2023 Triumph Scrambler 1200XE Chrome Edition Guide

2023 Triumph Scrambler 1200XE Chrome Edition
Contents: ReviewKey FeaturesFeatures & BenefitsSpecifications

2023 Triumph Scrambler 1200XE Chrome Edition 2023 Triumph Scrambler 1200XE Chrome Edition 2023 Triumph Scrambler 1200XE Chrome Edition 2023 Triumph Scrambler 1200XE Chrome Edition 2023 Triumph Scrambler 1200XE Chrome Edition 2023 Triumph Scrambler 1200XE Chrome Edition

Contents: ReviewKey FeaturesFeatures & BenefitsSpecifications

2023 Triumph Scrambler 1200XE Chrome Edition: STRIKING NEW STYLE.

Introducing the 2023 Triumph Scrambler 1200XE Chrome Edition…

Available for one year only, the Scrambler 1200 XE Chrome Edition brings a striking new style for 2023. The flawless full chrome fuel tank features a Brooklands Green painted stripe which incorporates the Triumph triangle tank badges. Brushed aluminium mudguards and silencer heat shields complement the tank perfectly while the headlight bowl and side panels are finished in deep Jet Black. A hand-picked set of accessories form the Scrambler 1200 XE Chrome Edition Accessory Kit, all of which are available to view on the Triumph configurator.

The benchmark for specification and all-road capability, the Scrambler 1200 XE Chrome Edition is powered by the torque-rich 1200cc Bonneville parallel twin engine with a dedicated Scrambler tune. High-quality suspension adds to its impressive credentials, with fully adjustable USD Showa forks and twin Öhlins rear suspension units offering 250mm of sublimely controlled wheel travel. Brembo M50 radial brakes with switchable optimised cornering ABS offer assured and safe braking in all conditions.

With incredible all-road capability and performance, plus class-defining looks, the new 1200 XE is the ultimate Scrambler.

The ultimate Scrambler, and the real deal for road and full-on off-road adventures. The new 1200 XE has the capability to take the rough with the smooth.

ICONIC SCRAMBLER STYLE
Stunning modern classic scrambler styling with category-leading finish and detailing. Crafted aluminum parts and brushed badges are highlighted against the deep, lustrous paint.

DUAL PURPOSE
The Scrambler’s natural feel on the tarmac and controllability on the dirt sets it aside as the benchmark crossover adventure motorcycle with unparalleled road and off-road capability.

THE REAL DEAL
The ground breaking Scrambler 1200 is now more refined than ever.

Scrambler 1200 XE and Scrambler 1200 XC
Triumph’s class-defining Scrambler 1200 line-up, for model year 2023, comes in three colours – the sophisticated Sapphire Black, a classic Matt Khaki Green and Matt Jet Black scheme, and a stunning new Carnival Red and Jet Black scheme that features a Carnival Red fuel tank with Jet Black tank stripe design, plus Jet Black side panel and headlight bowl.







2023 Triumph Scrambler 1200XE Chrome Edition Totalmotorcycle.com Key Features

  • Beautiful chrome fuel tank with stylish Brooklands Green painted tank stripe
  • Brushed aluminium mudguards and heat-shield, with Jet Black headlight bowl and side panels
  • Flawlessly finished with a beautiful chrome tank, bespoke paintwork and brushed aluminum detailing, this special edition Scrambler is available for just one year.



Engine 1200cc twin engine (Euro 5 compliant)
Suspension Fully-adjustable Showa upside-down forks and Öhlins long travel rear suspension units
Brakes Brembo M50 brakes with optimized cornering switchable ABS
Clutch Torque assist clutch
Riding Modes 6 riding modes (Road, Rain, Sport, Rider Configurable, Off-Road and Off-Road Pro)
Traction Control Ride-by-wire throttle with optimized cornering switchable traction control
Instruments Multi-functional instruments with personalizable TFT display
Connectivity My Triumph Connectivity System (Accessory fit)
Service 10,000 miles/12 months service interval, whichever comes first
Keyless Keyless ignition system, single button cruise control, under seat USB charging and illuminated switches







2023 Triumph Scrambler 1200XE Chrome Edition Totalmotorcycle.com Features and Benefits

THE TRIUMPH CHROME COLLECTION

TEN BEAUTIFULLY HAND-CRAFTED AND DISTINCTIVE LIMITED EDITION MOTORCYCLES

Inspired by the classic custom look that has been a significant part of Triumph’s iconic history, from the original chromed tank of the 1937 Speed Twin to the 1960s Tritons, and all the way up to the birth of the custom classic generation, this new collection of beautiful, limited editions celebrates the craftsmanship and artistry that sits at the heart of Triumph’s DNA.

All available for one year only, each of the ten new limited edition motorcycles in this stunning collection bring a unique, bold and beautiful new take on the latest generation of Triumph’s legendary modern classic Bonneville line-up and world leading Rocket 3, with a hand-crafted and distinctive chrome scheme, accompanied by new Chrome Edition accessory kits.

Following high demand for the 2022 Gold Line limited editions, which brought brighter colours and beautifully hand-finished schemes to eight of Triumph’s most iconic modern classics, now 2023 sees the introduction of a new ten-model-strong range of stunning, limited edition motorcycles – the Chrome Collection.

Inspired by the custom chrome design heritage of the brands iconic past, the Chrome Collection celebrates Triumph’s state-of-the-art chrome-detailing facility and the expert teams of specialist design and manufacturing engineers who have perfected the process over many years, across hundreds of accessories, beautiful badges and detailing. The result is a flawless chrome finish every time – distinctive, stylish and exquisitely hand-crafted.

Encompassing Triumph’s legendary Bonneville line-up and the world leading Rocket 3, each of the ten new limited editions feature a unique Chrome Edition scheme, chosen specifically to reflect each model’s rich heritage, and exquisitely finished to reinforce Triumph’s renowned reputation for premium quality and exceptional detailing. Together with the thrilling performance, neutral handling and modern capability of the modern classics range, these stunning specials combine contemporary design with nostalgic echoes of the Bonneville’s deep and rich history.

Available to order now, these exclusive limited editions are available for one year only and will be coming into dealerships around the world from late 2022/early 2023.



1200CC ENGINE

Updated with a dedicated scrambler tune, for a smooth, torque-rich delivery from the iconic 1200 cc Bonneville twin.

ENHANCED TWIN HIGH LEVEL EXHAUST

The deep, scrambler tune from the signature twin high-level exhaust now features improved heat distribution for enhanced rider comfort.

CLASS LEADING TECHNOLOGY

Cruise control, ride-by-wire, Scrambler-specific riding modes, ABS and easy-to-read TFT instruments bring class-leading technology to this modern classic.

RIDING MODES

In addition to the Road, Rain, Sport, Off-Road and Rider-Configurable riding modes, the XE features ‘Off-Road Pro’ for full on Scrambler fun.

FULL COLOR TFT

Easy to read in all light conditions, the Scrambler’s advanced full-color TFT display can be configured to suit you and your riding needs.

ILLUMATED SWITCHES

Intuitively designed, the Scrambler’s switches are backlit for easy, at-a-glance rider control, perfect for even the darkest adventures.

SPECIFICATION & CAPABILITY

The Scrambler’s category-dominating specification and high-end equipment deliver all-road capability for an adventure riding experience like no other.

DEDICATED SCRAMBLER FRAME

The dedicated frame and long travel aluminum swing arm are designed for pure scrambler performance when the going gets tough.

OPTIMIZED CORNERING

Optimized cornering traction control and ABS, supported by an IMU, deliver the optimum performance at all lean angles, for a class-leading and confidence-inspiring ride.

CLASS LEADING SUSPENSION

Premium Showa forks and twin spring Öhlins RSUs give 7.87 inches of wheel travel (9.84 inches on the XE) for precise, comfortable and confident riding on all surfaces.

PREMIUM BRAKING

Category-leading Brembo Monobloc M50 front calipers with twin 320mm floating discs and ABS deliver assured braking power in all conditions.













2023 Triumph Scrambler 1200XE Chrome Edition – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $16,645  USD
Canada MSRP Price: from $17,595 CDN
Europe/UK MSRP Price: from £13,995 (On The Road inc 20% Vat)

ENGINE & TRANSMISSION

Type Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel-twin
Capacity 1200 cc
Bore 3.84 in (97.6 mm)
Stroke 3.15 in (80 mm)
Compression 11.0:1
Max Power EC 89Hp (66.2kW) @7,400rpm
Max Torque EC 81.1 FT-lbs (110Nm) @ 3,950 rpm
System Multipoint sequential electronic fuel injection
Exhaust Brushed 2 into 2 exhaust system with brushed high level silencers
Final Drive X ring chain
Clutch Wet, multi-plate assist clutch
Gearbox 6-speed

CHASSIS

Frame Tubular steel with aluminum cradle
Swingarm Twin-sided, aluminum
Front Wheel Tubeless 36-spoke 21 x 2.15in, aluminum rims
Rear Wheel Tubeless 32-spoke 17 x 4.25in, aluminum rims
Front Tire 90/90-21
Rear Tire 150/70 R17
Front Suspension Showa 47mm fully adjustable upside down forks, 250mm travel
Rear Suspension Fully adjustable Ohlins twin shocks with piggy back reservoir, 250mm rear wheel travel
Front Brakes Twin 320mm Brembo discs, Brembo M50 4-piston radial monobloc calipers, ABS
Rear Brakes Single 255mm disc, Brembo 2-piston floating caliper, ABS
Instrument Display and Functions TFT multi­functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, clock and rider modes (Rain/Road/Sport/Off-­road/Rider-Configurable)

DIMENSIONS & WEIGHTS

Width Handlebars 35.6 in (905mm)
Height Without Mirror 49.2 in (1250mm)
Seat Height 34.2 in (870mm)
Wheelbase 61.8 in (1570mm)
Rake 26.9 º
Trail 5.09 in (129.2mm)
Dry Weight 456 lbs (207kg)
Tank Capacity 4.2 US gal (16l)

FUEL CONSUMPTION

Fuel Consumption 51.1 mpg (4.6 L / 100km)

SERVICE

Service Interval 10,000 miles/12 months service interval, whichever comes first







2023 Triumph Scrambler 1200XE Chrome Edition – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE & TRANSMISSION

Type Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel-twin
Capacity 1200 cc
Bore 3.84 in (97.6 mm)
Stroke 3.15 in (80 mm)
Compression 11.0:1
Max Power EC 89Hp (66.2kW) @7,400rpm
Max Torque EC 81.1 FT-lbs (110Nm) @ 3,950 rpm
System Multipoint sequential electronic fuel injection
Exhaust Brushed 2 into 2 exhaust system with brushed high level silencers
Final Drive X ring chain
Clutch Wet, multi-plate assist clutch
Gearbox 6-speed

CHASSIS

Frame Tubular steel with aluminum cradle
Swingarm Twin-sided, aluminum
Front Wheel Tubeless 36-spoke 21 x 2.15in, aluminum rims
Rear Wheel Tubeless 32-spoke 17 x 4.25in, aluminum rims
Front Tire 90/90-21
Rear Tire 150/70 R17
Front Suspension Showa 47mm fully adjustable upside down forks, 250mm travel
Rear Suspension Fully adjustable Ohlins twin shocks with piggy back reservoir, 250mm rear wheel travel
Front Brakes Twin 320mm Brembo discs, Brembo M50 4-piston radial monobloc calipers, ABS
Rear Brakes Single 255mm disc, Brembo 2-piston floating caliper, ABS
Instrument Display and Functions TFT multi­functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, clock and rider modes (Rain/Road/Sport/Off-­road/Rider-Customisable)

DIMENSIONS & WEIGHTS

Width Handlebars 35.6 in (905mm)
Height Without Mirror 49.2 in (1250mm)
Seat Height 34.2 in (870mm)
Wheelbase 61.8 in (1570mm)
Rake 26.9 º
Trail 5.09 in (129.2mm)
Dry Weight 456 lbs (207kg)
Tank Capacity 4.2 US gal (16l)

FUEL CONSUMPTION

Fuel Consumption 51.1 mpg (4.6 L / 100km)

SERVICE

Service Interval 10,000 miles/12 months service interval, whichever comes first







2023 Triumph Scrambler 1200XE Chrome Edition – Totalmotorcycle.com European Specifications/Technical Details

ENGINE & TRANSMISSION

Type Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel-twin
Capacity 1200 cc
Bore 97.6 mm
Stroke 80 mm
Compression 11 :1
Max Power EC 90PS/ 89bhp (66.2kW) @7,250rpm
Max Torque EC 110 Nm @ 4500 rpm
System Multipoint sequential electronic fuel injection
Exhaust Brushed 2 into 2 exhaust system with brushed high level silencers
Final Drive X ring chain
Clutch Wet, multi-plate assist clutch
Gearbox 6-speed

CHASSIS

Frame Tubular steel
Swingarm Twin-sided, aluminium, 579mm long
Front Wheel Tubeless 36-spoke 21 x 2.15in, aluminium rims
Rear Wheel Tubeless 32-spoke 17 x 4.25in, aluminium rims
Front Tyre 90/90-21
Rear Tyre 150/70 R17
Front Suspension Showa 47mm fully adjustable upside down forks, 250mm travel
Rear Suspension Fully adjustable Ohlins twin shocks with piggy back reservoir, 250mm rear wheel travel
Front Brakes Twin 320mm Brembo discs, Brembo M50 4-piston radial monobloc calipers, ABS
Rear Brakes Single 255mm disc, Brembo 2-piston floating caliper, ABS
Instrument Display and Functions TFT multi­functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, clock and rider modes (Rain/Road/Sport/Off-­road/Rider-Customisable)

DIMENSIONS & WEIGHTS

Width Handlebars 905 mm
Height Without Mirror 1250 mm
Seat Height 870 mm
Wheelbase 1570 mm
Rake 26.9 º
Trail 129.2 mm
Tank Capacity 16 L
Wet Weight 230 kg

FUEL CONSUMPTION

Fuel Consumption 4.6 litres / 100 km
CO2 Figures 105 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.

SERVICE

Service Interval 10,000 miles/16,000 Km or 12 Months, whichever comes first







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
