, wide ratio transmission and a range of cross country upgrades, the YZ250FX is an “out-of-the-box” Hare Scrambles and GNCC® competition machine. - Innovative Yamaha Power Tuner App
Yamaha’s free-of-charge Power Tuner app puts the flexibility and precision tunability of the GYTR® Power Tuner into your smartphone. Make fueling and ignition timing changes instantly and upload them to the bike for ultimate track-side tuning while the handlebar-mounted map switch allows you to adjust pre-loaded engine maps on the fly. - High Performance Four-Stroke Engine
The compact, powerful YZ250FX engine includes all the same race-developed technologies of the championship-winning YZ250F, tuned for cross country performance. Revised intake duct, intake port, exhaust camshaft profile, muffler and balancer weight position combine to further improve power and usability across the entire rev range. - Precisely Tuned Chassis
The highly developed aluminum bilateral beam frame features precisely tuned flex characteristics for competition-ready performance. The forged section at the swingarm pivot, and improved engine mounting brackets provide a nimble lightweight feeling in tight, technical terrain while still providing control in fast sections. As always, Yamaha’s class-leading KYB® suspension ensures maximum control and traction. - Cross Country Features
With the electric starting system, a 2.16-gallon fuel tank, rugged plastic skid plate, 18-inch rear wheel and high performance Dunlop® Geomax MX33 tires, the YZ250FX is ready to win right out of the box.
NEW FOR 2022
- Improved Engine Performance
Liquid-cooled 250cc four-stroke churns out stronger mid- to high-range power thanks to an improved air intake, wider intake port, redesigned exhaust camshaft, improved muffler and optimized ECU settings. - Selectable Fuel Maps
Increasing the YZ250FX’s ability to tackle a wide range of riding environments, the ECU has been optimized with two improved fuel injection maps—both of which can be loaded and tuned in the Yamaha Power Tuner app—accessible through a handlebar-mounted map switch for on-the-fly adjustments to changing riding conditions. Pre-loaded maps include one for fast, aggressive high-traction conditions and one with a smoother engine character for extreme, low-traction conditions. - Updated Braking Components
Improved high-spec braking components now include more rigid front caliper with larger diameter pistons, more aggressive brake pad compound and a redesigned 270mm front rotor. The rear brake gets a lighter rear brake caliper and hanger with a 240mm rear rotor to reduce unsprung weight. Brake improvements provide exceptional braking control. - Updated Bilateral Aluminum Frame
The highly developed aluminum bilateral beam frame taken from the class-leading YZ250F has been tuned for cross country performance and modified to match the more powerful engine. - Modified Balancer Position
Position of the balancer weight has been adjusted to reduce vibration in the low- to mid-rpm range for less rider fatigue and increased long-distance comfort. - New High-Capacity Muffler
Improves high-rpm power delivery while providing a deep, throaty exhaust note. - Sharp New Graphics Scheme
New graphics scheme highlights the YZ’s unmatched racing pedigree. Premium Yamaha Blue and dark blue graphics are embedded to provide excellent durability and scratch resistance.
Yamaha Motor Corporation, USA, is proud to introduce the new 2022 lineup of advanced, industry-leading four-stroke motocross and cross country motorcycles—bikes designed to offer cutting-edge performance for the highest levels of competition, along with the type of refinement and rideability that brings out the best in every rider. Highlights for 2022 include exciting updates to the class-defining YZ250F and YZ450F competition motocross models and a wide range of improvements to the highly capable YZ250FX cross country model.
For the YZ250FX, improved engine performance, new optimized fuel injection maps, frame and chassis refinements, and updated brake components all add to the dynamic abilities of the ultimate 250-class cross country racer. For the YZ250F and YZ450F, targeted reductions in unsprung weight aim to further enhance the motocross models’ already celebrated handling and suspension character. Across the board, Yamaha four-strokes offer an unmatched level of off-road performance and reliability.
“Yamaha has always been at the forefront of four-stroke off-road motorcycle design and we are thrilled to see that continue with the new 2022 lineup of high performance four-strokes,” said Derek Brooks, Yamaha Motorsports Motorcycle Product Line Manager. “Building on the race-proven success of the YZ450F and YZ250F, key improvements to the 2022 models look to raise that bar even higher. And on the cross country side, extensive changes to the already potent YZ250FX will position this model as a natural choice for riders looking to dominate XC2 competition.”
Welcome to the victorYZone
Yamaha’s off-road competition bikes offer the very latest in technology with performance features designed to help racing enthusiasts reach their maximum potential, win races and stand on top of the podium.
2022 Yamaha YZ250FX Totalmotorcycle.com Features and Benefits
ENGINE
- Competition-Ready Engine Performance
The revolutionary front-intake/rear-exhaust, liquid-cooled, fuel-injected, four-stroke engine has been developed for victories in the highly competitive GNCC® and Hare Scrambles race series. Intake and exhaust ports work with a higher compression piston for a wider spread of power without losing top-end performance. - Forward-Thinking Engine Design
Reversing the cylinder head while placing the intake forward and the exhaust to the rear allow for a straight shot, downdraft intake and straight exhaust port for maximized engine performance. - Innovative Yamaha Power Tuner App
The free-of-charge Yamaha Power Tuner app brings the power of the GYTR® Power Tuner to your iOS® or Android® device. Using wireless connectivity to talk to the bike’s onboard CAN-bus network, the app allows owners to adjust air/fuel mixture and ignition timing maps to tune engine performance for track conditions, record race log information and monitor a range of data such as maintenance and system diagnosis, engine run time and more. - Adjustable Engine and Fuel Mapping
A handlebar-mounted map switch allows the rider to quickly select between two preloaded engine maps—loaded and tunable in the Power Tuner app—to account for changing riding conditions. The fuel injection system uses 3D-mapped electronic control for the fuel and ignition timing that are optimized for cross country racing. Pre-loaded maps include one for fast, aggressive high-traction conditions and one with a smoother engine character for extreme, low-traction conditions. - Six-Speed Gearbox
A six-speed transmission is used to ensure the right gear is available for the wide variety of terrain found in cross country racing. Updated gearing ratios and a heavy-duty, large-diameter clutch bring enhanced durability in the extreme conditions of a three-hour GNCC® race. - Mass-Centralized Electric Starter System
The YZ250FX features a compact, centrally-mounted electric starter system to minimize restart delays mid-race and add convenience everywhere else. Powered by a high-capacity lightweight four-cell lithium-ion battery, the system adds minimal weight.
CHASSIS/SUSPENSION
- Slim Bodywork
The compact bodywork eases the rider’s movement across the machine in tough terrain. The fuel tank provides 2.16 gallons of fuel with a larger fuel cap opening. New graphics are embedded in the body moldings for long-lasting good looks. - Light and Strong Aluminum Frame
An all-aluminum bilateral beam frame provides strength, lightness and durability for cross country racing conditions and comes standard with a rugged plastic skid plate. - Advanced Suspension
Industry favorite KYB® fully adjustable spring-type forks with speed-sensitive damping and a KYB® rear shock have been thoroughly tested and tuned specifically for cross country racing. - Purpose-Built Tires
Special cross country racing Dunlop® Geomax MX33 tires maximize traction while delivering excellent durability. - High Performance Braking System
Improved high-spec braking components now include more rigid front caliper with larger diameter pistons, more aggressive brake pad compound and a redesigned 270mm front rotor. The rear brake gets a lighter rear brake caliper and hanger with a 240mm rear rotor to reduce unsprung weight. Brake improvements provide exceptional braking control.
ADDITIONAL FEATURES
- Practical Touches
Quick-adjust clutch, wide 55mm platform foot pegs, four-position rubber-mounted handlebar clamps, aluminum handlebars and a side stand come standard for added rider convenience. The YZ250FX is also pre-wired for an optional radiator fan for the most grueling conditions. - Easy Servicing
The air cleaner cover features tool-free access to the air filter. Thanks to a WR-style fuel level sensor in the tank, the YZ250FX includes a convenient low fuel indicator along with an engine warning indicator on the handlebar. - Sealed O-Ring Chain
High-quality O-ring chain is tough, durable and light.
- Liquid-cooled 250cc four-stroke churns out stronger mid- to high-range power thanks to an improved air intake, wider intake port, redesigned exhaust camshaft, improved muffler and optimized ECU settings
- Industry-leading and free-of-charge Yamaha Power Tuner app allows instant fueling and ignition timing changes on your smartphone for ultimate track-side tuning
- Two-mode adjustable engine mapping allows rider to select between two tuneable engine maps at the push of a button
- The highly developed aluminum bilateral beam frame taken from the class-leading YZ250F has been tuned for cross country performance and modified to match the more powerful engine
- Class-leading KYB® fully adjustable spring-type forks with speed-sensitive damping and linkage-type KYB® rear shock have been thoroughly tested and tuned specifically for cross country racing
- A new, more rigid front caliper and compact rear caliper work with new discs and new pad material to boost brake feel and controllability, while the new 240mm rear brake rotor dissipates heat more efficiently for more consistent racing performance
- New high-capacity muffler improves high-rpm power delivery while providing a deep, throaty exhaust note
- Position of the balancer weight has been adjusted to reduce vibration in the low- to mid-rpm range for less rider fatigue and increased long-distance comfort
- Convenient push-button electric start provides effortless restarts
- Heavy-duty, large-diameter clutch for enhanced durability in extreme cross country conditions
- Large 2.16-gallon fuel tank for increased range along with a convenient low fuel indicator light
- Lightweight aluminum handlebar
- Rubber-mounted four-position adjustable handlebar mounts reduce vibration
- New premium Yamaha Blue and dark blue graphics scheme is embedded to provide excellent durability and scratch resistance
- Race-developed Dunlop® Geomax MX33 tires
2022 Yamaha YZ250FX – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8799 USD
Canada MSRP Price: $10999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 250cc liquid-cooled DOHC 4-stroke; 4 titanium
valves
Bore x Stroke 77.0mm x 53.6mm
Compression Ratio 13.8:1
Fuel Delivery Mikuni® fuel injection, 44mm
Transmission 6-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® spring-type fork with speed sensitive
damping; fully adjustable, 12.2-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.5-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 240mm
Tires / Front 80/100-21 Dunlop® Geomax MX33F
Tires / Rear 110/100-18 Dunlop® Geomax MX33
L x W x H 85.6 in x 32.5 in x 50.4 in
Seat Height 37.6 in
Wheelbase 58.3 in
Rake (Caster Angle) 27.2°
Trail 4.6 in
Maximum Ground
Clearance
12.6 in
Fuel Capacity 2.2 gal
Wet Weight 245 lb
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue
*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2022 Yamaha YZ250FX – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
ENGINE Liquid-cooled, DOHC, 4-valve (titanium), single
DISPLACEMENT 250 cc
BORE AND STROKE 77 x 53.6 mm
COMPRESSION RATIO 13.8:1
FUEL DELIVERY 44 mm Keihin throttle body F.I.
LUBRICATION Wet sump
IGNITION / STARTING TCI / Electric
TRANSMISSION Constant mesh, 6-speed
FINAL DRIVE Chain
CHASSIS
SUSPENSION (FRONT) Fully adj. 48 mm, inverted fork / 310 mm (12.2″) wheel travel
SUSPENSION (REAR) Fully adj. Monocross / 318 mm (12.5″) wheel travel
BRAKES (FRONT) 270 mm, floating disc / twin piston caliper
BRAKES (REAR) 240 mm disc / single piston caliper
TIRES (FRONT) 80/100-21 Dunlop® Geomax MX33F
TIRES (REAR) 110/100-18 Dunlop® Geomax MX33
CRITICAL DATA
LENGTH 2,174 mm (85.6″)
WIDTH 825 mm (32.5″)
HEIGHT 1,280 mm (50.4″)
WHEELBASE 1,481 mm (58.3″)
GROUND CLEARANCE 320 mm (12.6″)
SEAT HEIGHT 955 mm (37.6″)
FUEL CAPACITY 8.2 litres (1.8 imp. gallons)
WET WEIGHT 111 kg (245 lb)
COLOUR(S) Yamaha Racing Blue
2022 Yamaha YZ250FX – Totalmotorcycle.com European Specifications/Technical Details
NA
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
